IV5016-E Issue J Page 6 of 7
150 cm free bre
ca. 11 cm tube
6C. Fibre tubes, in corrugated tubes
6.7 Preparaon of cable when using corrugated tube
Strip the cable 161 cm + the length of the corrugated tube and prepare as
shown in drawing 6.7. If rubber tubes, do not ghten the e-wraps too hard.
The tubes may in this case be 19 cm outside the corrugated tube and end as in
drawing 6.8.
Protect the bre-tubes using foam tape and fasten the tubes to the two
foremost punched out mounts in the drawer using e-wraps. The foam tape
will also protect the tubes from slipping. The corrugated tube is fastened with
e-wraps to the holes in the back-wall as shown in drawing 6.8.
Then follow the instrucons in chapter 6A gure 6.3, or chapter 6B gure 6.5
depending on number of bres.
6.8 Fastening of the corrugated tube.
Prepare the cable(s) as shown in drawing 6.4. It may be benecial to await
cung the tubes unl the respecve bres are to be used.
Loosen the snap-latches and pull out the drawer.
Up to 96 bres (LC): Insert the adapters from the outside with the key to
the right.
72 bres (SC)/144 bres (LC): Insert two adapters in each hole.
Both adapter types are inserted with the keys away from each
other (one le and one right) as shown.
Mount two splice holders in the two mid holes (one for each holder) as shown
in drawing 6.5. They are xed with rivets through one of the “nut holes” at
the end of the holder (shown as black dots).
Fasten the cable to the two foremost punched out mounts and to the lower
hole in the back-wall of the drawer using e-wraps. Any excess cable must be
handled outside of the panel
The adapter plate may be lied up and turned to give easier access to the
adapters on the inside. See ch. 4.3. Clean the adapters.
IMPORTANT: If the pigtails are more than 1.2 m long, they should be cut to
this length.
Aach splice protectors and splice the rst 4 bres, put the bres in the bre
guide crosses as shown in drawing 6.6 and place the splice protectors in the
splice holders. Clean the connectors and insert them in the adapters. Follow
the colour coding.
Connue with 4 and 4 bres unl the rst splice holder is full. Put the second
splice holder on top of the rst (clipped on, turned 180° compared to the
rst). Splice and place the next 12 bres, bre 13 to 24 in track 1 to 12 of this
splice holder.
Connue in the same way unl the le stack of the splice holder have
covered half of the total bre count. Then connue with the right stack.
Close the bre guides (see picture 3.2.1).
6.5 Fastening of cable .
6.6 Finished panel.
6.4 Cable preparaon.
6B. Fibre tubes, over 48 bres (High Density)
1
1-48
or
1-72
(2)
49-96
or
73-144
48 (SC) or 96(LC)
72 (SC) or 144(LC)
1 4
5 8
1 4
150 cm
8 cm
112
