DATASHEET FUJITSU ESPRIMO P5730 DESKTOP PC

Page 1 / 7 http://ts.fujitsu.com/ESPRIMO

DATASHEET

FUJITSU ESPRIMO P5730

DESKTOP PC

YOUR EXPANDABLE WORKHORSE

HALOGEN FREE

QUIET RUNNING

EASY ACCESS CABINET

TWINLOAD

FAMILY CONCEPT

MANAGEABILITY

KEYBOARD POWER ON

ESPRIMO P5730

The ESPRIMO P5730 combines high scaling with state-of-the-art Intel®technology and meets the daily

challenges of your business applications. Almost inaudible thanks to its innovative fan concept. The

optimized design makes installing and removing components child’s play. Downtimes are reduced to a

minimum. The use of environmentally conscious material means that the ESPRIMO P5730 today already

meets the environmental standards of tomorrow. It is a good investment for you and the environment.

MICROTOWER

Maximum performance and optimal extendability

Top-quality, high-value microtower, 6 drive bays, 4 PCI/PCI express interfaces

ENVIRONMENTALLY COMPATIBLE PRODUCT

Your contribution to environmental protection for the continued existence of our planet

Halogen-free mainboard, sophisticated product concept for the entire lifecycle

SILENT OPERATION

Pleasant working environment due to an extremely quiet system

Innovative hardware design, optimized cooling concept

SERVICEABILITY

Simple extendability and optimal user-friendliness without any additional tools

Easy access to all replaceable and expandable components

RELIABILITY

Reliable top-quality products designed and engineered in Germany

High product standards thanks to top-quality components and comprehensive testing in certied in-

house laboratories

COMPONENTS

PROCESSOR Intel®Core™2 Quad processor Q9650 (4C/4T, 3.0 GHz, 12 MB, 1333 MHz)

Intel®Core™2 Quad processor Q9550 (4C/4T, 2.83 GHz, 12 MB, 1333 MHz)

Intel®Core™2 Quad processor Q9505 (4C/4T, 2.83 GHz, 6 MB, 1333 MHz)

Intel®Core™2 Quad processor Q9400 (4C/4T, 2.66 GHz, 6 MB, 1333 MHz)

Intel®Core™2 Quad processor Q8300 (4C/4T, 2.5 GHz, 4 MB, 1333 MHz)

Intel®Core™2 Duo processor E8600 (2C/2T, 3.33 GHz, 6 MB, 1333 MHz)

Intel®Core™2 Duo processor E8500 (2C/2T, 3.16 GHz, 6 MB, 1333 MHz)

Intel®Core™2 Duo processor E8400 (2C/2T, 3.0 GHz, 6 MB, 1333 MHz)

Intel®Core™2 Duo processor E7600 (2C/2T, 3.06 GHz, 3 MB, 1066 MHz)

Intel®Core™2 Duo processor E7500 (2C/2T, 2.93 GHz, 3 MB, 1066 MHz)

Intel®Pentium®processor E6300 (2C/2T, 2.8 GHz, 2 MB, 1066 MHz)

Intel®Pentium®processor E5400 (2C/2T, 2.7 GHz, 2 MB, 800 MHz)

Intel®Pentium®processor E5200 (2C/2T, 2.5 GHz, 2 MB, 800 MHz)

Intel®Celeron®processor E3200 (2C/2T, 2.4 GHz, 1 MB, 800 MHz)

Intel®Celeron®processor 450 (1C/1T, 2.2 GHz, 512 KB, 800 MHz)

MEMORY MODULES 1 GB (1 module(s) 1 GB) DDR2, 800 MHz, PC2-6400, DIMM

2 GB (1 module(s) 2 GB) DDR2, 800 MHz, PC2-6400, DIMM

4 GB (1 module(s) 4 GB) DDR2, 800 MHz, PC2-6400, DIMM

HARD DISK DRIVES (INTERNAL) SSD SATA, 128 GB, 2.5-inch

SATA II, 7200 rpm, 1000 GB, 3.5-inch, S.M.A.R.T.

SATA II, 7200 rpm, 500 GB, 3.5-inch, S.M.A.R.T.

SATA II, 7200 rpm, 320 GB, 3.5-inch, S.M.A.R.T.

SATA II, 7200 rpm, 250 GB, 3.5-inch, S.M.A.R.T.

SATA II, 7200 rpm, 160 GB, 3.5-inch, S.M.A.R.T.

SATA II, 7200 rpm, 160 GB, 2.5-inch, S.M.A.R.T.

Hard disk notes Supporting NCQ and 3 GBit

GRAPHICS ADD ON CARDS (OPTIONAL) ATI Radeon®HD 3450, 256 MB

Dual DVI Adapter

DVI Adapter

NVIDIA®GeForce®9300GE, 256 MB

NVIDIA®GeForce®9300GE, 512 MB

NVIDIA®Geforce® 9300GE display port low prole, 512 MB

NVIDIA®GeForce®9500GS, 512 MB

NVIDIA®Quadro NVS 290, 256 MB

MODULAR BAY OPTIONS 1.44 MB Floppy

Blu-ray Disc Triple Writer, SATA I

DVD-ROM, SATA I

DVD Super Multi, SATA I

MultiCard Reader 20in1, 3,5-Inch, USB 2.0

INTERFACE ADD ON CARDS/COMPO-

NENTS (OPTIONAL)

WLAN III, 802.11g/Draft-n (Windows only)

WLAN II, 802.11g, 54Mbps (Windows only)

Parallel Interface

Modem adapter kit (EU)

Modem 56k incl. RJ11 modem cable

Gigabit Ethernet PCIe x1

FireWire PCI-Card IEEE1394

eSATA Interface

Dual serial card, PCI, EX-43092

Base unit ESPRIMO P5730

MAINBOARD

Mainboard type D2811

Formfactor µBTX

Chipset Intel®Q43

Processor socket LGA 775

Processor quantity maximum 1

System bus (FSB / HT / QPI) up to 1333 MHz

Memory slots 4 DIMM (DDR2)

Supported capacity RAM (max.) 16 GB

Memory frequency 800 MHz

Memory notes Dual channel support.

For dual channel performance, identical memory modules in each channel are necessary (minimum 2 modules).

LAN 10/100/1000 MBit/s Intel®82567 LF

BIOS version Phoenix 6.0

BIOS features BIOS Flash EPROM update by software

Recovery BIOS

Audio codec Realtek ALC663

Audio features Internal speaker supports audio playback, High Denition audio, 5.1 surround sound

I/O CONTROLLER ON BOARD

Serial ATA total 4

thereof eSATA 2 (optional)

Controller functions Serial ATA II

NCQ and 3 GBit

AHCI

INTERFACES

Audio: line-in 1

Audio: line-in / microphone 1

Audio: line-out 1

USB 2.0 total 12

USB front 2

USB rear 6

USB internal 4, thereof 2 optional rear

VGA 1

DVI optional

Serial (RS-232) 1 (9pi, 16 byte FIFO, 16550 compatible)

Mouse / Keyboard (PS/2) 2

Ethernet (RJ-45) 1

Parallel optional (25pin with EPP and ECP)

INPUT DEVICE / COMPONENTS

Optical USB tilt wheel mouse

Optional: Optical USB/PS2 tilt wheel mouse

DRIVE BAYS

Drive bays total 6

3.5-inch internal bays 2

3.5-inch external bays 2

5.25-inch external bays 2

SLOTS

PCI-Express 2.0 x16 1 x (230 mm) FlexySlot

PCI-Express x4 (mech. x8) 1 x (230 mm) full height

PCI (32-bit / 33 MHz) 2 x (170 / 315 mm) full height

GRAPHICS ON BOARD

Graphics brand name Intel®GMA 4500

GRAPHICS ON BOARD

Shared video memory up to 256 MB

Refresh rate 1024 x 768

(recommended / max.)

85 Hz / -

Refresh rate 1280 x 1024

(recommended / max.)

85 Hz / -

Refresh rate 1600 x 1200

(recommended / max.)

85 Hz / -

TFT resolution (VGA) 1360 x 768 pixel

1440 x 900 pixel

1680 x 1050 pixel

1920 x 1200 pixel

TFT resolution (DVI) 1360 x 768 pixel

1440 x 900 pixel

1680 x 1050 pixel

1920 x 1200 pixel

Graphics features DirectX 10

Graphics notes Tested resolutions, depending on display type additional resolutions and frequencies possible

Shared memory depending on main memory size

Resolution (color depth up to 32 Bit/pixel)

For TFT we recommend using 60Hz

ELECTRICAL VALUES

Power efciency note power supply efciency (at 230V; 20% / 50% / 100% load) : 71% / 77% / 76%

Rated voltage range 100 - 127 V / 200 - 240 V

Rated frequency range 50 - 60 Hz

Operating voltage range 90 - 137 V / 180 - 264 V

Operating line frequency range 47 - 63 Hz

Max. output of power supply 260 W

Power factor correction/active power passive

Monitor outlet Switched

POWER CONSUMPTION

Power consumption note See white paper Energy Consumption

Link to Energy White Paper http://docs.ts.fujitsu.com/dl.aspx?id=838373c8-dd75-4b46-81d9-e6d35e7f1abb

HEAT DISSIPATION

Heat dissipation notes See white paper Energy Consumption

NOISE FOR STANDARD CONFIGURATION (HDD, ODD, FDD)

Noise emission According to ISO9296

Related Processors for noise Intel®Core™2 Duo E8600

Noise Operation mode 1: ODD load

(Blue angel requirement)

4.9 B / 34 dB(A)

Noise Operation mode 2: HDD load

(Blue angel requirement)

3.7 B / 21 dB(A)

Noise Operation mode 3: CPU 90% load

(Blue angel requirement)

3.8 B / 23 dB(A)

Noise Operation mode 4: High load 3.8 B / 23 dB(A)

Noise Operation mode 5: Ofce

applications

3.9 B / 23 dB(A)

Idle mode (Blue Angel requirement) 3.7 B / 21 dB(A)

Noise notes / description A weighted sound power level Lwad (in B) / workplace related A-weighted sound pressure level LpAm (in dB(A)), Bystander

position

DIMENSIONS / WEIGHT / ENVIRONMENTAL

Dimensions (W x D x H) 203 x 390 x 392 mm

Operating position Vertical

Weight approx. 12 kg

Weight notes Actual weight may vary depending on conguration

Operating ambient temperature 15 - 35°C

COMPLIANCE

Product ESPRIMO P5730

Model MI3W-D2811

Germany GS optional

Europe CE

Nordic Swan

USA/Canada FCC Class B

cCSAus

Global RoHS (Restriction of hazardous substances)

WEEE (Waste electrical and electronical equipment)

Microsoft Operating Systems (HCT / HCL entry / WHQL)

Compliance link https://sp.ts.fujitsu.com/sites/certicates/default.aspx

OPERATING SYSTEM

Operating system optional preinstalled Microsoft®Windows®7 Home Premium

Microsoft®Windows®7 Professional

Microsoft®Windows Vista®Home Basic

Microsoft®Windows Vista®Home Premium

Microsoft®Windows Vista®Business 32-bit

Microsoft®Windows Vista®Business 64-bit

TwinLoad Microsoft®Windows®XP Professional (DVD)

Operating system compatible Linux

Operating system notes Windows Vista®Premium Logo: min. 1 GB RAM necessary.

All Windows Vista®and Windows® 7 versions are Ofce 2007 ready.

ADDITIONAL SOFTWARE

Additional software (preinstalled) Nero Essentials S (burning software)

Additional software (optional) Recovery DVD for Windows®

Drivers & Utilities DVD (DUDVD)

CyberLink PowerDVD BD (playback software for Blu-ray Disc™, only with Blu-ray Disc™ drive)

COMPATIBILITY (REFERENCES)

DMI 2.0

PC 2001

WMI 1.5

USB 2.0

MANAGEABILITY

Manageability features ASF 2.0 (Alert Standard Format)

DeskUpdate Driver management

DeskView Migrate (optional)

DeskView Control (optional)

PXE 2.1 Boot code

BootP Boot Code including Bootmanage Administrator Software (tested)

Wake up from S5 (off mode)

Intrusion switch (optional)

Intel®Standard Manageability

Manageability type DeskView 10.x client management including:

DeskView features On/Ofine remote client management

Detailed system inventory management and reports

BIOS Management

Remote power management

System notications

Advanced alerts (ASF implementation)

Security Remote Control

DeskView Helpdesk Integration

WoL (Wake on LAN)

Manageability link http://ts.fujitsu.com/manageability

http://www.altiris.com/fujitsu

SECURITY

Physical security Kensington Lock support

Eye for padlock

Optional: Integrated cabinet lock

SECURITY

System security Boot sector virus protection

Write protect option for the Flash EPROM

Embedded security (TPM 1.2)

Control of all USB interfaces

External USB ports can be disabled separately

Boot protection for oppy disk / CD drive and write protection for oppy disk drive

Control of external interfaces

User security User and supervisor BIOS password

SystemLock 2 BIOS SmartCard Security

Hard disk password

Optional: Access protection via external SmartCard reader

Optional: Access protection via internal SmartCard reader

SERVICEABILITY

FlexySlot

EasyFix

EasyChange for HDD

EasyChange for optical drives

PACKAGING INFORMATION

Packaging dimension 500x290x540 mm

Max. quantity / pallet 24

Material - Weight (g) Carton 1270 g

Material - Weight (g) EPS / PS 210 g

Material - Weight (g) PE appr. 60 g

Packaging notes printed user documentation is bleached in chlorine free process

WARRANTY

MAINTENANCE AND SUPPORT SERVICES - THE PERFECT EXTENSION

Recommended Service 5x9, Response Time: Next Business Day

Spare Parts availability 5 years

Service Weblink http://ts.fujitsu.com/Supportservice

CONTACT

FUJITSU Technology Solutions

Website: http://ts.fujitsu.com

2010-02-01 CE-EN

FUJITSU PLATFORM SOLUTIONS

In addition to Fujitsu ESPRIMO P5730, Fujitsu

provides a range of platform solutions. They

combine reliable Fujitsu products with the best in

services, know-how and worldwide partnerships.

Dynamic Infrastructures

With the Fujitsu Dynamic Infrastructures

approach, Fujitsu offers a full portfolio of IT

products, solutions and services, ranging

from clients to datacenter solutions, Managed

Infrastructure and Infrastructure as-a-Service.

How much you benet from Fujitsu technologies

and services depends on the level of cooperation

you choose. This takes IT exibility and efciency

to the next level.

Computing Products

www.fujitsu.com/global/services/computing/

Software

www.fujitsu.com/software/

MORE INFORMATION

Learn more about Fujitsu ESPRIMO P5730,

please contact your Fujitsu sales representative

or Fujitsu Business partner, or visit our website.

http://ts.fujitsu.com/ESPRIMO

FUJITSU GREEN POLICY INNOVATION

Fujitsu Green Policy Innovation is our worldwide

project for reducing burdens on the environment.

Using our global know-how, we aim to resolve

issues of environmental energy efciency

through IT. Please nd further information

at http://www.fujitsu.com/global/about/

environment/

COPYRIGHTS

rights. Changes to technical data reserved.

Delivery subject to availability. Any liability that

the data and illustrations are complete, actual or

correct is excluded.

Designations may be trademarks and/or

copyrights of the respective manufacturer,

the use of which by third parties for their own

purposes may infringe the rights of such owner.

For further information see http://ts.fujitsu.com/

terms_of_use.html

DISCLAIMER

Technical data are subject to modication and

delivery subject to availability. Any liability that

the data and illustrations are complete, actual

or correct is excluded. Designations may be

trademarks and/or copyrights of the respective

manufacturer, the use of which by third parties

for their own purposes may infringe the rights of

such owner

Table des matières

Autres manuels Fujitsu Ordinateur de bureau

Fujitsu

Fujitsu DESKPOWER 2000 Series Manuel utilisateur

Fujitsu

Fujitsu ESPRIMO P372 Series Manuel utilisateur

Fujitsu

Fujitsu CELSIUS W370 E85+ Manuel utilisateur

Fujitsu

Fujitsu SCENIC8651 Manuel utilisateur

Fujitsu

Fujitsu SCENIC6511 Manuel utilisateur

Fujitsu

Fujitsu CELSIUS C620 Manuel utilisateur

Fujitsu

Fujitsu ESPRIMO P15 Series Manuel utilisateur

Fujitsu

Fujitsu CELSIUS M720 Manuel utilisateur

Fujitsu

Fujitsu Supercomputer PRIMEHPC FX700 Manuel utilisateur

Fujitsu

Fujitsu DESKPOWER 2000 Series Manuel utilisateur

Fujitsu

Fujitsu Supercomputer PRIMEHPC FX700 Manuel utilisateur

Fujitsu

Fujitsu ESPRIMO E5635 Manuel utilisateur

Fujitsu

Fujitsu ESPRIMO G5010 Manuel utilisateur

Fujitsu

Fujitsu ESPRIMO Q5020 Manuel utilisateur

Fujitsu

Fujitsu PRIMEPOWER 800 Manuel utilisateur

Fujitsu

Fujitsu CELSIUS W570power Manuel utilisateur

Fujitsu

Fujitsu ESPRIMO P5635 Manuel utilisateur

Fujitsu

Fujitsu DESKPOWER 5000 Series Manuel utilisateur

Fujitsu

Fujitsu DESKPOWER P303 Manuel utilisateur

Fujitsu

Fujitsu ESPRIMO C710 Manuel utilisateur

Fujitsu

Fujitsu CELSIUS C620 Manuel utilisateur

Fujitsu

Fujitsu CELSIUS M740 Manuel utilisateur

Fujitsu

Fujitsu ESPRIMO D5 Series Manuel utilisateur

Fujitsu

Fujitsu ESPRIMO C7xx Manuel utilisateur

Manuels Ordinateur de bureau populaires d'autres marques

HP m9060n - Pavilion - Elite Fiche technique

Asus

Asus E210 Series Manuel utilisateur

Dell

Dell Inspiron 600m Manuel utilisateur

Dell

Dell Inspiron 3662 Manuel utilisateur

TotalFlow

TotalFlow uFLO Manuel utilisateur

HP Presario SV7000 - Desktop PC Manuel utilisateur

HP ProDesk 400 G5 Manuel

Logitech

Logitech MK320 Manuel utilisateur

Dell

Dell XPS 730 H2C Manuel utilisateur

Sony

Sony Vaio Series Manuel utilisateur

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Manuel utilisateur

Alto

Alto MD 250 Manuel utilisateur

Lenovo

Lenovo ThinkCentre Edge 72 Manuel

Lenovo

Lenovo ThinkStation D20 Manuel

Arbor Technology

Arbor Technology FPC-7800 Series Manuel utilisateur

Sony

Sony VAIO VGX-TP1 Series Manuel utilisateur

Asus

Asus Eee Box B204 Manuel utilisateur

Dell

Dell Optiplex 9010 All In One Manuel utilisateur
