Installation and Operation Manual

FD102CV-C-7-L/R

10.2” LCD Monitor Left/Right Arm Mount

Document Number:

MAN –FD102CV-C-7 (L/R)

Rev:

Revision Date:

05/05/2017

Page 2 of 12

TECHNICAL SUPPORT

470-239-7421 or FDSAvionics.com

Table of Contents

General Information.................................................................................................................3

Front View..................................................................................................................................3

Additional Information ...........................................................................................................3

Specifications.............................................................................................................................4

Installation Instructions ..........................................................................................................4

Power...........................................................................................................................................4

Power and Ground Wiring......................................................................................................5

Power/Video...............................................................................................................................6

HDSDI Pinout ...........................................................................................................................7

Operation Instructions.............................................................................................................8

Button Control ...........................................................................................................................8

Technical Drawing....................................................................................................................9

Technical Support...................................................................................................................10

Instructions for Continued Airworthiness ........................................................................10

Warranty ...................................................................................................................................11

Log of Revisions......................................................................................................................12

Document Number:

MAN –FD102CV-C-7 (L/R)

Rev:

Revision Date:

05/05/2017

Page 3 of 12

TECHNICAL SUPPORT

470-239-7421 or FDSAvionics.com

General Information

The FD102CV-C-7-L/R is a special mission military monitor. It consists of two separate

parts, the LCD monitor and the articulating arm.

Built with retrofit aircraft integration in mind, this display can switch between two video

input sources using the buttons on the bezel. Additional functions are added using the 8

bezel keys. These functions are generated by the mission computer.

The arm has 2 pivot points which enable it to have a range of rotation up to 180° at each

pivot point. This monitor also tilt forward and AFT 20° in either direction and can rotate

45left and right.

The LCD features NVG technology which can be switched to Day or Night mode using

the rocker switch. The NVG LCD filters out infrared rays in the 1000nm range.

Front View

Additional Information

The FD102CV-C-7-L/R is made of all metal components. The milled aluminium arm

represents the evolution of several design enhancements for an optimum mounting

solution.

Document Number:

MAN –FD102CV-C-7 (L/R)

Rev:

Revision Date:

05/05/2017

Page 4 of 12

TECHNICAL SUPPORT

470-239-7421 or FDSAvionics.com

Specifications

Display Type

10.2” TFT Color LCD

Display Color

262K color by 6 bi R.G.B Signal input

Screen Resolution

1024x600

Viewing Angle

140° Horizontal; 110° Vertical

Mount Dimensions (stowed)

11.10(W)x10.45(H)x2.95(D)

Mount Dimensions (deployed)

14.78”(W) x 10.45”(H) x 2.95”(D)

Display Dimensions

11.10”(W) x 6.75”(H)

Weight

4lbs. 5 oz.

Power

28V DC @ 1.0 Amp

Video Inputs Supported

2 - HDSDI

Video Types Supported

HDSDI

Screen Control

On Screen Display Menu

Mount Materials

Aluminum

DO-160 Testing

DO-160 Testing is completed on Parent

Products of a similar nature

Installation Instructions

All cabin entertainment equipment, such as the FD102CV-C-7-L/R, should be installed

on a non-essential bus and have a dedicated circuit breaker. It is a requirement that a

switch be installed in the cockpit so that the pilot can de-energize the monitor should it

become necessary.

Power

This is a 28VDC monitor that requires 1.0 Amps (28 Watts) of power.

Document Number:

MAN –FD102CV-C-7 (L/R)

Rev:

Revision Date:

05/05/2017

Page 5 of 12

TECHNICAL SUPPORT

470-239-7421 or FDSAvionics.com

Power and Ground Wiring

This is a 28VDC monitor that requires 1 amp of power to operate. To operate properly this

monitor requires an input voltage of 18-29VDC.

The rated current of the equipment and associated voltage drop should be taken into

consideration when selecting wire gauge. The following example is based on an install with

a 28VDC power system and a total of 50 feet of wire between the circuit breaker, monitor and

ground.

Example: 22awg wire has 16.2 Ohms per 1000 feet, this equates to .81 Ohms for 50 feet. 1

Amp of current on .81 Ohms will drop .81 Volts.

Resistance of Wire Type M22759/16-**

(** = Gauge)

Gauge (AWG)

OHMS/1000’

26.20

16.20

9.88

4.81

2.02

1.26

.701

Also, use short heavy gauge wire and a clean tight connection for ground.

It is the installer's responsibility to understand the product's requirements to install the

product in compliance with industry standards and safety.

Document Number:

MAN –FD102CV-C-7 (L/R)

Rev:

Revision Date:

05/05/2017

Page 6 of 12

TECHNICAL SUPPORT

470-239-7421 or FDSAvionics.com

J1 (Power/USB)

Connector P/N: M24308/2-287F

Contact, Socket P/N: M39029/57-354

J2 (HDSDI Input)

Number

Description

28VDC Power

28VDC Ground

N/C

USB Data + (Green)

USB Data –(White)

USB +5VDC (Red)

USB Ground (Black)

USB Shield

Document Number:

MAN –FD102CV-C-7 (L/R)

Rev:

Revision Date:

05/05/2017

Page 7 of 12

TECHNICAL SUPPORT

470-239-7421 or FDSAvionics.com

J3 (HDSDI Input)

Standard 75Ω BNC Receptacle (RG179 connector supplied)

Description

Center

Video Signal

Shell

Video Return

Document Number:

MAN –FD102CV-C-7 (L/R)

Rev:

Revision Date:

05/05/2017

Page 8 of 12

TECHNICAL SUPPORT

470-239-7421 or FDSAvionics.com

Operation Instructions

The FD102CV-C-7-L/R is continuously on but can be de-energized by removing power

from the system. No pilot or aircrew action is necessary during flight or ground operation.

The operator will be able to change the video input from the FD102CV-C-7-L/R using the

rocker switch on the LCD monitor.

When applying 28VDC power, the display will turn on and look for a valid input on the

last known source. If video is not displayed when power is applied, then increase the

backlight brightness using the Right Arrow on the 5 button keyboard as the first step in

troubleshooting.

Button Controls

Located at the bottom of the FD102CV-C-7-L/R are five buttons.

Operations for both switches and buttons are as follows:

Day/NVG –Rocker switch turns night vision on and off

½ - Rocker switch allows user to switch from one HDSDI input connection to the other.

BUTTON

DESCRIPTION

Menu - Used to change the configuration of the picture

settings (Backlight, Brightness, Contrast, Saturation, Hue,

etc.)

Left Arrow –Adjusts Down

Right Arrow –Adjusts Up

Arrow Down –Scrolls Down

Power Button

Document Number:

MAN –FD102CV-C-7 (L/R)

Rev:

Revision Date:

05/05/2017

Page 9 of 12

TECHNICAL SUPPORT

470-239-7421 or FDSAvionics.com

Technical Drawing

Document Number:

MAN –FD102CV-C-7 (L/R)

Rev:

Revision Date:

05/05/2017

Page 10 of 12

TECHNICAL SUPPORT

470-239-7421 or FDSAvionics.com

Technical Support

Should you have any questions concerning this product or other FDS Avionics Corp.

products, please contact our Product Support representatives at (470) 239-7421.

FDS Avionics Corp.

6435 Shiloh Road

Alpharetta, GA 30005

Phone: 470-239-7400

Fax: 470-239-7439

Email: [email protected]

For further product information, technical data and sample wiring diagrams, please click

on the Dealers section of our web site at www.FDSAvionics.com

Instructions for Continued Airworthiness

The FD102CV-C-7-L/R is designed not to require regular general maintenance.
