Fender 215 PRO Manuel utilisateur

215 PRO

(This is the model name for warranty claims)

Fender Musical Instruments Corporation, 8860 East Chaparral Road Suite 100 Scottsdale, AZ 85250

Issued: September, 2007

p/n 2215200000 (120V)

SERVICE MANUAL

ATTENTION:

WARRANTY SERVICE PROCEDURES

The Fender 215 PRO is covered by the standard FMIC 5 Year Electronic Limited Warranty as it

applies to Speaker Enclosures. PCB Assemblies and Electronic Components are covered for 5

years. Speakers, Drivers, Cabinet Assemblies, and Cabinet Hardware are covered for 1 year.

Cables and wiring harnesses for 90 days. This enclosure is considered to be repairable to the

component level in the field. If you have questions please contact the FMIC Customer Service

Support Center at (866) 345-3642 or Email service@fender.com

215 PRO

(This is the model name for warranty claims)

September, 2007

IMPORTANT NOTICE

information contained herein is CONFIDENTIAL

and PROPRIETARY and is the property of

Fender® Musical Instruments Corporation. It is

not to be sold or assigned to another party and is

disclosed solely for use by Fender Authorized

Service Centers for purposes of product service

and maintenance. All information is not to be dis-

closed to others without the expressed permission

of Fender® Musical Instruments Corporation. All

specifications are subject to change without no-

tice. This information and any copies produced

electronically or otherwise must be surrendered

upon demand of Fender® Musical Instruments

Corporation.

•Parts marked with two asterisks (**) indicate the

required use of that specific part. This is neces-

sary for RELIABILITY and SAFETY requirements.

DO NOT USE A SUBSTITUTE!

PARTS LIST CODES

The description codes used in the itemized Parts Lists are defined below:

CAPACITOR CODES

CAP AE = Aluminum Electrolytic

CAP CA = Ceramic Axial

CAP CD = Ceramic Disk

CAP CR = Ceramic Radial

CAP MPF = Metalized Polyester Film

CAP MY = Mylar

CAP PFF = Polyester Film/Foil

RESISTOR CODES

RES CC = Carbon Comp

RES CF = Carbon Film

RES FP = Flame Proof

RES MF = Metal Film

RES MOX = Metal Oxide

RES WW = Wire Wound

HARDWARE CODES

BLX = Black Oxide

CR = Chrome Plated

HWH = Hex Washer Head

M = Machine Screw

NI = Nickel Plated

OHP = Oval Head Phillips

PB = Particle Board

PHP = Pan Head Phillips

PHPS = Pan Head Phillips Sems

SMA = Sheet Metal "A" Point

SMB = Sheet Metal "B" Point

SS = Stainless Steel

TF = Thread Forming

ZI = Zinc Plated

215 PRO

(This is the model name for warranty claims)

SPECIFICATIONS

Model Name: 215 PRO

Release Number: PR 730

Part Number: 2215200000

Impedance: 4 ohms

Sensitivity: 101 dB, 1w-1m

Power Handling: 800 Watts, Continuous

1600 Watts, Program

Drivers: Two 15” (38.1 cm) Fender Special Design cast frame woofers with

3” (7.6 cm) voice coil and 105 0z. (2.98 kg) magnet (p/n 0075912000)

One horn tweeter with 1” (2.5 cm) voice coil and 8 oz. (0.23 kg) magnet

(p/n 0048847000)

Connections: Dual, parallel wired, ¼” (6.35 mm) high current input jacks and Speakon

connector

Cabinet: ¾” (1.9 cm) Baltic Birch plywood

Dimensions Height: 36 5/8 in (93.0 cm)

Width: 26 in (66.0 cm)

Depth: 17 in (43.2 cm)

Weight: 110 lb (50.0 kg)

Product specifications are subject to change without notice

215 PRO

(This is the model name for warranty claims)

SERVICE NOTES

Input Assembly removal is required for lamp re-

placement and is accomplished by following these

steps:

1. Remove the four screws from the input panel

corners.

2. Pull the panel out at the top until the L-pad is

clear of the mounting plate, then pull upward on

the assembly.

3. Use a small screwdriver or other tool to remove

the blown lamp, which is visible through a cut-

out in the circuit board.

4. Remove the spare lamp stowed on the side of

the circuit board and install it where the blown

lamp was removed.

5. Install the input assembly in the reverse order

of removal.

PCB EXCHANGE POLICY

Parts marked with a single asterisk (*) in the Part

Lists are not field replaceable. If a failure due to

one of these components is detected, please con-

tact the FMIC Customer Service Department to

order the complete PCB Assembly.

215 PRO

(This is the model name for warranty claims)

*Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY section above.

shaded Unique Fender® part. Order directly from the FMIC Parts Department.

shaded + *Access to this part or assembly is controlled. Please contact the FMIC Customer Service Department.

** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.

shaded + ** Both a unique Fender® part and a Safety Requirement part as defined above.

.PARTS LIST:

PCB ASSEMBLY

QTY. PART # DESCRIPTION REFERENCE DESIGNATION

1 0075753000 *PCB ASSEMBLY BASS PRO SPEAKERS

1 0051858000 INDUCTOR AIR CORE .18mH L1

2 0051857000 LAMP TYPE 561 LMP1, LMP2

4 0053475000 LAMP CLIP

4 0012555000 EYELET-ROLLED FLANGE G.S. 3-4

2 0051861000 CAP MPF RDL 3.3Uf 250v 10% C1, C2

2 0029175000 JACK PHONE ¼” HI CURRENT PC J1, J2

PARTS LIST:

INPUT ASSEMBLY

QTY. PART # DESCRIPTION REFERENCE DESIGNATION

1 0075735000 * INPUT ASSEMBLY FBA BASS PRO SPKRS

1 0075605000 PLATE INPUT FBA PRO SERIES

1 0049348000 CONTROL L PAD 8 OHM 50W

1 0064463000 KNOB PLASTIC W/POINTER XOVER

2 0016436000 WSHR LCK INTL 3/8x.687x.065 NI

2 0031153000 WSHR FLAT 3/8x.614 NI

2 0016352000 NUT HEX 3/8-32x3/32 TK NI

1 0040432000 JACK SPEAKON 4-POLE (NL-4MP)

2 0059914000 SCRW TF 4-40X3/8 FHP BLK

PARTS LIST:

CABINET ASSEMBLY

QTY. PART # DESCRIPTION REFERENCE DESIGNATION

1 0074214000 *CABINET ASSEMBLY 215 PRO

16 0021972000 NUT T 10-32x3/4 STR 3 PRNG BLX

2 0059919000 FOOT RUBBER 2.50 DIA

2 0059916000 WSHR FLAT 7/16X1X.070 STL ZI

2 0059918000 SCRW 3/8-16X1 ½ HH ZINC

2 0012094000 NUT T 3/8-16x7/16 TWIST 4 PRNG

8 0059920000 CORNER STL/NI STACKING C1335N

32 0026571000 SCRW SMAB 8X5/8 THP NI

2 0059843000 “CASTER FXD 3”” WHL W2080K/HD”

52 0033380000 SCRW SMAB 8x1 THP BLX

2 0059844000 HANDLE RECESSED STEEL BAR

2 0074224000 RAIL GLIDE HDPE 215/610 PRO

10 0059921000 SCRW SMA 10X1 ¼ THP BLK

1 0054842000 PLATE KICK 810 PRO

10 0037543000 SCRW SMAB 8x3/4 OHP NI

3.35 0051343000 VINYL TOLEX 4227A SY

PARTS LIST:

END ITEM ASSEMBLY

QTY. PART # DESCRIPTION REFERENCE DESIGNATION

1 0074214000 *CABINET ASSEMBLY 215 PRO

2 0075912000 SPEAKER 15 INCH 8 OHM CAST FRAME

1 0075735000 *INPUT ASSEMBLY FBA BASS PRO SPEAKERS

215 PRO

(This is the model name for warranty claims)

*Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY section above.

shaded Unique Fender® part. Order directly from the FMIC Parts Department.

shaded + *Access to this part or assembly is controlled. Please contact the FMIC Customer Service Department.

** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.

shaded + ** Both a unique Fender® part and a Safety Requirement part as defined above.

PARTS LIST:

END ITEM ASSEMBLY

QTY. PART # DESCRIPTION REFERENCE DESIGNATION

1 0073681000 GRILLE 215/610 PRO

1 0074228000 *BADGE X-LARGE FBA

1 0048847000 HORN FOSTER 8 OHM

1 0054212000 INPUT MOUNTING PLATE SUNN 410H

8 0030858000 SCRW SMA 8x5/8 PHP NI

4 0026553000 SCRW M 8-32 x 3/8 PHP BLX

4 0033380000 SCRW SMAB 8 x 1 THP BLX

11 0036112000 SCRW SMAB 6 x 1-1/4 OHP BLX w/WS

16 0057975000 SCREW M 10-32 x 1-1/4 FLHP STL BL

22 0055734000 RUBBER FOOT ¾” DIA

4 0059644000 SCRW CAP 6-32x3/8 HEX SKT NI

4 0069393000 NUT 6-32 HEX EXT LOCK

1 0055831000 GASKET HORN BASSMAN SERIES

215 PRO

(This is the model name for warranty claims)

Schematics and Drawings

Service Diagram (Schematic) ............Bassman 410 PRO

Input Assembly ............FBA Bass Pro Speakers

End Item Assembly ............215 PRO

FRACT. -------------------------------+/-1/32

.X ---------------------------------------+/-.050

.XX -------------------------------------+/-.015

.XXX------------------------------------+/-.010

ANGLES-------------------------------+/-.5 DEGREES

HOLE DIA-----------------------------+.005 -.001

UNMARKED ANGLES ARE 90 DEGREES.

TOL. UNLESS NOTED

FINISH

MATERIAL

NONE

CORONA, CALIFORNIA U.S.A.

ENGINEER

DRAWN

DATE

DATE DATE DATE

DATE

DFT. ENG. ENG.

APPROVED SHEET

SCALE

SIZE REV

PART NUMBER

1of1

TITLE

0075735000

INPUT ASSEMBLY FBA BASS PRO SPEAKERS

05/17/2007

NONE

FENDER MUSICAL INSTRUMENTS CORP.

DATE/ARCHIVE

EC NUMBERREV BY

123456

THIS DOCUMENT CONTAINS INFORMATION OF A PROPRIETARY NATURE TO FENDER

MUSICAL INSTRUMENTS AND IS SUBMITTED TO YOU IN CONFIDENCE AND SHALL

NOT BE DISCLOSED OR TRANSMITTED TO OTHERS WITHOUT AUTHORIZATION FROM

ASSEMBLY

09/27/2007

SERVICE MANUAL DOCUMENT

ITEM QTY DESCRIPTION

10 2 SCRW TF 4-40X3/8 FHP BLK

9 1 JACK SPEAKON 4-POLE (NL-4MP)

8 AR TAPE VINYL NITRITE W/ADHESIVE

7 1 PCB ASSEMBLY BASS PRO SPEAKERS

6 2 NUT HEX 3/8-32x3/32 TK NI

5 2 WSHR FLAT 3/8x.614 NI

4 2 WSHR LCK INTL 3/8x.687x.065 NI

3 1 KNOB PLASTIC W/POINTER XOVER

2 1 CONTROL L PAD 8 OHM 50W

1 1 PLATE INPUT FBA PRO SERIES

REF

GRN

RED

BLU

WHT

ORN

BRN

LOCATIONS

WIRING AND SOLDERING

BLU

GRN

WIRE TIE

4.25±.03

4.00±.03

FRACT. -------------------------------+/-1/32

.X ---------------------------------------+/-.050

.XX -------------------------------------+/-.015

.XXX------------------------------------+/-.010

ANGLES-------------------------------+/-.5 DEGREES

HOLE DIA-----------------------------+.005 -.001

UNMARKED ANGLES ARE 90 DEGREES.

TOL. UNLESS NOTED

FINISH

MATERIAL

NONE

SEE PARTS LIST

CORONA, CALIFORNIA U.S.A.

ENGINEER

DRAWN

DATE

DATE DATE DATE

DATE

DFT. ENG. ENG.

APPROVED SHEET

SCALE

SIZE REV

DRAWING NUMBER

TITLE

END ITEM ASSEMBLY 215 PRO

2215200000

06/07/2007

1of2

NONE

FENDER MUSICAL INSTRUMENTS CORP.

DATE/ARCHIVE

EC NUMBERREV BY

123456

THIS DOCUMENT CONTAINS INFORMATION OF A PROPRIETARY NATURE TO FENDER

MUSICAL INSTRUMENTS AND IS SUBMITTED TO YOU IN CONFIDENCE AND SHALL

NOT BE DISCLOSED OR TRANSMITTED TO OTHERS WITHOUT AUTHORIZATION FROM

ASSEMBLY

SEE DETAIL A

11X

16X

22X

58X

09/27/2007

(N.S.) = NOT SHOWN

SERVICE MANUAL DOCUMENT

BLACK WIRE FROM UPPER SPEAKER

"-" TO LOWER SPEAKER "-".

WHITE WIRE FROM UPPER SPEAKER

"+" TO LOWER SPEAKER "+".

GREEN WIRE FROM INPUT ASSEMBLY

TO "-" ON TWEETER.

BLUE WIRE FROM INPUT ASSEMBLY

TO "+" ON TWEETER.

BROWN WIRE FROM INPUT ASSEMBLY

TO "-" ON UPPER SPEAKER.

ORANGE WIRE FROM INPUT ASSEMBLY

TO "+" ON UPPER SPEAKER.

ITEM QTY DESCRIPTION

20 1 WIRE SET FINAL 215 PRO (N.S.)

19 1 LABEL INPUT 215 PRO

18 1 LABEL POP 215 PRO

17 1 LABEL SERIAL MEXICO

16 4 NUT 6-32 HEX EXT LOCK

15 4 SCRW CAP 6-32x3/8 HEX SKT NI

14 1 BADGE X-LARGE FBA

13 11 SCRW SMAB 6x1-1/4 OHP BLX w/WS

12 22 RUBBER FOOT 3/4" DIA

11 1 GRILLE 215/610 PRO

10 16 SCREW M10-32x1-1/4 FLHP STL BL

9 2 SPEAKER 15 INCH 8 OHM CAST FRAME

8 4 SCRW SMAB 8x1 THP BLX

7 1 GASKET HORN BASSMAN SERIES

6 1 HORN FOSTER 8 ohm

5 8 SCRW SMA 8x5/8 PHP NI

4 4 SCRW M 8-32x3/8 PHP BLX

3 1 INPUT MOUNTING PLATE SUNN 410H

2 1 INPUT ASSEMBLY FBA BASS PRO SPEAKERS

1 1 CABINET ASSEMBLY 215 PRO

Table des matières

Autres manuels Fender Intervenants

Fender

Fender Passport mini Manuel utilisateur

Fender

Fender BXR 15 Manuel utilisateur

Fender

Fender Acoustasonic Junior Manuel utilisateur

Fender

Fender Passport PD-250 Manuel utilisateur

Fender

Fender PASSPORT Manuel utilisateur

Fender

Fender Speaker Manuel utilisateur

Fender

Fender SPL 1225 Manuel utilisateur

Fender

Fender Bass Speaker Cabnets Manuel utilisateur

Fender

Fender NEWPORT Manuel utilisateur

Fender

Fender FORTIS F-10BT Manuel utilisateur

Fender

Fender SPL 1272A Manuel utilisateur

Fender

Fender PASSPORT 1270P Manuel utilisateur

Fender

Fender PASSPORT P250 Manuel utilisateur

Fender

Fender Super Sonic 60 Manuel utilisateur

Fender

Fender MA6 Manuel utilisateur

Fender

Fender PASSPORT Manuel utilisateur

Fender

Fender PASSPORT P150 Manuel utilisateur

Fender

Fender PASSPORT Manuel utilisateur

Fender

Fender ACE Series Manuel utilisateur

Fender

Fender Passport Executive PR 692 Manuel utilisateur

Fender

Fender Passport Event Manuel utilisateur

Fender

Fender Passport PD-250 Manuel utilisateur

Fender

Fender PASSPORT 1270P Manuel utilisateur

Fender

Fender FIGHTER 10 Manuel utilisateur

Manuels Intervenants populaires d'autres marques

argon audio

argon audio IE20 Manuel utilisateur

Denon

Denon SC-N7 Manuel utilisateur

Gemline

Gemline Ace 3952 Manuel utilisateur

Focal

Focal ON WALL 300 Mode d’emploi

HEADRUSH

HEADRUSH Maximus HRSP 5024 Manuel utilisateur

SoundLogic

SoundLogic BCCS-6/6395 Manuel utilisateur

Peavey

Peavey DTH 218 Manuel utilisateur

Avantree

Avantree Pluto Air Manuel utilisateur

Morel

Morel Integra Series INTEGRA OVATION 4 Manuel utilisateur

Oppo

Oppo SONICA Manuel utilisateur

Bose

Bose SoundLink Wireless Music System Manuel utilisateur

Rocksteady

Rocksteady Stadium Manuel utilisateur

Bowers & Wilkins

Bowers & Wilkins 4 Manuel utilisateur

Sonance

Sonance SONOS OUTDOOR Series Manuel utilisateur

Electro-Voice

Electro-Voice EVID FM4.2 Manuel utilisateur

Pioneer

Pioneer XW-HTD630 Manuel utilisateur

Onn

Onn BWA16AA002 Manuel utilisateur

HP GL313AA - USB Speakers PC Multimedia Manuel utilisateur
