Formax FD 8500CC Manuel utilisateur
Paper Shredders
FD 8500CC Cross-Cut
FD 8500SC Strip-Cu
t
OPERATOR MANUAL
SECOND EDITION
4/2007
Safety Devices and Other Features
Formax 8000 Series Shredders are equipped with various safety features:
Automatic Reverse Rotation
When too much paper is inserted, the cutter stops operating
and
automatically rotates in reverse to discharge the jammed paper. An
alarm sounds. Reduce the amount of paper and restart the operation.
Door Switch
If the door is open, the shredder will not operate.
Automatic Stop
When the shredded paper fi lls the wastebasket, the “FULL”
light
comes on and the cutter stops operation. Open the door, remove
the wastebasket and empty paper scraps. Replace the wastebasket,
close the door and continue operation.
Automatic Power Shut-Off
• If the shredder operates continuously for more than 30
minutes, the power is automatically shut off.
• If the motor is overloaded, the “STOP” LED will fl ash until it cools
down. When the fl ashing stops the shredder is ready to be used again.
Oil Indicator
The “MANUAL” LED will fl ash after every four (4) hours of operation as an
indicator to oil the shredder cutting blades. The LED will continue to fl ash until
oiled. NOTE: the shedder will still operate when the LED is fl ashing but at a
decreased load capacity.
To oil:
Spread shredder oil onto the cutters through the feed opening, and allow
the oil to sit for a few minutes to permeate the cutting blades, then press the “REV”
button and hold for fi ve seconds. “MANUAL” and “REV” LED indicators on control
panel will light. The shredder will operate in reverse for one minute, then the
“AUTO” LED will light indicating the shredder is ready.
Maintenance
• Disconnect power by pulling power cord plug from wall outlet.
• To clean the exterior, wipe the surface with a soft cloth. If the surface is
very dirty, use a neutral detergent, then wipe again with a soft cloth.
CAUTION:
• Never put water directly on the surface of the shredder.
• Never clean the case with benzene or thinner, since it will cause
discoloration.
• Do not dismantle the shredder. Contact your Formax Dealer for service.
Operation
1. Open the door and turn the power switch “ON.” Close door.
2.
Auto Start/Auto Stop
When the “START A/M” button is pushed, the signal lamp
“AUTO” will light. Insert paper to shred. The shredder will start
and stop automatically when using this function.
3.
Manual Operation
If paper is too small for the shredder’s sensors to detect, shred
it manually. Push the “START A/M” button once more and the
“MANUAL” lamp will light. Insert paper to be shredded. Three
minutes after shredding, the cutter automatically stops rotating.
Set-up Guidelines
1. Install the shredder on a level surface, away from heat sources and direct
sunlight.
2. Insert plug into wall outlet with the appropriate voltage, 110V. If the outlet
is shared with another electronic device, the total current should not exceed 30A
(at 110V).
Specifi cations
Cutting Style:
Cross Cut
Strip Cut
Shred Size:
5/32” x 1-1/5”
5/32”
Sheet Capacity:
16 to 18
20 to 22
Speed:
31 feet per minute
33 feet per minute
Feed Opening:
16”
16”
Dimensions:
24” W x 20” D x 35” H
24” W x 20” D x 35” H
Bin Capacity:
26 gal.
26 gal.
Weight:
242 lbs.
242 lbs.
Power supply:
110-120V, 60Hz
110-120V, 60Hz
Cutting heads accept credit cards, staples and paper clips.
FD 8500CC FD 8500SC
4.
Reverse Operation
Push the “REV” button and the signal lamp “REV” will light and cutters will operate
in reverse. If too much paper is inserted at one time in standard modes, the
shredder will automatically operate in reverse. If this occurs, remove the inserted
paper and shred in smaller amounts. NOTE: The maximum amount of paper to be
shredded differs according to paper quality, humidity and voltage. If the shredder is
to be used continuously, do not insert more than half of the maximum capacity.
5.
Full Sensor
If the wastebasket is full, the “FULL” lamp will light and the cutter will stop
automatically. Open the door, empty the wastebasket of paper strips/chips, replace
the wastebasket, close door, and continue to shred.
Safety Precautions
To avoid personal injury, and damage to the shredder, observe the following safety
precautions. Please keep these instructions for future reference.
NOTE:
In case of emergency, push the
“Power Switch” to cut off power and/or
pull the plug out of the wall outlet.
•
Keep hands, long hair, clothing, ties, jewelry
and loose items away from the feed opening
and shred outlet.
•
Do not use the shredder for anything other
than its intended purpose. Never use it to shred cloth, plastic, cardboard or any
hard material that will cause damage to the shredder blades.
•
Do not allow children to use the machine.
•
Do not operate with a damaged power cord or plug, or when the machine
is
damaged in any manner.
•
Unplug the shredder when it is being moved, or if it is not in use for an
extended
period of time.
•
Do not disconnect the power by pulling only the cord. Hold the plug when
disconnecting.
•
Keep the shredder away from direct sunlight.
•
Do not sit on the shredder or place anything on top of it.
•
Never open the fi xed switch or cover.
