Fanvil CS30 Manuel utilisateur
USB/Bluetooth Speakerphone
User Manual
www.fanvil.com
1
Product introduction
USB/Bluetooth Speakerphone is an omni-directional microphone
and a bluetooth speaker.
It is used as a high-quality microphone and speaker for online meeting and
compatible with apps such as Zoom\Teams. Users can enjoy clear
remote conference experience anytime, anywhere.
2
Product introduction
Accessories List
Speakerphone
Instructions
Data cable
3
Product introduction
Buttons and lighting instructions
Phone Calls
Short press to answer/
hang up calls
Volume/power indicator
means on
means off
Volume indicator
Maximum volume
Minimum volume
Power indicator (short press on power button)
Power>80%
Power≤20%
Volume down
Short press to turn down the volume
Volume up
Short press to turn up the volume
Microphone
Mute
Short press to switch microphone status
Status Indicator
Red: Microphone mute
White: Microphone unmute
4
Product introduction
Buttons and lighting instructions
Power
Press and hold for 3 seconds to turn on or off the device
Status Indicator
Red light breathing: battery is below 10%
White light breathing: charging
White light on: battery full or not charging
*When the power is off and charging, the light goes off to indicate that it is full
Bluetooth
Press and hold for 2 seconds to pair
Short press to disconnect Bluetooth
Status Indicator
Blue flashing: Bluetooth pairing
Blue on: Bluetooth connected
5
Instructions for use
1. Device connection
* Method 1: USB connection
• Connect the device to the computer via the supplied USB cable, and when you
hear a hint tone, the connection is successful.
• Choose “Fanvil CS30” as the input/output audio device in system setting or in the
online meeting software.
* Method 2: Bluetooth connection
• Press the Bluetooth key for 2 seconds until the Bluetooth indicator
flashes. Then open the phone or PC Bluetooth setting page, search the Bluetooth
device “Fanvil CS30” for pairing; Click to connect.
• If you have an Android phone that supports NFC, turn on the NFC of the phone，
and touch the device's NFC area to connect to Bluetooth.
Tip: The current version does not support OTG data cable directly connected to the
phone
6
Instructions for use
2.Charging instructions
* Charging
•When using the USB cable to connect to the computer, the device will enter
the charging mode.
•If you use a power adapter to supply power, you should
purchase a power adapter that is FCC/CE certified and meets the requirements of
the standard.
Tip: Before using the device for the first time, it is recommended that charge at least
1 hour to ensure sufficient power.
7
Instructions for use
Product name
AI Meeting Box
Product model
CS30
Product dimensions
112.5mm x 112.5mm x 35.4mm
Bluetooth
Bluetooth V5.1
Pickup radius
4 meters/13 ft
Microphone
4 omnidirectional microphone
Loudspeaker
5W
Battery capacity
2000mAh
Charging
5V—2A Type-C port
8
Frequently Asked Questions
Questions
Suggestions
The volume is not synchronized when the
device is connected to the phone by
Bluetooth
1.Confirm whether the phone supports Bluetooth
sound synchronization, some Android phones do not
support volume synchronization.
2.Some phone needs to open the volume setting
permission in the system settings.
When the device is connected to the phone
by Bluetooth, the ringtone of phone
calls does not come out from the device
1.Check whether the phone volume is turned on,
or the volume is too low.
2.Check whether the device can speak normally.
3.Choose audio input/output in the
meeting software.
No sound when device is connected to
Windows PC by Bluetooth
1.It is recommended that when playing music,
select the speaker with the name “stereo”
on your PC.
2.It is recommended to choose the speaker with the
name “hand free” for the audio output speaker during
the call or meeting.
No sound when the device is connected to
FaceTime/ Zoom/Teams/Google
Hangouts etc. by Bluetooth
1.Check whether the input /output of the call
software are properly set to “Fanvil CS30”.
2.Check whether the computer audio driver
is normal, it is recommended to restart
the computer and try again.
No response when the device
is connected to the computer using USB
1.Check whether the device is connected
to phone, please disconnect the connection
first, and then use the cable to connect the device.
2.Check whether the USB data cable is damaged.
3.Reboot the device and try again.
Fanvil Technology Co., Ltd
Website: www.fanvil.com
EMail: sales@fanvil.com support@fanvil.com
Tel: +86-755-2640-2199 Fax: +86-755-2640-2618
Add: 10/F Block A, Dualshine Global Science Innovation
Center, Honglang North 2nd Road, Bao'an District, Shenzhen,
China
