Frigidaire FRT15HB3D Manuel utilisateur

Product No. FRT15HB3DW3 FRT15HB3DZ3

Series R134a System R134a System

Color white (right) white (left)

Volts 115 115

Wiring Diagram 240398801 240398801

Owner's Guide 240400112 240400112

Market North America North America

Energy Guide 241538732 241538732

Service Data Sheet 240379015 240379015

Installation Instructions 240568300 240568300

N05L00004.eps N05DBDCJA1.eps N05BBAABA25.eps N05SADDCA21.eps

N05CAAAAA8.eps 240398801.eps 240398601.eps

u x Major Appliances

North & Latin America

P.O. BOX 212378

AUGUSTA, GA 30917

Publication No.

5995441432

05/07/12

(EN/SERVICE/WC)

390

TOP-MOUNT

REFRIGERATOR

Model No.

FRT15HB3D

Publication No: 5995441432 FRT15HB3D

07/05 2

DOOR

13A

21C

N05DBDCJA1

18A

21A

FRT15HB3D Publication No: 5995441432

# Functional Parts 3 07/05

* Non-Illustrated Parts

DOOR

Model Index: AFRT15HB3D (FRT15HB3DW3)

BFRT15HB3D (FRT15HB3DZ3)

POS. NO PART NO. DESCRIPTION

1 240554113 A B Gasket-frzr door, white, magnetic

2 240542114 A B Gasket-refr door, white, magnetic

4 240535101 A B Rack-door

4A 240535301 A B Rack-door

4B 240535201 A B Rack-door

7 240337701 A B Door-dairy, w/o graphics, white

8 240535001 A B Rack-door

10 240381301 A B Plug-button, white, hinge brg hole, (2)

11 240415401 A B Door, frzr, white

12 240415201 A B Label-nameplate, white

13 240312403 A B Door Stop, white, ref

13A 240312404 A B Door Stop, white, frzr

14 240494001 A B Plug-button, white

15 240415501 A B Door, refr, white

18A 218428101 A B Handle-door, white, w/block & screw

21 240383401 A B Screw, truss hd quad, #10-16 x .500

21A 240521301 A B Screw, #10-16 x 1/2

21C 218252200 A B Screw, #8 truss hd, 10-32CA x 0.500

22 240527101 A B Bearing-hinge, natural color

73 218396700 A B Block-handle mtg, dovetail

74 215503200 A B Screw, cr pan hd, 10-16 x 0.500

Publication No: 5995441432 FRT15HB3D

07/05 4

CABINET

12A

35A 36

N05BBAABA25

43 21C

21C

FRT15HB3D Publication No: 5995441432

# Functional Parts 5 07/05

* Non-Illustrated Parts

CABINET

Model Index: AFRT15HB3D (FRT15HB3DW3)

BFRT15HB3D (FRT15HB3DZ3)

POS. NO PART NO. DESCRIPTION

1 241652301 A B Cover-fan

2 240367001 A B Knob-damper control

3 5303001028 A B Nut, push-on

4 241523701 A B Damper-fan cover

5 # 5308000010 A B Fan Blade, red, evaporator fan

8 5300157666 A B Bushing-motor mtg, (2)

9 5303292396 A B Bracket-motor mtg, front

10 241652211 A B Cover-evap coil

10* 240568601 A B Seal-coil cover

10*# 241520701 A B Harness-wiring, freezer

11 5303208309 A B Plug-hole, factory test

12 241557601 A B Plug-ice maker harness, rectangular

12* 218843800 A B Screw, hex wshr hd, 8-15A x 0.500

12A 240374401 A B Plug-wtr inlet tube, round, 1"

12A* 241586701 A B Plug-foam-wtr-inlet, round

13 # 240369702 A B Motor-evap fan

13* 215474201 A B Washer, "slinger", nylon, evap fan shaft

13* 218931001 A B Clamp-motor wiring, nylon, w/adhesive tape

14 5303292397 A B Bracket-motor mtg, rear

14* 240433201 A B Screw, hex washer head, 8-18 x 0.375

21C 218252200 A B Screw, #8 truss hd, 10-32CA x 0.500

22 215774901 A B Plug-button, white, upr hinge holes

30 240357101 A B Bracket-lower hinge, zinc chromate

34 240311303 A B Washer, hinge, nylon, (2)

35 240357001 A B Bracket-ctr hinge, zinc

35A 240336802 A B Spacer-hinge, center

36 240516401 A B Pin-center hinge

37 241611301 A B Trim-cabinet corner, white, (2)

38 241622501 A B up-hinge, plastic, white

41 5308009759 A B Grommet, shelf mtg, 1.25", LH, (4)

42 240578901 A B Screw-hinge mtg, hex head, 1/4-20 x 5/8

43 241559602 A B Roller Assy, fixed, front LH

43* 241559601 A B Roller Assy, fixed, front RH

56 240516501 A B Pin-lower hinge

58 5303001343 A B Screw, hex washer head, 8-15A x 0.500

59 240442701 A B Screw-#10-32 X 3/4, zinc

72 240368301 A B Grille/Kickplate, white

81 5308016566 A B Screw, hex washer head, 8-15A x 0.625, low profile

82 5304418225 A B Roller, compressor base, rear, (2)

83 5303316859 A B Rivet, flat head, 1/4 OD x 1-3/4, roller pin

89 241574606 A B Cover-access, w/label

89* 241500302 A B Screw, hex washer head, 8-18AB x 0.625

92 241624301 A B Screw-hinge mtg, hex head, 1/4-20 x 1.00

* 240479601 A B Plug, button, cab liner holes, (2)

* 5303305324 A B Paint, touch-up, white

Publication No: 5995441432 FRT15HB3D

07/05 6

SHELVES

FRT15HB3D Publication No: 5995441432

# Functional Parts 7 07/05

* Non-Illustrated Parts

SHELVES

Model Index: AFRT15HB3D (FRT15HB3DW3)

BFRT15HB3D (FRT15HB3DZ3)

POS. NO PART NO. DESCRIPTION

11 5303282284 A B Shelf-freezer, "table type"

11* 5303299664 A B Spacer, shelf

12 241542001 A B Diffuser, air, top

13 240362601 A B Diffuser, air, bottom

14 # 241554901 A B Switch-light/lamp

15 241555401 A B Light Bulb

16 241559801 A B Socket-light

17 240368001 A B Control Box

17* 240568607 A B Seal

17*# 240388701 A B Wiring Harness, control box

18 240360801 A B Knob, temp control

21 # 5304421256 A B Control, temperature

22A 240468201 A B Tube, sensor sleeve, 31 inch, plastic, white

23* 5303001259 A B Screw-timer mtg, pan hd, 6-20 x 0.438, (2)

23# 241621501 A B Timer-defrost

24 240360902 A B Shelf, sliding, wire

25 240364706 A B Cover, crisper pan

26 240364501 A B Pan, crisper, (2)

81 5308016566 A B Screw, hex washer head, 8-15A x 0.625, low profile

Publication No: 5995441432 FRT15HB3D

07/05 8

SYSTEM

FRT15HB3D Publication No: 5995441432

# Functional Parts 9 07/05

* Non-Illustrated Parts

SYSTEM

Model Index: AFRT15HB3D (FRT15HB3DW3)

BFRT15HB3D (FRT15HB3DZ3)

POS. NO PART NO. DESCRIPTION

1 240444401 A B Condenser, dynamic

4 # 218944001 A B Drier-filter, R134a System

6 240496101 A B Wiring Harness, machine compt, w/electric cord

6* 241520701 A B Harness-wiring, freezer

6* # 240388701 A B Wiring Harness, control box

14 # 5303918203 A B Defrost Heater Kit

15 # 5303918275 A B Evaporator Kit

16 5308000110 A B Strap-evap/heater, aluminum, (2)

17 241551802 A B Trough-drain

20 241551901 A B Insulation Block

21 # 5303918202 A B Thermostat-defrost, kit

22 241602005 A B Base-compressor

22* 218252200 A B Screw, #8 truss hd, 10-32CA x 0.500

23 218513300 A B Grommet-compr mtg, (4)

25 240491501 A B Screw-compressor mtg, 1/4-28 x 1.16, shoulder, typ CF

26 240332608 A B Pan-defrost drain

29 # 5303918299 A B Compressor, w/electricals

30 # 241527802 A B Starter

32 241527901 A B Clamp, elec cont mtg, compressor

34 240405201 A B Grommet, rubber, black, cond tube/wire

41 240433202 A B Screw, hex washer head, 8-18 x 5/16

44 5303001199 A B Clamp-wiring harness, strain relief, galv steel

45 5308016566 A B Screw, hex washer head, 8-15A x 0.625, low profile

55 218909915 A B Capacitor-run, 220 VAC, 15 microfarad

57 240542601 A B Clip-wiring harness

58 218897002 A B Screw, hex washer head, 8-32 x 0.375

59 5304430246 A B Bracket-cond motor assy

59* 240346701 A B Tape-foam seal, shroud

59* 240359401 A B Screw-fan shroud, (2)

60 240525402 A B Motor, condensor fan

61 # 240524101 A B Fan Blade, galv steel, condenser fan

82 5304418225 A B Roller, compressor base, rear, (2)

83 5303316859 A B Rivet, flat head, 1/4 OD x 1-3/4, roller pin

84 240500801 A B Tube-drain, rubber, lower

85 240553501 A B Tube-connector, suction

* 240396801 A B Clamp, tube/wiring, nylon, black/natural

* 5303918263 A B Heat Exchanger Kit, suction line

* # 5303918222 A B Hot Tube Repair Kit, service

Publication No: 5995441432 FRT15HB3D

07/05 10

WIRING SCHEMATIC
