Fortinet FortiWiFi 60D Manuel de service

2016 Netsurion, LLC. All rights reserved.

Firewall Installation

Instructions

Please review the diagram on the next page. This is our

typical installation which fits most organizations. If your

particular environment requires a different setup, please

make sure you can easily locate the referenced devices.

If your site uses PPPoE or a static IP and you have not

given that information to Netsurion, please make sure to

have it ready and let the Netsurion support engineer know

before proceeding with the install. If you do not understand

the above terms, that’s ok! Simply reach out to us at

(800) 559-8157 for support.

Your firewall, when received, should be stored in a secure,

room-temperature location such as your back office. Do not

store your firewall in high-temperature areas.

Thank you from,

Netsurion Support Team

[email protected]

Connect an Ethernet cable

from this port to your

current router/firewall.

Connect all devices to ports 2 - 7.

This would include PC’s, Terminals,

Servers, DVR’s, etc. These devices

should be moved from your current

router/firewall to these ports. You

may use a switch to add port density

by plugging it into one of these ports.

Connect the antenna (included with firewall).

Make sure they are pointed perpendicular to

the ground at 90° angles. This allows for

wireless access point detection.

2016 Netsurion, LLC. All rights reserved.

Failover/Failback Options:

USB modem connection for a

phone line to a fax machine or

secondary line OR WAN2 as

secondary broadband connection

Connect your Point of

Sale (POS) system to

port 1 on the firewall.
