1 vi30/40 Dual Cooled QSG Version 2.1
Firestar™ vi30/40 Dual Cooled Laser Quick Start Guide
1. Unseat the wiring by sliding the harness out of
the notch, then down and out of the foam as
shown below.
2. Remove the laser from the box and locate the
mounting hardware kit at the bottom of the
box under the laser.
Important Re-packaging Note:
Assure the two (2) H2O ports are nested inside
the foam notches, & all residual water drained
from the system.
Carefully push the wire harness through the notch in the top foam piece, and save with packaging.
There is only one way the laser ts into the foam!
If laser does not reseat easily, try ipping it around
so the ports sit into the foam as shown.
Caution! Unpacking the wire harness incorrectly can lead to damage.
Keep All specially designed Foam Packaging and end-caps, you will need to re-use it
when re-packaging/moving your laser. Refer to this guide and the Technical Reference
chapters in the laser’s Operation Manual when re-packaging for shipping and/or reloca-
tion. Hint-if laser doesn’t re-seat into the foam easily, try ipping it around 180 degrees.
If you discover shipping damage, document the damage (photographically if possible), then immediately
notify the shipping carrier (responsible party) and SYNRAD. After unpacking, review the Inventory list in the
Intro section within the operators manual.
If you need a replacement box for packing and/or shipping your laser, contact us.
Caution! When re-packing the laser for relocation or shipment, use compressed shop air (less than 29
PSI) to blow out excess water from the cooling systems. Wear safety goggles! Nothing can be on the
sides of the laser at any time as damage will occur. There is only one way the laser ts into the foam! All
components must be stowed under the laser. Re-package the wire harness as shown above. The wire
harness &/or ports can be damaged in shipping if not re-packaged as shown in this guide, the drawings,
operation manual, and/or resources located in our website.
Caution
Possible
Equipment
Damage
Mounting feet and/or rails are optional, for complete details, refer to the laser’s Operator’s Manual and
drawings and Mounting Quick Start Guide located on our website.
Important
Note:
See your Marking Head (If utilized) and the laser’s Operators Manual for complete installa-
tion details and instructions.
Read all Danger, Warning, Caution terms, symbols, and instructions located in
the (Laser Safety Hazard information) sections in the Laser’s Operation Manual and in
our Laser Safety/Compliance 101 on our website.
Laser Unpacking:
Hint:
