ISM 1WB and 2WB Output Board • Setup Guide

The Extron® ISM 1WB (single output)

and ISM 2WB (dual output) are

wideband output boards for

the ISM 824. Both boards pass

signals through unprocessed

on either BNCs (ISM 1WB) or

dual 15-pin HD connectors (ISM 2WB). Both boards have

local audio output(s). The ISM 1WB and ISM 2WB boards

are mounted at the rear of the ISM 824, in the vertical

expansion slots. The ISM 1WB board can be mounted in

any of the four slots (numbered 1 to 4). The ISM 2WB

must be mounted in slots 1 and 2 (dual output slots). Refer to the ISM 824 User Guide,

online at www.extron.com for operating details.

To install an ISM 1WB or ISM 2WB output board in the ISM 824 unit,

1. Turn off the ISM 824. Remove the power cord. Repeat for all connected devices.

2. Select an open slot at the rear, or take out a blank plate by removing the two screws

(top and bottom), and lifting the plate away.

NOTE: Retain and re-use the screws to secure the new output board in place. Retain

the blank plates. If a board is installed in the desired slot, remove the screws

and carefully pull out the board.

3. Holding it by the frame, align the front

(non-connector end) of the board with the top

and bottom plastic guides in the ISM 824. Slide

the board in carefully, keeping within the guides.

Push it into place ﬁrmly, and secure it with the

retained screws.

4. If required, repeat steps 2 through 4.

5. Power on the ISM 824. The new output board(s)

is auto-detected, and takes approximately 30

seconds to initialize. The 16 character LCD display

indicates the new board type, slot used, and

counts down the initialization time. See inset for

example display for a new ISM 1WB board installed in slot #2,

with 7 seconds left.

6. Following the image at right, connect output device

cables to the BNC connectors to output RGBHV, RGBS,

RGsB, or HD component video signals. If using an ISM 2WB,

connect a suitable RGB display to the 15-pin HD connectors.

7. Insert a 5-pole captive screw connector into the local audio

output connector for balanced or unbalanced stereo audio

output. Wire the connector as shown below.

100

240

50/60 Hz

1.2A MAX.

2 3 4 5 6 7 8

1 2

3 4 5 6 7 8

INPUTS

OUTPUTS

R/R-Y

G/Y

VID

B/C

B-Y

H/HV

R/R-Y

G/Y

VID

B/C

B-Y

H/HV

PASS THRU

INPUTS

RESET

LAN

REMOTE

RS232/RS422 ACT LINK

OUTPUT

VIDEO

SCALER

70-545-01

R-Y

G/Y

B-Y

OUTPUT

UNIV.

SCALER

70-544-01

R-Y

G/Y

B-Y

OUTPUT

PASS

THRU

70-547-01

R-Y

G/Y

B-Y

Extron

ISM 824

Integration Scaling

Matrix Switcher

Align output board

with top and bottom

plastic guides.

R-Y

G/Y

B-Y

OUTPUT

SCAN

CONV.

70-546-01

Example Output Board Installation

New Wideband

Slot #2 07

RGB/R-Y,Y,B-Y

/YC/VID

OUTPUT

3 / 5

OUTPUT

4 / 6

RGB/R-Y,Y,B-Y

/YC/VID

LRLR

DUAL

WIDEBAND

ISM 2WB

ISM 1WB

R-Y

G/Y

B-Y

WIDEBAND

RGBHV

Video

RGsB or

Component

Video

RGBS

Video

R-Y

G/Y

B-Y

R-Y

G/Y

B-Y

R-Y

G/Y

B-Y

CAUTION: For unbalanced audio, DO NOT connect the sleeves to the negative

contacts. Connect to the center ground contact.

Unbalanced Stereo Output

Balanced Stereo Output

Tip

Ring

Sleeve(s)

Tip

Ring

L R

Left

Right

Tip

Sleeve(s)

Tip

L R

Left

Right

NO GROUND HERE.

Extron USA - West

Headquarters

+800.633.9 876

Inside USA / Canada Only

+1.714.491.1500

+1.714.491.1517 FAX

Extron USA - East

+800.633.9 876

Inside USA / Canada Only

+1.919.863.1794

+1.919.863.1797 FA X

Extron Europe

+800.3987.6673

Inside Europe Only

+31.33.453.4040

+31.33.453.4050 FAX

Extron Asia

+800.7339.8766

Inside Asia Only

+65.6383.4 400

+65.6383.4 664 FAX

Extron Japan

+81.3.3511.7655

+81.3.3511.7656 FAX

Extron China

+400.88 3.1568

Inside China Only

+86.21.3760.1568

+86.21.3760.1566 FAX

Extron Middle East

+971.4.2991800

+971.4.299188 0 FAX

68-1123-66

Rev A

08 10

ISM 1WB and 2WB Output Board • Setup Guide, cont’d

Command ASCII comm

(host to ISM)

Response

(ISM to host)

Additional description

Input selection

Video and audio X!*X@!OutX@•InX!•All]Tie video/audio input X! to X@.

Video X!*X@&OutX@•InX!•RGB]Tie video input X! to output X@.

Audio X!*X@$OutX@•InX!•Aud]Tie audio input X! to output X@.

Volume control

Set volume X@*X3$VOutX@•VolX3$] Set volume to X3$ for output X@.

Increment X@+VOutX@•VolX3$] Increase volume.

Decrement X@-VOutX@•VolX3$] Decrease volume.

View X@VX3$] View current volume setting.

Audio gain and attenuation

Speciﬁc gain X!*X3@GInX!•AudX3!] Set input X! gain to X3!.

Set attenuation X!*X3#gInX!•AudX3!] Set input X! attenuation to X3#.

Increment X!+G/gInX!•AudX3!] Raise input X! audio level to X3!.

Decrement X!-G/gInX!•AudX3!] Lower input X! audio level to X3!.

View X!G/gX3!] View audio level of input X!.

RGB Delay

Delay on 3*X@*X3&#X@DlyX3&] Set RGB delay.

View setting 3*X@#X3&] View RGB delay setting.

Video mute

Mute on X@*1BX@Vmt1]Mute selected video output.

Mute off X@*0BX@Vmt0]Unmute selected video output.

View X@B X1)] View the mute status.

Audio mute

Mute on X@*1ZX@Amt1]Mute selected audio output.

Mute off X@*0ZX@Amt0]Unmute selected audio output.

View X@ZX1)] View mute status.

Board-speciﬁc SIS commands

Speciﬁc SIS commands can be used with the ISM 1WB and ISM 2WB boards.

Refer to the ISM 824 User Guide at www.extron.com, for a detailed command list.

NOTE: X! = Input number, 0-8

X@ = Output number, 1-8

X1) = Mode status, 1 = on, 0 = off

X3! = Audio level adjustment range (-18 to +24)

X3@ = Audio gain adjustment range (0 to 24)

X3# = Audio attenuation adjustment range (18 to 0)

X3$ = Volume adjustment range (0 - 64)

X3& = RGB delay duration 00 to 50 in 0.1 second increments (0.0 second to 5.0 seconds)
