Fluke 353 Manuel utilisateur

353/355

Clamp Meter

Users Manual

PN 2842223

October 2007

All product names are trademarks of their respective companies.

LIMITED WARRANTY AND LIMITATION OF LIABILITY

This Fluke product will be free from defects in material and workmanship for three years from the date of purchase. This war-

ranty does not cover fuses, disposable batteries, or damage from accident, neglect, misuse, alteration, contamination, or

abnormal conditions of operation or handling. Resellers are not authorized to extend any other warranty on Fluke’s behalf.

To obtain service during the warranty period, contact your nearest Fluke authorized service center to obtain return authoriza-

tion information, then send the product to that Service Center with a description of the problem.

THIS WARRANTY IS YOUR ONLY REMEDY. NO OTHER WARRANTIES, SUCH AS FITNESS FOR A PARTICULAR

PURPOSE, ARE EXPRESSED OR IMPLIED. FLUKE IS NOT LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR

CONSEQUENTIAL DAMAGES OR LOSSES, ARISING FROM ANY CAUSE OR THEORY. Since some states or countries

do not allow the exclusion or limitation of an implied warranty or of incidental or consequential damages, this limitation of

liability may not apply to you.

Fluke Corporation

P.O. Box 9090

Everett, WA 98206-9090

U.S.A.

Fluke Europe B.V.

P.O. Box 1186

5602 BD Eindhoven

The Netherlands

11/99

Table of Contents

Title Page

Introduction .................................................................................................................... 1

Contacting Fluke ............................................................................................................ 1

Safety Information .......................................................................................................... 2

Features ......................................................................................................................... 5

Display ........................................................................................................................... 7

Using the Meter.............................................................................................................. 8

Measuring AC or DC Current..................................................................................... 8

Measuring Inrush Current.......................................................................................... 9

Measuring AC and DC Voltage (355 only)................................................................. 10

Testing Continuity (355 only)..................................................................................... 12

Measuring Resistance (355 only) .............................................................................. 13

Maintenance................................................................................................................... 14

Cleaning the Meter .................................................................................................... 14

Changing the Batteries .............................................................................................. 14

User Replaceable Parts ................................................................................................. 14

Specifications ................................................................................................................. 15

Electrical Specifications............................................................................................. 15

Standards and Agency Approval Specifications ........................................................ 18

Environmental Specifications .................................................................................... 18

353/355

Users Manual

iii

List of Tables

Table Title Page

1. Explanation of Symbols......................................................................................................... 4

2. Features and Buttons ............................................................................................................ 5

3. Rotary Switch Positions......................................................................................................... 6

4. Display................................................................................................................................... 7

353/355

Users Manual

List of Figures

Figure Title Page

1. Feature Locations.................................................................................................................. 5

2. The Display ........................................................................................................................... 7

3. Connecting the Meter ............................................................................................................ 8

4. Measuring Inrush Current...................................................................................................... 9

5. AC Voltage Measurement ..................................................................................................... 10

6. DC Voltage Measurement ..................................................................................................... 11

7. Measuring Continuity............................................................................................................. 12

8. Measuring Resistance........................................................................................................... 13

353/355

Users Manual

Clamp Meter

Introduction

The Fluke 353 and 355 are hand-held battery-operated

Clamp Meters (the Meter). Both Meters measure ac, dc

true rms, inrush current and frequency; The 355 also

measures ac, dc, true rms voltage, and resistance.

The Meter ships with:

•TL224 Test leads (355 only)

•AC285 Clips (355 only)

•TP74 Test Probes (355 only)

•Soft carrying case

•6 AA/LR6 Batteries, installed

•353/355 Users Manual (7 languages)

Contacting Fluke

To contact Fluke, call one of the following telephone

numbers:

USA: 1-888-99-FLUKE (1-888-993-5853)

Canada: 1-800-36-FLUKE (1-800-363-5853)

Europe: +31 402-675-200

Japan: +81-3-3434-0181

Singapore: +65-738-5655

Anywhere in the world: +1-425-446-5500

Or visit Fluke’s Web site at: www.fluke.com.

353/355

Users Manual

Safety Information

XWWarnings: Read First

To avoid possible electric shock or personal

injury:

•Use the Meter only as specified in this

manual or the protection provided by the

Meter might be impaired.

•Avoid working alone so assistance can

be rendered.

•Never measure ac current while the test

leads are inserted into the input jacks.

•Do not use the Meter in wet or dirty

environments.

•Do not use the Meter if it appears

damaged. Inspect the Meter before use.

Look for cracks or missing plastic. Pay

particular attention to the insulation

around the connectors.

•Inspect the test leads before use. Do not

use them if insulation is damaged or

metal is exposed.

•Check the test leads for continuity.

Replace damaged test leads before using

the Meter.

•Have the Meter serviced only by qualified

service personnel.

•Use extreme caution when working

around bare conductors or bus bars.

Contact with the conductor could result

in electric shock.

•Do not hold the Meter anywhere beyond

the tactile barrier. See Figure 1.

•When measuring current, center the

conductor in the clamp. See Figure 1.

•Do not apply more than the rated voltage,

as marked on the Meter, between the

terminals or between any terminal and

earth ground.

•Remove test leads from the Meter before

opening the Meter case.

•Never operate the Meter with the back

cover removed or the case open.

•Never remove the back cover or open the

case of an instrument without first

removing the test leads or the jaws from

a live conductor.

•Use caution when working with voltages

above 30 V ac rms, 42 V ac peak, or 60 V

dc. These voltages pose a shock hazard.

•Do not attempt to measure any voltage

that might exceed the maximum range of

the Meter- 600 V rms and 1 kHz or 1000 V

dc.

•Use the proper terminals, function, and

range for your measurements.
