WMPTAC02 (10-02)

Parts Manual

Packaged Terminal Air Conditioner

T Series

PTPT

PTACAC

ACAC

WallMaster

PTAC Model Number Identification Guide .............................................................. 3

PTAC Serial Number Identification Guide ............................................................... 3

Unit Assembly Drawing .......................................................................................... 4

Unit Assembly Parts List ........................................................................................ 5

Air Handler ............................................................................................................. 6

Air Handler Parts List ............................................................................................. 7

Control Box Assembly ............................................................................................ 8

Control Box Parts List ............................................................................................ 9

Front Cover Assembly Drawing ............................................................................. 10

Front Cover Parts .................................................................................................. 10

Central Desk Control Models ................................................................................ 11

Remote Thermostat Models .................................................................................. 11

Drain Kits and Flex Drive Retrofit Kits ................................................................... 11

Service Parts List .................................................................................................. 11

Notes & Comments ............................................................................................... 12

Table of Contents

PTAC Model Number Identification Guide

Model Number T H C 07 K 25 ST C

Series Engineering Code

T = T Series A - B - C

Unit Type Option

E = Electric Heat/No Heat ST = Standard Unit

H = Heat Pump RT = Remote Thermostat

Design Series DC = Central Desk Control

C = Friedrich Manufactured SP = Seacoast Protection

A & B = ICP Manufactured

Nominal Heater Size

Nominal Cooling Capacity (@ 230V or 265V)

07 = 6,500 - 7,200 BTUh 12 = 11,500 - 12,200 BTUh 00 = No electric heater

09 = 8,500 - 9,200 BTUh 15 = 14,000 - 15,000 BTUh 25 = 2.5 KW

34 = 3.4 KW

Voltage 50 = 5.0 KW

K = 208/230V - 1PH - 60Hz R = 265V - 1PH - 60Hz

Notes & Comments

Note Units Affected Note or Comment

Heat Pump All Identifies the parts or components used specifically in the heat

THC units pump units. All other components are consistent with all other

units.

Note 1 Identifies the parts or components used specifically in units built

A, B & C suffix prior to August 1997 (serial prefix JGHP.....)

Note 2 All Identifies the parts or components used specifically in units built

C suffix only starting September 1997 (serial prefix JGJP.....) to current.

Note 3 All The thermostat was changed from the original that had a short

A & B suffix only 3/8” diameter bulb to the thermostat that has a long 1/4” bulb.

Both have the same operating range. If changing from the 3/8”

bulb this kit is required.

265V All Identifies the parts or components used specifically in units built

Voltage code R to operate on 265V 1PH 60Hz (same as 277V 1PH 60Hz)

Serial Number JG A P 00000

Production Run Number

Year Manufactured

A = 1 D = 4 G = 7 K = 0

B = 2 E = 5 H = 8 Manufacturing Location

C = 3 F = 6 J = 9 S = San Antonio

Month Manufactured P = San Antonio

A = Jan D = Apr G = Jul K = Oct

B = Feb E = May H = Aug L = Nov

C = Mar F = Jun J = Sep M = Dec

PTAC Serial Number Identification Guide

Unit Assembly

Key Part Number Description 07 09 12 15 Notes

10 25016900 Coil, Evaporator 1

25018600 Coil, Evaporator 1 1 1

N/S 20094777 Capillary, Tube .054X37" 1

21058777 Capillary, Tube .054X22" 1

21058804 Capillary, Tube .064X24" 1

21058885 Capillary, Tube Heating/Cooling .070X29" 1 *

NS 21058713 Capillary, Tube Heating .049X17" 1 Heat Pump

21058787 Capillary, Tube Heating .049X13" 1 Heat Pump

21058812 Capillary, Tube Heating .049X17" 1 Heat Pump

NS 21058587 Check Valve 1 1 Heat Pump

21058568 Check Valve 1

NS 25018200 Reversing Valve (less coil) 1 1 Heat Pump

25018300 Reversing Valve (less coil) 1 1 Heat Pump

NS 21058643 Solenoid Coil Reversing Valve (230V) 1 1 1 1 Heat Pump

21058644 Solenoid Coil Reversing Valve (265V) 1 1 1 1 Heat Pump

11 25024901 Compressor 230V 1

21058641 Compressor 230V 1

21091571 Compressor 230V 1

21091573 Compressor 230V 1

25024900 Compressor 265V 1

21058642 Compressor 265V 1

21091572 Compressor 265V 1

21091574 Compressor 265V 1

12 25017000 Coil, Condenser 1 1

25017100 Coil, Condenser (Seacoast Protection)11

25019100 Coil, Condenser 1 1

25019200 Coil, Condenser (Seacoast Protection)11

13 21058599 Overload, Compressor 230V 1

21090197 Overload, Compressor 230V 1

60364596 Overload, Compressor 230V 1

61764506 Overload, Compressor 230V 1

21058614 Overload, Compressor 265V 1

21058621 Overload, Compressor 265V 1

21090034 Overload, Compressor 265V 1

21091325 Overload, Compressor 265V 1

14 25025900 Interior Grill (Starting w/ Serial No, JGJP) 1 1 1 1

15 21058694 Screen 1 1 1 1

16 25026100 Cut Off Plate - Evaporator 1 1 1 1

17 21058833 Outdoor Condenser Cutoff 1 1 1 1

18 21058553 Condensate Tube 1 1 1 1

19 21058876 Distribution Tray 1 1 1 1

20 21058402 Filter 1 1 1 1 note 1

25025600 Filter (top removal only) 1 1 1 1 note 2

21095059 Filter (Heavy Duty; 10 Pack Only) note 1

Unit Assembly Parts List

* A single capillary tube is used for both heating and cooling

** Units JGHP and prior require both the intake grille and the cutoff plate if either is to be replaced.

Air Handler

Page 5

Key Part Number Description 07 09 12 15 Notes

31 21058386 Blower Housing 1 1 1

21058867 Blower Housing 1

32 21062325 Blower Access Cover 1 1 1 1

33 21062145 Plate, Bearing Support 1 1 1 1

34 21058350 Scroll, Blower with Insulation 1 1 1

21059150 Scroll, Blower with Insulation 1

35 25007800 Blower Wheel, Indoor (evaporator) 1 1 1 1

36 25007801 Blower Wheel, Outdoor (condenser) 1 1 1

25007802 Blower Wheel, Outdoor (condenser) 1

37 21064013 Belt (black) 1 1 1

21064014 Belt (clear) 1

38 25009500 LH Pulley & Bearing Assy (outdoor wheel) 2.0” 1 1

25009400 LH Pulley & Bearing Assy (outdoor wheel) 2.5” 1 1

39 25009200 RH Pulley & Bearing Assy (Indoor wheel) 3.0” 1 1 1

25009300 RH Pulley & Bearing Assy (Indoor wheel) 2.5” 1

40 25009600 Short Shaft Bearing Assy (indoor wheel) 1 1 1 1

41 21062146 Isolator (without hole, pulley end) 2 2 2 2

42 21063375 Isolator (with hole idle end) 1 1 1 1

43 21058509 Bearing Cap 1 1 1 1

44 25021000 Outdoor Blower Flex Hub 1 1 1 1

NS 25009700 RH Collar Plate 1 1 1 1

NS 25009800 LH Collar Plate 1 1 1 1

45 21061128 Motor, 230V 1/10hp 1

21061127 Motor, 230V 1/4hp 1 1

21061131 Motor, 230V 1/4hp 1

21061130 Motor, 265V 1/8hp 1 265V

21061129 Motor, 265V 1/5hp 1 1 265V

21061132 Motor, 265V 1/4hp 1 265V

46 21058397 Vent Door 1 1 1 1

NS 21058398 Vent Door Lever 1 1 1 1

NS 21058530 Spring, Vent Door Lever 1 1 1 1

47 25006500 Retainer, Insulation 1 1 1

25006501 Retainer, Insulation 1

48 21058387 Insulation, Blower Access Cover 1 1 1 1

49 21058512 Heater, 2.5kW @ 230V 1 1 1 1

21058513 Heater, 3.4kW @ 230V 1 1 1 1

21058522 Heater, 5.0kW @ 230V 1 1 1 1

21058523 Heater, 2.5kW @ 265V 1 1 1 1 265V

21058524 Heater, 3.4kW @ 265V 1 1 1 1 265V

21058525 Heater, 5.0kW @ 265V 1 1 1 1 265V

50 21058407 Limit Switch, 2.5kW Heater 1 1 1 1

21058408 Limit Switch, 3.4kW Heater 1 1 1 1

21058409 Limit Switch, 5.0kW Heater 1 1 1 1

51 21059141 Baffle 1 1 1 1

Air Handler Parts List

Control Box Assembly

Control Box Parts List

Key Part Number Description 07 09 12 15 Notes

60 25032800 Pump, Condensate 230V 1 1 1 1

25032900 Pump, Condensate 265V 1 1 1 1 265V

61 21058433 Switch, Fan Speed Hi/Lo 1 1 1 1

62 21058433 Switch, Fan Continuous/Cycle 1 1 1 1

63 25011100 Thermostat, Defrost 1 1 1 1 Heat Pump

64 61080345 Capacitor 15/7.5mfd@440V 230V 1 1

61080343 Capacitor 15/5.0mfd@370V 265V 1 265V

61080339 Capacitor 25/5.0mfd@370V 265V 1 265V

61080337 Capacitor 25/7.5mfd@370V 230V 1 1

61080344 Capacitor 25/5.0mfd@440V 265V 1 1 265V

65 61822401 Thermostat, Indoor 1 1 1 1

21058517 Thermostat, Indoor 1 1 1 1 Note 3

25026700 Thermostat, (Kit for units prior to s/n JFLS ) 1 1 1 1 Note 3

66 21058437 Knob, Thermostat 1 1 1 1

NS 21058518 Retainer Clip, Thermostat Bulb (21058517) 1 1 1 1

NS 61715101 Retainer Clip, Thermostat Bulb (61822401) 1 1 1 1

67 25033400 Switch, Push-button 4 position 1 1 1 1

21058708 Switch, Push-button 3 position no heat unit 1 1 1 1

68 21058728 Push-button 4 4 4 4

69 21058427 Plate, Control Box 1 1 1 1

70 21058516 Plate, Dial 1 1 1 1

71 21058582 Cord, 15 amp (2.5 kW@230V) 1 1 1 1

21058583 Cord, 20 amp (3.4 kW@230V) 1 1 1 1

21058584 Cord, 30 amp (5.0 kW@230V) 1 1 1 1

72 60084036 Relay, Heat Anticipator (230V) 1 1 1 1 note 2

60084037 Relay, Heat Anticipator (265V) 1 1 1 1 note 2

73 25027901 Heat Anticipator (230V) 1 1 1 1 note 2

25027900 Heat Anticipator (265V) 1 1 1 1

74 21058444 Fuse Holder (2.5 kW @ 265V) 1 1 1 1 265V

21058446 Fuse Holder (3.4 kW @ 265V) 1 1 1 1 265V

21058447 Fuse Holder (5.0 kW @ 265V) 1 1 1 1 265V

NS 21058448 Fuse Time Delay (2.5 kW @ 265V) 1 1 1 1 265V

21058449 Fuse Time Delay (3.4 kW @ 265V) 1 1 1 1 265V

21058451 Fuse Time Delay (5.0 kW @ 265V) 1 1 1 1 265V

75 25028000 Control Box 1 1 1 1

76 21062001 Divider Wall 1 1 1 1

77 21058398 Vent Door Lever 1 1 1 1

NS 21058530 Spring, Vent Door Lever 1 1 1 1

Front Cover Parts

Key Part Number Description 07 09 12 15 Notes

91 21067151 Front Cover Complete (includes #92 & #93) 1 1 1 1 note 1

25027500 Front Cover Complete (includes #92 & #93) 1 1 1 1 note 2

92 25031900 Control Door 1 1 1 1

93 21058685 Return Air Grill 1 1 1 1

94 25025600 Filter (top removal only) 1 1 1 1 note 2

NS 21058402 Filter 1 1 1 1 note 1

NS 21095059 Filter (heavy duty) (10 pack only) note 1

Front Cover & Front Cover Parts List
