Frigidaire FEF365BGDD Manuel utilisateur

FACTORY PARTS CATALOG

ELECTRIC RANGE

P.O. Box 212378

Augusta, Georgia 30917

PRODUCT NO. BASE MODEL NO. COLOR MARKET

FEF365BGWD FEF365BG WHITE USA

FEF365BGDD FEF365BG ALMOND USA

Publication No.

5995342150

000804

-EN/SERVICE /CML

369

WIRING DIAGRAM # - 316002710

OWNER’S GUIDE # - 316135911

INSTALLATION GUIDE # - 316003025 ELECTRIC - RANGE

FEF365BGWD

FEF365BGDD

08/00 2

Publication number

5995342150 FEF365BGDD, FEF365BGWD

CAUTION: Use the part number on all orders, not the position number.

BACKGUARD

# - Fast Moving Parts

* - Non Illustrated Parts 3 6/98

Publication number

FEF365BGDD, FEF365BGWD 5995342150

CAUTION: Use the part number on all orders, not the position number.

BACKGUARD

A = FEF365BG (FEF365BGDD)

B = FEF365BG (FEF365BGWD)

POS. NO PART NO DESCRIPTION

* 316021105 A B Screw,hex ,8-18 x 0.375 ,back\bodyside

* 316021108 A B Screw,cup pt ,8-18 x 0.375,ind lght brkt,manifold pnl

* 316021110 A B Screw,semi gim ,8-18 X 1/2 ,black

1 316081601 A B Shield-backguard,rear wall

2 316015905 A B Shield-backguard,inner

11 316061851 A B Trim-wrapper,textured ,black

11 316083719 A B Trim-wrapper,textured ,black

14 316022503 A B Light/Lamp, indicator , surface ,250 V

15 316023108 A B Support-backguard,RH

15A 316023109 A B Support-backguard,LH

19 316100534 A B Panel-control,black

20 # 316101001 A B Clock/Timer

20* 316101503 A B Overlay-clock

23 316100301 A B Bracket-timer

24 # 316118100 A B Switch-rocker, black

36 316025108 A B Knob-control, infinite sw, black

40 316025800 A B Panel-manifold

46 316040201 A B Lens-light/lamp,indicator ,red

54 # 316021500 A B Switch-infinite, 6" element

54A# 316021501 A B Switch-infinite, 8" element

69 5303292005 A B Screw-switch/handle,8-32 x 5/32

08/00 4

Publication number

5995342150 FEF365BGDD, FEF365BGWD

CAUTION: Use the part number on all orders, not the position number.

BODY

# - Fast Moving Parts

* - Non Illustrated Parts 5 08/00

Publication number

FEF365BGDD, FEF365BGWD 5995342150

CAUTION: Use the part number on all orders, not the position number.

BODY

A = FEF365BG (FEF365BGDD)

B = FEF365BG (FEF365BGWD)

POS. NO PART NO DESCRIPTION

* 3203550 A B Plug-button

* 316021105 A B Screw,hex ,8-18 x 0.375 ,back\bodyside

* 316021108 A B Screw,cup pt ,8-18 x 0.375 ,hinge ,

* 316045000 A B Clip-wire,harness ,main top

* 316101600 A B Shield-vent,smoothtop

* 5303051099 A B Nut,hex ,#10-32

1 316080804 A B Back-main

3 316081034 - B Panel-bodyside,white ,RH

3 316081036 A - Panel-bodyside,almond ,RH

3 316081035 - B Panel-bodyside,white ,LH

3 316081037 A - Panel-body side,almond ,LH

5 316129200 A B Screw-leveling,plastic ,with stop

6 316067902 A B Rack-oven

7 316007002 A B Hinge-oven door,(2)

8 3203540 A B Panel-oven bottom

9 316081900 A B Pan-broiler

10 316082000 A B Insert-broiler pan

12 # 316027701 A B Switch-oven light

13 316026800 A B Rod-light switch /door

14 316116400 A B Socket-light

15 5303013071 A B Light Bulb/Lamp

16 08011086 A B Lens-light/lamp, glass , oven

17 316087500 A B Retainer-lens

18 # 316036300 A B Latch-door

21 3014099 A B Spacer-bodyside, (8)

25 3200848 A B Shield-heat,lower

29 3051162 A B Glide-drawer,front

37 # 316111202 A B Probe-oven temp

41 3131570 A B Cover-hinge cutout

44 3131903 A B Bumper-door/drawer, rubber

45 316066100 A B Shield-wire, s/t vent

57 316081101 A B Cover-access

58 3200847 A B Insulation,oven bottom

58A 316047708 A B Insulation, 2" ,oven wrapper

58B 316054200 A B Insulation, 2" ,oven back

59 316073602 A B Tube-oven vent

59A 316023600 A B Tube-oven vent,upper

59B 316040100 A B Bracket-mounting,vent tube

62 # 5303935061 A B Terminal Block

62* 316085600 A B Insulator

63 5301145190 A B Plate-ground strap

66 # 5303051140 A B Element-broil

67 # 316075103 A B Element-bake,67

68 316075300 A B Support-element, broil

71 316015805 A B Shield-rear wall

72 5303285692 A B Cover-light/switch rod

82 5303289913 A B Shield-insulation

87 316081200 A B Bracket-cable mtg

88 316026400 A B Rod-latch,auto

89 # 316028101 A B Motor-latch/lock

170 316107200 A B Anti-tip bracket

170* 316116000 A B Screw-Anti-tip,1.75” concrete

170* 5303935180 A B Kit-Anti-tip bracket(complete w/template & screws)

08/00 6

Publication number

5995342150 FEF365BGDD, FEF365BGWD

CAUTION: Use the part number on all orders, not the position number.

TOP/DRAWER

# - Fast Moving Parts

* - Non Illustrated Parts 7 08/00

Publication number

FEF365BGDD, FEF365BGWD 5995342150

CAUTION: Use the part number on all orders, not the position number.

TOP/DRAWER

A = FEF365BG (FEF365BGDD)

B = FEF365BG (FEF365BGWD)

POS. NO PART NO DESCRIPTION

* 3131903 A B Bumper-door/drawer, rubber

* 316021105 A B Screw,hex ,8-18 x 0.375 ,back\bodyside

* 316021108 A B Screw,cup pt ,8-18 x 0.375 ,hinge

* 316021110 A B Screw,semi gim ,8-18 X 1/2 ,black

* 316021112 - B Screw-8-18x1/2 Tr Sqd White

* 316021113 A - Screw-8-18x1/2 Tr Sqd Almond

* 316045000 A B Clip-wire,harness ,main top

* 316089600 A B Spacer-drawer,(2)

* 316112101 A B Cleaner-cooktop

* 5303280311 A B Screw, waf hd sdr , 10-32 x 5/16 , (2)

* 5308014215 A B Screw

1 316011501 A B Drawer-utility

2 3131975 A B Shield-panel

4 316084405 - B Panel-drawer,white

4 316084406 A - Panel-drawer,almond

4* 08067785 A - Screw,hex washer head ,8-18AB x 1/2

7 3051163 A B Glide-drawer,rear

10 5303280308 A B Screw-handle mtg,wafer head ,10-24T x 2

15A# 318178100 A B Element-surface,radiant ,small/6 inch ,1200W

15# 318178101 A B Element-surface,radiant, large,2100W

16 316098103 - B Main Top,white

16 316098104 A - Main Top,smooth top ,almond

18 5303273062 A B Hinge-main top,RH

18A 5303273063 A B Hinge-main top,LH

26 316099101 A B Channel-support,element

26A 316099201 A B Bracket-support,chassis

48 316100200 A B Shield-wire,main top

51 80142193 A B Indicator light

52 316099400 A B Clip-spring, element mtg,(8)

53 316099300 A B Bracket-indicator light,hot surface ,4 hole

88 316099500 A B Pin-guide, (2)

08/00 8

Publication number

5995342150 FEF365BGDD, FEF365BGWD

CAUTION: Use the part number on all orders, not the position number.

DOOR

# - Fast Moving Parts

* - Non Illustrated Parts 9 08/00

Publication number

FEF365BGDD, FEF365BGWD 5995342150

CAUTION: Use the part number on all orders, not the position number.

DOOR

A = FEF365BG (FEF365BGDD)

B = FEF365BG (FEF365BGWD)

POS. NO PART NO DESCRIPTION

* 3203618 A B Rivet-pop,warning-plate

* 316008401 A B Washer,3/4 x 1/4 ,steel

* 316021110 A B Screw,semi gim ,8-18 X 1/2 ,black

* 316065306 A B Plate-warning/caution

* 316132100 A B Spacer,sponge pad

* 5303212762 A - Screw,8-18 X 1/2

* 5303271648 A B Screw,wafer hd sq dr ,8-18AB x 1/2 ,

* 5303280311 A B Screw, waf hd sdr , 10-32 x 5/16 , (2)

* 5303292005 A B Screw-switch/handle,8-32 x 5/32

3 316067802 A B Trim-oven door,black

4 316089000 A B Glass-oven door,black ,outer

5 316088700 A B Glass-oven door,airwash

6 316088401 A B Shield-wool

7 316076403 A B Insulation-door

8 316088600 A B Glass-oven door,inner

9 316066610 A B Liner-oven door

10 5303280308 A B Screw-handle mtg,wafer head ,10-24T x 2

12 # 5303131601 A B Seal-oven door

14 5303208656 A B Reflector,aluminum foil

14A 5303208655 A B Reflector,aluminum foil

15 316081403 A B Bracket-glass mtg

16 316085701 A B Glass-oven door,heat barrier

39 316091114 A B Handle-door,black ,oven

52 316081303 A B Shield-oven door,black ,top

08/00 10

Publication number

5995342150 FEF365BGDD, FEF365BGWD

CAUTION: Use the part number on all orders, not the position number.

WIRING DIAGRAM
