FIILPOW A6 PRO Manuel utilisateur
User Manual
A6 PRO
TIRE INFLATOR
Thank you for choosing FIILPOW.
Thank you for purchasing FIILPOW Tire inflator A6 Pro. With up to 150PSI pressure value, this inflator can help
you to deal with emergencies at ease.
Contents
1. PRODUCT OVERVIEW
2. PACKAGE CONTENTS
3. CONNECTING AIR TUBE WITH INFLATED ITEMS
4. CONNECTING THE AIR TUBE AND NOZZLE
5. CONNECTING THE INFLATOR WITH THE CAR
6. TURN ON/OFF THE INFLATOR
7. DETECTING CURRENT PRESSURE VALUE
8. DETERMINING THE RIGHT PRESSURE VALUE
9. MANUAL MODE AND 4 SMART MODES
10. START / PAUSE
11. DISCONNECTING THE AIR TUBE
12. LIGHT
13. TROUBLESHOOTING
14. SPECIFICATIONS
15. SAFETY INSTRUCTIONS
16. INSTRUCTIONS ON ENVIRONMENT PROTECTION
17. WARRANTY CARD
- 01 -
02
03
04
04
05
06
06
06
08
11
11
12
12
13
14
15
16
1. PRODUCT OVERVIEW
10
11
- 02 -
12
1 2 3 4
6
5
7
8
9
1.Power button
2.Pressure value
3.Pressure unit
4.“+” button
5.“-” button
6.LED screen
7.Preset mode
8.Unit button
9.Air tube and connector
10.Emergency light
11.Light button
12.DC charging cable
2. PACKAGE CONTENTS
A6 Pro Tire
inflator × 1
Needle valve
adaptor × 1
Carrying
bag × 1
User
manual × 1
Extension
nozzle × 1
Schrader-Presta
valve
adaptor × 1
Replacement
fuse× 1
Carefully check package contents, if anything is missing or damaged, please contact online customer service for
support.
- 03 -
3. CONNECTING AIR TUBE WITH INFLATED ITEMS
4. CONNECTING THE AIR TUBE AND NOZZLE
1. Pull out the built-in air tube on the upside of inflator.
2. Connect the air tube with the inflated item.
Schrader Valve
Tires on cars, motorcycles, e-bikes, and most mountain bikes use a Schrader
valve.
To inflate: The inflator can be directly connected to a Schrader valve to start inflating.
To deflate: Use an proper tool(such as 4mm Allen wrench) to press the pin
inside the air valve to release air.
Presta Valve Adapter
Road bicycles and certain mountain bikes use a Presta valve which requires
the included Presta valve adapter to be used.
To inflate:
1. Connect the Presta valve adapter to the Schrader valve of the air tube.
2. Unscrew the ring of the Presta valve of the tire.
3. Connect the Presta valve adapter to the tire’s Presta valve to start inflating.
To deflate: Unscrew the ring of the tire’s Presta valve, and press the valve stem
down to release air.
Valve Type
Valve Type
Inflation Adapter
Inflation Adapter
- 04 -
5. CONNECTING THE INFLATOR WITH THE CAR
Needle Valve Adapter
To inflate balls like basketballs and footballs, the included needle valve
adapter will need to be used.
To inflate: Screw the needle valve adapter onto the Schrader valve
adapter, then insert the needle into the valve of the ball to start inflating.
To deflate: Insert the needle valve adapter into the valve of the ball, and
gently apply pressure to the ball to release air.
Valve Type Inflation Adapter
1. Open the cover of the DC cable compartment below the
inflator.
2. Take out the adapter of the DC cable and plug it into a
12V cigarette lighter socket.
Note:
Please make sure the car engine is running.
Please make sure the cigarette lighter socket functions
well before plugging the adapter of DC cable.
Small tips to replace the fuse:
1. Unscrew the cap on the head of the adapter of the DC
cable.
2. Take out the old fuse and insert the replacement fuse.
3. Screw back the cap.
- 05 -
OFF
SET
6. TURN ON/OFF THE INFLATOR
7. DETECTING CURRENT PRESSURE VALUE
8. DETERMINING THE RIGHT PRESSURE VALUE
Turn ON
Long press the power button 1.5 seconds to turn on.
Turn OFF
When the inflator is turned on, long press the power button 1.5
seconds to turn off.
When the inflator is turned on, connect the air tube to the inflated device, and
then the LED screen will automatically display current pressure value.
For safety and prevent injuries from bursting items due to over-inflation, always refer to the instructions or relevant
directions accompanying the item to be inflated before inflating it, in order to determine the correct air pressure.
Tires
The recommended air pressure of tires for cars, bicycles, and motorcycles is
indicated on the tire's sidewall. The recommended tire pressure for cars is also
indicated on the driver's side door jamb.
For details concerning load carrying capacity and recommended air pressures,
refer to your vehicle's instructions or manual.
- 06 -
Air Pressure Reference Table
Balls
The recommended air pressure for footballs, basketballs, volleyballs, and other balls is
indicated near the ball's air valve.
Category
Bicycles
Motorcycle
Cars
Balls
Type Recommended
Pressure Range
12-, 14-, & 16-inch bicycle tires
20-, 22-, & 24-inch bicycle tires
26-, 27.5-, & 29-inch mountain bike tires
700c road bike clincher tires
700c road bike tubular tires
30 - 50psi
40 - 50psi
45 - 65psi
100 - 130psi
120 - 145psi
Scooter & street motorcycle tires
Car tires
1.8 - 3.0 bar
2.2 - 2.8 bar
Basketball
Soccer ball
Volleyball
Football
7 - 9 psi
8 - 16 psi
4 - 5 psi
12 - 14 psi
- 07 -
9. MANUAL MODE AND 4 SMART MODES
For safety, please read the recommended inflation pressure value provided by the manufacturer of the inflated
devices before inflating. Otherwise, it might cause unexpected injury or burst due to over-inflation.
Switch Mode
Switch Pressure Unit
Click the unit button to cycle through car mode→ motorcycle mode→bicycle
mode→ball mode→manual mode.
Note:
1. The tire inflator will automatically turned on by manual mode. When in the
manual mode, no mode icon is selected on the screen.
When on the manual mode, long press 1.5 seconds to switch from PSI,Bar,
Kpa pressure unit.
- 08 -
Default Pressure Value Of Different Modes
Mode Default Pressure Value
Manual mode
(When in the manual mode, no
mode icon is selected on the
screen. )
Car mode
Motorcycle mode
Bike mode
Ball mode
2.5BAR
2.4BAR
45PSI
8PSI
30PSI(Can be changed)
- 09 -
