FujiFilm FinePix S5200 Manuel utilisateur

Gold

contact

area

Gold marking

S5200/

S5600

FPT-507107-PW

BL00485-200(1) E

A. Loading the batteries

1. Check that the camera is

turned off (set the Power

switch to “OFF”) before

opening the battery cover.

2. Load the batteries correctly

as indicated by the polarity

icons.

Press on the battery cover to

push the batteries down.

Slide the battery cover closed.

1. Align the gold marking on the

xD-Picture Card slot with the

gold contact area on the xD-

Picture Card™and push the

card firmly all the way into

the slot.

Close the slot cover.

B. Setting up the camera

2. To turn the camera on, set

the Power switch to “q” or

“w”.

Press the “MENU/OK” button

to set the date and time.

D. Viewing picture

1. Set the Power switch to “w”.

2. Press “d” or “c” to move

through your images.

Camera Controls

Picture Taking

Refer to Owner’s Manual for more detailed instructions

Still images that can be viewed on the FinePix S5200/FinePix S5600

You can use this camera to view still images recorded on the FinePix

S5200 / FinePix S5600 or still images (excluding some

uncompressed images) recorded on a FUJIFILM digital camera that

supports xD-Picture Card.

Exposure

compensation

button

Focus mode

selector button

Continuous

shooting

button

Shutter button

Focus mode

selector lock

switch

Mode dial

Still photography

Movie recording

Power switch

Playback mode

Power-OFF

Photography mode

Auto Programmed Auto

Manual

Anti-blur

Aperture-priority Auto

Shutter-priority Auto

Movie

Natural light

Night

Portrait

Landscape

Strap mount

Slot cover

USB socket (mini-B)

DC IN 5V (power input)

socket

A/V OUT (Audio /

Visual output) socket

Microphone

Flash

AF-assist

illuminator

Self-timer lamp

Speaker xD-Picture Card slot

Lens

W(Wide zoom) button

Photo mode ( ) button

DISP/BACK button

Low light view

button

Battery cover

MENU/OK button

4-direction (abd c) button

T(Tele zoom) button

Strap mount

Viewfinder (EVF)

Diopter adjustment dial

EVF/LCD

(monitor selector) button

Tr ipod mount

LCD monitor

Indicator lamp

d/ Macro button

c/ Flash button

Playback modePhotography mode

a/ Erase button

33. You can select your preferred

date format.

Press “d” or “c” to select the

date format, Year, Month,

Day, Hour or Minute.

Press “a” or “b” to correct the

setting.

Press the “MENU/OK” button

after you complete the setting.

✽Refer to owner’s manual for

date/time setup.

C. Taking pictures

1. Set the Power switch to “q”

and set the Mode dial to

“B”.

2. Press the shutter button down

halfway to adjust the focus.

3. Press the shutter button down

fully to take a picture. The

camera makes a “Click” sound

and takes the picture.

2007

2006

2005

2004

2003

11 2100

A M

YY.MM.DDYY.MM.DD

SETS E T CANCELC A N C E L

DATE/TIMED AT E / T I M E

Bebeep Click

2 3

1 2

Viewing images on your PC

FinePixViewer starts up automatically.

The “Found New Hardware” help message appears in the

bottom-right corner of your screen. This message will close

when the settings are completed. No action is required.

FinePixViewer starts up automatically.

Windows XP

Windows 98/98 SE/Me/2000 Professional

For more information

Refer to “How to use FinePixViewer” in the HELP menu, or chapter 5

and 6 in the Owner’s Manual, or visit Fujifilm “Q&A Search” in the

following website.

(http://home.fujifilm.com/products/digital/ )

For Macintosh users, refer to chapter 5 and 6 in the Owner’s Manual.

3. Turn your camera off.

4. If you have one, plug the AC power adapter connector into

the “DC IN 5V” socket on the camera and then plug the

adapter itself into the main power outlet, otherwise be sure

your batteries are fresh and charged.

5. Turn your PC on.

6. Connect the camera to the PC using the USB cable (mini-B).

7. Set the Power switch to “w”.

A. Install Software

Do not connect the camera to your PC until the software

installation is completed.

1. Turn on your PC and start up Windows.

●

Users of Windows 2000 Professional or Windows XP should log in

by using a system administrator account (e.g. “Administrator”).

2. Quit all other active applications until no applications are

shown in the taskbar.

3. Load the enclosed CD-ROM into the CD-ROM drive. The

installer starts up automatically.

4. The Setup screen appears.

Click the [Installing

FinePixViewer] button.

5. After installation completed, press [Close] button.

B. Connect the Camera to your PC

1. Load an xD-Picture Card containing photographed images

into your camera.

2. Set the Power switch to “w” to turn the camera on.

Select “¶” DSC in “ò” USB MODE in the “˜” SET-UP

menu (Refer to “USING THE SET-UP SCREEN” in the

owner’s manual).

DSCD S C

NTSCN T S CN T S CNTSC

SETSET

ENGLISHE N G L I S H

C. Save Images

1. The Save Image Wizard starts up. Click the [Start]button.

2. Check that the files are downloaded from the camera to your

PC and that a folder with the date is created.

Ex. \My Documents \ My Pictures \ 2005_0824

D. View Images

1. Click the [Show List of Images]

button.

Select “Preview” in the View menu to display an enlarged image.

A.Install Software

B.Connect a Camera to PC

C.Save Images

USB socket

Camera PC
