Fujitsu Siemens Computers AMILO Xi 3650 Manuel utilisateur
Issue January 2009
Version 5
AMILO Notebook Xi 3650
The art of entertainment
Pages 6
Experience impressive entertainment, exciting new technologies, inspiring innovations and features unified in the
AMILO Notebook X Series.
Key Features
Processor technology
Latest Intel® Centrino® 2 processor technology (optional)1for high-definition digital
entertainment experience, blistering performance, longer-lasting battery life and the
new wireless standard for connectivity
Operating System
Windows Vista® Home Premium
Innovation
NVIDIA® GeForce® 9600M GT graphic card with 512 MB GDDR3 dedicated high-
speed VRAM deliver the ultimate balance between mobility and performance for
astounding HD playback capabilities combined with 3D features to enable
visually-intense applications and games
NVIDIA HybridPower™ technology allows you to unleash graphics performance when
you need it, or instantly switch gears to a lower power mode from the motherboard
GPU for longer battery life and quieter operation. This reduces system power
consumption dramatically and extends battery life by up to 25%
Reliability
Spill-proof keyboard2to protect your notebook against accidentially spilt liquids
- Enough time to shut down the notebook
- Have the liquid removed from the notebook
- Protects your investment and your data
Engineered in Germany means the test center in Germany tests conformity to
international standards and customer-specific requirements
A+ grade LCD panels for better picture quality
Ease of use
Silent mode function that causes a noticeable reduction in fan noise
Multimedia LightTouch™ bar and integrated Vista remote control let you easily play,
stop or pause your DVDs or music CDs
Multimedia and Entertainment
18.4-inch HD+ or Full HD display with 16:9 aspect ratio and BrilliantView technology
that provides vivid colors, amazing sharpness and impressive contrast
The integrated AMILOcam (1.3 mega pixels) with low-light technology for great video
quality even in low-light conditions and the built-in digital array microphone are perfect
for Internet telephony (VoIP) and video chats
Connect the AMILO Notebook Xi 3650 to an external display via HDMI (with HDCP
support)
Options
Integrated Blu-ray Disc™ drive for the ultimate entertainment experience
Dual hard disk drive with Raid 0/1 function
- Raid 0 function: implements data striping to provide the best possible performance
- Raid 1 function: defines disk mirroring for simultaneous writing of data on two
disks, so if one drive becomes defect, all data can be accessed on
the second drive
Model: Reveal white
Model: Eclipse black
Data Sheet ⏐Issue: January 2009⏐AMILO Notebook Xi 3650 Page 2 / 6
Fujitsu Siemens Computers recommends Windows Vista® Home Premium
Operating systemand Recovery
Operating system Genuine Windows Vista® Home Premium (32-bit version)
Fujitsu Siemens Computers Recovery Program
Backup and restore the original status of the hard disk and create system
restore disks
or individual recovery media on CD or DVD are included
Product Design
Color Reveal white or eclipse black
Architecture
System architecture Intel® Centrino® 2 processor technology (optional)1
Chipset Intel® GM45 + ICH9M-Enhanced
Processors3
Intel® Core™2 Duo processor T5800 (2.0 GHz, 800 MHz FSB, 2 MB L2 cache)
T6400 (2.00 GHz, 800 MHz FSB, 2 MB L2 cache
P7350 (2.0 GHz, 1066 MHz FSB, 3 MB L2 cache)
P7450 (2.13 GHz, 1066 MHz FSB, 3 MB L2 cache)
P8400 (2.26 GHz, 1066 MHz FSB, 3 MB L2 cache)
P8600 (2.4 GHz, 1066 MHz FSB, 3 MB L2 cache)
T9400 (2.53 GHz, 1066 MHz FSB, 6 MB L2 cache)
T9550 (2. 66 GHz, 1066 MHz FSB, 6 MB L2 cache)
Memory 2 SO-DIMM memory slots (no memory on board)
Memory speed 1066 MHz
Memory type DDR 3 RAM
Memory modules 1024 or 2048 MB
Max. memory size3, 44096 MB
Drives
Hard disk drive
HDD type SATA
HDD size 2.5-inch
HDD speed 5400 rpm
HDD cache 8 MB
HDD capacity3250, 320 or 500 GB with single HDD;
500 (2x 250), 640 (2x 320) or 1000 (2x 500) GB with dual HDD
Option3:
HDD type SATA
HDD size 2.5-inch
HDD speed 4200 rpm
HDD cache 8 MB
HDD capacity3500 GB with single HDD;
1000 (2x 500) GB with dual HDD
Raid function (optional, if two HDDs are installed)
Raid 0: stripe set for performance
Raid 1: mirroring for security
Raid off: two physical HDDs
Optical disc drive3 (built-in)
ODD type SATA
ODD technology SuperMulti-format DVD burner with double layer (DL) support
ODD read speed CD-ROM 24x, DVD-ROM 8x
ODD write speed CD-R 24x, CD-RW 16x, DVD+R 8x, DVD-R 8x, DVD+RW 8x,
DVD-RW 6x, DVD+R DL (8.5 GB) 4x, DVD-R DL (8.5 GB) 4x,
DVD-RAM 5x
Blu-ray Disc™ (optional)3
ODD technology Built-in Blu-ray Disc™ drive incl. SuperMulti-format DVD burner with
double layer (DL) support
ODD read speed BD 1.6x, CD-ROM 24x, DVD-ROM 8x
ODD write speed CD-R 8x, CD-RW 8x, DVD+R 8x, DVD+RW 4x, DVD-R 8x, DVD-RW 4x,
DVD+R DL (8.5 GB) 2.4x, DVD-R DL (8.5 GB) 2x, DVD RAM 5x
Data Sheet ⏐Issue: January 2009⏐AMILO Notebook Xi 3650 Page 3 / 6
Fujitsu Siemens Computers recommends Windows Vista® Home Premium
Display
Display type BrilliantView LCD with dual lamp (90% NTSC)
Aspect ratio 16:9
Resolution type Full HD
Display size 18.4-inch
Display resolution (intern) 1920 x 1080 pixels
Display resolution (extern) 1920 x 1200 pixels
Reaction time (typ.) 8 ms
Brightness (typ.) 300 NIT
Contrast (typ.) 800 :1
Compliance with standards ISO 13406-2 class II
Option3
Display type BrilliantView LCD
Aspect ratio 16:9
Resolution type HD+
Display size 18.4-inch
Display resolution (intern) 1680 x 945 pixels
Display resolution (extern) 1920 x 1200 pixels
Reaction time (typ.) 16 ms
Brightness (typ.) 200 NIT
Contrast (typ.) 600 :1
Compliance with standards ISO 13406-2 class II
Graphics
Dedicated graphics (full name) NVIDIA® GeForce® 9600M GT
Dedicated video memory 512 MB GDDR3, 1066 MHz
Onboard graphics chip Mobile Intel® Graphics Media Accelerator 4500MHD
Shared video memory5Up to 1295 MB (depending on installed main memory)
3D Benchmark 2006 Up to 5044 points (depending on configuration)
Graphic features NVIDIA® HybridPower™ technology (hybrid graphic technology)
NVIDIA® PureVideo® HD technology
DirectX® 10 support
Interfaces
Video 1x HDMI (1.3) (incl. HDCP and S/PDIF out), 1x VGA
Audio Front: 1x line in, 1x microphone in, 1x line out /headphone out,
Side: 1x line out / S/PDIF out
Network 1x LAN (RJ-45)
Data 1x eSATA combined with USB 2.0, 3x USB 2.0,
1x IEEE1394 (FireWire™), 1x CIR,
1x ExpressCard slot (54 / 34 mm),
1x 15-in-1 card reader6
SD, miniSD, MicroSD, SDHC,
MS, MS-Duo,
MMC, RS-MMC, MMC-Micro,
MSPRO, MS-PRO Duo, MS-Pro HG, MS-Pro HG Duo, M2,
xD picture card
Power supply 1x DC-in
Communication
Integrated Bluetooth® 2.1
LAN (Local Area Network) Gigabit Ethernet LAN (10 / 100 / 1000 Mbps)
Built-in WLAN (Wireless Local Area Network) Yes
WLAN brand name Intel® WiFi Link 5100 AGN
WLAN type draft-n 802.11a/g/n
WLAN max. data rate up to 300 Mbps
WLAN encryption WEP, WPA and WPA2
For use in BE, CH, DK, DE, EE, FI, FR, EL, IE, IS, IT, LI, LV, LT, LU, MT, NL, NO,
PL, AT, PT, SE, SK, ES, CZ, HU, UK, CY
Data Sheet ⏐Issue: January 2009⏐AMILO Notebook Xi 3650 Page 4 / 6
Fujitsu Siemens Computers recommends Windows Vista® Home Premium
Multimedia
Audio Support of high-definition audio for S/PDIF output with up to 7.1 channels;
7.1 audio support also via 4x audio jacks (analog)
Audio chip Realtek ALC888
Speakers 2x built-in speakers (2 W each)
Microphone Built-in digital array microphone
Subwoofer 1x built-in subwoofer (3 W)
Input device Sound volume control via function key or via LightTouch™ bar
AMILOcam
Image sensor 1.3 mega pixels webcam
Frames per second 307
Features Powered by Logitech®
Auto focus
Automatic brightness adjustment with status LED (blue: on, red:
streaming / application on)
Low-light technology for great video-quality even in dark
surrounding
Input devices / Control buttons
Power button Located left of the keyboard, back lighted
Keyboard Spill-proof keyboard2with 85 keys, 21 key number block
Touchpad Hidden touchpad, with left and right mouse button,
touchpad disable function via function key combination (Fn+F6)
Multimedia keys Multimedia LightTouch™ bar located on top of the keyboard to launch the
following applications:
Silent mode (reduce noise level / fan speed, by reducing the CPU
performance, office applications, Internet and DVD playback are not
affected)
Hybrid graphics to switch between onboard graphics for extended
battery runtime and external graphics for better performance
DVD playback
Skip rewind
Play / pause
Skip forward
Volume control
Remote Control 26-key Vista remote control, shipped in ExpressCard slot
Hot keys The following hot keys or key combinations are available
Fn+F1 WLAN / Bluetooth on / off
Fn+F3 Mute on / off
Fn+F4 Volume down
Fn+F5 Volume up
Fn+F6 Touchpad on / off
Fn+F7 AMILOcam on / off
Fn+F8 Brightness down
Fn+F9 Brightness up
Fn+F10 Display switch
Fn+F11 Silent mode
Fn+F12 Suspend
Number block
4 individually configurable quick-start application buttons (A1, A2, A3, A4)
Status indicators The notebook has 3 status LEDs:
Power status (& suspend)
Blue (always on): on; Blue blinking: stand by; None: off
Battery charge
Blue (always on): full; Blue blinking: charging;
Red blinking: < 10 % capacity
WLAN / Bluetooth®
Blue: on; None: off
Data Sheet ⏐Issue: January 2009⏐AMILO Notebook Xi 3650 Page 5 / 6
Fujitsu Siemens Computers recommends Windows Vista® Home Premium
Security
Supervisor and user password Yes
Kensington lock Yes
Lid switch (hidden) Yes
ACPI functions ACPI 3.0 compliant for Vista requirement
Power on stand by (S1 LCD off)
Stand by / energy saving mode (S3 save to RAM)
Hibernate mode (S4 save to disk)
Off mode (S5 soft off)
Power System
Battery8
Battery type Lithium-Ion battery
8 cells, 14.8 V / 2400 mAh (cell) / 4800 mAh (pack)
Battery life (idle mode)9Onboard graphics: up to 4.7 hours
Dedicated graphics: up to 3.6 hours
Battery life (DVD playback)10 Onboard graphics: up to 3.1 hours
Dedicated graphics: up to 2.7 hours
Battery charging time (idle mode)11 Onboard graphics / dedicated graphics (charging 90%): up to 2.1 hours
Battery charging time (maximum active mode)12 Onboard graphics (charging 90%): up to 2.2 hours
Dedicated graphics (charging 90%): up to 2.5 hours
Battery charging time (normal use)13 Onboard graphics (charging 90%): up to 2.1 hours
Dedicated graphics (charging 90%): up to 2.05 hours
Battery charging time (off mode) Onboard graphics (charging 90%): up to 2.15 hours
Dedicated graphics (charging 90%): up to 2.1 hours
AC Adapter Dynamic charge supported, ACPI 3.0 supported
Wide Range AC adapter 110 - 240 V AC, 50 - 60 Hz
Output 90 W with 20 V DC, 4.5 A
Energy consumption
S0 (idle mode) Onboard graphics: 11.15 W; Dedicated graphics: 17.30 W
S0 (max. active mode)14 Onboard graphics: 58.59 W; Dedicated graphics: 84.14 W
S3 (stand by / energy saving mode) Onboard graphics: 2.05 W; Dedicated graphics: 1.56 W
S4 (hibernate) Onboard graphics/Dedicated graphics: 0.51 W
S5 (off mode) Onboard graphics/Dedicated graphics: 0.36 W
Noise emission
Idle mode15 27.8 dB(A) (silent mode off)
Maximum active mode16 28.3 dB(A) (silent mode off)
Operating conditions
Operational 5 °C to 35 °C (ambient temperature)
10 % to 90 % relative humidity, non-condensing
Dimensions and weight
W x D x H 438 x 294 x 43.5 (front) / 50.5 (back) mm
Weight 3.9 kg17
Certifications GOST (WLAN)
CE Marking
R&TTE (WLAN, Bluetooth®)
Warranty Country specific terms
Application Software
Home office Microsoft® Works
Microsoft® Office Home and Student Trial
Adobe Reader
Windows Mail (within Vista operating system)
Windows Calendar (within Vista operating system)
Data Sheet ⏐Issue: January 2009⏐AMILO Notebook Xi 3650 Page 6 / 6
Fujitsu Siemens Computers recommends Windows Vista® Home Premium
All rights reserved, including intellectual property rights. Technical data subject to modifications and
delivery subject to availability. Any liability that the data and illustrations are complete, actual or
correct is excluded.
Designations may be trademarks and/or copyrights of the respective manufacturer, the use of which
by third parties for their own purposes may infringe the rights of such owner.
For further information see http://www.fujitsu-siemens.com/terms_of_use.html
Copyright © Fujitsu Siemens Computers 01/2009
Published by
FSC IP CLI PMKT
Christiane Geis
Fujitsu Siemens Computers
http://www.fujitsu-siemens.com/
Company stamp
Multimedia Nero Essentials S (CD / DVD write software)
Vista DVD Playback Pack (DVD playback software)
Windows Media Player (within Vista operating system)
Windows Media Center (within Windows Vista® Home Premium
operating system)
Logitech® QuickCam® application software
Optional3
CyberLink Power DVD (playback software for Blu-ray Disc™, only with
Blu-ray Disc™ drive)
Internet Microsoft® Internet Explorer
Country specific Internet provider
Security Norman security software solution
Accessories
Included AC adapter 90 W
First Battery 8 cells
Integrated remote control
Cleaning wipe
Optional Find out more: www.fujitsu-siemens.com/accessories
Manuals Manual (on hard disk), quick start guide, safety guide, warranty guide,
recovery guide
Drivers Updates downloadable at http://www.fujitsu-siemens.com
Awards
Notebookjournal.de
Germany – 01/2009
“Best 18.4 inch notebook”
1Processor technology depends on actually installed processor:
2DISCLAIMER: The keyboard is spill-proof up to 50ml. This is enough to protect your notebook from an accidental spill. However, we recommend a backup as well
as a system shut-down should liquids come into contact with the keyboard. The spill-proof protection does not prevent data loss caused by water damage. If this
should happen, please contact your local customer service desk.
3Depending on exact configuration. Please check at your local retailer
4DISCLAIMER: Up to 1 GB may not be available with 32-bit operating systems due to system resource requirements if system is preinstalled with 4096 MB RAM
5Shared video memory size may vary depending on configuration. Used video memory size depends on Microsoft® Windows Vista® memory management
- 1024 MB system memory enables up to 271 MB shared memory
- 2048 MB system memory enables up to 783 MB shared memory
- 3072 MB system memory enables up to 1295 MB shared memory
- 4096 MB system memory enables up to 1295 MB shared memory
6An adapter is needed for the following card formats: RS-MMC, MMC-Micro, miniSD, MicroSD, SDHC, MS-Duo, MS-PRO Duo, MS-Pro HG, MS-Pro HG Duo, M2
7AMILOcam frame rate can vary significantly depending on the used software application
8DISCLAIMER: Battery life may vary depending on product model, configuration, applications, power management settings and features utilized. Recharge time
varies depending on usage. The recharge capacity may decrease after some months so that the battery lifetime as well as operating time can not be assured for the
whole lifetime of the notebook
9Tested with Battery Mark 4.0.1 (“power saver mode”)
10 DVD playback tested with Vista DVD playback
11 Tested without test program
12 Tested with 3DMark 2006
13 DVD playback tested with Vista DVD playback
14 Tested with 3DMark 2006
15 Tested according to ISO 7779 and ISO 9296
16 Tested with QAFE 8.01 / 2. sieve.exe (CPU stress test) / Diskload.exe according to ISO 7779 and ISO 9296
17 Weight may vary depending on actual configuration
The configuration described in this document is generic only and non-binding. For the exact
configuration of your AMILO, please contact your licensed dealer.
Autres manuels pour AMILO Xi 3650
1
Autres manuels Fujitsu Siemens Computers Ordinateur portable
Fujitsu Siemens Computers
Fujitsu Siemens Computers ESPRIMO Mobile V5545 Manuel utilisateur
Fujitsu Siemens Computers
Fujitsu Siemens Computers answers 2 LIFEBOOK C Series Manuel utilisateur
Fujitsu Siemens Computers
Fujitsu Siemens Computers AMILO Pro V3525 Edition Manuel utilisateur
Fujitsu Siemens Computers
Fujitsu Siemens Computers AMILO L 6810 Manuel utilisateur
Fujitsu Siemens Computers
Fujitsu Siemens Computers Lifebook E2010 Manuel utilisateur
Fujitsu Siemens Computers
Fujitsu Siemens Computers AMILO A1650G Manuel utilisateur
Fujitsu Siemens Computers
Fujitsu Siemens Computers LIFEBOOK P Series Fiche d'information produit
Fujitsu Siemens Computers
Fujitsu Siemens Computers Mobile Workstation Manuel utilisateur
Fujitsu Siemens Computers
Fujitsu Siemens Computers LIFEBOOK S Series Fiche d'information produit
Fujitsu Siemens Computers
Fujitsu Siemens Computers LIFEBOOK E8310 Fiche d'information produit
Fujitsu Siemens Computers
Fujitsu Siemens Computers LIFEBOOK P7120 Manuel utilisateur
Fujitsu Siemens Computers
Fujitsu Siemens Computers AMILO Xi Series Fiche d'information produit
Fujitsu Siemens Computers
Fujitsu Siemens Computers AMILO Pi 3540 Manuel utilisateur
Fujitsu Siemens Computers
Fujitsu Siemens Computers V2020 Fiche d'information produit
Fujitsu Siemens Computers
Fujitsu Siemens Computers AMILO Pro V7010 Manuel utilisateur
Fujitsu Siemens Computers
Fujitsu Siemens Computers CELSIUS H250 Fiche d'information produit
Fujitsu Siemens Computers
Fujitsu Siemens Computers AMILO Manuel utilisateur
Fujitsu Siemens Computers
Fujitsu Siemens Computers LIFEBOOK E Series Fiche d'information produit
Fujitsu Siemens Computers
Fujitsu Siemens Computers AMILO Pro V3515 Manuel utilisateur
Fujitsu Siemens Computers
Fujitsu Siemens Computers AMILO Si 1520 Manuel utilisateur
Fujitsu Siemens Computers
Fujitsu Siemens Computers LIFEBOOK E8010 Manuel utilisateur
Fujitsu Siemens Computers
Fujitsu Siemens Computers AMILO Pro V8010 Manuel utilisateur
Fujitsu Siemens Computers
Fujitsu Siemens Computers AMILO M1425 Manuel utilisateur
Fujitsu Siemens Computers
Fujitsu Siemens Computers 4AMILO Pi 2540 Manuel utilisateur
