Frigidaire FEF455WF Manuel utilisateur

PRODUCT NO. FACTORY NO. COLOR MARKET

FEF455WFBC 38154537E7063 BLACK U.S.A.

Publication No.

5995318549

990218

-EN/SERVICE /MG

377

ELECTRIC - RANGE

Model No.

FEF455WF

FACTORY PARTS CATALOG

ELECTRIC RANGE

WIRING DIAGRAM # -318045306

OWNERS GUIDE #-318068801

INSTALLATION INSTRUCTION #-318200870

FRIGIDAIRE HOME PRODUCTS

7075 ORDAN DRIVE

MISSISSAUGA, ONTARIO

CANADA L5T1K6

TEL :(905) 565-9200

02/99 2

Publication No. FEF455WF

5995318549 BACKGUARD

14A

15A

18A

LA9923G07

36 36 36

32A

# = Functional Part 302/99

* = Non-Illustrated Part

FEF455WF Publication No.

5995318549

POS. NO PART NO. DESCRIPTION

15303304006 A

35303286690 ALamp-fluorescent

4318110300 AReceptacle-lamp RH/LH

65308068062 AStarter-lamp

6A 318110400 AHolder, starter

10# 318122802 ABallast-lamp

12 5304400505 AOven control

14A 3051539 ALight/Lamp-oven

15 5303304000 ABracket-end cap RH

15A 5303304001 ABracket-end cap LH

18 5303304540 AEnd Cap,RH (black)

18A 5303304541 AEnd Cap,LH (black)

19 318005720 APanel-control black

20 # 318013006 AElectronic timer

21 318051301 ATrim-canopy

23 318015011 ABracket-timer

24# 316005602 ASwitch-oven light, rocker type

32A 318016325 AKnob-thermostat

36 5303299751 AKnob-surface unit black

46 5308006417 ALens-light/lamp

54 # 318120501 ASwitch-surface unit

69 5303323134 AScrew,switch mtg. ,8-32 x 3/16

98 318092405 AHarness wires

99 5303304544 ASpacer-end cap

* 5303211311 AScrew,#8 x ½

*08016432 AScrew truss head, 8-18 x 3/8

*318052086 AHarness wires

BACKGUARD

A= FEF455WF (FEF455WFBC)

02/99 4

Publication No. FEF455WF

5995318549 BODY

217

170

170A

191

84A

59A

58E

58F

102

262

142 62

134

260

LA9923V11

261

67A

66A

58B 58A

127 14

54A

17A

66 68

83A

139

140

77A

84B

129

128

137

27 141

12A

# = Functional Part 502/99

* = Non-Illustrated Part

FEF455WF Publication No.

5995318549

POS. NO PART NO

DESCRIPTION

1 5303310527 ABack-main

3 3201579 APanel-bodyside,black RH

3A 3201580 APanel-bodyside,black LH

4318073704 ABurner box

5 318175500 AScrew-levelling

6 5303310522 ARack-oven

6A 318119700 ARack-oven small

85303311141 AShield-heat insulation

8A 318071900 APanel-insulation bottom

9 5303317977 APan-broiler

10 5303317976 AInsert-broiler pan

12 # 318089910 ASwitch-light

12A# 5301314211 ASwitch light

14 5308011085 ASocket-light/lamp

15 3201908 ALamp-oven light

16 3201911 AGlass-oven light lens

17 5304400195 ARetainer lens

17A 5303205904 ARetainer lens

25 318133000 AShield-heat lower

27 5303284616 AClip-thermo bulb

29 3051654 AGuide-drawer front

30 318023909 ABracket main top

37 # 316111203 AProbe-oven temp

41 5303310526 ACover-hinge cutout

45 318057401 AShield-wire

54 5303310514 AHousing-oven light

54A 5303217606 AHousing oven light

57 318055700 APanel-back

58A 5303310539 AInsulation,oven wrapper

58B 5303310538 AInsulation,oven back

58E 5301305817 AInsulation, oven wrapper

58F 5301167905 AInsulation, oven back

59 318072501 ATube oven vent

59A 3017402 ATube oven vent LH

62 # 5303310518 ATerminal Block

63 5303310517 APlate-ground strap

66 # 5303310513 AElement-broil

66A# 318110100 AElement-broil small

67 # 5303310512 AElement-bake

67A# 318110600 AElement bake small

68 5304403015 ASupport-element

74 5308003107 ABumper door top

76 318056004 AFrame-front

77 318018000 ARail-drawer RH

77A 318018001 ARail-drawer LH

80 5303324473 ABracket-oven

81 5303301261 ASpring oven/ Attache four

83 318089600 ALiner-oven assy

83A 318089200 ALiner-oven assy small

84 3204822 AGusset-rear RH

84A 3204823 AGusset-rear LH

84B 318055901 AGusset-rear

86 5303310524 AChannel-hinge

87 318111800 APlate-mounting cord

88 5303311160 ARod-latch

89 # 318095901 AMotor-latch assy

89* 318120702 ASwitch latch

102 318111901 ASupport-oven front

127 5303310542 AAdapter assy

128 5303311163 ABushing

129 5303311164 ASpring

134 5303310515 ACover-wiring

137 3204318 APlate-strike

139 318042900 ABraket-filler

140 318071300 ARetainer-insulation

141# 318003600 AThermostat-safety

142 318123901 ADeflector

170 3203575 AAnti-tip bracket

170A 3203576 AAnti-tip bracket

191 5303304030 ABracket corner

217 316042300 APlate-warning

BODY

A= FEF455WF (FEF455WFBC)

02/99 6

Publication No. FEF455WF

5995318549 BODY

POS. NO PART NO. DESCRIPTION

260 318055500 ASupport-gusset

261 08014183 AGrill-broiler small

262 08011954 ASupport/ Support

*3204817 APlug button

*5303051099 ANut, hex #10-32

*5303211311 AScrew, #8 X ½

*5303307980 AScrew, 8-32 X 7/16

*5305151612 ANut

A= FEF455WF (FEF455WFBC)

02/99 7

Publication No. FEF455WF

5995318549 TOP/DRAWER

33A

34A

19A

108

27 109

109

106

107

15A

138A

138

LA9923T02

63A

139

39A

# = Functional Part 802/99

* = Non-Illustrated Part

FEF455WF Publication No.

5995318549

POS. NO PART NO DESCRIPTION

1 3202108 ADrawer-utility

2A 318048204 ALiner-small door

4 3201577 APanel-drawer black

4A 318009307 APanel-oven door

5318014500 ASpacer-handle

75301315217 AGlide-drawer

15 # 5303309001 AElement-surface,2600W

15A# 5303309000 AElement-surface,1500W

16 5304400734 AMaintop

18 3051745 ARetainer hinge pin

19 318067010 APan-surface element

19A 5303280336 APan-surface elementl

20 3201572 ASpacer, handle

27# 5303323704 ATerminal block

28 5303301461 AMedallion surface element

29 318141800 ASpacer-hinge pin

30 5301311649 AInsulation-door small

33 3201527 ACover-griddle

33A 5301313051 AHandle-cover

34 5304400770 AGriddle

34A 08005351 AHandle-griddle

39 3201576 AHandle-drawer

39A 3201575 AHandle-door

60 5303323139 AScrew, 10-24 X 29/32

61 318107700 A

63 318024505 AHinge-lower

63A 318024507 AHinge-top

65 3204306 ALatch-door

69 318053300 ASeal-oven door

93 318122500 ASupport terminal block

106 5304400772 ABracket receptacle

107 5303292139 AReceptacle porcelain

108 5303292140 ATerminal clip

109 5303323221 ASpacer fiber

138 5301315631 ABracket-hinge main top

138A 3051658 ABracket-hinge main top

139 08011955 AScrew, 10-24 X 3/8

*08002868 AScrew, 10-24 X ½

*5303211311 AScrew, #8 X ½

*5303320848 AScrew, 6-20 X ¼

*5303321106 APlug-button

*5303317975 AScrew, 10 X ½

*5304400427 AScrew, 6-20 X ½

*318086002 AWasher

*5304400790 APlug

TOP/DRAWER

A= FEF455WF (FEF455WFBC)

02/99 9

Publication No. FEF455WF

5995318549 DOOR

15A

18A

LA9923D08

# = Functional Part 10 02/99

* = Non-Illustrated Part

FEF455WF Publication No.

5995318549

POS. NO

PART NO DESCRIPTION

55303310508 AGlass-oven door

6 318057000 ABaffle-door

7 5303310532 AInsulation-door

7A 318106000 AInsulation-door

7B 5304400472 AInsulation-door

7C 3204813 AInsulation-door

9 318048702 ALiner-oven door

12 318053103 ASeal-oven door

13 318009103 APanel-oven door black

15 318024000 ABracket-glass mtg RH

15A 318024001 ABracket-glass mtg LH

16 5303310533 AGlass-oven door, heat barrier

17 318139000 ASpacer-glass

18 5303310531 ASeal-rope

18A 5303310505 ASeal (glass ext. door)

20 3201572 ASpacer-handle

22 5303310511 ARetainer-glass

23 318024700 AHinge

31 5303310536 ALatch-door

32 318057202 ADeflector-handle

35 5303310504 ASpacer-door handle

39 3201570 AHandle-door,oven

54 5303317975 AScrew, 10 X ½

60 3051070 AScrew, 10-24 X 7/16

* 5303211311 AScrew,#8 x 1/2

* 5303307980 AScrew,8-32 x 7/16

*3203618 ARivet-pop warning plate

*08016532 AScrew, 8-18 X 3/8

*5303311306 AScrew, 8-18 X 3/8

*318086002 AWasher

DOOR

A= FEF455WF (FEF455WFBC)
