INSTALLATION AND USER INSTRUCTION
GUIDE
Aviator Stove
Model No (s)
MBSC11ME
Electric Stove
This guide should be used to install and care for
your Flavel Electric heater.
Read all information carefully prior to installation
and use.
Supplied By www.heating spares.co Tel. 0161 620 6677
Installation
IMPORTANT
Please read the instructions below before
installation or use of your Flavel Electric Heater.
NEVER use this heater where it may come into
contact with water i.e. bathroom, show
er room, kitchen.
NEVER leave unsupervised children where the
heater is left switched ON or is left
unguarded.
NEVER use this heater beneath a fixed socket
outlet.
NEVER cover or obstruct the fan outlet, as this
will cause the appliance to overheat.
NEVER install the heater close to combustible
material i.e. curtains or similar. Allow a
minimum of one metre around the
heater.
NEVER route the mains cable beneath carpet.
NEVER use aerosols or similar close to the
heater.
NEVER use the heater to dry clothes or similar.
NEVER use the heater by means of an
automatic control or timer, as this may
cause risk of fire if the heater is moved
or covered.
The appliance MUST be disconnected from the mains
supply before commencing cleaning, or maintenance.
Ensure the heater is firmly secured to the fixing plain to
prevent it from falling forward.
Use a suitable fireguard to protect both the infirm and young
children who could come into contact with the heater.
Supplied By www.heating spares.co Tel. 0161 620 6677
Appliance Data
Supply Voltage 230V ac 50Hz
Fuse Rating 13 Amp
Heating Element 2 x 1kW
Mains Cable 1 x 1.9M PVC 1mm2Cable
Illumination 1 x 60W Amberglow Bulb
This Flavel Electric Heater is manufactured by: -
CFM Europe Limited
Trentham Lakes
Stoke on Trent
Staffordshire
ST4 4TJ
Installation Requirements
The Flavel Electric heater is supplied with a moulded three-
pin plug (13Amp) and approximately 2 metres of flexible
mains cable (1mm2). The appliance and surround should
therefore be located close to a suitable mains socket to
enable connection. The electrical socket MUST be easily
accessible to allow disconnection.
This appliance must not be directly installed on a
carpet or similar material. We recommend that it
is fitted onto a hearth or similar non-combustible
material.
This heater MUST be earthed. If in any doubt consult a
suitable competent person.
Connections
L = Brown
N = Blue
E = Green / Yellow
Replacement fuses should be approved and conform to BS
1362. Before use ensure that the supply voltage matches
that marked on the appliance. The mains cable should be
routed from the heater to the socket connection without
Supplied By www.heating spares.co Tel. 0161 620 6677
being trapped or being liable to damage. If the mains cable
is damaged it should be replaced by a suitably competent
qualified person.
The heater is suitable for installation as a free standing
appliance.
A minimum of 300mm clearance is required at each side
and at the rear of the appliance. Do not install this appli-
ance if you do not have 300mm clearance to the side and
rear panel.
If fitted into an open draught type fireplace or chimney then
it may be advisable to blank off the aperture to reduce the
amount of draught created through the fireplace, which can
cause operation of the safety cut-out.
Unpacking The Appliance
This Flavel Electric heater is supplied in a single pack
carton.
All Instructions should be read prior to unpacking or
installing the appliance.
Ensure all parts including loose items have been removed
prior to discarding the packaging.
Product Checklist
1off Flavel Electric Heater Main Body
including Bulb Assy
1off Instruction / Guarantee Literature
Supplied By www.heating spares.co Tel. 0161 620 6677
Operation Of Heater
The heater is operated via the use of three switches situated
on the left hand side of the canopy.
Switch No Marking Operation
Switch On O I On / Off. Depress to I,
this operates the flame
effect.
Switch Two I1kW heat setting and
Fan
Switch Three II 2kW heat setting and
Fan
All three switches are mechanically linked, therefore when
switch one is turned off, all switches are turned to Off.
Note:
When turning off the heat settings it may be
necessary to wait for the fire to ‘reset’ before
turning heat settings back on. This is due to the
normal operation of the ‘safety cut-out’ device.
IMPORTANT
Safety Cut Out
This appliance is fitted with an automatic safety cut out. This
operates if the air outlet beneath the canopy becomes
covered or blocked. This will prevent the fan heater from
operating.
In order to RESET the appliance the following procedure
should be followed:-
Switch OFF the appliance and disconnect the appliance
from the mains supply
Leave the appliance disconnected for a MINIMUM of 10mins
Check the appliance is free from all obstructions and remove
safely
Switch ON the appliance at the mains supply socket
Supplied By www.heating spares.co Tel. 0161 620 6677
Operate the appliance as shown above
If the appliance fails to operate, repeat the above procedure
ENSURING the appliance is disconnected from the mains
supply at the wall socket.
If after repeating this procedure the appliance fails to oper-
ate CHECK the fuse within the wall socket / plug. If after car-
rying out both of the above procedures the appliance still
fails to operate, then call a suitably qualified person or CFM
Europe Service Engineer.
Care and Cleaning
Always dis-connect the appliance from mains
supply and allow to cool before any cleaning
operation.
Trim parts may be cleaned using a clean, damp cloth.
Never use any abrasive cleaners and chemical agents as
damage may occur to the paint finish.
Supplied By www.heating spares.co Tel. 0161 620 6677
TROUBLESHOOTING
Fire Illuminates but no flame effect Check the flame effect disc is free
is seen from obstruction (behind coal effect)
Fire operates with heat then cuts out Safety ‘Cut-Out’ has operated,
ensure the heater is not covered or
obstructed. Turn off appliance and
wait 10 mins to reset. Retry
appliance.
No flame effect is seen after switch is Check condition of bulb (see below)
switched to position I If bulb is ok check condition of fuse.
It is important that any electrical work is undertaken by a suitably
qualified, competent person.
CHANGING THE LIGHTBULB
Disconnect from mains supply.
Remove brass trim (three parts)
Remove coalform retaining brackets (LH / RH) secured with two screws.
Remove one of two screws retaining flame effect disc and rotate away from bulb.
Remove bulb from bulbholder, and refit new 60W firelglow bulb.
Refit the flame effect disc / holder (two screws).
Refit coalform and retaining brackets (ensure flame effect disc is freely rotating)
Refit brass trim.
The Following Spare Parts are available from the manufacturer (details on
back page)
B-53310 Coal Effect Front
B-59870 60W Fireglo Bulb
B-61020 LH Trim
B-61030 RH Trim
B-61040 Top Trim
Supplied By www.heating spares.co Tel. 0161 620 6677
CONTACT INFORMATION
Technical Enquiries
(01782) 339039
Service
(08700) 101187
Spares Enquires
(01782) 339010
The Following Information Will Be Required When Contacting CFM
Europe Ltd. For Advice :-
Customer Address including postcode
Model No.
Serial No.
Brief Description of Fault
Due to our policy of continual improvement and development the exact accuracy of
descriptions and illustrations contained within this book cannot be guaranteed.
Part No. B-59630 Issue 1
CFM Europe Ltd.
Trentham Lakes
Stoke-on-Trent
Staffordshire
ST4 4TJ
Telephone - General Enquiries : (01782) 339000
