FujiFilm X-PRO2 Manuel utilisateur

DIGITAL CAMERA

X-Pro2

New Features Guide

Version 5.00

Features added or changed as a result of rmware updates may no longer match the

descriptions in the documentation supplied with this product. Visit our website for

information on the updates available for dierent products:

http://www.fujifilm.com/support/digital_cameras/software/fw_table.html

BL00004986-200

ENGLISH

Contents

X-Pro2 rmware version 5.00 adds or updates the features listed below. For the latest manual, visit the following

website.

http://fujifilm-dsc.com/en/manual/

No.

Description

X-Pro2

See

Ver.

To view separate RGB histograms and a display showing areas of the frame that will be overexposed

at current settings superimposed on the view through the lens, press the function button to which

HISTOGRAM is assigned.

EN-1

4.00

2During movie recording, you can press the shutter button halfway to refocus using autofocus.

EN-1

4.00

3The focus stick can be used to change focus areas when the display is zoomed in during checking

focus.

EN-2

4A FLICKER REDUCTION option has been added to ASHOOTING SETTING in the shooting menu.

EN-3

5.00

5Changes have been made to the contents of the BMOVIE SETTING> MOVIE MODE item in the

shooting menu.

104

EN-4

4.00

6LARGE INDICATORS MODE(EVF/OVF) and LARGE INDICATORS MODE(LCD) options have been

added to DSCREEN SETTING in the setup menu.

118

EN-5

EN-6

5.00

7A LARGE INDICATORS DISP. SETTING option has been added to DSCREEN SETTING in the setup

menu.

118

EN-7

5.00

8A SELECT FOLDER option has been added to DSAVE DATA SETTING in the setup menu.

123

EN-8

5.00

9ACCESS POINT SETTINGS and IP ADDRESS options have been added to DCONNECTION

SETTING> WIRELESS SETTINGS in the setup menu.

124

EN-9

4.00

10 A DCONNECTION SETTING> PC CONNECTION MODE item has been added to the setup menu.

124

EN-10

4.00

11 In addition to the instax SHARE printers listed in “Accessories from FUJIFILM”, the camera now sup-

ports the SP-3.

141

EN-11

4.00

12 Third-party studio ash commanders compatible with the FUJIFILM ash system can now be used.

143

EN-11

4.00

RThe asterisks in the “Ver.” column indicate features available in earlier versions; only the descriptions in the

manual have been changed.

EN-1ENGLISH

Changes and Additions

The DISP/BACK Button

X-Pro2 (Version 3.10) Owner’s Manual: P34 Ver. 4.00

Histograms

Histograms show the distribution of tones in the image.

Brightness is shown by the horizontal axis, the number

of pixels by the vertical axis.

Shadows Highlights

No. of pixels

Pixel brightness

Optimal exposure: Pixels are distrib-

uted in an even curve throughout

the tone range.

Overexposed: Pixels are clustered

on the right side of the graph.

Underexposed: Pixels are clustered

on the left side of the graph.

To view separate RGB histograms

and a display showing areas of

the frame that will be overex-

posed at current settings super-

imposed on the view through the

lens, press the function button to

which HISTOGRAM is assigned.

AOverexposed areas blink

BRGB histograms

Recording Movies

X-Pro2 (Version 3.10) Owner’s Manual: P44 Ver. 4.00

RZoom can be adjusted while recording is in progress.

RFrame size and rate can be selected using WMOVIE

SETTING> MOVIE MODE. Focus mode is selected

using the focus mode selector; for continuous focus

adjustment, select C, or choose Sand enable Intel-

ligent Face Detection. Intelligent Face Detection is

not available in focus mode M.

RDuring movie recording, you can press the shutter

button halfway to refocus using autofocus.

RDuring recording, exposure compensation can be

adjusted by up to ±2EV.

RThe indicator lamp lights while movies are being

recorded.

EN-2 ENGLISH

Changes and Additions

Focus Mode

X-Pro2 (Version 3.10) Owner’s Manual: P65 *

Checking Focus

To zoom in on the current focus area for precise focus, press the

center of the rear command dial. Press the center of the rear com-

mand dial again to cancel zoom. In manual focus mode, zoom can

be adjusted by rotating the rear command dial when STANDARD

or FOCUS PEAK HIGHLIGHT is selected for GAF/MF SETTING>

MF ASSIST, while if ON is selected for GAF/MF SETTING> FOCUS

CHECK, the camera will automatically zoom in on the selected focus area when the focus ring is rotated. Focus

area selection using the focus stick is available during focus zoom. Focus zoom is not available in focus mode

Cor when GAF/MF SETTING> PRE-AF is on or an option other than rSINGLE POINT is selected for AF

MODE.

M M

EN-3ENGLISH

Changes and Additions

SHOOTING SETTING

X-Pro2 (Version 3.10) Owner’s Manual: P99 Ver. 5.00

FLICKER REDUCTION

Select ON to reduce icker in pictures and the display when shooting under uorescent lighting and other similar light sources.

QEnabling icker reduction disables the electronic shutter and increases the time needed to record pictures.

Options: ON/OFF

EN-4 ENGLISH

Changes and Additions

MOVIE SETTING

X-Pro2 (Version 3.10) Owner’s Manual: P104 Ver. 4.00

MOVIE MODE

Select a frame size and rate for movie recording.

• U2160/29.97 P: 3840 × 2160 (29.97 fps)

• U2160/25 P: 3840 × 2160 (25 fps)

• U2160/24 P: 3840 × 2160 (24 fps)

• U2160/23.98 P: 3840 × 2160 (23.98 fps)

• i1080/59.94 P: 1920 × 1080 (59.94 fps)

• i1080/50 P: 1920 × 1080 (50 fps)

• i1080/29.97 P: 1920 × 1080 (29.97 fps)

• i1080/25 P: 1920 × 1080 (25 fps)

• i1080/23.98 P: 1920 × 1080 (23.98 fps)

• h720/59.94 P: 1280 × 720 (59.94 fps)

• h720/50 P: 1280 × 720 (50 fps)

• h720/29.97 P: 1280 × 720 (29.97 fps)

• h720/25 P: 1280 × 720 (25 fps)

• h720/23.98 P: 1280 × 720 (23.98 fps)

EN-5ENGLISH

Changes and Additions

SCREEN SETTING

X-Pro2 (Version 3.10) Owner’s Manual: P118 Ver. 5.00

LARGE INDICATORS MODE(EVF/OVF)

Select ON to display large indicators in the electronic/optical viewnder (EVF/OVF). The indicators displayed can be selected

using DSCREEN SETTING > LARGE INDICATORS DISP. SETTING.

OFF ON

QSome icons are not displayed when ON is selected for LARGE INDICATORS MODE(EVF/OVF), including:

• Focus indicator • AF+MF indicator • Microphone/remote release

• Distance indicator • Focus mode • Others

RIf LARGE INDICATORS MODE is assigned to a function button, the button can be used to toggle LARGE INDICATORS

MODE on (ON) and o (OFF) (P51, 119).

EN-6 ENGLISH

Changes and Additions

SCREEN SETTING

X-Pro2 (Version 3.10) Owner’s Manual: P118 Ver. 5.00

LARGE INDICATORS MODE(LCD)

Select ON to display large indicators in the LCD monitor. The indicators displayed can be selected using DSCREEN SETTING >

LARGE INDICATORS DISP. SETTING.

OFF ON

QSome icons are not displayed when ON is selected for LARGE INDICATORS MODE(LCD), including:

• Focus indicator • AF+MF indicator • Microphone/remote release

• Distance indicator • Focus mode • Others

RIf LARGE INDICATORS MODE is assigned to a function button, the button can be used to toggle LARGE INDICATORS

MODE on (ON) and o (OFF) (P51, 119).

EN-7ENGLISH

Changes and Additions

SCREEN SETTING

X-Pro2 (Version 3.10) Owner’s Manual: P118 Ver. 5.00

LARGE INDICATORS DISP. SETTING

Choose the indicators displayed when ON is selected for

SCREEN SETTING > LARGE INDICATORS

MODE(EVF/OVF) or LARGE INDICATORS MODE(LCD).

Scale

Expo. DISP.

LARGE INDICATORS DISP. SETTING

Option

Description

Expo. DISP.

Expo. DISP. Choose the items listed at the bottom of the display. Selected items are indicated by check marks

(R); to deselect, highlight the check marks and press MENU/OK.

Scale

Scale Select ON to display the exposure indicator.

L1, L2, L3, L4

L1, L2, L3, L4 Choose up to four large icons for display on the left side of the screen.

R1, R2, R3, R4

R1, R2, R3, R4 Choose up to four large icons for display on the right side of the screen.

EN-8 ENGLISH

Changes and Additions

SAVE DATA SETTING

X-Pro2 (Version 3.10) Owner’s Manual: P123 Ver. 5.00

SELECT FOLDER

Create folders and choose the folder used to store subsequent pictures.

Option

Description

SELECT FOLDER

SELECT FOLDER To choose the folder in which subsequent pictures will be stored, press the selector up or down to

highlight an existing folder and press MENU/OK.

CREATE FOLDER

CREATE FOLDER Enter a ve-character folder name to create a new folder in which to store subsequent pictures.
