Data Sheet Fujitsu ESPRIMO E420 E85+ Desktop PC

Page 1 / 8 www.fujitsu.com/fts/ESPRIMO

Fujitsu recommends Windows 8 Pro.

Data Sheet

Fujitsu ESPRIMO E420 E85+

Desktop PC

Your Immediately Deliverable Office PC

The FUJITSU PC ESPRIMO E420 delivers high-quality computing for your ofce applications and projects

at a very attractive price point. You can choose cost-optimized xed congurations for immediate

delivery. Alternatively, you can use conguration options to meet your specic hardware needs, while

staying within your budget.

High performance and best price/performance ratio

Cost-effective system for price-conscious customers

4th generation Intel® Core™ processor family

Flexibility

Freedom of choice with tailored systems, perfect t for specic requirements

Flexible logistic concept - optional customizing program

Reliability

High-quality and functional stability

Development and production in Europe

Lifecycle

Hardware continuity for long-term projects

Managed lifecycle up to 12 months

Meets ENERGY STAR®requirements

Low power consumption and low costs, without any loss in performance

Power supply with 85% efciency

Data Sheet Fujitsu ESPRIMO E420 E85+ Desktop PC

Page 2 / 8 www.fujitsu.com/fts/ESPRIMO

Fujitsu recommends Windows 8 Pro.

Components

Processor Intel® Core™ i7-4770 processor (4 Cores / 8 Threads, 3.40 GHz, up to 3.9 GHz, 8 MB, Intel® HD Graphics 4600) *

Intel® Core™ i5-4670 processor (4 Cores / 4 Threads, 3.40 GHz, up to 3.8 GHz, 6 MB, Intel® HD Graphics 4600) *

Intel® Core™ i5-4570 processor (4 Cores / 4 Threads, 3.20 GHz, up to 3.6 GHz, 6 MB, Intel® HD Graphics 4600) *

Intel® Core™ i5-4440 processor (4 Cores / 4 Threads, 3.10 GHz, up to 3.3 GHz, 6 MB, Intel® HD Graphics 4600)

Intel® Core™ i3-4130 processor (2 Cores / 4 Threads, 3.40 GHz, 3 MB, Intel® HD Graphics 4400)

Intel® Pentium® processor G3420 (2 Cores / 2 Threads, 3.20 GHz, 3 MB, Intel® HD Graphics)

Intel® Pentium® processor G3220 (2 Cores / 2 Threads, 3.00 GHz, 3 MB, Intel® HD Graphics)

*with Intel® Turbo Boost Technology (clock speed and performance will vary depending on workload and other

variables)

Operating systems

Operating system Windows 8.1 Pro

Windows 8.1

Windows® 7 Professional 64-bit

Windows® 7 Professional 32-bit

Operating system compatible openSUSE Linux

Memory modules 2 GB (1 module(s) 2 GB) DDR3, unbuffered, non-ECC, 1600 MHz, PC3-12800, DIMM

4 GB (1 module(s) 4 GB) DDR3, unbuffered, non-ECC, 1600 MHz, PC3-12800, DIMM

8 GB (1 module(s) 8 GB) DDR3, unbuffered, non-ECC, 1600 MHz, PC3-12800, DIMM

Hard disk notes Up to 20 GB of HDD space is reserved for system recovery

SSHD (Solid State Hard Disk, Hybrid drive)

SSD (Solid State Disk)

SED (Self-Encrypting Drive)

Hard disk drives (internal) SSHD SATA III, 7,200 rpm, 1,000 GB, 3.5-inch

SSHD SATA III, 5,400 rpm, 500 GB, 2.5-inch

SSD SATA III, 256 GB, 2.5-inch

SSD SATA III, 128 GB, 2.5-inch, SED

SSD SATA III, 128 GB, 2.5-inch

HDD SATA III, 7,200 rpm, 2,000 GB, 3.5-inch

HDD SATA III, 7,200 rpm, 1,000 GB, 3.5-inch

HDD SATA III, 7,200 rpm, 500 GB, 3.5-inch

HDD SATA III, 7,200 rpm, 250 GB, 3.5-inch

HDD SATA II, 5,400 rpm, 320 GB, 2.5-inch

Graphics NVIDIA® NVS 300 LP, 512 MB

NVIDIA® GeForce® GT630 DisplayPort 2GB LP, 2 GB

NVIDIA® GeForce® 605 DisplayPort 1GB LP, 1 GB

LFH59/ 2x DVI-I adapter cable

LFH59/ 2x DP adapter cable

DVI to VGA Adapter

DP to DVI-D (single link) Adapter Cable

Drives (optional) BD Triple Writer SATA slim (tray)

DVD-ROM

DVD Super Multi

MultiCard Reader 24in1 USB 2.0 3.5”

Data Sheet Fujitsu ESPRIMO E420 E85+ Desktop PC

Page 3 / 8 www.fujitsu.com/fts/ESPRIMO

Fujitsu recommends Windows 8 Pro.

Interface add on cards/components

(optional)

WLAN III, 802.11g/Draft-n (Windows only, dedicated regions only, not for Indonesia)

WLAN 802.11 abgn (2x2), (dedicated regions only, not for Indonesia)

USB 3.0 PCIe x1

Gigabit Ethernet PCIe x1, DS

Dual serial card PCIe x1

Base unit ESPRIMO E420 E85+

Mainboard

Mainboard type D3230

Formfactor μATX

Chipset Intel® H81

Processor socket LGA 1150

Processor quantity maximum 1

Memory slots 2 DIMM (DDR3)

Supported capacity RAM (max.) 16 GB

Memory frequency 1,600 MHz

Memory notes Dual channel support.

For dual channel performance, identical memory modules in each channel are necessary (minimum 2 modules).

LAN 10/100/1,000 MBit/s Realtek RTL8111G

BIOS version AMI Aptio 4.6

BIOS features BIOS Flash EPROM update by software

Recovery BIOS

Unied Extensible Firmware Interface (UEFI)

Audio codec Realtek ALC671

Audio features High Denition Audio, 5.1 surround sound

I/O controller on board

Serial ATA total 3

thereof SATA III 2

Controller functions Serial ATA II (3 Gbit)

Serial ATA III (6 Gbit)

NCQ

AHCI

Interfaces

Audio: line-in 1

Audio: line-in / microphone 1

Audio: line-out 1

Front audio: microphone 1

Front audio: headphone 1

USB 2.0 total 6

USB 3.0 total 2

USB front 2x 2.0

USB rear 2x 2.0/ 2x 3.0

USB internal 2x 2.0

VGA 1

DVI 1 (DVI-D)

Mouse / Keyboard (PS/2) 1/1

Ethernet (RJ-45) 1

Input device / components

Optical USB wheel mouse

Data Sheet Fujitsu ESPRIMO E420 E85+ Desktop PC

Page 4 / 8 www.fujitsu.com/fts/ESPRIMO

Fujitsu recommends Windows 8 Pro.

Input device / components

Input devices (optional) Optical USB/PS2 tilt wheel mouse

KBPC PX ECO

Mouse M440 ECO

Drive bays

Drive bays total 3

3.5-inch internal bays 1

3.5-inch external bays 1

5.25-inch external bays 1

Drive bay notes 3,5” bay can be used for 2,5” drives; optional external bay as internal 3,5”;

Slots

PCI-Express 3.0 x16 1 x (210 mm / 7.87 inch) Low prole

PCI-Express x1 2 x (210 mm / 8.27 inch) Low prole

Graphics on board

Graphics brand name Intel® HD Graphics, HD Graphics 4400, HD Graphics 4600 (depending on processor)

Shared video memory up to 1,782 MB

TFT resolution (VGA) 1,024 x 768 pixel

1,280 x 1,024 pixel

1,360 x 768 pixel

1,440 x 900 pixel

1,600 x 900 pixel

1,600 x 1,200 pixel

1,680 x 1,050 pixel

1,920 x 1,080 pixel

TFT resolution (DVI) 1,280 x 1,024 pixel

1,360 x 768 pixel

1,440 x 900 pixel

1,600 x 900 pixel

1,680 x 1,050 pixel

1,920 x 1,080 pixel

1,920 x 1,200 pixel

Graphics features Dual display support

DirectX® 11.1

HDCP support

Open GL® 3.3

Open CL® 1.2

Graphics notes up to 1 GB dedicated video memory (main memory owned and locked for graphics use)

Tested resolutions, depending on display type additional resolutions and frequencies possible

Shared memory depending on main memory size and operating system

Resolution (color depth up to 32 Bit/pixel)

For TFT we recommend using 60Hz

Electrical values

Power efciency note power supply efciency (at 230V; 20% / 50% / 100% load) : 83% / 86% / 85%

0-Watt mode with hard-off switch

Rated voltage range 100 V - 240 V

Rated frequency range 50 Hz - 60 Hz

Operating voltage range 90 V - 264 V

Operating line frequency range 47 Hz - 63 Hz

Max. output of single power supply 280 W

Power factor correction/active power active

Monitor outlet No

Power consumption

Power consumption note See white paper Energy Consumption

0-Watt mode with hard-off switch

Data Sheet Fujitsu ESPRIMO E420 E85+ Desktop PC

Page 5 / 8 www.fujitsu.com/fts/ESPRIMO

Fujitsu recommends Windows 8 Pro.

Power consumption

Link to Energy White Paper http://docs.ts.fujitsu.com/dl.aspx?id=f0855939-4ca1-4504-b17a-716d665eff8d

Heat dissipation

Heat dissipation notes See white paper Energy Consumption

Noise emission

Related Processors for noise Intel® Core™ i7 4770

Standard noise emission 2x2 GB, HDD, ODD, Windows

According to ISO 7779:2010, ECMA-74

Standard noise notes / description A-weighted sound power level Lwad (in B) / Workplace related A-weighted sound pressure level LpAm (in dB(A))

Bystander position

Standard noise operation mode: CPU

50% load

3.6 B / 22 dB(A) Bystander; 25 dB(A) Operator position

Standard noise operation mode: HDD

load

3.4 B / 21 dB(A) Bystander; 23 dB(A) Operator position

Standard noise operation mode: Idle

mode

3.3 B / 20 dB(A) Bystander; 22 dB(A) Operator position

Standard noise operation mode: ODD

load

4.6 B / 31 dB(A) Bystander; 36 dB(A) Operator position

Standard noise operation mode: Ofce

applications 2.0

3.3 B / 20 dB(A) Bystander; 22 dB(A) Operator position

Dimensions / Weight / Environmental

Dimensions (W x D x H) 330 x 405 x 104 mm

13.0 x 15.95 x 4.1 inch

Operating position horizontal / vertical (optional, feet needed)

Weight 9 kg

Weight (lbs) 20.22 lbs

Weight notes Actual weight may vary depending on conguration

Operating ambient temperature 10 - 35 °C (50 - 95 °F)

Compliance

Product ESPRIMO E420

Model DTL2

Germany TÜV GS

Europe CE

USA/Canada FCC Class B

cCSAus

Global RoHS (Restriction of hazardous substances)

WEEE (Waste electrical and electronic equipment)

Microsoft Operating Systems (HCT / HCL entry / WHQL)

ENERGY STAR® 5.0 (dedicated regions)

EPEAT® Gold (dedicated regions)

Compliance link http://globalsp.ts.fujitsu.com/sites/certicates

Additional Software

Additional software (preinstalled) Workplace Protect (secure authentication solution)

Adobe® Reader® (pdf reader)

McAfee Multi Access Security (anti-virus and internet security software; 60 days trial version)

Win7: Fujitsu Recovery (hard disk based recovery)

Win8: Microsoft Push Button Recovery (hard disk based recovery)

Microsoft Ofce (buy license to activate the pre-installed Microsoft Ofce)

Additional software (optional) Recovery DVD for Windows®

Drivers & Utilities DVD (DUDVD)

CyberLink PowerDVD BD (playback software for Blu-ray Disc™)

CyberLink PowerDVD DVD (playback software for DVD)

Nero Essentials XL

Miscellaneous

Data Sheet Fujitsu ESPRIMO E420 E85+ Desktop PC

Page 6 / 8 www.fujitsu.com/fts/ESPRIMO

Fujitsu recommends Windows 8 Pro.

Compatibility (references)

DMI 2.0

PC 2001

WMI 1.5

USB 2.0

SMBIOS

Manageability

Manageability technology DeskUpdate Driver management

PXE 2.1 Boot code

Wake up from S5 (off mode)

WoL (Wake on LAN)

Security

Physical Security Kensington Lock support

Eye for padlock

System and BIOS Security Boot sector virus protection

Write protect option for the Flash EPROM

Control of external interfaces

User Security User and supervisor BIOS password

Hard disk password

Access protection via external SmartCard reader (optional)

Access protection via internal SmartCard reader (optional)

Packaging information

Packaging dimension (mm) 467 x 265 x 540 mm

Packaging dimension (inch) 18.39 x 10.43 x 21.26 inch

Max. quantity / pallet 28

Material - Weight (g) Carton 1140 g

Material - Weight (lbs) Carton 2.51 lbs

Material - Weight (g) EPS / PS 180 g

Material - Weight (lbs) EPS / PS 0.4 lbs

Material - Weight (g) PE 60 g

Material - Weight (lbs) PE 0.13 lbs

Packaging notes printed user documentation is bleached in chlorine free process

Warranty

Standard Warranty 1 year

Service level Bring-In / Onsite Service (for countries within region FTS CEMEA&I, for all other countries depending on local

regulations, minimum: 1 year material warranty)

Warranty Terms & Conditions http://support.ts.fujitsu.com/warranty

Maintenance and Support Services - the perfect extension

Recommended Service 9x5, Response Time: Next Business Day

Spare Parts availability 5 years after end of product life

Service Weblink http://www.fujitsu.com/fts/services/support

Recommended Accessories

Mouse M440 ECO Fujitsu Mouse M440 ECO is made from 100% bio material and has a

completely PVC free cable. The elegant M440 ECO works on nearly every

surface and follows all your hand movements smoothly and precisely.

It features two main buttons and as well as a scroll wheel providing

comfortable computing to both right and left-handed users.

Order Code:

S26381-K450-L200

Data Sheet Fujitsu ESPRIMO E420 E85+ Desktop PC

Page 7 / 8 www.fujitsu.com/fts/ESPRIMO

Fujitsu recommends Windows 8 Pro.

SOUNDSYSTEM DS E2000 Air The new more powerful SOUNDSYSTEM DS E2000 Air gives you impressive,

well-balanced sound throughout the frequency band. It is an unbeatable

USB speaker set with a surprisingly small form factor. The robust satellite

speakers are decorated with a deluxe piano nish and the base is adorned

with warm ambient lighting.

Order Code:

S26391-F7128-L600

HS E2000 Communicator

Headset

The Fujitsu HS E2000 Communicator headset allows you to use your

personal computer for Voice over IP (VoIP) in stereo audio quality. This

premium headset is designed to provide superb audio quality and comfort

for the telephony, internet chat, speech recognition, video conferencing and

multimedia applications.

Order Code:

S26391-F7139-L5

Keyboard KBPC PX ECO Fujitsu’s KBPC PX ECO keyboard is the perfect contribution to Green IT. The

keyboard is made out of 45% renewable raw material and comes with a PVC

free USB cable. In addition, the KBPC PX ECO offers rst class comfort and

ergonomics. It attracts attention with its impressive modern design and

useful extras.

S26381-K341-L1** (**:

country specic variation)

Data Sheet Fujitsu ESPRIMO E420 E85+ Desktop PC

Page 8 / 8 www.fujitsu.com/fts/ESPRIMO

Fujitsu recommends Windows 8 Pro.

Contact

FUJITSU Technology Solutions

Website: www.fujitsu.com/fts

2014-01-27 CE-EN

Fujitsu OPTIMIZATION Services

In addition to Fujitsu ESPRIMO E420 E85+,

Fujitsu provides a range of platform solutions.

They combine reliable Fujitsu products with

the best in services, know-how and worldwide

partnerships.

Fujitsu Portfolio

Build on industry standards, Fujitsu offers a full

portfolio of IT hardware and software products,

services, solutions and cloud offering, ranging

from clients to datacenter solutions and

includes the broad stack of Business Solutions,

as well as the full stack of Cloud offering. This

allows customers to leverage from alternative

sourcing and delivery models to increase

their business agility and to improve their IT

operation’s reliability.

Computing Products

www.fujitsu.com/global/services/computing/

Software

www.fujitsu.com/software/

More information

Learn more about Fujitsu ESPRIMO E420

E85+, please contact your Fujitsu sales

representative or Fujitsu Business partner, or

visit our website.

www.fujitsu.com/fts/ESPRIMO

Fujitsu green policy innovation

Fujitsu Green Policy Innovation is our

worldwide project for reducing burdens on the

environment.

Using our global know-how, we aim to

contribute to the creation of a sustainable

environment for future generations through IT.

Please nd further information at http://www.

fujitsu.com/global/about/environment

Copyrights

property rights. Changes to technical data

reserved. Delivery subject to availability. Any

liability that the data and illustrations are

complete, actual or correct is excluded.

Designations may be trademarks and/or

copyrights of the respective manufacturer,

the use of which by third parties for their

own purposes may infringe the rights of such

owner.

For further information see www.fujitsu.com/

terms

Disclaimer

Technical data are subject to modication and

delivery subject to availability. Any liability

that the data and illustrations are complete,

actual or correct is excluded. Designations

may be trademarks and/or copyrights of the

respective manufacturer, the use of which

by third parties for their own purposes may

infringe the rights of such owner.

More information

Any liability that the data and illustrations are complete, actual or correct is excluded.

Designations may be trademarks and/or copyrights of the respective manufacturer, the use of which by third parties for their

own purposes may infringe the rights of such owner.

For further information see www.fujitsu.com/terms

Table des matières

Autres manuels Fujitsu Ordinateur de bureau

Fujitsu

Fujitsu CELSIUS C620 Manuel utilisateur

Fujitsu

Fujitsu CELSIUS Manuel utilisateur

Fujitsu

Fujitsu Supercomputer PRIMEHPC FX700 Manuel utilisateur

Fujitsu

Fujitsu Esprimo P2 Series Manuel utilisateur

Fujitsu

Fujitsu ESPRIMO E3520 Manuel utilisateur

Fujitsu

Fujitsu ErgoPro e Series Manuel utilisateur

Fujitsu

Fujitsu ESPRIMO PH300 Manuel utilisateur

Fujitsu

Fujitsu DESKPOWER 6000 Series Manuel utilisateur

Fujitsu

Fujitsu ESPRIMO P556 Manuel utilisateur

Fujitsu

Fujitsu Supercomputer PRIMEHPC FX700 Manuel utilisateur

Fujitsu

Fujitsu SCALEO EV Manuel utilisateur

Fujitsu

Fujitsu ESPRIMO D70 Series Manuel utilisateur

Fujitsu

Fujitsu M2361A Manuel d'installation et d'exploitation

Fujitsu

Fujitsu ESPRIMO P372 Series Manuel utilisateur

Fujitsu

Fujitsu DESKPOWER 5000 Series Manuel utilisateur

Fujitsu

Fujitsu DESKPOWER 2000 Series Manuel utilisateur

Fujitsu

Fujitsu ESPRIMO D5 Series Manuel utilisateur

Fujitsu

Fujitsu DESKPOWER 6000 Seriesl DESKPOWER 6000 SD... Manuel utilisateur

Fujitsu

Fujitsu 8000 SERIES Manuel utilisateur

Fujitsu

Fujitsu ErgoPro m664 Series Manuel utilisateur

Fujitsu

Fujitsu CELSIUS H5511 Manuel utilisateur

Fujitsu

Fujitsu SCENIC6511 Manuel utilisateur

Fujitsu

Fujitsu CELSIUS M770 Manuel utilisateur

Fujitsu

Fujitsu ESPRIMO E352 Series Manuel utilisateur

Manuels Ordinateur de bureau populaires d'autres marques

HP m9060n - Pavilion - Elite Fiche technique

Asus

Asus E210 Series Manuel utilisateur

Dell

Dell Inspiron 600m Manuel utilisateur

Dell

Dell Inspiron 3662 Manuel utilisateur

TotalFlow

TotalFlow uFLO Manuel utilisateur

HP Presario SV7000 - Desktop PC Manuel utilisateur

HP ProDesk 400 G5 Manuel

Logitech

Logitech MK320 Manuel utilisateur

Dell

Dell XPS 730 H2C Manuel utilisateur

Sony

Sony Vaio Series Manuel utilisateur

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Manuel utilisateur

Alto

Alto MD 250 Manuel utilisateur

Lenovo

Lenovo ThinkCentre Edge 72 Manuel

Lenovo

Lenovo ThinkStation D20 Manuel

Arbor Technology

Arbor Technology FPC-7800 Series Manuel utilisateur

Sony

Sony VAIO VGX-TP1 Series Manuel utilisateur

Asus

Asus Eee Box B204 Manuel utilisateur

Dell

Dell Optiplex 9010 All In One Manuel utilisateur
