Fortis T300 Manuel utilisateur

ELECTRIC FOLDABLE

TREADMILL T300

FSEFBTM300A

1. Caution

To a v o i d i n j u r y, p l e a s e r e a d t h i s m a n u a l c a r e f u l l y b e f o r e u s e .

• For safety purposes, do not stand on the running belt when starting the unit.

• Please stop immediately if you feel any nausea or the unit’s motion is no longer

smooth.

• Always increase or decrease speed at a slow rate.

• Never adjust the belt during use.

• It is suggested to wear sports shoes when using the machine.

• Children, the elderly, pregnant women should not use the machine.

• Always clip the safety key on your clothing during use.

• Firmly hold the grip bars during use

2. Safety Information

• Place the machine on flat ground. Do not use the machine in the following

locations:

1. Outdoors. (The machine is specially designed for indoor use only).

2. Any ground that is uneven.

3. Any areas in high sunlight or in close proximity to heating units.

• The input for the machine is AC 220V.

• An error may appear if the power is not stable. The unit must not have any other

items connected to the same power socket and should not be used through a

power board.

• It is suggested to wear sports shoes and gym clothes when using the machine.

• Always increase or decrease speed at a slow rate.

• Be careful of children or surrounding objects when folding and unfolding the

machine.

• Never put the machine near wet objects or areas. The unit may produce an error if

it is wet.

SAFETY & WARNINGS

3. Caution during use

• If you do not feel well during exercise, please consult with your doctor.

• No liability will be accepted for improper use of the device and any resulting injuries

or damage.

• Please pull out safety key after use.

• Please pull out the safety key when moving or changing any parts of the machine.

• Children, the elderly, pregnant women should not use the machine.

• Do not place any items within two meters of the machine.

• Do not start the machine when it is folded.

• Ensure water does not come in contact with the machine, especially the motor,

power cable and plug.

• Never wear long dresses or other unsuitable garments during use.

• Do not use the machine in enclosed spaces, locations with uncirculated air or

flammable areas.

• Do not put any objects on the machine.

• Keep the plug away from heat.

• Please switch off the unit and remove the plug after using.

• Please do not stand directly on the belt while starting the machine.

• Do not disassemble or modify this machine in any way.

• Please make sure the running belt is fastened before use.

• The running belt on this treadmill has a visible joint mark. This is completely

normal and will not affect the performance or operation of your treadmill.

Hardware and Tools

1 Main Frame

2M6x20 Knob

3M12x20 knob

4 Silicone oil

5 Allen key with screwdriver

6 Safety key

OVERVIEW

Parts List

Serial No

Part Name

Spec

Qty

Console PCB

1PC

Console up and down cover

ABS

1PC

Washer

ABS

1PC

M6 Knob

M6x12

1PC

Armrest foam

Cannot tear

2PCS

Left and right Columns

Q335

1Set

Power cord

Black,2150mm

1PC

Switch

Red

1PC

Pipe plug

Motor

External six angle screw

M12x70

2PCS

M12 Knob

M12x20

1PC

Foot pads

Nylon

4PCS

Six angle screws in the cylinder

head

M5x40

2PCS

Wheel

ABS

2PCS

Self locking nut

2PCS

Motor down cover

ABS

1PC

Controller

1PC

Frame

Q235

1PC

Strengthen the angle iron

Q235

1PC

Self locking nut

6PCS

Foot pad

Rubber

2PCS

Left end cover

Nylon

1PC

Inner six angle screw

M6x50

3PCS

Rear roller

1PC

Right end cover

Nylon

1PC

Cross head self drilling screws

ST4.2x16

6PCS

Running board

MDF

1PC

Socket Cap Screw

M8x30

6PCS

Running belt

Drill Texture

1PC

Side rail

PVC

2PCS

Front roller

1PC

Pan head tapping screws

ST4x12

2PCS

Strap

140J

1PC

Console upper handle cover

Q235

1PC

Safety key

Red

1PC

Fasten the M12 knob and M6 knob in the corresponding positions.

Ensure the safety key placed is place in the middle of console and keep clear free from the

M6 knob.

ASSEMBLY

1. Ensure the safety key is in place and press the "START" key, the machine will start

by counting down for 3 seconds with audible beeps before starting slowly at 1km/h.

2. Press the "+" key to speed up and the "-" key to slow down. The fastest speed is 5

km/h and lowest is 1km/h.

3. Press the “DISPLAY" key to change the display between Distance, Time and

Calories. When "scan" is selected the screen will automatically move between

Distance, Time and Calories every 5 seconds.

4. The treadmill has 3 inbuilt programs. To select a program, ensure that the treadmill

is in standby with the belt stationary. Press the "PROG" button to select the desired

program then press “START” to start the machine.

5. To s t o p t h e u n i t i n a n e m e r g e n cy, p u l l t h e r e d s a f e t y k e y. T h e m a c h i n e w i l l t h e n

stop. When the red safety key magnet is not in place the screen will show “Err”.

When the Red safety key magnet is in place, the display will show “OFF”.

6. Press "STOP" to stop the machine after use.

Auto Mode:

OPERATION

Unfolding

• Pull out the tension knob then carefully lower the running board.

• Secure the treadmill using the fixed knob.

• Connect the treadmill to a power outlet.

• The treadmill is ready for operation.

Fold & Move:

• Tu r n t h e f i x e d k n o b t h e n l i f t t h e r u n n i n g b o a r d t o fold the treadmill.

• Pull out the tension knob, aimed at the platform then release the knob to fix the

treadmill in place.

• The treadmill can be moved and stored safely.

TRANSPORTING
