FOURKAY FKA07M1 Manuel utilisateur

U S E R M A N U A L

4X4 HDMI Matrix

Model No:

A07M1

Dear customer

INTRODUCTION

FEATURES

Thank you for purchasing this product. For optimum performance and safety, please

read these instructions carefully before connecting, operating or adjusting this

product. Please keep this manual for future reference.

Our series of HDMI converters, switchers, extenders, matrixes and splitters are designed

to make your A/V device use more convenient, more comfortable, more productive

and more cost-efficient.

The 4x4 HDMI Matrix can connect four HD Sources with four HD Displays; it can easily

switch and distribute four HD Source signals to four HD displays at the same time.

Our devices offer solutions for noise, space and security concerns, data center control,

information distribution, conference room presentation, school and corporate training

environments.

● Four Input HD Source signals switch and distribute to four HD Displays

● Support 30/36 Bit Deep Color

● Support Blue-Ray DVD24/50/60fs/HD-DVD/xvYCC

● Support Audio Format:DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD

● Support Signal Retiming

● Input HDMI Cable length up to 10M if use the standard AWG26 HDMI Cable;

Output HDMI Cable length up to 15M if use the standard AWG26 HDMI Cable.

● Use12V1.5A Power Adaptor

www.FOURKAY.net

Package Content:

1. Main Unit

2. Power Adaptor

3. Remote

4. User Manual

5. CD （RS232 Control Software）

6. IR Extender Cable

7. RS232 Serial Port Cable

1- 4：HDMI Input Status Led Light

IR ：infrared sensor

Switch A ：HDMI A Port Switch Button

Switch B ：HDMI B Port Switch Button

Switch C ：HDMI C Port Switch Button

Switch D ：HDMI D Port Switch Button

Picture 1.0 Front Panel Picture

Pictures Showing Ports:

12V: Power Port

IR Extend：IR Extend Port

Picture 1.1 Rear Panel Picture

Output A-Output D：HDMI Output Port

Input 1- Input 4 ：HDMI Input Port

Picture 1.2 Side Panel Picture

RS232：RS232 Serial Port

OPERATION AND CONNECTION:

1. Use HDMI cables to connect four HD sources with the HDMI input ports of the matrix.

2. Use HDMI cables to connect four HD displays with the HDMI output ports of the matrix.

3. Connect the power adaptor with the matrix.

4. Use the RS232 cable to connect the RS232 port of the matrix with your control equip-

ment to control to the matrix.

IR E xt end

1234 A B CD

IN PU T OU T PU T

SPECIFICATIONS:

HDMI Input/Output Resolution……24/50/60fs/3D/1080p/1080i/720p/576p/5

76i/480p/480i

Deep Color…………………………………..……24bit/deep color 30bit,36bit

HDMI Audio Format……DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD

HDMI Max bandwidth………………………………………………………225MHz

HDMI Max baud rate…….…………………….…………………………6.75Gbps

Input/Output TMDS signal …………….…………………0.5~1.5Volts p-p（TTL）

Input/Output DDC signal…………….……………………………5Volts p-p (TTL)

HDMI Input cable distance.…... ………≤10m AWG26 HDMI standard cable

Output cable distance…………………≤15m AWG26 HDMI standard cable

Max working current……………………………….………………………...900mA

Power adapter format…………………..………………………….………12V/1.5A

Operating Temperature range……..…………….…….…………(-15 to +55℃)

Operating Humidity range……………………5 to 90%RH (No Condensation)

Product size (L x W x H)……………………………….…………308X151X36 (mm)

Weight…..………………………………………………………..……………1216g

COM Select : Choose your COM port; click the "Connect" button. The "Connect"

button will light up and matrix will be under control.

Message Receive ：Shows the information received from the device.

Status: Refresh current status info.

Clear ： Delete the print info at the window.

EDID Setting ： Preset the best EDID or copy the chosen output port EDID and

save it to the device.

Button A-D ：Represent the four output ports

Button 1-4 ： Represent the chosen Input sources. The bright number represents

the current chosen input source.

Matrix RS232 Control Software

Serial Port Protocol

Serial Port Protocol Format: Lenght+Start Code(0x55)+Instruciton Code+Parameter

(It can be without)+Finish Code(0x77)

Command (hex) feedback description

0x04 0x55 0x20 0x77 \r\n s1x s2x s3x s4x EEx

To get the output port working

status and the EDID status.

0x05 0x55 0x19 0x09 0x77 s10

0x05 0x55 0x19 0x1D 0x77

0x05 0x55 0x19 0x1F 0x77

0x05 0x55 0x19 0x0D 0x77

0x05 0x55 0x19 0x17 0x77

0x05 0x55 0x19 0x12 0x77

0x05 0x55 0x19 0x59 0x77

0x05 0x55 0x19 0x08 0x77

0x05 0x55 0x19 0x5E 0x77

0x05 0x55 0x19 0x06 0x77

0x05 0x55 0x19 0x05 0x77

0x05 0x55 0x19 0x03 0x77

0x05 0x55 0x19 0x18 0x77

0x05 0x55 0x19 0x44 0x77

0x05 0x55 0x19 0x0F 0x77

0x05 0x55 0x19 0x51 0x77

0x05 0x55 0x18 0x00 0x77

0x05 0x55 0x18 0x01 0x77

0x05 0x55 0x18 0x02 0x77

0x05 0x55 0x18 0x03 0x77

0x05 0x55 0x18 0x04 0x77

0x05 0x55 0x18 0x05 0x77

0x05 0x55 0x18 0x06 0x77

0x05 0x55 0x18 0x07 0x77

0x05 0x55 0x18 0x08 0x77

0x05 0x55 0x18 0x09 0x77

0x05 0x55 0x18 0x0a 0x77

s11

s12

s13

s20

s21

s22

s23

s30

s31

s32

s33

s40

s41

s42

s43

Ee0

Ee1

Ee2

Ee3

Ee4

Ee5

Ee6

Ee7

Ee8

Ee9

Eea

Output 1 chosen the input 1

EDID mix

EDID copy form output 1

EDID copy form output 2

EDID copy form output 3

EDID copy form output 4

EDID 2D 2CH

EDID 2D 5.1CH

EDID 2D 7.1CH

EDID 3D 2CH

EDID 3D 5.1CH

EDID 3D 7.1CH

Output 1 chosen the input 2

Output 1 chosen the input 3

Output 1 chosen the input 4

Output 2 chosen the input 1

Output 2 chosen the input 2

Output 2 chosen the input 3

Output 2 chosen the input 4

Output 3 chosen the input 1

Output 3 chosen the input 2

Output 3 chosen the input 3

Output 3 chosen the input 4

Output 4 chosen the input 1

Output 4 chosen the input 2

Output 4 chosen the input 3

Output 4 chosen the input 4

1. The machine should be placed far from damp, high-temperature, dusty,

and corrosive environments.

2. Do not shake, hit or drop the matrix.

3. Do not touch the power adaptor or matrix with the wet hands.

4. Do not pull the power adaptor from the electric socket by the cord.

5. Please turn the power off when the machine is not use for long time.

6. Do not open the cover and do not touch the internal parts.

7. Please use the original factory supplied power adaptor.

Notes:

Pls use the machine according to the instructions to ensure long use lifetime of

the matrix.

Before powering the device on, please check the connections line carefully.

Make sure that all interfaces are properly connected.

BAUD RATE 9600

DATA BITS = 8

PARITY = No

FLOW CONTROL = NONE

STOP BITS = 1
