Fluke ProcessMeter 787 Instructions originales

PN 4271802

August 2012, Rev. 1, 7/17

Specifications are subject to change without notice.

All product names are trademarks of their respective companies.

787

ProcessMeter

Safety Information

Go to www.fluke.com to register your product and find more

information.

A Warning identifies conditions and procedures that are dangerous to

the user.

XW Warning

To prevent possible electrical shock, fire, or personal injury:

•Read “Safety Information” before you use the meter.

•Do not use the meter if it is damaged. Before you

use the meter, inspect the case. Look for cracks or

missing plastic. Pay particular attention to the

insulation surrounding the connectors.

•Make sure the battery door is closed and latched

before you operate the meter.

•Remove test leads from the meter before you open

the battery door.

•Inspect the test leads for damaged insulation or

exposed metal. Check test leads continuity. Replace

damaged test leads before you use the meter.

•Measure a known voltage first to make sure that the

meter operates correctly. If you are unsure, have the

meter examined.

•Do not operate the meter around explosive gas,

vapor, or dust. Do not use in wet or damp

environments.

•Use only a single 9 V battery, properly installed in

the meter case, to power the meter.

•When servicing the meter, use only specified

replacement parts.

•Before a current measurement, do the fuse test.

•Use the correct terminals, function, and range for

measurements.

•Do not work alone.

•For current measurements, connect the meter to the

circuit after you remove circuit power. Always put

the meter in series with the circuit.

•Comply with local and national safety requirements

when in hazardous locations.

•Only use test leads that have the same voltage,

category, and amperage ratings as the meter and

that are approved by a safety agency. When used

with optional accessories, the lowest category

rating applies.

•To avoid possible electric shock, do not use

TouchHold to determine if dangerous voltage is

present. TouchHold will not capture unstable or

noisy readings.

•To avoid false readings, which could lead to

possible electric shock or personal injury, replace

the battery as soon as the battery indicator (M)

appears.

•To avoid electrical shock, remove test leads from

the meter before you open the battery door.

•Close and latch the battery door before you use the

meter.

•To avoid personal injury or damage to the meter,

use only the specified replacement fuse, 440 mA

1000 V fast-blow, Fluke PN 943121.

•Do not exceed the Measurement Category (CAT)

rating of the lowest rated individual component of a

Product, probe, or accessory.

•Do not use the TL175 or TP175 test probes in CAT

III or CAT IV environments without the probe tip

fully extended and correct category rating visible in

the window.

•When the TL175 is used with instruments or other

accessories, the lowest category rating of the

combination applies. One exception is when the

probe is used with the AC172 or AC175.

Safety Specifications

Battery Type: 9 V battery, IEC 6LR61

Temperature:

Operating: -20 °C to +55 °C

Storage: -40 °C to +60 °C

Altitude: Operating: 2000 m

Symbols

Symbol Description

XWARNING. HAZARDOUS VOLTAGE. Risk of electric

shock.

WARNING. RISK OF DANGER.

Consult user documentation

AC (Alternating Current)

DC (Direct Current)

Alternating or direct current

Earth

MBattery

Fuse

TDouble Insulated

)

Conforms to relevant North American Safety Standards.

Conforms to relevant Australian EMC standards.

Conforms to relevant South Korean EMC Standards.

Measurement Category II is applicable to test and

measuring circuits connected directly to utilization points

(socket outlets and similar points) of the low-voltage

MAINS installation.

Measurement Category III is applicable to test and

measuring circuits connected to the distribution part of

the building’s low-voltage MAINS installation.

¾Measurement Category IV is applicable to test and

measuring circuits connected at the source of the

building’s low-voltage MAINS installation.

This product complies with the WEEE Directive marking

requirements. The affixed label indicates that you must

not discard this electrical/electronic product in domestic

household waste. Product Category: With reference to

the equipment types in the WEEE Directive Annex I, this

product is classed as category 9 "Monitoring and

Control Instrumentation" product. Do not dispose of this

product as unsorted municipal waste.

LIMITED WARRANTY &

LIMITATION OF LIABILITY

This Fluke product will be free from defects in material and

workmanship for three years from the date of purchase. This warranty

does not cover disposable batteries or damage from accident,

neglect, misuse or abnormal conditions of operation or handling.

Resellers are not authorized to extend any other warranty on Fluke’s

behalf. To obtain service during the warranty period, send your

defective meter to the nearest Fluke Authorized Service Center with a

description of the problem.

THIS WARRANTY IS YOUR ONLY REMEDY. NO OTHER

WARRANTIES, SUCH AS FITNESS FOR A PARTICULAR

PURPOSE, ARE EXPRESSED OR IMPLIED. FLUKE IS NOT LIABLE

FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR

CONSEQUENTIAL DAMAGES OR LOSSES, ARISING FROM ANY

CAUSE OR THEORY.

Since some states or countries do not allow the exclusion or limitation

of an implied warranty or of incidental or consequential damages, this

limitation of liability may not apply to you.

Fluke Corporation

P.O. Box 9090

Everett, WA

98206-9090 U.S.A.

Fluke Europe B.V.

P.O. Box 1186

5602 BD Eindhoven

The Netherlands

11/99
