Fluke 59 MAX Manuel utilisateur

PN 4311999

March 2013

Specifications are subject to change without notice.

All product names are trademarks of their respective companies.

59 MAX/59 MAX +

Infrared Thermometer

Users Manual

LIMITED WARRANTY AND LIMITATION OF LIABILITY

This Fluke product will be free from defects in material and workmanship for one

year from the date of purchase. This warranty does not cover fuses, disposable

batteries, or damage from accident, neglect, misuse, alteration, contamination, or

abnormal conditions of operation or handling. Resellers are not authorized to

extend any other warranty on Fluke’s behalf. To obtain service during the warranty

period, contact your nearest Fluke authorized service center to obtain return

authorization information, then send the product to that Service Center with a

description of the problem.

THIS WARRANTY IS YOUR ONLY REMEDY. NO OTHER WARRANTIES, SUCH

AS FITNESS FOR A PARTICULAR PURPOSE, ARE EXPRESSED OR IMPLIED.

FLUKE IS NOT LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR

CONSEQUENTIAL DAMAGES OR LOSSES, ARISING FROM ANY CAUSE OR

THEORY. Since some states or countries do not allow the exclusion or limitation of

an implied warranty or of incidental or consequential damages, this limitation of

liability may not apply to you.

Fluke Corporation

P.O. Box 9090

Everett, WA 98206-9090

U.S.A.

Fluke Europe B.V.

P.O. Box 1186

5602 BD Eindhoven

The Netherlands

11/99

Table of Contents

Title Page

Introduction.................................................................................................................1

How to Contact Fluke ................................................................................................. 1

Safety Information ...................................................................................................... 2

Maintenance............................................................................................................... 5

How to Change the Battery ....................................................................................5

How to Clean the Product ......................................................................................5

Specifications .............................................................................................................6

Standards and Agency Approval................................................................................ 8

Nominal Surface Emissivity........................................................................................ 9

The Product ................................................................................................................10

59 MAX/59 MAX +

Users Manual

Introduction

The Fluke 59 MAX and 59 MAX + Infrared Thermometers (the Product) can determine the

surface temperature by measuring the amount of infrared energy radiated by the target’s

surface.

Warning

Read all safety information before you use the Product.

How to Contact Fluke

To contact Fluke, call one of the following telephone numbers:

•Technical Support USA: 1-800-44-FLUKE (1-800-443-5853)

•Calibration/Repair USA: 1-888-99-FLUKE (1-888-993-5853)

•Canada: 1-800-36-FLUKE (1-800-363-5853)

•Europe: +31 402-675-200

•Japan: +81-03-6714-3114

•Singapore: +65-6799-5566

•Anywhere in the world: +1-425-446-5500

59 MAX/59 MAX +

Users Manual

Or, visit Fluke's website at www.fluke.com.

To register your product, visit http://register.fluke.com.

To see, print, or download the latest manual supplement, visit

http://us.fluke.com/usen/support/manuals.

Safety Information

A Warning identifies conditions and procedures that are dangerous to the user. A Caution

identifies conditions and procedures that can cause damage to the Product or the equipment

under test.

Table 1 tells you about symbols used on the Product and in this manual.

Warning

To prevent possible electrical shock, fire, or personal injury:

•Read all safety Information before you use the Product.

•Do not use the Product if it operates incorrectly.

•Use the Product only as specified, or the protection supplied by the

Product can be compromised.

•Examine the case before you use the Product. Look for cracks or

missing plastic. Carefully look at the insulation around the terminals.

Infrared Thermometer

Safety Information

•See emissivity information for actual temperatures. Reflective objects

result in lower than actual temperature measurements. These objects

pose a burn hazard.

•Do not look directly into the laser with optical tools (for example,

binoculars, telescopes, microscopes). Optical tools can focus the laser

and be dangerous to the eye.

•Do not look into the laser. Do not point laser directly at persons or

animals or indirectly off reflective surfaces.

•Replace the batteries when the low battery indicator shows to prevent

incorrect measurements.

•Do not use the Product around explosive gas, vapor, or in damp or wet

environments.

•Use the Product only as specified or hazardous laser radiation exposure

can occur.

•Carefully read all instructions.

59 MAX/59 MAX +

Users Manual

Table 1. Symbols

Symbol Meaning Symbol Meaning



Risk of danger.

Important information.

See Manual.

Conforms to relevant North American Safety

Standards.

Warning. Laser. Conforms to European Union directives.

Battery Conforms to relevant Australian standards.



This product complies with the WEEE Directive (2002/96/EC) marking

requirements. The affixed label indicates that you must not discard this

electrical/electronic product in domestic household waste. Product Category:

With reference to the equipment types in the WEEE Directive Annex I, this

product is classed as category 9 "Monitoring and Control Instrumentation”

product. Do not dispose of this product as unsorted municipal waste. Go to

Fluke’s website for recycling information.

Infrared Thermometer

Maintenance

Warning

To prevent possible electrical shock, fire, or personal injury, have an

approved technician repair the Product.

Caution

To avoid damage to the Product, do not leave the thermometer on or near

objects of high temperature.

How to Change the Battery

To install or change the AA IEC LR06 battery, open the battery compartment and replace the

battery as shown in Figure 16.

How to Clean the Product

Use soap and water on a damp sponge or soft cloth to clean the Product case. Carefully wipe

the surface with a moist cotton swab. The swab may be moistened with water. See Figure 17.

59 MAX/59 MAX +

Users Manual

Specifications

59 MAX 59 MAX +

Temperature Range -30 °C to 350 °C (-22 °F to

662 °F)

-30 °C to 500 °C (-22 °F to

932 °F)

Accuracy (Calibration

geometry with ambient

temperature 23 °C ±2 °C)

≥0 °C: ±2.0 °C or ±2.0 % of

reading, whichever is greater

(≥32 °F: ±4.0 °F or ±2.0 % of

reading, whichever is

greater)

≥-10 °C to <0 °C: ±2.0 °C

(≥14 °F to <32 °F: ±4.0 °F)

< -10 °C: ±3.0 °C (<14 °F:

±6.0 °F)

≥0 °C: ±1.5 °C or ±1.5 % of

reading, whichever is greater

(≥32 °F: ±3.0 °F or ±1.5 % of

reading, whichever is

greater)

≥-10 °C to <0 °C: ±2.0 °C

(≥14 °F to <32 °F: ±4.0 °F)

< -10 °C: ±3 °C (<14 °F:

±6.0 °F)

Response Time (95 %) <500 ms (95 % of reading) <500 ms (95 % of reading)

Spectral Response 8 μm to 14 μm

Emissivity 0.10 to 1.00
