BB 1000M • Installation Guide

Overview

The Extron BB 1000M back box is used to mount an Extron TLP 1000MV TouchLink™ panel in a wall. This Installation

Guide provides instructions for an experienced installer to retroﬁt the box in existing drywall or mount the wall box in a

new installation. For complete instructions about installing and calibrating the TouchLink panel, see the TLP 1000MV and

TLP 1000TV User Guide, which are available on the Extron web site (www.extron.com).

Retrot an Existing Installation (with the Drywall in Place)

1. Remove the screws holding the top and bottom endplates of the wall box to the

U-plate (sides and back). Separate and remove the endplates.

2. Use the back face of the U-plate to mark the position where the hole will be cut. Use a

level to ensure the U-plate is level.

NOTE: The hole is 10.22 inches (25.96 cm) wide x 7.16 inches

(18.2 cm) high.

3. Using a drywall saw, carefully cut a hole where the touchpanel will be installed. Cut on

the lines that you marked in step 2.

4. Run the cable conduit through the wall. The conduit can be attached to any of the

available knock-out holes in the top, bottom, or either side. Leave

some slack to connect the conduit to the wall box and the cables

to the touchpanel.

5. Run cables to the installation site.

6. Clear the cables and conduits from the space behind the hole.

7. Insert the U-plate into the hole (see ﬁgure 1).

NOTE: The tabs of the wall box sit on the outer face of the

drywall.

8. Pull back the cables that were cleared out of the way in step 5.

9. Secure one or more conduits to the knock-out holes (see ﬁgure 2).

10. Slide the endplates into the gap between

the back of the U-plate and the top ﬂanges

on the side of the U-plate (see the inset

in ﬁgure 2). The endplate must pass the

drywall so that the trailing edge can be

pushed in behind it.

11. Finish installing the TouchLink panel

as shown in ﬁgure 3 and described in

“Mounting the Touchpanel” on the next

page.

Figure 1.

Figure 2.

Figure 3.

Tabs (4)

U-plate

Faceplate Snaps to Unit

(4 plcs ea side)

Tighten Screws to

Rotate Locking Arms

BB 1000M • Installation Guide (Cont’d)

New Construction Installation

1. Before the drywall has been secured to the studs, place the wall

box in a suitable place so that the tabs on the sides of the box are

ﬂat against a vertical stud.

2. Secure the wall box to the stud (metal or wooden) using two nails

or screws.

3. Run the cable conduits to the box and connect them to one of

the available knock-out holes. Leave enough cable to provide

slack for installing the TouchLink panel.

4. Measure the position of the wall box, and mark and cut a hole in

the drywall where the box is placed.

NOTE: The hole is 10.22 inches (25.96 cm) wide x 7.16 inches

(18.2 cm) high.

5. Secure the drywall to the studs.

NOTE: The tabs of the wall box sit on the stud against the

inner face of the drywall.

6. If required, paint the drywall. Insert the cardboard cover (provided) into the wall box to avoid getting paint on it.

Mounting the Touchpanel

For complete instructions about installing

and calibrating the TouchLink panel, see the

TLP 1000MV and TLP 1000TV User Guide,

available on the Extron website (www.

extron.com).

1. Connect the cables to the back of the

TouchLink panel (see the User Guide).

Feed excess cable back into the conduit.

2. Test the connections and conﬁgure the

TouchLink panel (see the User Guide).

3. Fold the locking arms into their recesses

on the side of the touchpanel and slide

the unit into the wall box.

4. Tighten the screws on the front of the

unit so that the locking arms rotate into

place behind the top and bottom plates

of the wall box and hold the unit in

place (see ﬁgures 3 or 5).

5. Snap the faceplate into position (see ﬁgures 3 or 5).

Extron USA - West

Headquarters

+800.633.9876

Inside USA/Canada Only

+1.714.491.1500

+1.714.491.1517 FAX

Extron USA - East

+800.633.9876

Inside USA/Canada Only

+1.919.863.1794

+1.919.863.1797 FAX

Extron Europe

+800.3987.6673

Inside Europe Only

+31.33.453.4040

+31.33.453.4050 FAX

Extron Asia

+800.7339.8766

Inside Asia Only

+65.6383.4400

+65.6383.4664 FAX

Extron Japan

+81.3.3511.7655

+81.3.3511.7656 FAX

Extron China

+400.883.1568

Inside China Only

+86.21.3760.1568

+86.21.3760.1566 FAX

Extron Middle East

+971.4.2991800

+971.4.2991880 FAX

68-2095-01 Rev. A

04 11

Mounting Screws (2)

Extron BB 1000M

Wall Box

for Wall-mounting

Extron TLP 1000MV

Tabs are in contact

with the wall stud.

Figure 4.

Figure 5.

Faceplate Snaps to Unit

(4 plcs ea side)

Tighten Screws to

Rotate Locking Arms
