Frigidaire FES367D Manuel utilisateur

PRODUCT NO. BASE MODEL NO. FACTORY NO. SERIES COLOR

FES367DBA FES367D 37954336F4061 30" slide-in black

FES367DQA FES367D 37954336F4041 30" slide-in bisque

FES367DSA FES367D 37954336F4011 30" slide-in white

MARKET

North America

Publication No.

5995395125

030903

-EN/SERVICE /ECL

377

ELECTRIC

RANGE

Model No.

FES367D

FACTORY PARTS CATALOG

RANGE

WIRING DIAGRAM - # 318045089

OWNER’S GUIDE - # 318200840

TIMER INSTRUCTION SHEET - # 318200191

INSTALLATION INSTRUCTIONS - # 318201606

ELECTROLUX HOME PRODUCTS, INC.

P.O. BOX 212378, Augusta, GA 30917

08/03 2

Publication No. FES367D

5995395125

BACKGUARD

# = Functional Parts 3 08/03

* = Non-Illustrated Parts

FES367D Publication No.

5995395125

BACKGUARD

A = FES367D (FES367DSA)

B = FES367D (FES367DBA)

C = FES367D (FES367DQA)

POS. NO PART NO DESCRIPTION

14 # 318044825 A B C Light,indicator ,125v ,(2)

16 318235000 A - - Console,assy. ,white ,w/ end caps

16 318235001 - B - Console,assy. ,black ,w/ end caps

16 318235002 - - C Console,assy. ,bisque ,w/ end caps

19 318235144 A - - Panel,control ,white

19 318235145 - B - Panel,control ,black

19 318235146 - - C Panel,control ,bisque

19A 318224401 A B C Panel,control mtg.

20 # 318185446 A - - Clock/Timer,electronic ,white ,ES300

20 # 318185447 - B - Clock/Timer,electronic ,black ,ES300

20 # 318185448 - - C Clock/Timer,electronic ,bisque ,ES300

20* 316220804 A - - Overlay,clock ,white ,ES300

20* 316220805 - B - Overlay,clock ,black ,ES300

20* 316220806 - - C Overlay,clock ,bisque

24 # 316005607 A - - Switch,rocker ,white

24 # 316005602 - B - Switch,rocker ,black

24 # 318037520 - - C Switch,rocker ,bisque ,oven light

35 318233701 A - - Retainer,control panel ,white

35 318233700 - B - Retainer,control panel ,black

35 318233702 - - C Retainer,control panel ,bisque

36 318229300 A - - Knob,control ,white

36 318229301 - B - Knob,control ,black

36 318229302 - - C Knob,control ,bisque

42 318224301 A B C Trim,vent ,black ,bottom

46 318228300 A B C Lens,indicator light

54 # 318120521 A B C Switch,surface unit

69 5303323134 A B C Screw,switch mtg. ,8-32 x 0.188

99A 318223900 A B C Gasket,dark grey

* 3201861 A B C Screw,6 x 0.375

* 08016432 A B C Screw,truss head ,8-18 x 0.375

* 5303211311 A B C Screw,8 x 0.500

* 5303311528 A B C Screw,oval hd sq dr ,6-20AB x 0.625 ,black

08/03 4

Publication No. FES367D

5995395125

BODY

# = Functional Parts 5 08/03

* = Non-Illustrated Parts

FES367D Publication No.

5995395125

BODY

A = FES367D (FES367DSA)

B = FES367D (FES367DBA)

C = FES367D (FES367DQA)

POS. NO PART NO DESCRIPTION

1 318066402 A B C Panel,main back

1A 318225100 A B C Panel,main back ,upper

2A 318227600 A B C Shield,oven top

3 318225200 A B C Panel,bodyside ,upper RH

3A 318225201 A B C Panel,bodyside ,upper LH

3B 318160010 A B C Panel,body side ,lower RH

3C 318160011 A B C Panel,body side ,lower LH

5 318175503 A B C Screw,leveling

6 318025308 A B C Rack,oven

9 5303317977 A B C Pan,broiler

10 5303317976 A B C Insert,broiler pan

12 # 318089913 A B C Switch,light

14 318224000 A B C Receptacle,oven light

15 5303013071 A B C Bulb/Lamp,oven light

16 3201911 A B C Cover,oven light ,glass

17 5304400195 A B C Retainer,light cover

25 318179107 A B C Panel,heat shield ,sm oven bottom

37 # 316217002 A B C Probe,oven temp

41 5303310526 A B C Cover,hinge cutout

54 318222400 A B C Housing,oven light

56 318225901 A - - Trim,oven ,white

56 318225902 - B - Trim,oven ,black

56 318225903 - - C Trim,oven ,bisque

58A 318133783 A B C Insulation,oven wrapper

58B 318133785 A B C Insulation,oven back

59 318072534 A B C Tube,vent ,oven

62 5303935061 A B C Terminal Block Kit

62* 5303323144 A B C Nut,10-32

63 316208500 A B C Plate,grounding strap

66 # 5303310513 A B C Element,broil ,2750 W

67 # 5303310512 A B C Element,bake ,3000 W

68 5304403015 A B C Support,element hanger

70 318194400 A B C Shield,insulation

71 5303310515 A B C Panel,wiring cover ,rear

76 318225302 A B C Front,oven

80 5303324473 A B C Bracket,oven mounting

81 318192400 A B C Spring,oven

83 318089613 A B C Liner,oven

86 5303310524 A B C Receptacle,hinge

86* 318246500 A B C Deflector,RH

86* 318246600 A B C Deflector,LH

87 318111803 A B C Plate,mounting

88 318118904 A B C Rod,latch

89 # 318095937 A B C Motor,latch assy ,w/brkt & switch

89* 318120711 A B C Switch

102 5303311142 A B C Support,oven front

108# 318073016 A B C Motor,blower

112# 318112701 A B C Relay

127 5303310542 A B C Adapter,vent tube ,with converter

128 5303311163 A B C Bushing

129 5303311164 A B C Spring

141# 318005201 A B C Switch,thermal cutout

141B 318003607 A B C Thermostat,safety

142 318123901 A B C Deflector

170 5304405244 A B C Anti-tip & accessories

191 5303304030 A B C Bracket,angle ,corner

284 318226600 A B C Box,vent tube

285 318236200 A B C Shield,hidden wires

* 08016432 A B C Screw,truss head ,8-18 x 0.375

* 5303211311 A B C Screw,8 x 0.500

* 5303307980 A B C Screw,8-32 x 0.437

08/03 6

Publication No. FES367D

5995395125

MAINTOP/DRAWER

# = Functional Parts 7 08/03

* = Non-Illustrated Parts

FES367D Publication No.

5995395125

MAINTOP/DRAWER

A = FES367D (FES367DSA)

B = FES367D (FES367DBA)

C = FES367D (FES367DQA)

POS. NO PART NO DESCRIPTION

1 318107104 A B C Drawer

4 318134011 A - - Panel,drawer ,white ,front

4 318134012 - B - Panel,drawer ,black ,front

4 318134013 - - C Panel,drawer ,bisque ,front

11 5303311125 A B C Bracket,drawer

13 5303311129 A B C Channel,drawer ,RH

13A 5303311130 A B C Channel,drawer ,LH

15 # 318198810 A B C Element,surface ,6" ,1200 W

15A# 318198812 A B C Element,surface ,8" ,2200 W

15B# 316224200 A B C Element,surface ,9" ,2500W ,radiant

16 318223600 A - - Main Top,glass assy. ,black/white

16 318223602 - B - Main Top,glass assy. ,black

16 318223601 - - C Main Top,glass assy. ,black/bisque

46 318225401 A B C Box,burner

51 # 318044822 A B C Light,indicator ,clear

52 318122007 A B C Spring,element mtg ,large

52A 318122006 A B C Spring,element mtg ,small

52B 318122010 A B C Spring,element mtg ,1000W/2500W

70 5303311143 A B C Bracket,slide ,rear

71 5303311144 A B C Magnet & spring assy

72 5303311145 A B C Bracket & wheel assy

165 318227500 A B C Plate,mounting

193 5303325173 A B C Cap,plug

* 08016432 A B C Screw,truss head ,8-18 x 0.375

* 5303211311 A B C Screw,8 x 0.500

08/03 8

Publication No. FES367D

5995395125

DOOR

# = Functional Parts 9 08/03

* = Non-Illustrated Parts

FES367D Publication No.

5995395125

DOOR

A = FES367D (FES367DSA)

B = FES367D (FES367DBA)

C = FES367D (FES367DQA)

POS. NO PART NO DESCRIPTION

1 318180310 A B C Bracket,trim mtg

2 318180312 A B C Bracket,upper trim mtg

3 318187810 A - - Trim,door ,white ,RH side

3 318187814 - B - Trim,door ,black ,RH side

3 318187812 - - C Trim,door ,bisque ,RH side

3A 318187811 A - - Trim,door ,white ,LH side

3A 318187815 - B - Trim,door ,black ,LH side

3A 318187813 - - C Trim,door ,bisque ,LH side

3B 318176646 A - - Trim,door ,white ,top

3B 318176647 - B - Trim,door ,black ,top

3B 318176648 - - C Trim,door ,bisque ,top

4 318187715 A - - Panel,door front assy ,glass ,white ,with lower trim

4 318187714 - B - Panel,door front assy ,glass ,black ,with lower trim

4 318187716 - - C Panel,door front assy ,glass ,bisque ,with lower trim

6 318056802 A B C Shield,insulation

7 318133781 A B C Insulation,oven door

9 318157011 A B C Liner,door

10 5303311174 A B C Screw,10-24 x 3/8

12 318053103 A B C Gasket,oven door seal

16 318041603 A B C Panel,glass ,inner oven door

17 318042102 A B C Spacer,glass

18 318053001 A B C Seal,window

23 318024700 A B C Hinge,oven door

31 5303310536 A B C Latch,oven door

39 316203001 A - - Handle,door ,white

39 318231200 - B - Handle,black

39 316203003 - - C Handle,door ,bisque

54 5303300265 A B C Screw,8-18 x 0.500 ,chrome

64 5304417120 A B C Tape,0.762 m ,Neoprene

77 318043100 A B - Bracket,trim ,handle ,(2)

* 316221001 A B C Label,anti-tip

* 08016432 A B C Screw,truss head ,8-18 x 0.375

* 5303211311 A B C Screw,8 x 0.500

* 5303307980 A B C Screw,8-32 x 0.437

08/03 10

Publication No. FES367D

5995395125

WIRING DIAGRAM
