Frigidaire FGGF3041K Mode d’emploi

FGGF3041KFA.eps CFGGF3031KBA.eps BFGGF3031KBA.eps VFGGF3031KBA.eps

TFGGF3041KFA.eps DFGGF3041KFA.eps

Product No. FGGF3041KFA

Series 30" f/s elec

Color stainless

Market North America

Owner's Guide 316901203

Installation Instructions 316259343

Service Data Sheet 316904012

Electrolux Major Appliances

North & Latin America

P.O. BOX 212378

AUGUSTA, GA 30917

Publication No.

5995538815

09/04/23

(EN/SERVICE/ECL)

369

30-INCH FREE-

STANDING GAS

RANGE

Model No.

FGGF3041K

Publication No: 5995538815 FGGF3041KFA

04/09 2

BACKGUARD

CFGGF3031KBA

15A

20A

FGGF3041KFA Publication No: 5995538815

# Functional Parts 3 04/09

* Non-Illustrated Parts

BACKGUARD

POS. NO PART NO. DESCRIPTION

1 316557600 Shield, rear wall

2 316497601 Shield, backguard, inner

15 316546702 Cap, backguard, black, RH end

15A 316546703 Cap, backguard, black, LH end

19 316572406 Panel, backguard, stainless

20 # 316418301 Clock/Timer, electronic, ES330

* 316021110 Screw, 8-18 x 0.5, black

20A 316419333 Overlay, clock, black, ES330

21 316546601 Cap, backguard, black, top

36 316564508 Knob, top valve, black, (5)

40 316249046 Panel, manifold, stainless steel

* 316021108 Screw, cup pt, 8-18 x 0.375, chrome

* 316021109 Screw, 8-18 x 0.5, chrome

42 316416200 Trim, extrusion, black

56 316230701 Shield, backguard, inner

* 316021105 Screw, hex head cup pt, 8-18 x 0.375, black

* 316089500 Screw, 10-16 x .486

Publication No: 5995538815 FGGF3041KFA

04/09 4

BURNER

BFGGF3031KBA

11C

11B

10B

10A

11A

11D

11C 44C

11A 44A

11 44

12 12

10C 10C

11B 44B

11D 44C

FGGF3041KFA Publication No: 5995538815

# Functional Parts 5 04/09

* Non-Illustrated Parts

BURNER

POS. NO PART NO. DESCRIPTION

1 # 316551202 Manifold, pipe

2 # 5303935233 Valve, 17K burner, w/mtg screw

2A # 5303935235 Valve, 5K burner, w/mtg screw

2B # 5303935236 Valve, 14K burner, w/mtg screw

2C # 5303935234 Valve, 9.5K burner, w/mtg screw

* 316215600 Screw, valve mtg., 1/4 - 20

3 # 316219023 Wiring Harness, w/igntr switch

8 # 318079001 Module, spark

* 316443200 Bracket-support

* 316021109 Screw, 8-18 x 0.5, chrome

10 # 316438400 Burner, sealed, 16/17K

10A# 316438200 Burner, sealed, 5K

10B# 316438600 Burner, sealed, 14K

10C# 316527400 Burner, sealed, 9.5K

11 # 316449603 Ignitor/orifice assy, top burner, right front, 17K, w/tube & holder

11A# 316449500 Ignitor/orifice assy.,, top burner, right rear, 5K, w/holder, tube

11B# 316548102 Ignitor/orifice assy., top burner, left rear, 14K, w/holder, tube

11C# 316449302 Ignitor/orifice assy.,, top burner, left front, 9.5K, w/tube & holder

11D# 316449304 Ignitor/orifice assy.,, top burner, center, 9.5K, w/tube & holder

12 316529700 Screw, burner head, mtg., (8)

13 # 316545700 Tube, 3/8, aluminum, rgltr to manf, with fittings

14 # 316091706 Regulator, pressure

14* 316021104 Screw, hex, 8-18 x 3/8, nick, (3), regulator brkt

15 316091600 Bracket, regulator

16 # 316431000 Tube-valve to rgltr, 3/8

17 # 316404901 Valve, safety

17* 316498100 Shield, wire, safety valve

* 316089500 Screw, 10-16 x .486

18 # 316404400 Burner, oven

19 # 316489404 Ignitor, oven burner

20 316401401 Baffle, oven burner

21 5303013272 Nut, hex head sems

22 # 316537100 Tube-valve to mixer

23 # 316404300 Burner, broiler

24 # 316409700 Elbow, mixer

* 316021132 Screw, 8-18 X 11/16, black, (3)

25 316401301 Baffle, broil burner

26 # 316489403 Ignitor, burner

26* 316401500 Cover, broil Ignitor

37 316240600 Screw, assy mtg, (8), ignitor/orifice

44 # 316527511 Orifice, top burner, 14K

44A# 316527504 Orifice, top burner, 5K

44B# 316527509 Orifice, top burner, 17K

44C# 316527500 Orifice, top burner, 9.5K

47 # GRLP3 LP Conversion Kit, w/instructions

47* 316417518 Instructions, LP conversion

* # 316526902 Harness, ignitor

* # 316064103 Wire, ground assembly

* 316001003 Screw, ground wire

* 316021105 Screw, hex head cup pt, 8-18 x 0.375, black

* 316021110 Screw, 8-18 x 0.5, black

Publication No: 5995538815 FGGF3041KFA

04/09 6

BODY

ANTI-TIP

BRACKET

ANTI-TIP

BRACKET

NOTE: Oven Liner N/A

Ass. du four N/A

170

151

58A

58B

58G

170

VFGGF3031KBA

151

26A

FGGF3041KFA Publication No: 5995538815

# Functional Parts 7 04/09

* Non-Illustrated Parts

BODY

POS. NO PART NO. DESCRIPTION

1 316401600 Back, main

* 316021109 Screw, 8-18 x 0.5, chrome

2 316437100 Brace, oven top

* 316021132 Screw, 8-18 X 11/16, black, (3)

3 316400118 Panel, bodyside, black, RH

3 316400119 Panel, bodyside, black, LH

4A 316446900 Bracket, chassis, front, (2)

5 316272900 Screw, leveling, plastic, rear, (2)

5A 316498900 Leveling Leg Assy, metal, front, (2), bracket & leg

6 316496202 Rack, oven, (2)

6A 316496206 Rack, oven, (1)

8 316400603 Panel, oven bottom

9 316081900 Pan, broiler, OPTIONAL ACCESS0RY

10 316082000 Insert, broiler pan, OPTIONAL ACCESS0RY

12 # 316445500 Switch, oven light, door frame

14 # 316116400 Receptacle, oven light

15 # 316538901 Lamp, oven light

16 318406100 Lens, oven light, glass

17 316087500 Retainer, lens

18 316405800 Latch Assembly, oven door

* 5303285179 Screw, wafer head, 8-32T x 0.500, black

21 316408000 Clip, bodyside

25 316406200 Shield, heat, lower

26A 316498200 Bracket-support, chassis, aluminum

29 316407301 Glide, drawer, front

33 316405900 Shield, rear wall

35 316542100 Gasket-flue

36 316208901 Flue

37 # 316490000 Probe, oven temp

39 # 3202006 Cord, electric power

42 316400700 Shield, wool, lower

43 3131732 Screw, 8-18 x 1.438, oven bottom

44 316517600 Spacer, oven door

49 316260000 Clip, maintop mtg, (2)

54 316404200 Shield, heat

55 316404800 Shield, flue

58A 316403700 Insulation, oven wrapper

58B 316403600 Insulation, oven back

58G 08067973 Insulation, main front

82 316400801 Shield, bake burner

86 316537400 Receptacle, hinge, (2)

* 316418900 Screw, sims lp, #8-32 x 5/16", black

87 316401201 Bracket, harness

88 316232700 Rod, auto latch

89 # 316439000 Motor, latch/lock

90 316401100 Shield, main front

91 316401000 Shield, front, burner

151 316404600 Shield, bodyside

170 316112004 Anti Tip Kit, assembly

170* 316107200 Bracket, anti-tip

170* 316116000 Screw, concrete, 1.75", anti-tip brkt

170* 316541700 Template, anti-tip

* # 316512556 Harness Wiring, main

* 316432800 Clip, wire

* 316539800 Retainer, wire

* 316021105 Screw, hex head cup pt, 8-18 x 0.375, black

* 316021110 Screw, 8-18 x 0.5, black

* 316089500 Screw, 10-16 x .486

Publication No: 5995538815 FGGF3041KFA

04/09 8

TOP/DRAWER

20A

22A

22C

22B

TFGGF3041KFA

22C

FGGF3041KFA Publication No: 5995538815

# Functional Parts 9 04/09

* Non-Illustrated Parts

TOP/DRAWER

POS. NO PART NO. DESCRIPTION

1 316408703 Drawer, utility

* 316021110 Screw, 8-18 x 0.5, black

2 316403200 Liner, drawer

4 316409312 Panel, drawer, stainless, outer

7 316407400 Glide, drawer, rear

16 316469661 Maintop panel, black

20 316499502 Grate, black, (2)

20A 316551802 Grate, center, black

22 316438504 Cap, 16/17K-burner, black

22A 316438304 Cap, 5K burner, black

22B 316438704 Cap, 14K burner, black

22C 316527704 Cap, 9.5K burner, black, medium

39 316554005 Handle, door/drawer, stainless

60 5304414648 Screw, handle mtg.

88 316099500 Pin, guide, (2)

* 316021105 Screw, hex head cup pt, 8-18 x 0.375, black

Publication No: 5995538815 FGGF3041KFA

04/09 10

DOOR

60B

DFGGF3041KFA

10B
