ING. O. FIORENTINI S.p.A.

INDUSTRIAL CLEANING MACHINES

FLOOR SCRUBBER-DRYER

MODEL BIG 38/48

INSTRUCTIONS FOR USE

AND MAINTENANCE

CONTENTS

GENERAL INFORMATION

1.1. Symbols used……………………………….…….........................……..................page

1.2. Disclaimer…...............................................................................................................

1.3. Use of the manual…………......…………………………....….........…….............…….

1.4. Warranty..............................................................…………...…………...….…...........

1.5. Declaration of Conformity........................................…...........………….………..……

MACHINE FEATURES AND TECHNICAL DATA

2.1. Identification………………......…...............................….…………….….……............

2.2. Description and components….……………...…....................................................…

2.3. Technical data sheet................................…........……………………….....…............

SAFETY

3.1. Intended use.…………..………....……………....…....……………….....………….......

3.2. Improper use…………………………………………………………………..…………...

3.3. Recommended equipment……………………………………………………….....……

3.4. Operator qualifications..............……………….......……………...…………................

3.5. Safety and warning devices……………..................…...………….............................

3.6. Residual risks………………………………………………………………………………

3.7. Safety signs……………………………………………………………….................…...

STAR-TUP AND OPERATION INSTRUCTIONS

4.1. Transport and handling............. .….....................…....………….….…………........

4.2. Storage........................... ...............…………….………….....................................

4.3. Unpacking the machine... .....................……………………..........................….....

4.4. Handling the unpacked machine…. .…..........………………………..……............

4.5. Installation…..........................................................………………..……................

4.5.1. Battery installation……..........……..….......……………….…...….…….........….....

4.6. Control and monitoring devices……………………………….............................…

4.6.1. Dashboard…………………………………………………………………….......……

4.7. Operation…………………………………………..........................................……..

4.7.1. Starting and preparing the machine………………………………..……………….

4.7.2. Choice of detergent………………………………………………………….………..

4.7.3. Adjustment of the driving position….………………………………............………

Congratulations on your choice!

Thank you for choosing to purchase a product by FIORENTINI S.p.A., a global leader in

the manufacture and marketing of industrial cleaning machines.

Our long-standing experience and acquired know-how are the best guarantee of the

technical quality of your purchase; all our products are built from top quality materials to

ensure maximum reliability, sturdiness and functionality and to meet the requirements of

even the most demanding customers. FIORENTINI has recently obtained UNI EN ISO

9001:2000 certification for its quality system certificate.

Feel free to contact us with any technical or commercial inquiry; we will be happy to

supply any details and information that you may need.

4.7.4. Pedal functions…………………………………………………………..........……..

4.7.5. Regulating the detergent solution………………………………………….….……

4.7.6. Squeegee adjustment…..……………………………….………………….….……

4.7.7. Drain hoses………………….............…......………….………..................….……

4.7.8. Replacing the brushes………………………………..…………………….....….…

4.7.9. Replacing the squeegee blade………………….…………………………....…….

4.7.10 Tilting the fairing…………………………..............…………………………

MAINTENANCE

5.1. Routine maintenance table…… ……..................….....…..………….................

5.2. Battery maintenance……………………..……………………………………..…..

5.2.1. Measuring specific gravity……………………….……………..................….

5.2.2. Topping up the water…………………………...............................................….

5.2.3. Charging limits……………………………………………………………………….

5.2.4. Batteries not in continuous service or inactive …..........………..............……...

5.2.5. Battery disposal….......………………………………………..…………………….

5.3. Maintenance of the suction motor…..……………………....……………………..

5.4. Checking the electrical system………………………………….……….………….

5.5. Inspection summary schedule……………………………….................………….

5.6. Maintenance Log………………………...............………………………………….

TECHNICAL SUPPORT

6.1. Contact details for technical support............…………................……..................

6.2. Complaint report……………………………..…………...…………………..............

MACHINE FEATURES AND TECHNICAL DATA

BIG 38/48

1. GENERAL INFORMATION

1.1. SYMBOLS USED

This symbol is used to call the operator’s attention to important procedures or precautions

required to prevent harmto users orthemachine

This symbol is used to call the operator's attention to important general information.

1.2. DISCLAIMER

1.3. USE OF THE MANUAL

This manual provides extensive coverage of all topics deemed necessary for easy and safe use of the

machine, in compliance with European Directives on product safety.

We therefore advise all authorised operators to read all parts of the manual carefully, to follow its indications

thoroughly and to contact FIORENTINI S.p.A. for clarifications in case of any doubt. The manual should also

be used for reference whenever there are doubts concerning a procedure or operation and for training new

operators.

For reasons of printing, the pictures and drawings may appear slightly different from the actual machine

parts, without however casing any confusion.

Special symbols and bold and/or Italic fonts are used to highlight important information, particularly with

regard to safety.

The current revision code is indicated at the bottom left corner of every page. The list of revised pages is

shown at the end of the manual.

1.4. WARRANTY

The warranty terms and conditions are stated below unless otherwise specified in the order confirmation.

This manual is the property of FIORENTINI S. p. A.

The reproduction of all or part of this manual or its transmission to third parties by any

mechanical or electronic means or otherwise is forbidden without written authorisation

from the manufacturer. This manual is supplied to customers in a single original copy

unless otherwise specified at the time of ordering.

This manual is supplied as an integral part of the machine and should remain with the machine if transferred

to a new owner. This manual should be kept in a safe location for the entire working life of the machine. The

purchaser is responsible for making this manual available to all users. If this manual is lost,a duplicateshould be

obtained fromFIORENTINI.

FIORENTINI S.p.a. will not be held responsible for any damages to persons and/or property resulting from

failure to comply with the instructions in this manual.

FIORENTINI reserves the right to introduce any required technical and commercial changes without prior

notice. Therefore, any data and information contained in this manual may be changed and/or updated.

MACHINE FEATURES AND TECHNICAL DATA

BIG 38/48

SCOPE OF THE WARRANTY

The machine has been designed and built for trouble-free use over several years. However, if any

malfunction occurs during the warranty period, FIORENTINI S.p.A. undertakes to repair or replace free of

charge any parts revealing damage or premature wear due to faulty materials, factory defects or incorrect

assembly. The warrantydoes notcover any parts with damage or premature wear dueto:

failure to observe the instructions contained in this manual;

tampering or alterations made without FIORENTINI’s specific approval;

use of non-original spare parts;

worn replacement parts, such as brushes, squeegee blades etc.

For installed electrical parts and commercially available parts, FIORENTINI S.r.l. extends to purchasers the

same warranty terms granted to FIORENTINI itself by the suppliers of the parts.

WARRANTY PERIOD

The warranty is valid for 12 months, starting from the machine delivery date. This is a fixed warranty term

and may not be extended due to replacements or repairs carried out during the warranty period.

EXCLUSIONS

The warranty does not cover materials and components subject to normal wear (brushes, squeegee blades

etc.) and those whose working life cannot be determined beforehand.

WARRANTY APPLICATION TERMS

Defective components must be returned to FIORENTINI S.p.a. in order to establish the causes of any

defects discovered and determine warranty applicability. Repairs and replacement under warranty will be

carried out on FIORENTINI’s premises, by third parties or on the customer's premises. For services carried

out on the customer premises, power sources and any special equipment necessary for the repairs will have

to be provided by the customer.

PRODUCT RETURNS

Written approval must be obtained from FIORENTINI's Technical Support office before returning parts for

replacement or repair under warranty.

All defective parts must be carefully repacked in order to avoid damage during transport. Products must be

returned on a free-on-board basis, complete with:

the serial number from the machine data plate (see point 2.1);

the item code and installation position of the returned part, as given on the spare part list;

a detailed description of the defect and the conditions under which it became apparent;

In the case of defective electrical or electronic components,

please return the parts separately from other materials, so that

waste containing dangerous substances can be segregated and

Waste Electrical and Electronic Equipment (WEEE) can be recycled

in accordance with Directive 2002/96/EC.

A missing machine data plate will result in immediate loss of any warranty rights.

1.5. DECLARATION OF CONFORMITY

The Declaration of Conformity is supplied with the purchased machine and the use and maintenance

manual.

MACHINE FEATURES AND TECHNICAL DATA

BIG 38/48

MACHINE FEATURES AND TECHNICAL DATA

BIG 38/48

2. MACHINE FEATURES AND TECHNICAL DATA

2.1. IDENTIFICATION

The machine is identified by an adhesive plate attached to the protective casing of the steering column,

which contains indelible data regarding “CE” marking.

The plate must never be removed and should always be kept legible. In case of damage,

a duplicate should be ordered. The machine cannot be sold without the plate.

2.2. DESCRIPTION AND COMPONENTS

The BIG 38/48 scrubber-dryer is designed to clean all flat surfaces by washing and then suctioning the waste

water. The scrubber-dryer has a drive system consisting of two gear motors installed on the rear wheels,

directly on the brushes and powered in turn by electric accumulators, as are the suction motors.

The machine uses three rotating brushes to clean the floor surfaces, assisted by the action of the water and

detergent. As the machine travels forward, the rear brush (squeegee), in contact with the floor, collects the

water, which is immediately conveyed by suction to the recovery tank.

The dashboard regulates all the machine functions and provides the operator with an LED system that

indicates the remaining battery capacity and any errors detected by the electronic board, which are displayed

as rapid flashes. All the main functions of the machine can be activated through the dashboard. In detail,

these include:

raising, lowering and switching on the brushes;

regulating the water delivery flow;

starting the suction motors;

lowering/raising the squeegee;

turning the lights on and off;

turning on the flashing beacon and the buzzer;

starting and stopping the machine.

The load-bearing structure of the machine consists of a cold-galvanised or stainless steel chassis, which

prevents oxidation problems that could affect its reliability.

The machine comprises the following main components:

a cold galvanized or stainless steel chassis;

Ing. O.Fiorentini S.p.A.

MADE

50030 Piancaldoli (FI)

IN ITALY

Mod

BIG38

S.N.

101

2008

rpm

3600

780

174

4.75

FIGURE 2.1

MACHINE FEATURES AND TECHNICAL DATA

BIG 38/48

an ABS plastic washing liquid tank;

an ABS plastic waste water recovery tank with flexible suction and drainage hoses;

three washing brushes;

a squeegee;

one idle wheel;

two drive wheels controlled by electric motors;

the steering assembly;

the driver’s seat.

In consideration of recent EU product safety concerns, FIORENTINI has designed and built this machine in

compliance with the safety and health requirements provided by the applicable Directives. High quality

materials, advanced technology and FIORENTINI’s experience have been combined to produce a machine

of high performance and reliability. Each machine undergoes rigorous testing during construction and careful

final inspection.

MACHINE FEATURES AND TECHNICAL DATA

BIG 38/48

2.3. TECHNICAL DATA SHEET

The specifications provided above are not binding on the manufacturer and may therefore be

changed without notice. FIORENTINI can be contacted at any time for further information

(see point 6.1.).

UNIT OF MEASUREMENT CONVERSION TABLE

Length

1 inch = 1” = 25.4 mm

Power

1 kW = 1.36 CV = 1.34 BHP

Temperature

T (K) = t (°C) + 273 / t (°F) = 1.8 t (°C) + 32

Pressure

1 bar =100 kPa = 14.5 psi

MODEL

BIG 38

BIG 48

MAIN SPECIFICATIONS

Total working width

950 mm

1150 mm

Maximum output per hour

5700 m²/h

6900 m²/h

Maximum working autonomy

5-6 h

5 h

Solution tank capacity

300 l

Recovery tank capacity

300 l

300l

GENERAL SPECIFICATIONS

Traction (front/rear)

rear

Type of traction

Two electric gear motors

Travel speed

0/6 km/h

Max. gradient with a full load

12%

Depression

1600 mBar

Brush head pressure

0/100 kg

Noise (operator’s ear)

<75 dB

Minimum turning radius

2450 mm

2800 mm

ELECTRICAL SYSTEM

Power supply voltage

36V

Suction motor

2x 850W

Brush motors

3x 750W

Drive motors

2x 750W

Power supply

36V - 450A/h

DIMENSIONS AND WEIGHT

Length

1800 mm

Width

1000 mm

Height

1820 mm

Number/diameter of brushes

3x Ø330 mm

Squeegee width

1300 mm

1470 mm

Battery weight

530 kg

SAFETY

BIG 38/48

3. SAFETY

3.1. INTENDED USE

The BIG 38/48 is a floor scrubber-dryer machine designed and built for use in

industrial environments for washing and drying, with waste water removal, of flat

horizontal surfaces or sloping surfaces with gradients not exceeding 12%.

3.2. IMPROPER USE

machine operation by unauthorised personnel;

washing uneven and/or bumpy surfaces;

washing of sloping surfaces;

washing of surfaces with a gradient exceeding 12%;

performing U-turns on a slope exceeding 5% and with a speed of over 1 km/h;

using the machine in environments containing dangerous substances, and

particularly in explosive atmospheres or unsuitable microclimatic conditions;

cleaning machine surfaces in the presence of flammable substances;

use of the machine as a means of transport for people or other vehicles;

modifying or tampering with the protection devices;

charging the batteries in locations with insufficient ventilation;

failure of operators to comply with current safety regulations/procedures;

fitting equipment/devices likely to interfere with machine operation;

introducing changes or alterations not authorised by FIORENTINI;

using acid solutions likely to damage the machine;

failure to comply with the specifications of the use and maintenance manual.

The information labels placed on the machine should be read carefully and should not be

covered for any reason. FIORENTINI shall assume no liability in any case of improper use

of the machine as described above.

3.3. RECOMMENDED EQUIPMENT

To make the best use of your machine, equipment specially designed and tested by Fiorentini and original

spare parts should be used. The FIORENTINI S.p.A. technical department is available to customers to meet

any design needs concerning parts and components required for a particular use of the machine.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels FIORENTINI Machine de plancher

FIORENTINI

FIORENTINI S 48B Manuel utilisateur

FIORENTINI

FIORENTINI SCOIATTOLO 75 Manuel utilisateur

FIORENTINI

FIORENTINI I32NEW Manuel utilisateur

FIORENTINI

FIORENTINI JOLLY 17 Manuel utilisateur

FIORENTINI

FIORENTINI I38UE Manuel utilisateur

FIORENTINI

FIORENTINI HS 2000 Instructions d'utilisation

FIORENTINI

FIORENTINI I 42TE Manuel utilisateur

FIORENTINI

FIORENTINI DE LUXE 43B Manuel utilisateur

FIORENTINI

FIORENTINI N 45B Manuel utilisateur

FIORENTINI

FIORENTINI SMILE 70 Manuel utilisateur

FIORENTINI

FIORENTINI DELUXE 55-60 Instructions d'utilisation

FIORENTINI

FIORENTINI JOLLY 13 Manuel utilisateur

FIORENTINI

FIORENTINI N45E Manuel utilisateur

FIORENTINI

FIORENTINI I 16 Instructions d'utilisation

FIORENTINI

FIORENTINI CARPETFOAM-18 Manuel utilisateur

FIORENTINI

FIORENTINI ASPIRIK Manuel utilisateur

FIORENTINI

FIORENTINI JOLLY 20 Manuel utilisateur

FIORENTINI

FIORENTINI I42TD Manuel utilisateur

Manuels Machine de plancher populaires d'autres marques

Nilfisk-Advance

Nilfisk-Advance Advance SC370 17B Manuel utilisateur

Numatic

Numatic ET 4045 Manuel utilisateur

HAWK ENTERPRISES

HAWK ENTERPRISES HP1513-180BRUTE Manuel utilisateur

Mytee

Mytee 8070 Mytee-Lite Manuel utilisateur

Kärcher

Kärcher B 140 R Manuel utilisateur

Triple S

Triple S Ace 26T1 Manuel utilisateur

Nilfisk-Advance

Nilfisk-Advance SW 750 Manuel utilisateur

Tornado

Tornado Marathon 2000 98190 Manuel

Windsor

Windsor ADMIRAL Admiral 8 Manuel utilisateur

Numatic

Numatic TTB 1117/100 Manuel utilisateur

Tennant

Tennant 8210D Manuel utilisateur

Nobles

Nobles Frontier Manuel du produit

lavina

lavina 21-X Manuel utilisateur

KENT

KENT Edge 28B Manuel utilisateur

Tennant

Tennant 215 Manuel du produit

Windsor

Windsor BDP 51/2000C Manuel utilisateur

CleanFreak

CleanFreak DURA-18HD Manuel utilisateur

Nilfisk-Advance

Nilfisk-Advance Warrior 34RST Guide de l'administrateur
