Refrigerator

use &care

Introduction.......................................................2

Important Safety Information ....................3

Features..............................................................6

Installation .........................................................7

Door Removal...................................................9

Door Handle Installation............................. 13

Water Supply Connection..........................14

Controls and Settings.................................. 16

Automatic Ice and Water Dispenser...... 19

Storage Features........................................... 21

Storing Food and Saving Energy........... 25

Normal Operating Sounds........................ 26

Filter Replacement ...................................... 27

Care and Cleaning .......................................30

Troubleshooting............................................ 32

Limited Warranty ......................................... 37

A26330701 (November 2022)

INTRODUCTION

Doors

Handles are secure and tight

Door seals completely to cabinet on

all sides

Leveling

Refrigerator is level side-to-side and

slightly elevated in front to assist

with door and drawer closing (front

should be higher than back)

Cabinet is setting solid on all corners

Electrical Power

House power turned on

Refrigerator plugged in

Ice Maker

House water supply connected to

refrigerator (Warning: Potable

water supply only)

No water leaks present at all

connections - recheck in 24 hours

Ice maker is turned ON

Ice & water dispenser

operates correctly

Final Checks

Shipping material removed

Fresh food and freezer

temperatures set

Registration card sent in

Installation Checklist



Welcome to our family

Thank you for bringing Frigidaire into

your home! We see your purchase as the

beginning of a long relationship together.

This manual is your resource for the use

and care of your product. Please read

it before using your appliance. Keep it

handy for quick reference. If something

doesn’t seem right, the troubleshooting

section will help you with common issues.

FAQs, helpful tips and videos, cleaning

products, and kitchen and home accessories

are available at Frigidaire.com.

We are here for you! Visit our website,

chat with an agent, or call us if you need

help. We may be able to help you avoid

a service visit. If you do need service, we

can get that started for you.

Let’s make it ocial! Be sure to register

your product.

Keep your product info here so it’s easy

to ﬁnd.

Model Number

Serial Number

Purchase Date

jfdka; jfdk;a jfdk; jfdk;a j;da

Serial Number Location

WARNING

WARNING indicates a potentially

hazardous situation which, if not avoided,

could result in death or serious injury.

IMPORTANT

IMPORTANT indicates installation, oper-

ation or maintenance information which

is important but not hazard-related.

DANGER

DANGER indicates an imminently

hazardous situation which, if not avoided,

will result in death or serious injury.

CAUTION

CAUTION indicates a potentially

hazardous situation which, if not

avoided, may result in minor or

moderate injury.

Safety Deﬁnitions

This is the safety alert symbol. It is

used to alert of potential personal injury

hazards. Obey all safety messages that

follow this symbol to avoid possible injury

or death.

WARNING

CALIFORNIA RESIDENTS ONLY

Cancer and Reproductive Harm

www.P65Warnings.ca.gov

IMPORTANT SAFETY INFORMATION

WARNING

Please read all instructions before using

this refrigerator.

DANGER

DANGER Risk of ﬁre or explosion.

Flammable refrigerant used. Do not use

mechanical devices to defrost refrigera-

tor. Do not puncture refrigerant tubing.

DANGER Risk of ﬁre or explosion.

Flammable refrigerant used. To be

repaired only by trained service person-

nel. Use only manufacturer-authorized

service parts. Any repair equipment

used must be designed for ﬂammable

refrigerants. Follow all manufacturer

repair instructions. Do not puncture

refrigerant tubing.

CAUTION

CAUTION Risk of ﬁre or explosion.

Dispose of refrigerator properly

in accordance with the applicable

federal or local regulations. Flammable

refrigerant used.

CAUTION Risk of ﬁre or explosion

due to puncture of refrigerant tubing.

Follow handling instructions carefully.

Flammable refrigerant used.

WARNING

Do not use electrical appliances inside

the food storage compartments of the

appliance unless they are of the type

recommended by the manufacturer.

4IMPORTANT SAFETY INFORMATION

Safety Instructions

• DO NOT store or use gasoline, or

other ﬂammable liquids in the vicinity

of this or any other appliance. Read

product labels for warnings regard-

ing ﬂammability and other hazards.

• DO NOT operate the refrigerator in

the presence of explosive fumes.

• Avoid contact with any moving parts

of automatic ice maker.

• Remove all staples from the carton.

Staples can cause severe cuts, and

also destroy ﬁnishes if they come in

contact with other appliances

or furniture.

IMPORTANT

CFC/HCFC Disposal

Some old refrigerators may have a cool-

ing system that used CFCs or HCFCs

(chloroﬂuorocarbons or hydrochloro-

ﬂuorocarbons). CFCs and HCFCs are

believed to harm stratospheric ozone if

released to the atmosphere. Other re-

frigerants may also cause harm to the en-

vironment if released to the atmosphere.

If disposing of an old refrigerator, make

sure the refrigerant is removed for proper

disposal by a qualiﬁed technician. Inten-

tionally released refrigerant may subject

one to ﬁnes and imprisonment under

provisions of environmental legislation.

Before disposing of an old refrigerator/

freezer:

• Remove doors.

• Leave shelves in place so children

may not easily climb inside.

• Have refrigerant removed by a

qualiﬁed service technician.

Child Safety

Destroy or recycle the carton, plastic

bags, and any exterior wrapping material

immediately after the refrigerator is

unpacked. Children should NEVER use

these items to play. Cartons covered with

rugs, bedspreads, plastic sheets or stretch

wrap may become airtight chambers, and

can quickly cause suocation.

Proper Disposal of Refrigerator

or Freezer

Risk of child entrapment

Child entrapment and suocation are not

problems of the past. Junked or aban-

doned refrigerators or freezers are still

dangerous – even if they will sit for “just

a few days”. When disposing of an old

refrigerator or freezer, please follow the in-

structions below to help prevent accidents.

Proper Disposal of Refrigerators/Freezers

We strongly encourage responsible appli-

ance recycling/disposal methods. Check

with the utility company or visit energy-

star.gov/recycle for more information on

recycling an old refrigerator.

IMPORTANT SAFETY INFORMATION

Grounding type wall receptacle

Power cord with

3-prong grounded plug

Do not, under

any circumstances,

cut, remove,

or bypass the

grounding prong.

Electrical information

• The refrigerator must be plugged

into its own dedicated 115 Volt, 60

Hz., 15 Amp, AC only electrical outlet.

The power cord of the appliance

is equipped with a three-prong

grounding plug for protection against

electrical shock hazards. It must

be plugged directly into a properly

grounded three prong receptacle.

The receptacle must be installed in

accordance with local codes and

ordinances. Consult a qualiﬁed

electrician. Avoid connecting

refrigerator to a Ground Fault

Interrupter (GFI) circuit. Do not use

an extension cord or adapter plug.

• If the power cord is damaged, it

should be replaced by an authorized

service technician to prevent any risk.

• Never unplug the refrigerator by

pulling on the power cord. Always

grip the plug ﬁrmly, and pull straight

out from the receptacle to prevent

damaging the power cord.

• Unplug the refrigerator before

cleaning and before replacing a light

bulb to avoid electrical shock.

• Performance may be aected if

the voltage varies by 10% or more.

Operating the refrigerator with

insucient power can damage the

compressor. Such damage is not

covered under the warranty.

• Do not plug the unit into an electrical

outlet controlled by a wall switch or

pull cord to prevent the refrigerator

from being turned o accidentally.

NOTE

This unit is equipped with a cooling

system where one of the Refrigerator/

Freezer sections may cool slower than

the other initially. Allow 24 hours for

unit to stabilize and reach the desired

temperatures.

IMPORTANT

Accessories are available for refrigerator and can be purchased at Frigidaire.com or

by calling 1-800-374-4432.

6FEATURES

A Anti-tip Leg

B Lower Freezer Basket

C Upper Freezer Drawer

D Ice Bin

E Ice Maker

F Custom-Flex™ Temp Drawer

G Adjustable Hinges

H Door Bin*

I Side Water Dispenser

J Appliance Display Control

K Flipper Mullion

L Flipper Guide

M Air Filter

NWater Filter

O Dairy Compartment*

P Shelf

Q Adjustable Door Bin

R CrispSeal™ Fresh Crispers

S Gallon Door Bins

INSTALLATION

Tools Necessary:

Phillips Head

Quadrex Head

Screwdriver

(OR) OR

8mm Socket

Wrench

Adjustable

Wrench

⅜"

Fixed

Wrench

ANDAND

6mm

Allen Wrench

CAUTION

Do Not install the refrigerator where

the temperature will drop below 55°F

(13°C) or rise above 110°F (43°C).

The compressor will not be able to

maintain proper temperatures inside

the refrigerator.

WARNING

Installation

Allow the following clearances for ease

of installation, proper air circulation, and

plumbing and electrical connections:

Sides & Top ⅜" (9.5 mm)

Back 1" (25.4 mm)

This Use & Care Manual provides general

installation and operating instructions for

this model. We recommend using a service

or kitchen contracting professional to

install the refrigerator. Use the refrigerator

only as instructed in this Use & Care

Manual. Before starting the refrigerator,

follow these important ﬁrst steps.

Location

• Choose a place near a grounded, non-

GFCI, electrical outlet. Do Not use an

extension cord or an adapter plug.

• If possible, place the refrigerator out of

direct sunlight and away from a range,

dishwasher, or other heat sources.

• Install the refrigerator on a ﬂoor that

is level and strong enough to support

a fully loaded refrigerator.

• Consider water supply availability for

models equipped with an automatic

ice maker.

Door opening

Position the refrigerator to allow easy

access to a counter when removing food.

For best use of refrigerator drawers and

freezer baskets, position the refrigerator

where both can be fully opened.

NOTE

If you place the refrigerator with the

door hinge side against a wall, allow

additional space so you can open the

door wider.

WARNING

This appliance is intended for use

in residential household and similar

interior applications such as:

• a kitchen/kitchenette

• a pantry room

• a basement

• an enclosed garage

• other interior

residential-type environments

12.25 in

8.75 in

1 in

56.75 in

25.4 mm

.37 in

9.5 mm

.37 in

9.5 mm

8INSTALLATION

Cabinet Leveling & Refrigerator

Door Alignment (if necessary)

Guidelines for ﬁnal positioning of refrigerator:

• All four corners of the cabinet must

rest ﬁrmly on the ﬂoor.

• The front should be slightly elevated

to ensure the doors close and

seal properly.

• Doors should align with each other

and be level.

Most of these conditions can be met by raising

or lowering the adjustable anti-tip legs.

To level the cabinet using the anti-tip legs:

1. Slightly open freezer drawer.

2. Lower the anti-tip legs until they are

both touching the ﬂoor. Use a pair of

pliers to adjust.

To raise unit: turn leg clockwise

(as shown below).

To lower unit: turn leg counterclockwise.

Raise

Flipper Mullion

Adjust the ﬂipper mullion for proper

connection with the mullion guide by

ensuring the ﬂipper mullion is folded and

perpendicular to the fresh food door. If

the mullion

guide is not

in the correct

position, it

could prevent

the door

from closing

completely.

WRONG

Anti-Tip

Legs

3. Ensure both doors are bind-free with

their seals touching the cabinet on all

4 sides and the cabinet is stable.

Door

To make ﬁnal door height adjustments:

1. Open the Custom-Flex Temp drawer

to make the lower hinge visible.

2. Insert a 6 mm AllenTM wrench into

the shaft of the lower hinge.

To lower door: turn the adjustment

screw clockwise.

To raise door: turn the adjustment

screw counterclockwise

(as shown below).

CAUTION

Be sure doors are set aside in a secure

position where they cannot fall and

cause personal injury, or damage to the

doors or handles.

DOOR REMOVAL

Getting through narrow spaces

If the refrigerator will not ﬁt through an

entrance area, you can remove the doors.

Check ﬁrst by measuring the entrance.

To prepare for removing the doors:

1. Make sure the electrical power cord

is unplugged from the wall outlet.

2. Remove any food from the door

shelves and close the doors.

To remove the refrigerator doors:

1. Open doors to 90°.

2. Remove all 5 PhillipsTM screws from

top hinge cover and lift up.

5. Pull up on the water line gently to

remove it from the door.

3. Trace lightly around the door’s top

hinges with a pencil. This makes

reinstallation easier.

4. Disconnect electrical harness

running from door to hinge cover. 6. Remove three 8 mm bolts from both

top hinges. Lift the doors up o the

lower hinges and carefully set aside.

NOTE

Use care while pulling the water tube

from the door to be sure the tube does

not kink. To prevent damaging the water

line, install the water line in a protective

spring after reinstalling the doors.

NOTE

You will pull approximately 4' of water

tube from the refrigerator door.

10 DOOR REMOVAL

Lower Hinge Removal

Once both doors are in place, ensure they

are aligned with each other and level

(Reference INSTALLATION for more de-

tails), and replace the top hinge cover.

8. To reinstall the doors, reverse

the procedure.

7. You may need to remove the lower

hinges for clearance purposes. To gain

access to the lower hinge, ﬁrst extend

the Custom Flex Temp Drawer. Unscrew

the 3 lower hinge screws and slide the

hinge inward.

To remove the Custom-Flex

Temp Drawer

1. Fully open the drawer.

2. Remove the basket from the drawer.

3. Unsnap the 4 cable ties by pressing

clip sides together and pushing

them through the opening.

NOTE

When reinserting the water tube and

replacing the top hinge cover, carefully

ensure the tube does not kink.

IMPORTANT

Make sure the water line tubing goes

through the hole at the top of the

dispenser pocket. There is also a metal

wrap on the tubing to prevent damage

from the hinge rubbing against it. This

needs to be ﬁxed back around the tube

in the proper location upon reinstallation

(just as long as the tube is protected

from the hinge).

Table des matières

Autres manuels Frigidaire Réfrigérateur

Frigidaire

Frigidaire FGHS2334KE - Gallery 23 Cu. Ft. Side Manuel utilisateur

Frigidaire

Frigidaire FRS6B5EE Mode d’emploi

Frigidaire

Frigidaire FRT18IQGJ Manuel utilisateur

Frigidaire

Frigidaire FGHS2399K Mode d’emploi

Frigidaire

Frigidaire FRS26HF5A Manuel utilisateur

Frigidaire

Frigidaire FRT18PCG Manuel utilisateur

Frigidaire

Frigidaire FRT18IG4A Manuel utilisateur

Frigidaire

Frigidaire GLRT184TC Manuel utilisateur

Frigidaire

Frigidaire EFMIS351 Manuel utilisateur

Frigidaire

Frigidaire FGHT2144KF - 21 CF Lery SS Group Manuel utilisateur

Frigidaire

Frigidaire FGHS2655PF0 Manuel utilisateur

Frigidaire

Frigidaire LGHB2869LF3 Manuel du propriétaire

Frigidaire

Frigidaire FRT17G5CSK5 Manuel utilisateur

Frigidaire

Frigidaire Compact Refrigerator Manuel utilisateur

Frigidaire

Frigidaire FRS6LR5E Manuel utilisateur

Frigidaire

Frigidaire FRT18LN5B Manuel utilisateur

Frigidaire

Frigidaire Single Door Refrigerator 297005500 Manuel utilisateur

Frigidaire

Frigidaire FRS3R3E Manuel utilisateur

Frigidaire

Frigidaire FRS26RBC Manuel utilisateur

Frigidaire

Frigidaire FGTC2349KS - Gallery 22.6 Cu. Ft.... Instructions d'installation

Frigidaire

Frigidaire FRS26KF6E Manuel utilisateur

Frigidaire

Frigidaire FRT18P5A Manuel utilisateur

Frigidaire

Frigidaire FGHB2844LF2 Manuel du propriétaire

Frigidaire

Frigidaire FRT21HC5D Manuel utilisateur

Manuels Réfrigérateur populaires d'autres marques

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manuel utilisateur

Sharp

Sharp SJ-BA31IEXW2-EU Manuel utilisateur

CORBERO

CORBERO CC2300MCW Manuel utilisateur

KitchenAid

KitchenAid 2205264 Manuel utilisateur

Stengel

Stengel KU 1101 A++ Manuel utilisateur

NEFF

NEFF KI181 Series Manuel utilisateur

Hoshizaki

Hoshizaki Reach-In Manuel utilisateur

Amana

Amana ASD2524VES00 Manuel utilisateur

BOMANN

BOMANN KGC 213 Manuel utilisateur

Danby

Danby DAR044A1SLDD Instructions de montage

Samsung

Samsung RF323TE Manuel utilisateur

Beko

Beko CSA31022 Manuel utilisateur

IKEA

IKEA FROSTIG C 185 E Manuel utilisateur

Electrolux

Electrolux ER 6821 D Manuel utilisateur

True

True TS-28 Manuel utilisateur

Beko

Beko LSP4579W Manuel utilisateur

Teledyne

Teledyne 6712FR and Mode d'emploi
