Fortinet FortiDB 3000D Manuel utilisateur

Database security & compliance

FortiDB™3000D

QuickStart Guide

Table of contents

Package contents ........................................1

Installing SFP transceivers ..................................2

Connecting to FortiDB .....................................4

Shutting down ...........................................6

Registering your product ...................................7

Ports & LEDs............................................8

Environmental speciﬁcations ...............................11

Safety ................................................12

Regulatory compliance ...................................13

License agreement & warranty..............................14

2 Power Cables Console Cable Ethernet Cable

FortiGate-30B

Tools and Documentation

Tools and

Documentation

QuickStart Guide

DATABASE SECURITY & COMPLIANCE

FortiDB™3000D

QuickStart Guide

Faceplate Keys

Cable

Management

Kit

Sliding Rail

Kit

Package contents

The box should contain:

FortiDB 3000D appliance

FortiDB 3000D QuickStart Guide

Tools and Documentation CD

2 Power cables

Ethernet cable

Console cable

Faceplate keys

Sliding rail kit

Cable management kit

Installing SFP transceivers

If not already installed, install the SFP transceivers that will be used to

connect your appliance to the network.

Caution: Do not install or remove SFP transceivers while ﬁber optic cables

are attached. This can damage the cables, cable connectors, and optical

interfaces. It may also prevent the transceiver from latching correctly into

the socket.

Note: Installing and removing SFP transceivers can shorten their life. Do

not install or remove transceivers more than is necessary.

Extraction Lever

Transmit

Optical Bore

Receive

Optical Bore Socket Latch

SFP Cage Sockets

To install SFP transceivers

1. On the appliance’s front panel, remove the caps from SFP cage sockets.

2. Position the SFP transceiver in front of the cage socket so that the

extraction lever is level with the socket latch.

Note: SFP cage socket orientation may vary. Verify that the SFP

transceiver module is correctly oriented.

3. Holding the sides of the SFP transceiver, gently slide it into the cage

socket.

Caution: Do not force SFP transceivers into cage slots. Force can cause

damage. If the transceiver does not easily slide in and click into place,

it may not be aligned correctly or may be upside down. If this happens,

remove the SFP transceiver, realign or rotate it, and try again.

4. Press the transceiver ﬁrmly into the cage socket with your thumb until it

clicks, indicating that it is latched.

5. Verify that the transceiver is latched: grasp the sides and trying to pull it

out without lowering the extraction lever.

If you can remove the transceiver, it was not latched correctly, and could

become accidentally dislodged. Try again.

To remove SFP transceivers

1. Disconnect the ﬁber optic cable from the transceiver connector.

2. To prevent dust from entering the optical bores, insert clean plugs.

3. To eject the transceiver, pull the extraction lever out and down.

Tip: Instead of using your ﬁnger, try a small ﬂat-head screwdriver.

4. Hold the sides of the transceiver and carefully pull it from the cage socket.

5. Replace the cap on the SFP cage socket.

6. Put the removed SFP transceiver into an anti-static bag.

Connecting to FortiDB

FortiDB appliances should be installed in a restricted access location

such as a locked data center to ensure their physical security, which is

fundamental to your network security. Either place the FortiDB appliance

on a ﬂat surface, or mount it in any standard 19 inch (48.3cm) rack

with the rack-mount brackets. In a rack, a FortiDB 3000D occupies 2U

(3.5inches/8.9 cm). If the appliance has a redundant power supply, each

power cable should be connected to a different power source.

You can conﬁgure FortiDB for your network through a connection to

eitherits web UI or command line interface (CLI).

Connect FortiDB only to your computer until you ﬁnish setup. (If you place

FortiDB in your network before FortiDB is set up, device IPs could conﬂict.)

Deployment instructions are in the FortiDB Handbook.

iDRAC

LICENSE

REQUIRED

234

LINK/ACT

1000=YEW

100=GRN

P0 P1

Switch

Application

Server

Administrator

Firewall

Internet

FortiDB

Database

SPAN mirrors

database trafﬁc

to FortiDB

To administrator,

database,

Internet

LAN

WAN

To connect to the web UI

Requires: Microsoft Internet Explorer 8, Mozilla Firefox 20, Apple Safari 6,

or Google Chrome 20 or newer

1. Using the Ethernet cable, connect port1 of the appliance to your computer.

2. Conﬁgure your computer to match the appliance’s default port1 subnet.

For example, on Windows 7, click the Start (Windows logo) menu to

open it, then click Control Panel. Click Network and Sharing Center,

Local Area Connection, and then the Properties button. Select

Internet Protocol Version 4 (TCP/IPv4) then click its Properties button.

Select Use the following IP address, then change your computer’s

settings to:

• IP address: 192.168.1.2

• Subnet mask: 255.255.255.0

3. To connect to FortiDB’s web UI, start a web browser and go to

https://192.168.1.99 . (Remember to include the “s” in https://.)

4. Type admin in the User Name ﬁeld, type fortidb1!$ in the Password

ﬁeld blank, then click Login.

To connect to the CLI via serial console

Requires: Terminal emulator such as PuTTY, TeraTerm, or a terminal server

1. Using the console cable, connect the appliance’s console port to your

terminal server or computer.

2. On your computer or terminal server, start the terminal emulator.

Usethesesettings:

• Baud rate: 9600

• Data bits: 8

• Parity: None

• Stop bits: 1

• Flow control: None

3. Press Enter on your keyboard to connect to the CLI.

Shutting down

Always properly shut down the FortiDB

appliance’s operating system before turning off

the power switch or unplugging the appliance.

This causes it to ﬁnish writing buffered data, and

to slow and park the harddisks.

Do not unplug or switch off the FortiDB

appliance before halting the operating

system. Failure to shut down correctly could

cause dataloss and hardware problems.

To power off the appliance via the CLI

1. Connect to the CLI using a terminal emulator.

2. Enter the following command:

execute shutdown

You may be able to hear the appliance become more quiet when the

appliance stops its hardware and operating system, indicating that it is

ready for power to be disconnected.

3. Disconnect the power cable from the power supply.

Registering your product

You must register the product with Fortinet

inorder to receive:

•Technical support •Software updates

•FortiGuardupdates

Enregistrer

Vous devez enregistrer le produit pour recevoir:

•Support technique •Mises-à-jour logiciel

•Mises-à-jourFortiGuard

Registra

La registrazione vi permette di usufruire di:

•Supporto tecnico •Aggiornamenti software •AggiornamentiFortiGuard

Registrar

Debe registrar el producto para recibir:

•Apoyo técnico •Actualizaciones de software

•ActualizacionesFortiGuard

登録のお願い

下記フォーティネットからのサービスを受けるために、ご購入製品の登録が必要

です。

• テクニカルサポート • ソフトウェアのアップデート • FortiGuardのアップデート

请马上注册

您的飞塔产品

您在注册以后才能得到技术支持, 软件升级, 及FortiGuard最新威胁防护

Web: https://support.fortinet.com/

Toll free: 1 866 648 4638

Phone: 1 408 486 7899

Fax: 1 408 235 7737

Email: r[email protected]

Ports & LEDs

DVD+ReWritable

MULTI

RECORDER

Ultra Speed

ReWritable

COMPACT

IP 192.168.001.099

FortiDB 3000D

iDRAC

LICENSE

REQUIRED

i12 3 4

LINK/ACT

1000=YEW

100=GRN

P0 P1

7 7

1110 1283

12 3 45

# Interface Type Protocol Description

1 Power Button with green power LED.

2 Video VGA Reserved for future use.

3 USB USB-A USB 2.0 Reserved for future use.

4 Flash Media SD Reserved for future use.

5 Optical Drive SATA Reserved for future use.

6 Ethernet Ports

5 & 6

SFP Gigabit

Ethernet

Connections to your network and the

Internet. SerDes small form-factor pluggable

(SFP) transceiver.

7 6 PCIe Slots PCIe Reserved for future use.

8 Ethernet Ports

1 - 4

RJ-45 Gigabit

Ethernet

Connections to your network & the Internet.

Port1 default: https://192.168.1.99

9 Hard Drives SATA Two 2TB hot swappable hard drives. 6

additional hard drive slots.

10 iDRAC7

Enterprise

Reserved for future use. Disabled.

11 Console DB-9 RS-232

serial

Connection to the management computer.

9600 bps access to the CLI.

12 Power

(Redundant)

100 - 240 V 750W AC

60 - 50 Hz

4 - 2 A
