X3 User Tips
Fanvil Product Department
2014/9/30
仅内部使用
Tip#1
Phone Setup
•For physical assembly/installation, please
refer to the backside of X3 box.
•Please make sure handset and network cable
is connected correctly to the corresponded
ports.
Handset
PC
Port
Headphone
Network
Port
Power
Adapter
仅内部使用
Tip#2
Long-press Key Function
•Some keys and soft-button on X3 supports
long-press function, such as:
1. Up/Down –Fast scrolling.
2. Line (L1/L2) –Open line configuration.
3. Hands-free –Switch Hands-free / Headphone.
4. And more…
•For keys have specific long-press function,
there will be a function icon on the top-right
corner of the key.
•Try to discover hidden function by long-
press keys. There maybe some surprise.
仅内部使用
Tip#3
Help ‘?’
•User can press key ‘3’ for 1.5 seconds (long-
press) to get into the help menu, or press
soft-button Help ‘ ’, which will provide the
definition and description of menu icons and
functions.
仅内部使用
Tip#4
Initialization Configuration Wizard (ICW)
•! This feature is only available after RC3.2.440.
•The ICW will help user to configure the following settings:
1. Language - Only English is available now, multi-language version will
be provided in the later upgrade version.
2. Network –DHCP/Static/PPPoE, three mode is supported.
3. Line1 –User may configure Line1 account via, (1) Service Provider
Provisioning, (2) Private Server Provisioning, (3) Manual configuration.
! (1)&(2) are still in experimental stage.
4. User PIN –For user who wants to limit the accessibility of phone, user
can set a PIN code to lock the phone for protection. If PIN code is set,
the phone will be locked after boot up. User must unlock the phone
with PIN first before using it and modify line configuration and user
profile also requires PIN code validation too. User can skip PIN code
setting or make it blank (default) to remove PIN code protection.
•ICW runs only at the first boot up after reset to factory default,
but user can run ICW manually from phone menu / settings.
仅内部使用
Tip#5
Online Update
•! This feature is only available after RC3.1.404. For the earlier
versions, user has to update the phone manually to the latest
version.
•X3 supports online update function which will periodically check
for newer X3 version online after boot up.
•If a newer version software is available, phone will pop up a
message to ask user whether to upgrade to the newer version.
•If user canceled the upgrade, phone will not prompt update
message of this version until a newer one is available.
•If user selected upgrade, phone will download new software and
upgrade itself automatically. During the upgrade procedure, all
phone features are not available until upgrade finished.
•User can run software update check manually from phone menu /
settings.
仅内部使用
Tip#6
Phone Information
•User can get phone information, such as
software version, IP address, etc., by long-
press key ‘2’.
仅内部使用
Tip#7
Configure Line(s)
•User can enter the line configuration by long-press line key
(L1 or L2).
•The phone provide basic line account configuration, such
as,
1. SIP Server Address
2. SIP Server Port
3. SIP User
4. SIP Authentication User
5. SIP Display Name
•To configure other advance line options, user should user
web management portal to modify.
•In line configuration, user can set Auto-Answering and DND
on the individual line.
仅内部使用
Tip#8
Making / Receiving Calls
•! Press ‘#’ after phone number to dial is not supported.
•User may open audio channel first, such as hands-free (or
line key), handset, or headphone, then dial the number.
The number will be dialed in 5 seconds timeout, or user can
press the OK ‘ ‘ button to dial immediately.
•User can also dial number first in standby screen then (1)
pick handset, (2) turn on headphone/hands-free, (3) press
line key (hands-free), (4) press ‘ ‘ button (hands-free,
default line), to make phone call.
•User can answer incoming calls by open audio channel or
press ‘ ‘ button.
•User may reject an incoming call by pressing Cancel
‘ ‘ button.
仅内部使用
Tip#9
Intelligent Contact Match (ICM)
•ICM allows user to quickly find matched
contact from phonebook or call log without
enter complete number.
•User can enter partial number and matched
contacts will be listed. User can then scroll
up/down the list to find desired contact and
dial the number.
