Driver Manual

(Supplement to the FieldServer Instruction Manual)

FS-8700-112 FCI 7100 Series Serial Driver

Driver Version: 1.01

Document Revision: 1

FS-8700-112_FCI_7100 Driver Manual Table of Contents

TABLE OF CONTENTS

1. FCI 7100 SERIES SERIAL DRIVER DESCRIPTION........................................................3

2. DRIVER SCOPE OF SUPPLY...........................................................................................4

2.1. Supplied by FieldServer Technologies for this driver ...................................................4

2.2. Provided by the Supplier of 3rd Party Equipment..........................................................4

2.2.1. Required 3rd Party Hardware.....................................................................................4

2.2.2. Required 3rd Party Software......................................................................................4

2.2.3. Required 3rd Party Configuration...............................................................................4

2.2.4. Optional Items...........................................................................................................4

3. HARDWARE CONNECTIONS ..........................................................................................5

4. CONFIGURING THE FIELDSERVER AS A FCI 7100 SERIES SERIAL DRIVER

CLIENT.........................................................................................................................................7

4.1. Data Arrays/Descriptors ...............................................................................................7

4.2. Client Side Connection Descriptions ............................................................................8

4.3. Client Side Node Descriptors .......................................................................................9

4.4. Client Side Map Descriptors.......................................................................................10

4.4.1. FieldServer Related Map Descriptor Parameters....................................................10

4.4.2. Driver Related Map Descriptor Parameters ............................................................10

4.4.3. Timing Parameters..................................................................................................11

4.5. Map Descriptor Example 1 – Sensor / Module Events...............................................12

4.6. Map Descriptor Example 2 – Bit Storage....................................................................13

5. CONFIGURING THE FIELDSERVER AS A FCI 7100 SERIES SERIAL DRIVER

SERVER.....................................................................................................................................14

APPENDIX A. ADVANCED TOPICS ......................................................................................15

Appendix A.1. Events and Event Categories........................................................................15

Appendix A.2. Extending the Event Table............................................................................16

Appendix A.3. How Data is stored........................................................................................16

Appendix A.4. Panel Synchronization...................................................................................18

Appendix A.5. What happens when the panel sends a Reset Message..............................18

FS-8700-112 FCI 7100 Series Driver Manual Page 3 of 24

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: [email protected]

1. FCI 7100 Series Serial Driver Description

The FCI 7100 Series System Control Units are manufactured by Fire Control Instruments. A

7100 with an enabled serial port can transmit data to a FieldServer which can, in turn, make the

data available to other devices including those which communicate using different protocols

(e.g. BACnet)

This passive Client driver does not poll for data, nor does it send data or commands to the

7100. Messages received from the 7100 are ignored or stored on the FieldServer depending on

the status of the panel. The method of message processing and location on the FieldServer is

determined in the FieldServer configuration file. Once stored in the FieldServer the data is

available to be read or written using other protocols such as BACnet.

No automatic panel data synchronization technique exists. The data in the FieldServer and the

panel status have to be synchronized manually. This typically requires a panel reset.

Since the driver cannot send data or commands to the 7100 it cannot be used to acknowledge,

silence or reset alarms and other events.

The driver can process the single line messages sent from 7100 firmware versions earlier than

2.20 and 3 line messages produced in firmware versions 2.20 and later. Processing of 3 line

messages requires the 20 character System ID label to be defined.

The driver can process messages from networked panels. The driver connects to the main

panel. Subsidiary panels are configured to send event data to the main panel which then sends

messages to the FieldServer. If the panel is configured to send 3 line messages then the

source node information is sent in the line preceding the event and the driver uses this to

determine the panel at which the event originated and to store data appropriately.

The driver provides both client and server emulation. The server side of the driver is intended to

support FieldServer’s Quality Assurance program and is not intended to provide complete

emulation of a 7100 and is thus not fully documented. Should you require the Server side

functionality to be documented and enhanced, please contact FieldServer’s sales group.

Max Nodes Supported

FieldServer Mode Nodes Comments

Client 1

1 Node per serial port. If there is more than one alarm

panel they can be networked and configured to send event

data to the primary panel. The driver can process

messages which identify the node of origin.

Server 1 1 Node per serial port

FS-8700-112 FCI 7100 Series Driver Manual Page 4 of 24

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: [email protected]

2. Driver Scope of Supply

2.1. Supplied by FieldServer Technologies for this driver

FieldServer Technologies

PART # Description

FS-8915-10 UTP cable (7 foot) for Ethernet connection

23069 RJ45-RJ11/12 Cable assembly for FS connection to FCI

panel.

-FS-8700-110 Driver Manual.

2.2. Provided by the Supplier of 3rd Party Equipment

2.2.1. Required 3rd Party Hardware

FCI Panel must be equipped with a RS-232 Serial Printer Port.

FCI Panel must be equipped with a PTRN module for isolation of the serial port.

2.2.2. Required 3rd Party Software

None

2.2.3. Required 3rd Party Configuration

None known.

2.2.4. Optional Items

None.

FS-8700-112 FCI 7100 Series Driver Manual Page 5 of 24

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: [email protected]

3. Hardware Connections

The FieldServer is connected to the FCI panel as shown in the connection drawing.

BASE NAME:

FILE NAME:

FIELDSERVER

FCI 7100

CONNECTION DIAGRAM

DATE: 3/1/05

BY: MF

(408)-262-2299

FCI 7100 Series Panel

3Wire Cable (Tx, Rx, Gnd)

One Panel per Port

FieldServer provide a pre-fabricated cable.

FCI

Panel RJ45

FieldServer

In this view the RJ12 and RJ45 converter

clips are facing away from the viewer and

are not visible.

FS-8700-112 FCI 7100 Series Driver Manual Page 6 of 24

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: [email protected]

Top right hand side of

board.

Connector J3 – label on

right.

FS-8700-112 FCI 7100 Series Driver Manual Page 7 of 24

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: [email protected]

4. Configuring the FieldServer as a FCI 7100 Series Serial Driver Client

For a detailed di7100ssion on FieldServer configuration, please refer to the FieldServer

Configuration Manual. The information that follows describes how to expand upon the factory

defaults provided in the configuration files included with the FieldServer (See “.csv” sample files

provided with the FieldServer).

This section documents and describes the parameters necessary for configuring the FieldServer

to communicate with a FCI 7100 Series 7100.

4.1. Data Arrays/Descriptors

The configuration file tells the FieldServer about its interfaces, and the routing of data

required. In order to enable the FieldServer for FCI 7100 Series Serial Driver

communications, the driver independent FieldServer buffers need to be declared in the

“Data Arrays” section, the destination device addresses need to be declared in the “Client

Side Nodes” section, and the data required from the servers needs to be mapped in the

“Client Side Map Descriptors” section. Details on how to do this can be found below.

Note that in the tables, * indicates an optional parameter, with the bold legal value being the

default.

Section Title

Data_Arrays

Column Title Function Legal Values

Data_Array_Name Provide name for Data Array Up to 15 alphanumeric

characters

Data_Array_Format Provide data format. Each Data

Array can only take on one format.

Float, Bit, UInt16, SInt16,

Packed_Bit, Byte,

Packed_Byte,

Swapped_Byte

Data_Array_Length

Number of Data Objects. Must be

larger than the data storage area

required by the Map Descriptors for

the data being placed in this array.

1-10,000

Example

// Data Arrays

Data_Arrays

Data_Array_Name, Data_Array_Format, Data_Array_Length

DA_AI_01, UInt16, 200

DA_AO_01, UInt16, 200

DA_DI_01, Bit, 200

DA_DO_01, Bit, 200

FS-8700-112 FCI 7100 Series Driver Manual Page 8 of 24

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: [email protected]

4.2. Client Side Connection Descriptions

Section Title

Connections

Column Title Function Legal Values

Port Specify which port the device is

connected to the FieldServer P1-P8, R1-R21

Protocol Specify protocol used FCI_7100, FCI_7100_series,

FCI7100

Baud* Specify baud rate 1200 – Vendor Limitation

Parity* Specify parity None – Vendor Limitation.

Data_Bits* Specify data bits 8– Vendor Limitation

Stop_Bits* Specify stop bits 1– Vendor Limitation

Handshaking* The 7100 series panels do not support hand shaking.

Poll _Delay* This commonly used parameter has no meaning for this driver.

Example

// Client Side Connections

Connections

Port, Protocol, Baud, Parity

P8, FCI_7100, 1200 None

1Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction

manual for details of the ports available on specific hardware.

FS-8700-112 FCI 7100 Series Driver Manual Page 9 of 24

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: [email protected]

4.3. Client Side Node Descriptors

Section Title

Nodes

Column Title Function Legal Values

Node_Name Provide name for node Up to 32 alphanumeric characters

Node_ID

This parameter only has meaning

for this driver when multiple

panels are networked in an FCI

network. In this case the

NODE_ID is the panel number.

Set the Node_ID of the local panel

to zero, and create one node

descriptor for each panel setting

the Node_ID to the panel number.

The protocol is node-less - the

messages do not contain

information identifying a unique

source and/or destination node

address. Thus this parameter need

not be specified if only one 7100 is

connected per FieldServer serial

port. In networked configurations,

specify whole numbers 0,1,2,3 …

Protocol Specify protocol used FCI_7100, FCI_7100_series,

FCI7100

FCI_Reset_Acti

on_Option*

Only required for networked

configurations.

This parameter tells the driver

what to do with ‘Reset’ messages.

When not specified or set to

‘Reset_by_any_Node ‘ then the

driver will reset the data array

points associated with the given

node irrespective of the reset

message’s origin.

When set to

‘Reset_by_this_Node_Only’ then

the driver only resets the data

associated with the given node if

the reset originated from the same

node.

Reset_by_any_Node,

Reset_by_this_Node_Only

Connection Specify which port the device is

connected to the FieldServer P1-P8, R1-R21

Example

// Client Side Nodes

Nodes

Node_Name, Protocol, Connection

Panel-01, FCI_7100, P8

FS-8700-112 FCI 7100 Series Driver Manual Page 10 of 24

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: [email protected]

4.4. Client Side Map Descriptors

4.4.1. FieldServer Related Map Descriptor Parameters

Column Title Function Legal Values

Map_Descriptor_Name Name of this Map

Descriptor Up to 32 alphanumeric

characters

Data_Array_Name

Name of Data Array

where data is to be

stored in the

FieldServer

One of the Data Array

names from “Data Array”

section above

Data_Array_Offset Starting location in Data

Array 0 to maximum specified in

“Data Array” section above

Function Function of Client Map

Descriptor. Server, Passive_Client

4.4.2. Driver Related Map Descriptor Parameters

Column Title Function Legal Values

Node_Name Name of Node to fetch data from One of the node

names specified

in Section 4.3

Event Type

This driver uses this parameter to determine

the suitability of a Map Descriptor when

looking for a location to store data from an

incoming message.

A Map Descriptor may be defined to store

only ‘Alarm’, ‘Fault’, ‘Trouble’ or ‘Other events.

Alternatively, specify “Any”

A table of events vs. categories is provided in

Appendix A.1

Any, Other, Fault,

Alarm, Trouble

Point Type

This driver uses this parameter to determine

the suitability of a Map Descriptor when

looking for a location to store data from an

incoming message.

Zone, Relay,

Loop, Sensor,

Module, Panel

Relay/Loop/Zone

Number

Ignored when the Point Type is ‘Panel’

Point Type = Relay 1..255

Point Type = Zone 1..8

Point Type = Loop 1..2

Point Type = Module 1..2

Point Type = Sensor 1..2

Whole Numbers

1, 2 , etc

Length Each Map Descriptor defines storage

locations for a series of addresses. This

parameter specifies the length of the series.

1,2,3 .etc

Whole numbers

Table des matières

Autres manuels FieldServer Stockage

FieldServer

FieldServer NCA2-NFS2-3030 Manuel utilisateur

FieldServer

FieldServer FS-8700-115 Manuel utilisateur

FieldServer

FieldServer FS-8700-01 Manuel utilisateur

FieldServer

FieldServer FS-8700-104 ControlNet X30 Manuel utilisateur

FieldServer

FieldServer FS-8700-105 Note de version

FieldServer

FieldServer Gardner Denver FS-8700-60 Manuel utilisateur

FieldServer

FieldServer FS-8700-66 Manuel utilisateur

FieldServer

FieldServer FS-8700-39 EST3 ECP Manuel utilisateur

FieldServer

FieldServer FS-8704-12 Manuel utilisateur

FieldServer

FieldServer FS-8700-12 Note de version

FieldServer

FieldServer FS-8700-73 Manuel utilisateur

FieldServer

FieldServer FS-8700-43 Manuel utilisateur

FieldServer

FieldServer FS-8700-12 Manuel utilisateur

FieldServer

FieldServer Honeywell Zellweger IR-148 FS-8700-102 Manuel utilisateur

FieldServer

FieldServer FS-8700-16 Manuel utilisateur

FieldServer

FieldServer FS-8700-01 Note de version

FieldServer

FieldServer FS-8700-130 Note de version

FieldServer

FieldServer Profibus FS-8700-113 Manuel utilisateur

FieldServer

FieldServer FS-8704-07 Manuel utilisateur

Manuels Stockage populaires d'autres marques

QNAP

QNAP TS 32PXU Series Manuel utilisateur

LaCie

LaCie RUGGED RAID Manuel utilisateur

Freecom

Freecom CLS DOCK Manuel utilisateur

PNY

PNY Attache P-FD64MBATT3 Manuel utilisateur

HP StorageWorks MSL2024 Manuel utilisateur

OLT

OLT 6x6 Maximizer Manuel utilisateur

Transcend

Transcend JetFlash 160 Manuel utilisateur

LaCie

LaCie RUGGED MINI Manuel utilisateur

Thunderbolt

Thunderbolt 600 Manuel utilisateur

Panasonic

Panasonic LB-DH8 series Manuel

Intel

Intel RAID High Availability Manuel utilisateur

LaCie

LaCie 12big Thunderbolt 3 Manuel utilisateur

Spectra Logic

Spectra Logic T-Series Spectra T50e Manuel utilisateur

Panasonic

Panasonic LKM-F931-1 Manuel utilisateur

Tabernus

Tabernus Enterprise Erase E2400 Manuel utilisateur

Rocstor

Rocstor COMMANDER 3F series Manuel utilisateur

HP P9000 Manuel utilisateur

Western Digital

Western Digital Ultrastar Data60 Manuel utilisateur
