User

User Manual

Manual

Wireless IP Camera

Model: R3 R5 X3 X5 X3E

V1.0

Table of Contents

Security Warning................................................................................................................................................................... 1

1 Overview............................................................................................................................................................................. 2

1.1 Key Features...........................................................................................................................................................2

1.2 Read before Use.................................................................................................................................................... 3

1.3 Packing Contents................................................................................................................................................... 3

1.4 Physical Description.............................................................................................................................................. 3

1.5 SD Card Management...........................................................................................................................................4

1.6 Add Device: Connection via the Foscam App................................................................................................... 5

1.7 Installation............................................................................................................................................................... 5

2 Default Parameters........................................................................................................................................................... 6

3 Specification....................................................................................................................................................................... 7

Security Warning

Please change the password of your doorbell regularly, using a combination of numbers, letters and

special characters.

We recommend that you regularly update your doorbell to the latest available software and firmware

versions to help ensure the best experience for your doorbell.

1 Overview

Welcome to use our product, Foscam Camera. Foscam Camera is an integrated IP Camera with a color

CMOS sensor enabling viewing in High Definition resolution.It combines a high quality digital video camera,

with a powerful free Foscam Video Management Software，to bring clear video to your desktop from anywhere

on your network or over the APP.

It supports P2P function. Thanks to the P2P easy access technology, you don’t need to do complicated Port

Forwarding and DDNS settings, you just need to scan the QR code on the side of the camera to connect it on

smart phone, or input the UID on CMS software to realize remote access.

The Doorbell supports the industry-standard H.265 compression technology, drastically reducing file sizes and

conserving valuable network bandwidth.

The camera is designed for indoor surveillance with wide applications such as at home, in retail store and in

office. Controlling the camera and managing images are simplified by using the provided web interface across

the network in either wired or wireless way.

1.1 Key Features

3.0Megapixels Pan/Tilt Wireless IP Camera(R3 X3), 5.0Megapixels Pan/Tilt Wireless IP Camera(R5 X5

X3E)

Supports WPA and WPA2 Encryption

Support full duplex real-time 2-way Audio

Supports AI algorithm (Humanoid detection)

P2P Feature for Easy Remote Access

H.265/H.264 video Compression

Motion/Sound/Human Detection

Support 2.4GHz WiFi

Supports image snapshot

Supports dual-stream

Built-in High efficiency IR LED, has excellent night vision image

Supports remote viewing & record from anywhere anytime

Multi-level users management with password protection

Supports multiple network protocols: IP、TCP、UDP、DHCP,RTSP,Onvif

Providing Video Management Software to manage or monitor multi-cameras

Supports Alexa

Supports Google Assistant

Supports 128G Micro SD Card Storage(External)

1.2 Read before Use

Please first verify that all contents received are complete according to the Package Contents listed below.

Before the Network Camera is installed, please carefully read and follow the instructions in the Quick Setup

Guide to avoid damage due to faulty assembly and installation. This also ensures the product is used properly

as intended.

1.3 Packing Contents

● IP Camera × 1

● Mounting Platet × 1

● AC Adapter × 1

●USB Power Cable× 1

● Quick Setup Guide × 1

● Ethernet Cable× 1（Only X3 X5）

● Expansion Screws × 1

1.4 Physical Description

X3 X5:

R3 R5:

Lens: Fixed focus lens

Microphone: Built-in Microphone.

Speaker: Built-in speaker

LAN: 10/100 Mbps RJ-45 port for wired connection(Only support X3 X5 )

Power : : DC 5V/1.5A or DC 5V/2A Power supply.

Reset: Press and hold on the reset button for 3 seconds. Releasing the reset button, the password will back to

the factory default administrator password.

Micro SD Card slot: Supports up to 128GB SD card for storing the video.

1.5 SD Card Management

The record files of the IP camera can be stored in the Micro SD Card.

This camera supports Micro SD Card and the max size of Micro SD card must be under 128G.

You need to find the Micro SD card slot on the camera body and insert the Micro SD card, then plug the Micro

SD card into Micro SD card slot inside the IP camera.

When you plug in the Micro SD card during the camera work process, please reboot the camera again, or else

the Micro SD Card may be cannot work well.When you re-install the cover, please ensure the tightness with

the camera.

1.6 Add Device: Connection via the Foscam App

Scan the QR code below to download and install the Foscam APP.

Please refer to the Quick Setup Guide.

1.7 Installation

Please refer to the Quick Setup Guide.

1.Place the camera directly on a desk.

2.Install the mounting plate on a wall or ceiling with the supplied fixing screws.

Note: Align points a and b to insert the camera base to the mounting plate. Rotate so that points a and b are

aligned, which attaches the camera securely to the base.

2 Default Parameters

Default network parameters

IP address: obtain dynamically

Subnet mask: obtain dynamically

Gateway: obtain dynamically

3 Specification

ITEMS

R3/X3

Image Sensor

Sensor

High Definition Color CMOS Sensor

Display Resolution

3.0M Pixels

Min. Illumination

0 Lux (With IR Illuminator)

Lens

Lens Type

Glass Lens

focal length

f 3.6mm

Aperture

F 2.4

Angle of view

Diagonal:89° Horizontal:71° Vertical :52°

Video

Image Compression

H.265/H.264

Image Frame Rate

Max25fps (3MP), downward adjustable

Resolution

3MP,1080P, 720P,VGA

Stream

Dual stream

Image adjustment

The hue, brightness, contrast, saturation, sharpness are adjustable

Pan/Tilt Angle

Horizontal:350° & Vertical:70°

Flip image

Flip and mirror

Infrared mode

4pcs SMD IR-LEDs

Night mode

Automatic modes

Night visibility

8 m

Audio

Input/Output

Two-way audio,build-in microphone and speaker

Audio Compression

PCM/ AAC

Network

Ethernet

R3:N/A, X3: YES

Wireless Standard

IEEE802.11b/g/n

Data Rate

IEEE802.11b: 11Mbps(Max.);

IEEE802.11g: 54Mbps(Max.);

IEEE802.11n: 150Mbps(Max.).

Wireless Security

WPA, WPA2

Remote Access

P2P

Wifi configuration

mode

Support scan QR code

Network Protocol

IP、TCP、UDP、DHCP,RTSP,Onvif

System

Requirements

Operating System

Microsoft Windows XP,7,8,10;Mac OS;iOS、Android

Other

Features

Motion Detection

Push message to mobile phone and push stream to Cloud

Sound Detection

Push message to mobile phone and push stream to Cloud

Human Detection

Push message to mobile phone and push stream to Cloud

Privacy Block

Yes

User Accounts

Three levels user role

Reset

Reset button is available

Power

Power Supply

Micro USB 5V/1.5A or 5V/2A

Power Consumption

7.5Watts (Max.)

Physical

Dimension(LxWxH)

83(L)x76 (W)x114 (H) mm

Net Weight

186g

Environment

Operating

Temperature

-10°C~ 50°C (14°F ~ 122°F)

Operating Humidity

20% ~ 85% non-condensing

Storage

Temperature

-20°C ~ 60°C (-4°F ~ 140°F)

Storage Humidity

0% ~ 90% non-condensing

Certification

CE, FCC, RoHS,WEEE

ITEMS

R5/X5/X3E

Image Sensor

Sensor

High Definition Color CMOS Sensor

Display Resolution

5.0M Pixels

Min. Illumination

0 Lux (With IR Illuminator)

Lens

Lens Type

Glass Lens

focal length

f 3.6mm

Aperture

F 2.4

Angle of view

Diagonal:89° Horizontal:71° Vertical :52°

Video

Image Compression

H.265/H.264

Image Frame Rate

Max15fps (5MP), downward adjustable

Resolution

5MP,1080P, 720P,VGA

Stream

Dual stream

Image adjustment

The hue, brightness, contrast, saturation, sharpness are adjustable

Pan/Tilt Angle

Horizontal:350° & Vertical:70°

Flip image

Flip and mirror

Infrared mode

4pcs SMD IR-LEDs

Night mode

Automatic modes

Night visibility

8 m

Audio

Input/Output

Two-way audio,build-in microphone and speaker

Audio Compression

PCM/ AAC

Network

Ethernet

R5:N/A, X5: YES

Wireless Standard

IEEE802.11b/g/n

Data Rate

IEEE802.11b: 11Mbps(Max.);

IEEE802.11g: 54Mbps(Max.);

IEEE802.11n: 150Mbps(Max.).

Wireless Security

WPA, WPA2

Remote Access

P2P

Wifi configuration

mode

Support scan QR code
