Fluidmaster S2DBL Manuel utilisateur
Q
S
T
R
U
V
Z
C
B
L
M
N
H
I
J
A
E
O
F
P
G
K
D
D
W
X
Y
N.
O.
P.
Q.
R.
S.
T.
U.
V.
W.
X.
Y.
Z.
Release clip
Flush valve lock nut
Rubber gasket
Fill valve
Threaded shank
Shank washer
Lock nut
Cone washer
Water supply line
Rell mount
Corrugated tube
Roller clamp
Rell tube &
locking clamp
PARTS LIST
A.
B.
C.
D.
E.
F.
G.
H.
I.
J.
K.
L.
M.
Flush valve
Lever mounting base
Flush handle assembly
Grey/Blue oat stop
Grey oat (Full Flush)
Flush valve washer
Bolt
Rubber washer
Brass washer
Brass nut
Overow tube
Rail
Blue oat (Half Flush)
www.uidmaster.com 1
Overview READ ENTIRE INSTRUCTIONS BEFORE STARTING INSTALLATION
4
2
1
3
1
2
3
1.6
1.4
1.5
1.7
(2) Remove tank top.
Mark existing
water level inside.
(3) Flush tank a
single time.
(4) Mark a line at the
residual water level
inside.
(1) Press and hold lever to
drain water. Remove excess
water with sponge.
(2) Disconnect supply line.
(3) Place bucket under-
neath ll valve shank. Use
Channel Locks® to loosen
and remove lock-nut from
ll valve shank. Allow water
to drain into bucket.
(1) Turn o
water supply.
www.uidmaster.com2
Step 1: Remove old parts
1.2
1.1 Prepare
Remove ll valve
3
1
2
Use Channel Locks® to loosen and
remove ush valve nut.
Cover the toilet seat with a towel. Place
the tank horizontally on top of the towel.
This will protect both surfaces.
(1) Remove ush valve. (2) Loosen and remove lever nut (lever nut is reverse threaded).
(3) Remove old gasket.
NOTE: SAVE the existing parts until installation is complete.
Measure and record distance of old ush
valve from bottom of tank to top of the
overow tube.
Use screw driver to loosen nuts in
tank. Use crescent wrench to loosen if
the nut is too tight. Remove tank from
bowl.
www.uidmaster.com 3
Measure ush valve
1.6
Remove lock nuts
1.3 1.4 Remove tank
Place tank on seat
1.5
1.7 Remove old parts
O
2.5
F
Remove ush valve lock nut (O) from
base of Dual Flush Valve assembly. Make
sure ush valve washer (F) stays in place.
www.uidmaster.com
4
Step 2: Install Flush Valve
2.1 Prepare ush valve
W
W
X
O
8
1
N
2
1
A
K
3
K
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
18
17
16
15
14
13
12
11
10
9
8
7
6
2
Place Dual Flush Valve (A) in tank
ensuring washer is seated fully onto
shank of Dual Flush Valve. Match height
of new overow tube (K) on Dual Flush
Valve with recorded measurement from
step 1.3.
Remove Dual Flush Valve from tank.
(1) Press inward on release clip (N) and
(2) remove rell mount (W).
(1) Cut the excess overow tube (K) with
a saw at measurement taken in step 1.3.
NOTE: DO NOT cut below segment 2.
(2) Insert rell mount (W) ensuring it is
low enough to t inside the tank and
clears the lid, but high enough to allow
a minimum of 2” clearance between the
top of the overow tube and the top of
the rell mount.
(3) Cut corrugated rell hose (X) if
necessary.
NOTE: DO NOT cut lever attachment.
Place ush valve in tank. Install ush
valve lock nut (O) to ush valve
threaded shank and hand-tighten.
Flush valve should remain in same
position after nut is tightened.
NOTE: Hand tighten only.
www.uidmaster.com 5
2.2 2.3Measure Remove rell mount
2.4 Cut to size Install in tank2.5
2” minimum
COUPLING NUT
SHANK AND
CONE WASHER
LOCK NUT
ANGLE ADAPTER
CONE
WASHER
SHANK
WASHER
Disassemble small parts - carefully separate cone washer from
center of shank washer. Lock nut and shank washer are required
for ll valve installation; cone washer and coupling nut for water
supply connection. The angle adapter will not be needed for this
installation.
NOTE: There are several union types, please refer to identication
chart at end of instruction manual.
www.uidmaster.com
6
Step 3: Install ll valve
3.1 Prepare
2
T
3”
1
S
Locking
ring
1
2
3
18
17
16
15
14
13
12
11
10
9
8
7
6
18
17
16
15
14
13
12
11
10
9
8
7
6
(1) Put shank washer (S), onto ll valve
shank and (2) place ll valve in tank.
Check height of the ll valve. It must be
approximately 3” higher than the
overow tube. Adjust by twisting the
threaded shank in or out.
NOTE: DO NOT move the locking ring
to adjust shank.
(1) Place ll valve in tank.
(2) Fasten ll valve lock nut (T) to shank
(3) hand tighten.
NOTE: DO NOT over-tighten.
www.uidmaster.com 7
3.2 Reconnect 3.3 Adjust
Install3.4
1
Z
4.4
P
18
17
16
15
14
13
12
11
10
9
8
7
6
H
G
I
J
Important: Attach the
end of rell hose to
nipple on Dual Flush
Valve as shown in
picture. Make sure both
tubes are clear of ll
valve and ush valve
operation. Ensure hose
clamp is secure.
Slide rubber gasket (P) onto threaded
end of ush valve. Use old gasket if
supplied new gasket does not t.
Secure tank to bowl with bolts (G), rubber
washers (H) brass washers (I) and hex nut (J).
Tank should be level after it has been installed.
NOTE: DO NOT over-tighten. May break tank.
Nut will not be used with all toilets.
www.uidmaster.com
8
4.3
Step 4: Reassemble
Secure rell hose
4.1 4.2
Prepare Replace
FULL
HALF
FULL
HALF
1
Reverse threads
B
A
1
2
1
1
1
V
2
Attach handle lever to tank and hand-
tighten lever lock-nut.
Note: Nut is reverse threaded. Make sure
tabs on collar are oriented vertically.
Line up tabs on lever into the slots on
lever mounting base (B) and snap into
base. Tabs on lever shank need to be
installed vertically.
(1) Reconnect water supply line (V). Use
Step 3.1 chart (on pg. 13) to determine
the appropriate assembly parts required
to properly reconnect the water supply.
NOTE: Hand tighten only. DO NOT use
thread lubricants. Use of thread sealants
or lubricants can damage plastic nut
and result in ooding and property
damage.
If you need to adjust the
orientation of the ush
valve (A), release from
base by (1) turning
counterclockwise until
tabs unlock. (2) Lift
valve out and
adjust/orient as needed.
Turn on water supply. Check for leaks.
www.uidmaster.com 9
4.5 Install handle
4.4 Rotate (if necessary)
4.6 Reconnect 4.7 Turn on water supply
+
_
5.1
5.2
5.3
2
1
M
D
L
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
Compare water level after tank has lled with existing
line marked in step 1.1. The new ll valve comes with an
adjustment screw found at the end of oat control arm.
Turn screw clockwise to increase water level, and
counter-clockwise to decrease water level.
As marked
in step 1.1
The blue oat controls the
half ush.
(1) Pull out stop (D) on blue
oat (M).
(2) Raise blue oat (M) to the
TOP of the rail (L).
www.uidmaster.com
10
Step 5: Final adjustments
5.1 Fill valve adjustment
5.2 Adjust blue oat
