FERREX DM600VARIO Manuel utilisateur
AFTER SALES SUPPORT 702030
1300 855 831
MODEL:
DM600VARIO
3
YEAR
WARRANTY
AU
Made in China
FERREX®is a registered trademark of ALDI Stores
DISTRIBUTED BY:
ALDI STORES
1 SARGENTS ROAD
MINCHINBURY NSW 2770
www.aldi.com.au
AU
ALDI guarantees that our exclusive brand products are developed to our
stringent quality specifications. If you are not entirely satisfied with this
product, please return it to the nearest ALDI store within 60 days from the
date of purchase, for a full refund or replacement, or take advantage of our
after sales support by calling the supplier’s Customer Service Hotline.
05/2023
User Manual
WOOD LATHE
DM600VARIO
Contents
Dok./Rev.-Nr. 702030_20220829
Overview ..................................................................................... 3
Package contents/part list .........................................................6
Explanation of Symbols .............................................................. 7
Introduction ................................................................................8
Layout ..........................................................................................9
Scope of delivery.........................................................................9
Intended use ..............................................................................10
Safety regulations...................................................................... 11
Attachment and operation........................................................17
Cleaning and maintenance........................................................21
Technical data ........................................................................... 22
Storage and transport .............................................................. 23
Disposal and recycling .............................................................. 23
Troubleshooting........................................................................ 24
Warranty Details........................................................................ 25
Repair and Refurbished Goods or Parts Notice ....................... 26
3
11 2 3 4 5 6 7 8 9 10
11
A
12
A
A
A13
14
21 4 3115
4
4
13
6
59
11
10
5
56
Package contents/part
list
1Motor unit, 1x
2Headstock drive centre, 1x
3Tool rest, 1x
4Tool support, 1x
5Centering pin, 1x
6Tailstock, 1x
7Machine bed, 1x
8Faceplate, 1x
9Wrench, 2x
10 Clamping lever tool rest, 1x
11 Fastening screws, 8 x
12 Warranty card
13 Instruction manual
Kapitelüberschrift
7
Explanation of Symbols
The use of symbols in this manual is intended to draw your attention to possible risks.
The safety symbols and the explanations that accompany them must be perfectly un-
derstood. The warnings in themselves do not remove the risks and cannot replace
correct actions for preventing accidents.
Warning! Potential danger to life, risk of injury or dam-
age to the tool when ignoring the instructions.
Before commissioning, read and observe the operating
instructions and safety instructions!
Wear safety goggles!
Wear hearing protection!
Do not wear long hair uncovered. Use a hair net.
Do not wear gloves.
Protection class II (double shielded)
Made in China
Complies with the Australian norms and standards.
336 Warranty period.
Warranty class.
Explanation of symbols
Kapitelüberschrift
8
Introduction
Congratulations on choosing to buy a FERREX®product.
All products brought to you by FERREX®are manufactured to the highest standards
of performance and safety, and as part of our philosophy of customer service and
satisfaction, are backed by our comprehensive 3 Year Warranty.
We hope you will enjoy using your purchase for many years to come.
Note:
According to the applicable product liability law the manufacturer of this device is
not liable for damages which arise on or in connection with this device in case of:
• improper handling,
• non-compliance with the instructions for use,
• repairs by third party, non-authorised skilled workers,
• installation and replacement of non-original spare parts,
• improper use.
Recommendations:
Read the entire text of the operating instructions prior to the assembly and operation
of the device.
These operating instructions are intended to make it easier for you to get familiar
with your device and utilise its intended possibilities of use.
The operating instructions contain important notes on how to work safely, properly
and economically with your machine and how to avoid dangers, save repair costs,
reduce downtime, and increase the reliability and working life of the machine.
In addition to the safety regulations contained herein, you must in any case comply
with the applicable regulations of your country with respect to the operation of the
machine.
Keep the operating instructions in a clear plastic folder to protect them from dirt and
humidity; store them near the machine. The instructions should be read and careful-
ly understood by each operator prior to using the machine. Only persons who have
been trained in the use of the machine and are aware of the related dangers and
risks should be allowed to use the machine. The local required minimum age must
be met.
In addition to the safety notes contained in these operating instructions and any
specific regulations in your country, the generally recognised technical rules for the
operation of identically constructed machines must be observed.
Introduction
