Fantasea Nano LED Pro Set Manuel utilisateur

Table of Contents

1. Introduction ........................................................................................................3

2. Installing and Removing Batteries............................................................. 4

3. Turning the Nano LED Pro On/Off.............................................................. 5

4. Assembling the Cone and Multi-Colored Plastic Disks .......................6

5. Using the Nano LED Pro as a Signaling Device..................................... 6

6. Using the Nano LED Pro as a Back-up Light.......................................... 7

7. Specifications...................................................................................................... 8

1. Introduction

The Nano LED Pro is a compact and powerful multi-purpose LED

light system. The Nano LED Pro Set was uniquely designed to be

used as a:

•Powerful diving torch

•Focus light for underwater photography

•Signaling light for above and below water, perfect for

diver or vessel identification

This set combines a compact, powerful multi-use diving torch and

focus light with a new application, similar to the old "Chemical Stick

Lights", but re-usable and environmentally friendly.

Included in the kit are the Nano LED Pro light, white plastic cone

with a lanyard, 4 colored disks and a Y-S Mount, which enables easy

attachment to Flex or Ball & Joint arms.

Cone

Color

Disks

Nano LED Pro

Cone

Lan

ard

Y-S Mount

2. Installing and Removing Batteries

A. Prior to installing batteries, the white cone should be

removed. Simply detach the cone from the flashlight’s

head by gently pulling them away from each other. Make

sure that when separating the cone from the flashlight,

there is no tension exerted on the cone’s lanyard, which is

wrapped around the flashlight.

B. To open the Nano LED Pro, hold the hand grip firmly in one

hand and turn the flashlight head counterclockwise until it

separates. Pull the flashlight head off. Please make sure

that the light is pointed in an upward position so the

contents do not fall out when opened. Take special care

not to stare into the light beam which is very powerful and

could damage your eyes.

C. Gently remove the LED head by pulling it out.

D. Install or remove the 4 AAA Alkaline batteries carefully.

Please note that this light should not be used with

rechargeable batteries. Make sure that you follow the

instructions diagram printed on the inside of the light. Note

that there are two sets of two batteries, each set pointing

in a different direction.

E. Replace the LED head carefully, making sure that the two

protrusions on the inside of the battery compartment

correspond with the two niches on the LED head. This is

the only way it will fit properly.

F. Carefully place the flashlight head over the threads, and

tighten evenly in a clockwise fashion. Do not use force and

do not allow it to screw down unevenly. Take special care

not to stare into the light beam which is very powerful and

could damage your eyes.

G. It is recommended to occasionally apply a slight amount of

silicone grease to the black O-ring seal found on the

flashlight after unscrewing the flashlight head

counterclockwise.

H. In order to attach the cone to the flashlight again, simply

cover the flashlight’s head with the open side of the cone,

so it wraps around it. The cone on the flashlight's head is

held in place by friction. There is no need to force the cone

down on the rubber light cover, but it should be attached

firmly to assure that it is watertight and does not allow

water to seep into the cone. The cone is what gives the

necessary buoyancy to the Nano LED Pro.

3. Turning the Nano LED Pro On/Off

A. It is recommended that you detach the cone from the

flashlight’s head prior to turning the Nano LED Pro on/off in

order to prevent tension from being exerted on the cone’s

lanyard.

B. In order to switch the light on, carefully turn the flashlight

head counterclockwise just enough for the light to turn on.

Once the light is turned on, do not keep turning the

flashlight head counterclockwise, or else the

watertight seal of the light will be damaged.

C. In order to switch the light back off, turn the flashlight

head in a clockwise fashion to the end. Please note that

there is never a need to use force when closing or opening

the light or turning it on or off.

D. Please note: If you are turning the flashlight head more

than half a turn and nothing happens, you are probably

turning it the wrong way.

4. Assembling the Cone and Multi-Colored Plastic Disks

A. Detach the cone from the flashlight’s head by gently

pulling them away from each other. Make sure that when

separating the cone from the flashlight, there is no tension

exerted on the cone’s lanyard, which is wrapped around

the flashlight.

B. Choose one of the colorful plastic disks included with the

kit.

C. Push the chosen plastic disk into the white plastic cone,

until it is positioned inside the dedicated track. Note that

the shiny side of the disk should be positioned towards the

bottom open part of the cone.

D. Cover the flashlight head with the open side of the cone, so

it wraps around it. The cone on the flashlight's head is held

in place by friction.

E. When turned on, the Nano LED Pro emits a diffused colorful

light.

F. In order to replace the colored plastic, detach the cone

from the flashlight head, and pull the disk out from the

open side of the cone, by gently pulling the string attached

to the disk. Follow steps A-D in order to insert the new

colored disk into the cone.

5. Using the Nano LED Pro as a Signaling Device

A. When turned on, the Nano LED Pro can be used by divers

as a signaling device.

B. Tie the flashlight’s hand lanyard to the diver’s equipment.

The best way to do this is to tie the hand lanyard around

the tank valve, where the regulator’s first stage is

connected to the tank.

C. Leave as little slack as possible to the hand lanyard, so the

light is tied to the tank valve as closely as possible.

D. Since the cone consists of positive buoyancy, the Nano LED

Pro will be pointing up during the dive.

E. After the dive, detach the Nano LED Pro from the tank

valve and soak and rinse exterior components in fresh

water.

6. Using the Nano LED Pro as a Night Dive Light

A. The Nano LED Pro can also be used as a night dive light.

Its compact size means that it can easily be stored inside a

BCD’s pocket and pulled out when necessary.

B. Prior to the dive detach the cone from the flashlight’s head

by gently pulling them away from each other. Make sure

that when separating the cone from the flashlight, there is

no tension exerted on the cone’s lanyard.

C. To get maximum light you should pull the cone off from

the end of the rubber LED cover, leaving it free and only

attached to the light by the lanyard. Or you can detach the

cone’s lanyard from the flashlight by gently pulling the

flashlight out of the plastic lanyard’s ring.

D. Make sure batteries are properly installed (see section 1:

Installing and Removing Batteries).

E. After the dive, carefully soak and rinse exterior

components in fresh water.

7. Specifications

•Batteries: 4 x AAA batteries

•Burn time: Up to 2 hours per set of batteries

•LED life time: Over 10,000 hours

•Luminous intensity: Over 50 lumen

•LED type: 3W High-power LED

•Color temperature: 5,000-10,000K

•Color of torch: Metallic coated finish

•Color of light: Clear, yellow, green, blue and red

•Size (mm): 36(W) x 36(D) x 132.5(H)

•Weight: 83 grams (not including batteries)

•Depth ratio: 100 meters/330 feet

For further information please contact us at [email protected]m or

visit our website at www.fantasea.com

•You must carefully soak and rinse exterior components in fresh

water after each use.

•Store in a protected, dry and shaded area.

•Remove batteries when storing for an extended period of time.
