FujiFilm X-S10 Manuel utilisateur

New Features Guide

Version 3.00

Features added or changed as a result of rmware updates may no

longer match the descriptions in the documentation supplied with

this product. Visit our website for information on the updates avail-

able for dierent products:

https://fujifilm-x.com/support/download/firmware/cameras/

BL00005270-200 EN

Contents

X-S10 rmware version 3.00 adds or updates the features

listed below. For the latest manuals, visit the following

website.

https://fujifilm-dsc.com/en/manual/

No. Description X-S10

See

PVer.

Touch zoom is now available with compatible lenses. A

TOUCH ZOOM option has consequently been added to

DBUTTON/DIAL SETTING> TOUCH SCREEN SETTING

in the setup menu.

227

15 2.50

Added support for the optional XLR microphone adapt-

er, resulting in the addition of XLR MIC ADAPTER

SETTING options under BMOVIE SETTING >

AUDIO SETTING in the photo menus and under

PAUDIO SETTING in the movie menus. A 4ch

AUDIO PLAYBACK option has also been added under

DSOUND SET-UP in the setup menus.

153

176

212

2.30

The camera now supports instax mini Link and instax

Link WIDE smartphone printers, resulting in changes

to the instax PRINTER PRINT item in the playback

menu. In addition, the DCONNECTION SETTING>

instax PRINTER CONNECTION SETTING item in

the setup menu has been renamed instax PRINTER

SETTING and its content has been changed.

202

236

289

290

293

2.10

An bAREA SETTING option has been added under

USER SETTING in the setup menu, resulting in a change

to the basic setup procedure and adjustments to TIME

DIFFERENCE. In addition, DATE/TIME now oﬀers a 24-hour

clock.

207 10 3.00

55The items listed in the setup menu under

USER SETTING>

RESET have changed. 210 11 3.00

No. Description X-S10

See

PVer.

The

CONNECTION SETTING> Bluetooth SETTINGS

item in the setup menu has been renamed Bluetooth/

SMARTPHONE SETTING and now oﬀers an IMAGE

TRANSFER WHILE POWER OFF option. In addition, AUTO

IMAGE TRANSFER and SMARTPHONE SYNC. SETTING

have respectively been renamed AUTO IMAGE TRANSFER

ORDER and SMARTPHONE LOCATION SYNC.

234 18 3.00

Upload timing has changed. Pictures can now be uploaded not

only during playback or when the camera is oﬀ but also while

shooting is in progress.

234 18 3.00

CONNECTION SETTING> GENERAL SETTINGS has

been reorganized as follows:

•

LOCATION INFO has been moved to

SCREEN

SET-UP,

• rBUTTON SETTING has been moved to

BUTTON/DIAL SETTING and renamed aISO

BUTTON SETTING,

• GEOTAGGING has been moved to D

SAVE DATA

SET-UP, and

• NAME and RESIZE IMAGE FOR SMARTPHONE

Hhave been moved to Bluetooth/

SMARTPHONE SETTING.

220

226

233

234

3.00

99The procedure for connecting wirelessly to smartphones has

changed. 278 30 3.00

1010

Digital zoom lenses equipped with lens function buttons

are now supported. A POWER ZOOM LENS FUNCTION

(Fn) SETTING option has consequently been added to

DBUTTON/DIAL SETTING in the setup menu. In addition,

the roles that can be assigned to the function buttons have

changed.

223

252

256

263

2.50

1111

A LENS ZOOM/FOCUS SETTING item has been added to

DBUTTON/DIAL SETTING in the setup menu to control

the behavior of digital zoom lenses equipped with lens func-

tion buttons.

225 13 2.50

No. Description X-S10

See

PVer.

1212

FOCUS RING has consequently been renamed FOCUS RING

ROTATE and has, together with FOCUS RING OPERATION,

been moved to LENS ZOOM/FOCUS SETTING.

225 13 2.50

1313 A LOCK item has been added to DBUTTON/DIAL

SETTING in the setup menu. 228 17 2.00

1414

A Bluetooth DEVICE LIST item has been added to

CONNECTION SETTING > Bluetooth SETTINGS in

the setup menu.

234 18 2.60

1515

A NETWORK SETTING item has been added to

DCONNECTION SETTING in the setup menu, al-

lowing wireless LAN settings to be adjusted for use with

wireless tethered shooting.

235 20 2.00

1616

The DCONNECTION SETTING > INFORMATION

item in the setup menu now shows the IP address in

addition to the MAC and Bluetooth addresses.

239 20 2.00

1717

The DCONNECTION SETTING > CONNECTION

MODE item has been modiﬁed to support not only

photo upload, RAW conversion, and the upload and

download of camera settings, but also such features as

tethered still photography and movie recording.

237 21 2.00

1818 The TG-BT1 tripod grip has been added to the optional

accessory list. 292 34 2.60

Changes and Additions

Changes and additions are as follows.

X-S10 Owner’s Manual: P24 Ver. 2.50

Shooting Touch Controls

Touch Zoom

If the lens supports touch zoom, you can

zoom in and out by touching the display.

Tap the touch zoom button in the display

to enable touch zoom.

Touch zoom is controlled using the but-

tons in the display.

ButtonButton DescriptionDescription

Touch zoomTouch zoom Enable touch zoom.

Zoom inZoom in Zoom in or out.Touch and hold to zoom in or out at a constant

speed.

Zoom outZoom out

Rocker switchRocker switch Swipe to choose a zoom position. Touch and hold to zoom in

or out at a speed corresponding where you put your ﬁnger.

DisableDisable Disable touch zoom.

X-S10 Owner’s Manual: P50 Ver. 2.30

Recording Movies

Using an External Microphone

Sound can be recorded with external micro-

phones that connect using jacks 3.5mm in di-

ameter; microphones that require plug-in pow-

er cannot be used. See the microphone manual

for details.

XLR Microphone Adapters

The camera can be used with TEAC TASCAM CA-XLR2d-F XLR microphone

adapters. For more information, visit the TASCAM website.

https://tascam.jp/int/product/ca-xlr2d/#CA-XLR2d_Website

X-S10 Owner’s Manual: P153, 176 Ver. 2.30

XLR MIC ADAPTER SETTING

Adjust microphone input channel settings and the like for use

with XLR microphone adapters.

OptionOption DescriptionDescription

MIC INPUT CHANNEL

Record four-channel (quadraphonic) sound with the

help of the camera’s built-in microphone, or two-channel

(stereo) sound using only a microphone connected via the

XLR microphone adapter.

• 4ch XLR+CAMERA: Record four-channel sound with

the help of the camera’s built-in microphone.

•

2ch XLR ONLY: Record two-channel sound using

only an external microphone connected via the XLR

microphone adapter.

4ch AUDIO MONITORING

Choose the source of sound output to headphones or

other audio monitors during movie recording.

• XLR: Monitor sound from external microphones con-

nected via the XLR microphone adapter.

•

CAMERA: Monitor sound from camera’s built-in mi-

crophone.

HDMI 4ch AUDIO

OUTPUT

Choose source of audio output to the HDMI connector.

• XLR: Audio from external microphones connected via

the XLR microphone adapter is output to the HDMI con-

nector.

•

CAMERA: Audio from camera’s built-in microphone is

output to the HDMI connector.

• If an external microphone is connected to the camera’s microphone

jack, audio will be recorded not via the camera’s built-in microphone

but via the external microphone instead.

• Four-channel recording is available only when MOV/H.264 LPCM is

selected for BMOVIE SETTING> FILE FORMAT.

X-S10 Owner’s Manual: P212 Ver. 2.30

4ch AUDIO PLAYBACK

Adjust audio settings for use when viewing 4ch movies.

OptionOption DescriptionDescription

XLR

The camera plays audio recorded via external micro-

phones connected via the XLR microphone adapter.

CAMERA

The camera plays audio recorded via the camera’s built-in

microphone or external microphones connected via the

microphone jack.

X-S10 Owner’s Manual: P202, 290 Ver. 2.10

instax PRINTER PRINT

Printing Pictures

Pictures can be printed using optional printers in the instax

Link and instax SHARE series. The printer must rst paired with

the camera using DCONNECTION SETTING > instax PRINTER

SETTING.

instax Link Series Printers

1 Turn the printer on.

2 Select instax PRINTER PRINT in

the playback menu, then highlight

instax Bluetooth CONNECTION and

press MENU/OK.

PRINTER PRINT

Wi-Fi CONNECTION

Bluetooth CONNECTION

EXIT

3 The camera will connect to the printer.

FUJIFILM-CAMERA-1234

CONNECTING

CANCEL

PRINTER PRINT

instax-12345678

4 Use the focus stick (focus lever) to

display the picture you want to print,

then press MENU/OK.

100-0020

SET CANCEL

instax-12345678

PRINTER PRINT

• Pictures taken with other cameras cannot be printed.

•

Pictures are cropped and printed at a size selected automatical-

ly by the printer, and consequently not all the picture appears

in the printed copy.

•

When using instax WIDE lm, you can choose the crop be-

fore printing pictures shot with an option other than O3:2,

P3:2, or Q3:2 selected for HIMAGE QUALITY SETTING>

IMAGE SIZE.

•

The displays may vary depending on the printer connected.

5 The picture will be sent to the printer and printing will start.

The camera cannot connect to a smartphone while connected to a

printer.

instax Image Quality Mode

In addition to the existing “instax-Natural Mode”, the instax IMAGE

QUALITY MODE item in the instax PRINTER SETTING menu oers an

“instax-Rich Mode” featuring vibrant colors for use with instax Link WIDE

printers.

These options are also available when the camera is connected to

the printer.
