DATA SHEET FUJITSU LIFEBOOK T730 TABLET PC
Page 1 / 7 http://ts.fujitsu.com/tabletpc
Windows®. Life without Walls™.
Fujitsu recommends Windows 7.
DATA SHEET
FUJITSU LIFEBOOK T730 TABLET PC
TWIST TO TOUCH
LIFEBOOK T730
The LIFEBOOK T730 is a 12.1-inch Tablet PC based on the new Intel®Core™ i7 vPro™ technology that
supports the new multiple touch technology. With the dual digitizer this multifunctional device accepts
input either with a pen or with your ngers, just as occasion demands. With the optional integrated GPS
technology you will never get lost and be on track. With the modular bay and the port replicator this device
answers all questions concerning mobile exibility!
PEN- OR FINGER-BASED WORK WITHOUT ANY RESTRICTIONS
Either as notebook or Tablet PC, comfortable working in any situation.
Bi-directional rotatable, tiltable 30.7 cm (12.1-inch) dual digitizer display with multiple touch capability
FLEXIBLE WORKING
Increase your productivity and adapt the notebook to your particular way of work.
Modular bay for an optional second hard disk drive, DVD drive, Blu-ray Disc™ combo drive or second
battery
MAXIMUM CONNECTIVITY
Stay connected wherever you are; wireless connectivity anytime anywhere, even if there is no hotspot
nearby.
Optional embedded 3G/UMTS with GPS, WLAN and Bluetooth
HIGHEST SECURITY
Protect your most valuable asset – your data.
Advanced Theft Protection, Computrace® enabled BIOS, optionally integrated TPM Module and
ngerprint sensor
ERGONOMIC WORKING
Automatic adaption of the brightness of your display to your working environment for a longer battery
runtime.
Ambient Light Sensor (ALS)
DATA SHEET FUJITSU LIFEBOOK T730 TABLET PC
Page 2 / 7 http://ts.fujitsu.com/tabletpc
Windows®. Life without Walls™.
Fujitsu recommends Windows 7.
COMPONENTS
PROCESSOR Intel® Core™ i5-460M processor (2.53 GHz, 3 MB)
Intel® Core™ i5-450M processor (2.4 GHz, 3 MB) *
Intel® Core™ i3-370M processor (2.40 GHz, 3 MB)
Intel® Core™ i3-350M processor (2.26 GHz, 3 MB) *
Intel® Core™ i7-640M processor (2.80 GHz, 4 MB)
Intel® Core™ i7-620M processor (2.66 GHz, 4 MB)
Intel® Core™ i5-560M processor (2.66 GHz, 3 MB)
Intel® Core™ i5-540M processor (2.53 GHz, 3 MB)
Intel® Core™ i5-520M processor (2.4 GHz, 3 MB)
PROCESSOR NOTES *Processor only for retail, SMB, education and government
OPERATING SYSTEM
Operating system optional preinstalled Genuine Windows®7 Professional 64-bit
Operating system compatible Genuine Windows Vista®Business 32-bit
Genuine Windows®XP Tablet PC Edition 2005
Operating system notes Driver support for Microsoft®Windows®XP
Microsoft Ofce 2010 preloaded. Purchase a Product Key to activate a full Microsoft Ofce 2010 suite.
MEMORY MODULES 2 GB (1 module(s) 2 GB) DDR3, 1066 MHz, PC3-8500, SO DIMM
4 GB (1 module(s) 4 GB) DDR3, 1066 MHz, PC3-8500, SO DIMM
Supported capacity RAM (max.) 8 GB
Memory slots total 2
Memory slot type DIMM
HARD DISK DRIVES (INTERNAL) SSD SATA, 128 GB, 2.5-inch
SSD SATA, 64 GB, 2.5-inch
SATA, 7200 rpm, 500 GB, 2.5-inch, S.M.A.R.T.
SATA, 5400 rpm, 320 GB, 2.5-inch, S.M.A.R.T.
SATA, 5400 rpm, 160 GB, 2.5-inch, S.M.A.R.T.
FDE, 5400 rpm, 320 GB, 2.5-inch, S.M.A.R.T.
Hard disk notes ShockSensor for HDD shock protection
One Gigabyte equals one billion bytes, when referring to hard disk drive capacity.
Accessible capacity may vary, also depending on used software
WLAN (OPTIONAL) Atheros Minicard b/g/n
Intel®Centrino® 6200 802.11 a/b/g/n
WIRELESS TECHNOLOGIES
Antennas 2 Dual band WLAN antennas, 2 UMTS antennas, 1 Bluetooth antenna
WLAN notes Import and usage according to country-specic regulations.
3G/UMTS (OPTIONAL) Sierra Wireless Gobi 2000 (downlink 7.2 Mbit/s, uplink 5.76 Mbit/s)
BLUETOOTH (OPTIONAL) Bluetooth 2.1
DISPLAY 30.7 cm (12.1-inch), TFT dual digitizer, (WXGA), anti-glare touchscreen, 1280 x 800 pixel, 600, 200 cd/m²
30.7 cm (12.1-inch), TFT dual digitizer, (WXGA), anti-glare touchscreen, 1280 x 800 pixel, 500, 300 cd/m2
MODULAR BAY OPTIONS 2nd battery
2nd hard disk drive
Blu-ray Disc™ Combo Drive
DVD Super Multi
Weight saver
Base unit LIFEBOOK T730
DATA SHEET FUJITSU LIFEBOOK T730 TABLET PC
Page 3 / 7 http://ts.fujitsu.com/tabletpc
Windows®. Life without Walls™.
Fujitsu recommends Windows 7.
GENERAL SYSTEM INFORMATION
Chipset Intel®QM57
Chipset notes supports iAMT 6.0, vPro requires Core i5-5xx / i7 processor, Intel W-LAN & TPM module
BIOS features BIOS Flash EPROM
BIOS based on Phoenix TrustedCore Notebook
Display
Display notes Optional Wide-View High-Brightness LED WXGA Display (for enhanced outdoor viewing) or standard LED WXGA Display
Brightness - typical 300 cd/m² (high brightness display), 200 cd/m² (standard display)
Contrast - typical 500
GRAPHICS
TFT resolution (HDMI) up to 1920 x 1080
TFT resolution (VGA) up to 1920 x 1200
TFT resolution (DVI on Port Replicator) up to 1920 x 1200
Max. resolution external display 1920 x 1200 / true color / 85 Hz
Graphics brand name Intel® HD Graphics
Graphics features DirectX® 10.1 support - for stunning 3D graphics and shading effects
INTERFACES
Memory card slots 1 (for SD/SDHC/SDXC/MS/MSPro)
ExpressCard slots 1 (34mm and 54mm supported)
SIM card slot 1 (usable only with 3G/UMTS)
USB 2.0 total 3
FireWire (IEEE1394) 1
VGA 1
HDMI 1
Ethernet (RJ-45) 1
DC-in 1
Audio: line-in / microphone 1
Audio: line-out / headphone 1
Internal microphones 2
Docking connector for Port Replicator 1
Kensington Lock support 1
WIRED COMMUNICATION
LAN Built-in 10/100/1000 MBit/s Intel® 82577 LM
KEYBOARD AND POINTING DEVICES
Spill-resistant keyboard
Number of keyboard keys: 85, Keyboard pitch: 19 mm, Keyboard stroke: 2.7 mm
Fingerprint sensor
Launch keys
Status LED
Application buttons
Tablet Pen
Touch-screen
Touchpad with two mouse buttons and ergonomic scroll sensor
MULTIMEDIA
Audio type On board
Audio codec Realtek ALC269
Audio features Stereo speakers, 2 internal microphones
Camera Optional: Built-in webcam, 2.0 megapixel
POWER SUPPLY
AC adapter 19 V / 80 W (4.22 A)
Rated voltage range 100 - 240 V (AC Input)
Rated frequency range 50 - 60 Hz
DATA SHEET FUJITSU LIFEBOOK T730 TABLET PC
Page 4 / 7 http://ts.fujitsu.com/tabletpc
Windows®. Life without Walls™.
Fujitsu recommends Windows 7.
POWER SUPPLY
1st battery Li-Ion battery 6-cell, 5200 mAh, 56 Wh
Li-Ion battery 6-cell, 5800 mAh, 63 Wh
2nd battery (optional) Li-Ion battery 6-cell, 3800 mAh, 41 Wh
Battery features Dynamic charge supported (rapid charge)
Benchmark Mobile Mark 2007 (readers mode – e.g. surng the internet, writing E-mails, viewing documents)
Runtime 1st battery up to 7 h
Runtime 1st + 2nd battery up to 11 h
Battery notes Battery life may vary depending on product model, conguration, applications, power management settings and features
utilized. Battery recharge time depends on usage.
POWER CONSUMPTION
Power consumption note See white paper Energy Consumption
Link to Energy White Paper http://docs.ts.fujitsu.com/dl.aspx?id=1fc40c36-e743-4f37-8bd1-e95b89cad403
DIMENSIONS / WEIGHT / ENVIRONMENTAL
Dimensions (W x D x H) 297 x 233 x 38.4 (without foot)
Weight From 1.8 kg
Weight notes Actual weight may vary depending on conguration
Operating ambient temperature 5 - 35°C
Operating relative humidity 20 - 85 % (running)
ADDITIONAL SOFTWARE
Additional software (preinstalled) Adobe Acrobat Reader
Application Panel
Camera
Drivers & Utilities DVD (DUDVD)
Microsoft® Ofce Ready (Trial)
Nero Essentials (burning software)
EasyGuide online user documentation
Tablet Button Utility
Microsoft®Touch Pack for Windows®7
Norton Internet Security (incl. Firewall) 90 days version
Display Manager
Security Application Panel
Additional software (optional) Drivers & Utilities DVD (DUDVD)
UMTS connection manager (optional with UMTS)
DVD playback software
Recovery DVD (Windows® 7)
Additional software (included as a CD/
DVD)
SmartCase Logon+
MANAGEABILITY
Manageability features DeskUpdate Driver management
Intel®vPro™ technology
Manageability type DeskView 10.x client management including:
DeskView features On/Ofine remote client management
Detailed system inventory management and reports
BIOS Management
Remote power management
System notications
Security Remote Control
DeskView Helpdesk Integration
WoL (Wake on LAN)
Supported standards WMI
PXE
BootP (made4you)
Manageability link http://ts.fujitsu.com/solutions/it_infrastructure_solutions/manageability/featurender.html
SECURITY
Physical security Kensington Lock support
DATA SHEET FUJITSU LIFEBOOK T730 TABLET PC
Page 5 / 7 http://ts.fujitsu.com/tabletpc
Windows®. Life without Walls™.
Fujitsu recommends Windows 7.
SECURITY
System security Computrace®enabled BIOS
Norton Internet Security (incl. Firewall) 90 days version
Write protect option for the Flash EPROM
Control of all USB interfaces
Advanced Theft Protection
User and supervisor BIOS password
Optional: Trusted platform module (TPM 1.2)
User security Integrated Fingerprint Sensor
Hard disk password
SmartCase Logon+ incl. ngerprint & security software
User and supervisor BIOS password
COMPLIANCE
Model LIFEBOOK T730
Germany TÜV GS
Europe CE
CB
EN 60601-1-2:2007 certied for use in environment with medical application (in progress)
USA/Canada cUL
FCC Class B
Global Microsoft Operating Systems (HCT / HCL entry / WHQL)
RoHS (Restriction of hazardous substances)
WiFi certied
WEEE (Waste electrical and electronical equipment)
ENERGY STAR®5.0
EPEAT® Gold
Compliance link https://sp.ts.fujitsu.com/sites/certicates/default.aspx
PORTREPLICATOR INTERFACES (OPTIONAL)
Portreplicator\AC Adapter\EU-Cable Kit Portreplicator\AC Adapter\GB-Cable Kit
DC-in 1 1
Power on switch 1 1
Audio: headphone 1 1
USB 2.0 total 4 4
VGA 1 1
DVI 1 1
Ethernet (RJ-45) 1 1
Kensington Lock support 1 1
WARRANTY
Standard Warranty 2 years
Service level Collect & Return Service / Bring-in Service (depending on country)
MAINTENANCE AND SUPPORT SERVICES - THE PERFECT EXTENSION
Recommended Service 3 years, On-site Service
Spare Parts availability 5 years
Service Weblink htttp://ts.fujitsu.com/Supportservice
RECOMMENDED ACCESSORIES
DATA SHEET FUJITSU LIFEBOOK T730 TABLET PC
Page 6 / 7 http://ts.fujitsu.com/tabletpc
Windows®. Life without Walls™.
Fujitsu recommends Windows 7.
LIFEBOOK bundle (Port rep\AC
Adapter\EU-Cable Kit)
Flexibility, expandability, desktop replacement – to name just a few benets of
Fujitsu docking options.
Order Code:
S26391-F794-L310
LIFEBOOK bundle (Port rep\AC
Adapter\UK-Cable Kit)
Flexibility, expandability, desktop replacement – to name just a few benets of
Fujitsu docking options.
Order Code:
S26391-F794-L410
2nd battery With a second battery you can maximize the working time of your notebook
and work wherever you want for a whole working day. Just put the 2nd battery
into the modular bay and enjoy truly mobile working – free from the power
socket!
Order Code:
S26391-F777-L200
Prestige Case Midi Zip-down case with cushioned Notebook compartment; separate second
compartment for mobile accessories and documents; exterior compartment
with workstation for mobile accessories; cushioned shoulder strap; trolley
fastening strap an the back side For Tablet PC and Notebooks up to 370 x 295
x 50 mm
Order Code:
S26391-F119-L60
Presenter IV Air Do you often give presentations? Would you like to communicate pro actively
with your audience during your presentations? Step up to the plate and make
use of your freedom of movement with the Presenter IV Air
Whether you’re leang through informative material, adjusting audio les or
using the laser pointer to indicate special features, you have everything reliably
under control with this presenter.
Thanks to the 2D air mouse function you can even do away with the cable
mouse and navigate through your les with ease
Order Code:
S26381-K440-L100
DATA SHEET FUJITSU LIFEBOOK T730 TABLET PC
Page 7 / 7 http://ts.fujitsu.com/tabletpc
Windows®. Life without Walls™.
Fujitsu recommends Windows 7.
CONTACT
FUJITSU Technology Solutions
Website: http://ts.fujitsu.com
2010-10-21 CE-EN
FUJITSU PLATFORM SOLUTIONS
In addition to Fujitsu LIFEBOOK T730, Fujitsu
provides a range of platform solutions. They
combine reliable Fujitsu products with the best in
services, know-how and worldwide partnerships.
Dynamic Infrastructures
With the Fujitsu Dynamic Infrastructures
approach, Fujitsu offers a full portfolio of IT
products, solutions and services, ranging
from clients to datacenter solutions, Managed
Infrastructure and Infrastructure as-a-Service.
How much you benet from Fujitsu technologies
and services depends on the level of cooperation
you choose. This takes IT exibility and efciency
to the next level.
Computing Products
www.fujitsu.com/global/services/computing/
Software
www.fujitsu.com/software/
MORE INFORMATION
Learn more about Fujitsu LIFEBOOK T730,
please contact your Fujitsu sales representative
or Fujitsu Business partner, or visit our website.
http://ts.fujitsu.com/tabletpc
FUJITSU GREEN POLICY INNOVATION
Fujitsu Green Policy Innovation is our worldwide
project for reducing burdens on the environment.
Using our global know-how, we aim to resolve
issues of environmental energy efciency
through IT.
Please nd further information at http://www.
fujitsu.com/global/about/environment/
COPYRIGHTS
All rights reserved, including intellectual property
rights. Changes to technical data reserved.
Delivery subject to availability. Any liability that
the data and illustrations are complete, actual or
correct is excluded.
Designations may be trademarks and/or
copyrights of the respective manufacturer,
the use of which by third parties for their own
purposes may infringe the rights of such owner.
For further information see http://ts.fujitsu.com/
terms_of_use.html
Copyright © Fujitsu Technology Solutions
DISCLAIMER
Technical data are subject to modication and
delivery subject to availability. Any liability that
the data and illustrations are complete, actual
or correct is excluded. Designations may be
trademarks and/or copyrights of the respective
manufacturer, the use of which by third parties
for their own purposes may infringe the rights of
such owner
Autres manuels pour Lifebook T730
6
Table des matières
Autres manuels Fujitsu Ordinateur portable
Fujitsu
Fujitsu N7010 - LifeBook - Core 2 Duo 2.26 GHz Manuel utilisateur
Fujitsu
Fujitsu LIFEBOOK U939 Manuel utilisateur
Fujitsu
Fujitsu N6110 - LifeBook - Pentium M 1.86 GHz Manuel
Fujitsu
Fujitsu V1040 - LifeBook - Core 2 Duo 2.4 GHz Manuel de service
Fujitsu
Fujitsu Lifebook N3410 Manuel utilisateur
Fujitsu
Fujitsu T2020 - LifeBook Tablet PC Manuel utilisateur
Fujitsu
Fujitsu Lifebook P1110 Fiche d'information produit
Fujitsu
Fujitsu Lifebook UH900 Manuel utilisateur
Fujitsu
Fujitsu T4215 - LifeBook Tablet PC Manuel
Fujitsu
Fujitsu A3110 - LifeBook Notebook Computer Manuel
Fujitsu
Fujitsu LifeBook V700 Manuel utilisateur
Fujitsu
Fujitsu LIFEBOOK U5313X Manuel utilisateur
Fujitsu
Fujitsu FPCR46023 Manuel utilisateur
Fujitsu
Fujitsu LIFEBOOK C-6XX7 Manuel utilisateur
Fujitsu
Fujitsu LifeBook A6020 Manuel
Fujitsu
Fujitsu S7211 - LifeBook - Core 2 Duo GHz Manuel utilisateur
Fujitsu
Fujitsu LifeBook P1120 Manuel utilisateur
Fujitsu
Fujitsu N7010 - LifeBook - Core 2 Duo 2.26 GHz Manuel utilisateur
Fujitsu
Fujitsu LifeBook C6659 Manuel utilisateur
Fujitsu
Fujitsu Lifebook C2310 Manuel utilisateur
