Flycam 5000 Manuel utilisateur
1
G-Axis 5000 Gimbal Support Handheld
Camera Stabilizer (FLCM-GX-5000)
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
Assembly Manua l
What’s In The Box
Please inspect the contents of your shipped package to ensure you have received everything that is listed
below.
12 x Weights
Bag Packing
Gimbal Support
Gimbal extension
Allen Key (3/16”)
Flycam G-Axis 5000 Stabilizer
Base Weight Plaorm
2
Insert the Flycam G-Axis 5000 Stabilizer into
the Base Weight Plaorm.
Then rotate the Flycam G-Axis 5000 Stabilizer
and ghten it properly as shown in the
image.
Then insert the weights into the base
plaorm, as shown in the image.
NOTE: You can add/adjust the counterweight
as per your requirement.
Then loosen the bolts on each side of the
Gimbal extension and insert it onto the
Flycam Stabilizer, as shown in the image.
Now loosen knobs on both sides of the
Flycam Stabilizer.
G-Axis 5000 Gimbal Support Setup
Tighten it properly with the help of the knob.
3
Now insert the bolts in both the sides and
ghten them properly.
NOTE:PROAIM, G-Axis 5000 stabilizer for
Gimbals, allows you to transform the weight of
the gimbal including your heavy camera setup
onto the enre body through your arm & vest.
Loosen the knob and bolt using a 3/16” Allen
Key.
Now increase the height of the Flycam
Stabilizer.
NOTE: It oers a great range of handle height
adjustment, which lets you achieve an ideal
balance & create cinemac jib shots
transioning from low to high-angle & high to
low-angle.
Again, ghten the knob and bolt properly
using a 3/16’ Allen Key.
NOTE: When you shoot with heavy loads on
your arms, it not only aects your physics badly
but also minimizes the producvity & lowers the
visual quality drascally.
4
Loosen both the knobs and insert the Gimbal
support.
NOTE: Handle is provided with the 1/4” threads
to mount accessories like monitor, follow focus
etc.
Then securely ghten both the knobs, as
shown in the image.
Then insert the P-QRG into the Gimbal’s
handle and secure it properly with a screw
driver.
Mount the Gimbal (Not Included) onto the
Flycam Stabilizer and secure it by ghtening
the knob.
NOTE: P-QRG is a compact plate that quickly
mounts handheld Gimbal to dierent gears. It is
constructed of High-Grade CNC Aluminum &
features both 3/8"-16 and 1/4"-20 screws for
mounng.
Loosen the knob and remove the P-QRG.
NOTE: The quick-release mechanism oers you
easy swapping of camera gimbals & the smooth
padding on top of it protects your gimbal from
twisng & scratching.
5
Then ghten the knob properly and your
setup is now ready, as shown in the image.
Loosen the knob of the Gimbal support and
mount it on a C-stand(Not Included).
Then ghten the knob properly.
NOTE: You can use your stand for the
balancing process or in-between takes to hold it.
Now loosen both the knobs of the Base
Weight Plaorm, as sown in the image.
Then to balance the Flycam Stabilizer, move
the Base Weight Plaorm and properly
ghten it from both the knobs.
C-Stand Setup
Loosen the knobs and slide the handle as
shown in the image.
6
YOUR FLYCAM G-AXIS 5000 GIMBAL SUPPORT CAMERA STABILIZER
ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,
we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it
cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon
and evaluaon by us.
Liability: We are not liable for damage caused by products that we do not supply or from mishandling in
transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.
Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our
utmost support and care unl you use our product.
NOTE: It oers a great range of handle height
adjustment which lets you achieve an ideal balance
& create cinemac jib shots transioning from low
to high-angle & high to low-angle.
