Frigidaire FRT21P5A Manuel utilisateur

Product No. FRT21P5ABI FRT21P5AQI FRT21P5AWI

Series R134a R134a R134a

Color black bisque white

Volts 115 115 115

Wiring Diagram 240398801 240398801 240398801

Owner's Guide 240400112 240400112 240400112

Market North America North America North America

Energy Guide 218791400 218791400 218791400

Service Data Sheet 240379014 240379014 240379014

Installation Instructions 240568300 240568300 240568300

N05L00006.eps N05DAACKA1.eps N05BBAABD4.eps N05SAAAEE13.eps

N05CABBAB6.eps 240398801.eps 240398601.eps

ELECTROLUX HOME PRODUCTS, INC.

P.O. Box 212378

Augusta, GA 30917

Publication No.

5995429478

05/02/18

(EN/SERVICE/WC)

390

TOP-MOUNT

REFRIGERATOR

Model No.

FRT21P5A

Publication No: 5995429478 FRT21P5A

02/05 2

DOOR

13A

21C

N05DAACKA1

FRT21P5A Publication No: 5995429478

# Functional Parts 3 02/05

* Non-Illustrated Parts

DOOR

Model Index: AFRT21P5A (FRT21P5ABI)

BFRT21P5A (FRT21P5AQI)

CFRT21P5A (FRT21P5AWI)

POS. NO PART NO. DESCRIPTION

1 # 240514611 A - - Gasket, seal, black, frzr door, magnetic

1 # 240514607 - B C Gasket, seal, white, frzr door, magnetic

2 # 240514612 A - - Gasket, seal, black, refr door, magnetic

2 # 240514608 - B C Gasket, seal, white, refr door, magnetic

4 240534901 A B C Rack-door

4B 240534701 A B C Rack-door, 4B

7 240337703 A B C Door-dairy, w/o graphics, clear

8 240534801 A B C Rack-door

10 240381303 A - - Plug-button, black, hinge brg hole

10 240381302 - B - Plug-button, bisque, hinge brg hole, (2)

10 240381301 - - C Plug-button, white, hinge brg hole, (2)

11 240450313 A - - Door-frzr, black, complete assy

11 240450305 - B - Door, frzr, bisque

11 240450301 - - C Door, frzr, white

12 240415204 A - - Label-nameplate, black

12 240415203 - B - Label-nameplate, bisque

12 240415201 - - C Label-nameplate, white

13 240312405 A - - Door Stop, black, refr

13 240312407 - B - Door Stop, bisque, ref

13 240312403 - - C Door Stop, white, ref

13A 240312406 A - - Door Stop, black, frzr

13A 240312408 - B - Door Stop, bisque, frzr

13A 240312404 - - C Door Stop, white, frzr

14 240494003 A - - Plug-button, black

14 240494002 - B - Plug-button, bisque

14 240494001 - - C Plug-button, white

15 240450413 A - - Door-refr, black, complete assy

15 240450405 - B - Door, refr, bisque

15 240450401 - - C Door, refr, white

18 218668003 A - - Handle-door, black

18 218668004 - B - Handle-door, bisque

18 218668001 - - C Handle-door, white

21 240383401 A B C Screw, truss hd quad, #10-16 x .500

21C 218252200 A B C Screw, #8 truss hd, 10-32CA x 0.500

22 240527102 A - - Bearing-hinge, black

22 240527101 - B C Bearing-hinge, natural color

37 215870636 A - - Trim-handle, 2.47", black, w/satin AL band

37 215870633 - B - Trim-handle, 2.47", bisque, w/satin AL band

37 215870629 - - C Trim-handle, 2.47", white, w/satin AL band

37* 218676004 A B C Band-decorative, satin aluminum, handle trim

Publication No: 5995429478 FRT21P5A

02/05 4

CABINET

12A

35A 36

N05BBAABD4

21C

FRT21P5A Publication No: 5995429478

# Functional Parts 5 02/05

* Non-Illustrated Parts

CABINET

Model Index: AFRT21P5A (FRT21P5ABI)

BFRT21P5A (FRT21P5AQI)

CFRT21P5A (FRT21P5AWI)

POS. NO PART NO. DESCRIPTION

1 240355402 A B C Cover-fan

2 240367001 A B C Knob-damper control

3 5303001028 A B C Nut, push-on

4 241523701 A B C Damper-fan cover

5 5308000010 A B C Fan Blade, red, evaporator fan

8 5300157666 A B C Bushing-motor mtg, (2)

9 5303292396 A B C Bracket-motor mtg, front

10 240313610 A B C Cover-evap coil, w/o light

10* 240568606 A B C Seal-coil cover

10*# 240524701 A B C Wiring Harness, freezer section

11 5303208309 A B C Plug-hole, factory test

12 241557601 A B C Plug-ice maker harness, rectangular

12* 218843800 A B C Screw, hex wshr hd, 8-15A x 0.500

12A 240374401 A B C Plug-wtr inlet tube, round, 1"

12A* 241586701 A B C Plug-foam-wtr-inlet, round

13 240369702 A B C Motor-evap fan

13* 218931001 A B C Clamp-motor wiring, nylon, w/adhesive tape

14 5303292397 A B C Bracket-motor mtg, rear

14* 240433201 A B C Screw, hex washer head, 8-18 x 0.375

21C 218252200 A B C Screw, #8 truss hd, 10-32CA x 0.500

22 215774918 A - - Plug-button, black, upr hinge holes

22 215774919 - B - Plug-button, bisque, upr hinge holes

22 215774901 - - C Plug-button, white, upr hinge holes

28 240335501 A B C Bolt-roller adj, hex washer head, 1/4-20 x 4.020, (2), special

30 240314003 A - - Bracket-lower hinge, black

30 240314001 - B C Bracket-lower hinge, zinc

34 240311303 A B C Washer, hinge, nylon, (2)

35 240313803 A - - Bracket-ctr hinge, black

35 240313801 - B C Bracket-ctr hinge, zinc

35A 240336802 A B C Spacer-hinge, center

36 240516401 A B C Pin-center hinge

37 240337603 A - - Trim-cabinet corner, black, (2)

37 240337604 - B - Trim-cabinet corner, bisque, (2)

37 240337601 - - C Trim-cabinet corner, white, (2)

38 240313701 A B C Bracket-upper hinge

40 240354404 A - - Cover-upper hinge, black

40 240354403 - B - Cover-upper hinge, bisque

40 240354401 - - C Cover-upper hinge, white

41 5303001609 A B C Grommet, shelf mtg, 0.69", RH

41* 5308009759 A B C Grommet, shelf mtg, 1.25", LH, (4)

42 240578901 A B C Screw-hinge mtg, hex head, 1/4-20 x 5/8

43 240335003 A B C Roller Assy, front, (2)

47 218233300 A B C Channel-shelf mtg, side, (2)

48 5303292395 A B C Channel-shelf mtg, center

49 218362500 A B C Screw, hex washer head, 8-18AB x 1.250, spacer, (2)

56 240516501 A B C Pin-lower hinge

58 5303001343 A B C Screw, hex washer head, 8-15A x 0.500

59 240442703 A - - Screw-#10-32 X 3/4, black

Publication No: 5995429478 FRT21P5A

02/05 6

CABINET

12A

35A 36

N05BBAABD4

21C

FRT21P5A Publication No: 5995429478

# Functional Parts 7 02/05

* Non-Illustrated Parts

CABINET

Model Index: AFRT21P5A (FRT21P5ABI)

BFRT21P5A (FRT21P5AQI)

CFRT21P5A (FRT21P5AWI)

POS. NO PART NO. DESCRIPTION

59 240442701 - B C Screw-#10-32 X 3/4, zinc

72 240368207 A - - Grille/Kickplate, black

72 240368206 - B - Grille/Kickplate, bisque

72 240368205 - - C Grille/Kickplate, white

81 5308016566 A B C Screw, hex washer head, 8-15A x 0.625, low profile

82 5304418225 A B C Roller, compressor base, rear, (2)

83 5303316859 A B C Rivet, flat head, 1/4 OD x 1-3/4, roller pin

89 241574607 A B C Cover-access, w/label

89* 241500301 A B C Screw, hex washer head, 8-18AB x 0.500

92 216850900 A B C Screw, hex washer hd, 1/4 x 7/8, hinge mtg

* 240479601 A B C Plug, button, cab liner holes, (2)

* 5303305345 A - - Paint, touch-up, black

* 5304414035 - B - Paint, touch-up, bisque

* 5303305324 - - C Paint, touch-up, white

Publication No: 5995429478 FRT21P5A

02/05 8

SHELVES

25B

25C

N05SAAAEE13

123

22A

FRT21P5A Publication No: 5995429478

# Functional Parts 9 02/05

* Non-Illustrated Parts

SHELVES

Model Index: AFRT21P5A (FRT21P5ABI)

BFRT21P5A (FRT21P5AQI)

CFRT21P5A (FRT21P5AWI)

POS. NO PART NO. DESCRIPTION

10 215667501 A B C Tray, ice cube, plastic

11 240358003 A B C Shelf, freezer, full-width, wire

12 240545901 A B C Diffuser-air, top

13 240362601 A B C Diffuser, air, bottom

13* 240392601 A B C Seal-diffuser

14 # 241554901 A B C Switch-light/lamp

15 240436702 A B C Light Bulb/Lamp, A-15, clear, 40 W, 120 V, miniature

16 241559801 A B C Socket-light

17 240368101 A B C Control Box

17*# 240388701 A B C Wiring Harness, control box

18 240360801 A B C Knob, temp control

21 # 5304421256 A B C Control, temperature

22A 5303916855 A B C Tube, sensor sleeve, plastic, clear

23 # 215846606 A B C Timer, defrost, 60 Hz, 0.25 W, 120 V, 10 hour/30 min

23* 5303001259 A B C Screw-timer mtg, pan hd, 6-20 x 0.438, (2)

24 240373105 A B C Frame-shelf, cantilever, full width

25 240364717 A B C Cover-crisper pan

25B 240361202 A B C Knob, humidity cont.

25C 240361301 A B C Damper, humidity cont.

26 240343803 A B C Pan, crisper, (2)

29 240357701 A B C Trim-shelf, 24.48", front

31 240530903 A B C Pan-meat, w/o graphics, clear

36 240373106 A B C Frame, cantil shelf, half width

37 240357702 A B C Trim, shelf, 11.95", front

40 240443323 A B C Glass-shelf, 24.45" x 17.60", full shelf

41 240357801 A B C Trim-shelf, 24.48", rear

42 240530601 A B C Track, meat pan hanger, LH

42* 240530701 A B C Track, meat pan hanger, RH

43 240443318 A B C Glass-shelf, 11.92" x 17.60", half shelf

44 240357802 A B C Trim, shelf, 11.95", rear

47 240350654 A B C Insert-pan cover, glass

81 5308016566 A B C Screw, hex washer head, 8-15A x 0.625, low profile

123 215005100 A B C Screw, hanger/rlr mtg, 8-10x 0.438

Publication No: 5995429478 FRT21P5A

02/05 10

SYSTEM

N05CABBAB6
