fann 686CS Manuel utilisateur
© 2016 Fann Instrument Company
Constant Speed Mixer, Model 686CS
Instruction Manual
Manual No. D00312132, Revision G
Instrument No. 101656308
Model 686CS Instruction Manual
D00312132 Revision G, February 2016 2
Constant Speed Mixer, Model 686CS Instruction Manual
©2016 Fann Instrument Company
Houston, Texas, USA
All rights reserved. No part of this work covered by the copyright hereon may be reproduced or
copied in any form or by any means (graphic, electronic, or mechanical) without first receiving the
written permission of Fann Instrument Company, Houston, Texas, USA.
Printed in USA.
The information contained in this document includes concepts, methods, and apparatus which may be
covered by U.S. Patents. Fann Instrument Company reserves the right to make improvements in
design, construction, and appearance of our products without prior notice.
FANN®and the FANN logo are registered trademarks of Fann Instrument Company in the United
States and/or other countries. All other trademarks mentioned in the operating instructions are the
exclusive property of the respective manufacturers.
Contact Fann Instrument Company
Phone
1-281-871-4482
1-800-347-0450
Fax
1-281-871-4358
Postal Address
Fann Instrument Company
P.O. Box 4350
Houston, Texas, 77210 USA
Shipping Address
Fann Instrument Company
14851 Milner Road, Gate 5
Houston, Texas, 77032, USA
Online
www.fann.com
Model 686CS Instruction Manual
D00312132 Revision F, October 2015 3
Table of Contents
1 Introduction...............................................................................................................6
1.1 Document Conventions ....................................................................................7
2 Safety .......................................................................................................................8
3 Features and Specifications......................................................................................9
3.1 Mechanical Features ......................................................................................10
3.2 Control Features.............................................................................................10
4 Installation ..............................................................................................................12
5 Operation................................................................................................................13
5.1 Key Functions.................................................................................................14
5.2 Basic Operating Instructions...........................................................................15
5.3 Profile Programming Instructions....................................................................16
5.4 Preprogrammed Profile...................................................................................18
5.5 USB Remote Control......................................................................................18
5.6 Basic Mixing Instructions ................................................................................19
6 Test Analysis..........................................................................................................20
7 Troubleshooting and Maintenance..........................................................................21
8 Accessories............................................................................................................22
9 Parts List.................................................................................................................23
10 Warranty and Returns.............................................................................................24
10.1 Warranty.........................................................................................................24
10.2 Returns...........................................................................................................24
Model 686CS Instruction Manual
D00312132 Revision F, October 2015 4
List of Figures
Figure 3-1 Constant Speed Mixer, Model 686CS ............................................................9
Figure 3-2 Model 686CS Control Panel.........................................................................11
Figure 5-1 Blade Assembly ...........................................................................................13
Figure 5-2 Remote Control............................................................................................18
Model 686CS Instruction Manual
D00312132 Revision F, October 2015 5
List of Tables
Table 3-1 Constant Speed Mixer, Model 686CS Specifications.......................................9
Table 8-1 Optional Accessories for the Model 686CS Mixer..........................................22
Table 9-1 Parts List for the Model 686CS Mixer............................................................23
Table 9-2 Waring Blade Assembly Model 686CS Mixer ................................................23
Model 686CS Instruction Manual
D00312132 Revision F, October 2015 6
1 Introduction
The Fann Constant Speed Mixer, Model 686CS is designed to mix cements to
comply with American Petroleum Institute (API) specifications and recommended
practices.
As deeper wells are being drilled, heavier weight cements are needed to withstand
higher downhole pressures. The Model 686CS has a heavy-duty motor that can
handle thicker cements at the proper speed.The mixer has control buttons that the
operator can use to program the proper mixing speeds and times. One control
button, the API Profile button is preprogrammed with the API standard settings,
12,000 rpm for 35 seconds. These programming features save the operator time.
For specification details, refer to the following API documents:
•API Recommended Practice for Testing Well Cements, API RP 10B-2
•API Specification for Cements and Materials for Well Cementing,
API Spec 10A
Model 686CS Instruction Manual
D00312132 Revision F, October 2015 7
1.1 Document Conventions
The following icons are used as necessary in this instruction manual.
NOTE.Notes emphasize additional information that may be
useful to the reader.
CAUTION. Describes a situation or practice that requires operator
awareness or action in order to avoid undesirable consequences.
MANDATORY ACTION. Gives directions that, if not observed,
could result in loss of data or in damage to equipment.
WARNING! Describes an unsafe condition or practice that if not
corrected, could result in personal injury or threat to health.
ELECTRICITY WARNING! Alerts the operator that there is risk of
electric shock.
HOT SURFACE! Alerts the operator that there is a hot surface and
that there is risk of getting burned if the surface is touched.
Model 686CS Instruction Manual
D00312132 Revision F, October 2015 8
2 Safety
This blender is similar to any mixing blender and does not present any unusual
hazards.
Follow these recommended safety practices:
1. The operator should always wear safety glasses in case the mixture splatters
when adding ingredients.
2. The operator should not drop any foreign objects in the container while mixing
is occurring. These foreign objects could strike the operator or damage the
mixing blades and container.
3. The Model 686CS should be plugged in to a properly grounded outlet with the
ground prong in place.
4. Do not use extension cords.
5. Always remove the plug from the receptacle before performing any work on the
mixer base.
6. Do not immerse the mixer in any fluid or spray it with any fluids.
7. The blender should be at a comfortable height for the operator. The operator
should be able to add ingredients without straining to reach the mixer. Also, the
mixer should be close enough to shut it off quickly if necessary.
8. The mixing cup should be cleaned thoroughly after use to prevent the buildup
of cement or other deposits. These deposits can cause accelerated wear of
components. The mixing blades should be checked daily for damage. Damaged
or worn blades should be replaced immediately.
Model 686CS Instruction Manual
D00312132 Revision F, October 2015 9
3 Features and Specifications
This unit is based on a standard, heavy-duty mixing blender manufactured by
Waring. It is specially designed to comply with API standards and to allow
automatic programming of some mixing procedures. The mixer comes with a
remote control for optional use.
Table 3-1 Constant Speed Mixer, Model 686CS Specifications
Category
Specification
Speed Range
1,000 to 28,000 rpm
Container with lid
32 oz (946 mL) stainless steel container
Dimensions (Width x Depth x Height)
11 x 10 x 16 inches
28 x 25 x 41 centimeters
Weight
17 lb (7.7 kg)
Power Supply
120 V, Frequency 50/60 Hz,
Current 13 amps
Figure 3-1 Constant Speed Mixer, Model 686CS
Model 686CS Instruction Manual
D00312132 Revision F, October 2015 10
3.1 Mechanical Features
The Constant Speed Mixer (CSM) is equipped with a 32 ounce (946 mL) stainless
steel jar.
An additional 64 ounce (1.9 liter) stainless steel container is also available and can
be ordered separately.
Both stainless steel containers (32 or 64 ounces) fit directly onto
the mixer base. Adapters are not required.
3.2 Control Features
The Model 686CS Mixer has a liquid crystal display (LCD) screen that shows the
operating messages on a sharp, blue backlight, making it easy to read.
The mixer has programming features that can be set up using these buttons:
•Set Button- for programming profiles and mixer settings
•Profile Buttons – for executing a previously programmed profile
•API Button – to use preprogrammed API standard setting
The mixer also has these control features for easy operation:
•Power on/Off Button
•Start/Stop Button
•Speed Controls
•Time Controls
Figure 3-2 shows the control panel. How to use each key (button) is explained in
section 5.1.
