DMP 128 Plus • Setup Guide

This guide provides basic instructions for an experienced technician to install the DMP 128 Plus ProDSP™Digital Matrix

Processor. For more information, specications, and the user guide, see the DMP 128 Plus product page on www.extron.com.

Disconnect Power and Mount the DMP 128 Plus

Disconnect power from the DMP 128 Plus and turn off all devices that will be connected to it. The DMP 128 Plus is housed in a

full rack width, 8.5 inch deep, 1U high metal enclosure that can be rack mounted or placed on a table with the provided rubber

feet. Select a suitable mounting location, then choose an appropriate mounting option. Mounting information can be found in the

DMP128 Plus User Guide on www.extron.com.

Make all external device connections before applying power.

Rear Panel Connections

100-240V 0.7A MAX

50 - 60 Hz

DMP 128 Plus C V AT

INPUTS

RxTx G

RS-232

+S+V -S G

GIN

O1 O2 GIN

O1 O2

56 78

11 12

234

910

12 3 4 5 6 7 8

I/O

OUTPUTS

DMP EXP

ACP

REMOTE

USB AUDIORESET

1(SEC) 234

(PRI)

LAN/VoIP

A B C D E F G HJ K

Figure 1. DMP 128 Plus Rear Panel

AAC Power — IEC power connector, 100—240 VAC, 50—60 Hz.

BDigital I/O Ports — Connect up to eight 4-pole 3.5 mm captive screw connectors. These configurable digital input and

output ports are designed to connect to microphones with logic circuitry for mic mute and tally back functionality. Each port

provides a common ground.

CMic/Line Inputs — On inputs 1 through 8, use 3-pole 3.5 mm captive screw connectors to connect eight balanced or

unbalanced microphone or mono line level sources (see 3-pole Audio Input Wiring below). Inputs 1 through 8 provide

phantom power (all models) and AEC (C models only).

On inputs 9 through 12, use 6-pole 3.5mm captive screw connectors to connect up to four balanced or unbalanced

microphone or mono line level sources or two stereo sources (see 6-pole Audio Input Wiring below).

NOTES:

• Balanced or unbalanced stereo sources can be connected to the

6-pole inputs.

• When using the 5-pole CSR adapter, connect it so the far left plug

is inserted into the far left jack of the 6-pole input (see the example

to the right).

Figure 1

DMP 128 Plus C V AT

RS-

+S+V -S G

O1 O2 GIN

O1 O2

5 6 7 8

11 12

234

910

OUTPUTS

DMP EXP

ACP

REMOTE

DO NOT

Connect Here

5-pole CSR

"(5 mm) MAX. (typ)

3-pole Audio INPUT Wiring

Balanced Input

Sleev

Ring

Tip Tip

Sleeve

Jumper

Unbalanced Input

Tip

Slee

Ring

Tip

Slee

Ring

Tip

Sleeve

Tip

Sleeve

6-pole Audio INPUT Wiring

Balanced Input Unbalanced Input

Jumper

IMPORTANT:

Go to www.extron.com for the

complete user guide

, installation

instructions, and specifications.

DLine Outputs — Use 6-pole 3.5 mm captive screw connectors to connect up to eight balanced or unbalanced mono line level

devices or four stereo devices (see Audio Output Wiring below).

Tip

Sleeve

Tip

Sleeve

Tip

Slee

Ring

Tip

Slee

Ring

6-pole Audio OUTPUT Wiring

Balanced Output Unbalanced Outpu

NO Ground Here

3-pole Audio OUTPUT Wiring

Unbalanced Output

Tip

Sleeve

NO Ground Here

Balanced Output

Tip

Sleev

Ring

EEXP Port — Connect an EXP-enabled device to this RJ-45 port for a digital audio connection using Extron proprietary

protocol. Use the included one foot long shielded CAT 6 cable to connect two EXP-enabled devices to form a larger matrix

system. The expansion bus supports 16 bidirectional channels of audio (see the DMP 128 Plus User Guide for EXP bus

operation details).

FACP Panel Port — Use a 4-pole 3.5 mm captive screw connector to connect

an ACP control device for configuration via DSP Configurator (wiring shown to

the right).

GRS-232 Port — Use a 3.5 mm 3-pole captive screw connector to connect the

host RS-232 cable for bidirectional RS-232 (±5V) serial control (wiring shown

to the right). The default baud rate is 38400.

HLAN Ports — One RJ-45 port (non-V models) or two RJ-45 ports (V models)

are available for control network traffic (all models) and VoIP network traffic (V models only). On DMP 128 Plus V models, the

LAN/VoIP ports have multiple configuration options (refer to the DMP 128 Plus User Guide for configuration options). On

Vmodels, by default, both control and VoIP traffic are transported on LAN/VoIP 1.

Port Default IP Address Default Subnet Mask Default Gateway Default DHCP

LAN 1 192.168.254.254 255.255.255.0 0.0.0.0 OFF

LAN 2 (V models only) 192.168.1.254 255.255.255.0 0.0.0.0 OFF

IAT Ports (AT models only) — Four RJ-45 ports form a Gigabit switch that interfaces with the AT bus. The AT expansion bus

uses Dante™protocol for digital audio networking and allows DMP 128 Plus AT models to connect with other Dante-enabled

devices to form a larger matrix (see the DMP 128 Plus User Guide for operation details).

NOTE: Dante Controller software is required to configure the AT expansion bus. Dante Controller is available at

www.extron.com (see the DMP 128 Plus User Guide for instructions on installation and operation).

JUSB Audio Port — Connect a Windows or Mac computer to this USB mini type B port to interface with the DMP 128 Plus as

a 4x4 USB audio device (see the DMP 128 Plus User Guide for USB audio interfacing capabilities).

KReset Button and LED — The reset button returns the DMP 128 Plus to different tiers of default states. When using the reset

function, the LED blinks to signify the different reset modes. When not using the reset function, the LED operates as a power

indicator and matches the front panel power LED (see the Reset Modes section of the DMP 128 Plus User Guide for more

information on the different reset modes).

When all connections have been made, power up the input and output devices, then apply power to the DMP 128 Plus.

Front Panel Features

DIGITAL MATRIX PROCESSOR

CONFIG

CLIP

EXP LAN USB SIGNAL

CLIP

SIGNAL

123456 7 8 1 2 3 4 5 6 7 89 10 11 12

ACTIVITY

INPUTS OUTPUTS

DMP 128 Plus

B C D EA

Figure 2. DMP 128 Plus Front Panel

APower LED — Blinks during boot up and lights steadily when the DMP 128 Plus is operational.

BUSB Config Port — One USB mini type B port is used for configuration. This port can also be used for firmware updates.

ATTENTION: For unbalanced audio outputs, connect the sleeves to the ground contact. DO NOT connect the sleeves

to the negative (-) contacts.

ATTENTION : Pour l’audio asymétrique, connectez les manchons au contact au sol. Ne PAS connecter les manchons

aux contacts négatifs (–).

Ground

+Signal

Signal

+12 VDC

RS-232

Tx Rx G

REMO

Transmit

Receive

Ground

Figure 2

CActivity Indicator LEDs — These LEDs indicate activity or status on the rear panel EXP, LAN, and USB ports.

DInput Indicator LEDs — Stacked green and red LEDs display input signal presence and input signal clipping.

EOutput Indicator LEDs — Stacked green and red LEDs display output signal presence and output signal clipping.

DSP Conﬁgurator Software Installation

There are no hardware controls for the DMP 128 Plus. All conguration and control is done using ExtronDSPCongurator

software. Install DSP Congurator on a PC running Microsoft®Windows®. For full computer requirements, see the DSP

Congurator product page on www.extron.com.

Download DSP Conﬁgurator from the Extron Website:

1. From the Extron home page (www.extron.com), click the Download tab to open the Download page.

2. Under Software, on the left side of the page, select DSP Configurator Software. The DSPConfiguratorSoftware

product page opens.

3. Click the Download button and follow the on-screen instructions.

NOTE: An Extron Insider account is required to download DSP Configurator.

DMP 128 Plus Conﬁguration

When power is connected to the DMP 128 Plus and the rest of the audio system, audio output can easily be tailored to any

listening environment. When conguration is required, changes are made using DSP Congurator.

Conﬁgure the DMP 128 Plus:

1. Ensure the control computer is connected to

the LAN port (recommended), front panel USB

Cong port, or RS-232 port of the

DMP 128 Plus. Full conguration that includes

macros and ACP conguration requires a LAN

connection.

2. Start the DSP Congurator software. From the

splash screen drop-down menu, select the

DMP 128 Plus model corresponding to the

model connected to the control computer.

Click OK and the main workspace opens.

3. The software starts in Emulate mode.

a. To create a conguration le ofine and

upload (push) that conguration to the

DMP 128 Plus at a later time, remain in

Emulate mode and save the conguration

le.

b. To push a conguration to the DMP128Plus or pull the current conguration from the DMP 128 Plus, enter Live mode.

When in Live mode, changes made in DSP Congurator affect the connected DMP128Plus immediately. To enter Live

mode, click Live at the top of the DSP Congurator workspace, select Tools >Connect to Device, or press <F6>

on the keyboard.

NOTE: When Live mode is selected, a connection dialog box appears. Select the desired connection type and

follow the on-screen prompts (see the DMP 128 Plus User Guide for more information on connecting Live to a

device).

The main workspace provides access to mix matrices, gain blocks, and DSP processors for conguring the DMP 128 Plus. It also

provides a menu bar across the top with additional conguration tools. For more information about using DSP Congurator, see

the DSP Conﬁgurator Software section of the DMP 128 Plus User Guide or the DSP Conﬁgurator Help le that can be accessed

by selecting Help >Contents or pressing <F1> on the keyboard. Most dialog boxes within DSP Congurator contain a context

sensitive Help button ( ) in the top right corner. Click this button to open the help le topic for that specic dialog box.

Extron Headquarters

+800.633.9876 Inside USA/Canada Only

Extron USA - West Extron USA - East

+1.714.491.1500 +1.919.850.1000

+1.714.491.1517 FAX +1.919.850.1001 FAX

Extron Europe

+800.3987.6673

Inside Europe Only

+31.33.453.4040

+31.33.453.4050 FAX

Extron Asia

+65.6383.4400

+65.6383.4664 FAX

Extron Japan

+81.3.3511.7655

+81.3.3511.7656 FAX

Extron China

+86.21.3760.1568

+86.21.3760.1566 FAX

Extron Middle East

+971.4.299.1800

+971.4.299.1880 FAX

Extron Australia

+61.8.8113.6800

+61.8.8351.2511 FAX

Extron India

1800.3070.3777

(Inside India Only)

+91.80.3055.3777

+91.80.3055.3737 FAX

Conﬁgure Dante Device Settings (AT Models Only):

Dante settings on DMP 128 Plus AT models can be congured from DSP Congurator. The Dante device can be named here,

which aids in device identication in the DanteController software when there are multiple Dante devices on the audio network.

ATTENTION: It is essential that a Dante device be named before audio subscriptions with other devices are

established. Existing subscriptions are removed when a device is renamed.

To configure Dante device settings:

1. Open DSP Congurator and connect Live to the DMP 128 Plus AT (see step 3b on the previous page).

2. Select Tools>Device Settings. The Device Settings dialog box opens.

3. From the tabs at the top of the Device Settings dialog box, select Dante

Device.

a. It may be necessary to use the right navigation arrow ( ) at the top right

corner of the Device Settings dialog box to navigate to the Dante

Device tab (see gure to the right).

4. In the Device name eld, give the DMP 128 Plus AT a meaningful name

(such as device model and location) so that it can be easily identied in

DanteController.

5. Dante device network settings can also be congured from this dialog box.

Use the radio buttons and text elds to choose DHCP (recommended) or

Static IP and enter a static IP address conguration.

NOTE: The device name and IP configuration in the Dante Device tab

only affect the Dante interface of the DMP128PlusAT. These settings

do not affect the device name recognized in DSP Configurator or the IP

address of the rear panel LAN port.

6. Select Enable Redundant Mode only if conguring the DMP 128 Plus AT

for use on redundant networks. A separate set of redundancy network settings opens for conguration (see Physical Dante

Network Setup in the DMP 128 Plus User Guide for more information on redundant conguration).

7. Click Apply.

8. Click OK to conrm changes and close the Device Settings dialog box.

For more information on conguring a DMP 128 Plus AT model in Dante Controller, refer to the Dante Controller section of the

DMP128PlusUser Guide (www.extron.com).

68-2826-50 Rev. C

07 17

Table des matières

Autres manuels Extron electronics Équipement d'enregistrement

Extron electronics

Extron electronics RGB 190FV Manuel utilisateur

Extron electronics

Extron electronics RGB 203 Rxi Manuel utilisateur

Extron electronics

Extron electronics CIA111 Manuel utilisateur

Extron electronics

Extron electronics RWM 1 Manuel utilisateur

Extron electronics

Extron electronics RGB 124 Manuel utilisateur

Extron electronics

Extron electronics MAV Series Manuel utilisateur

Extron electronics

Extron electronics KNX 100G Manuel utilisateur

Extron electronics

Extron electronics IP Link Pro xi IPL EXP I/O Series Manuel utilisateur

Extron electronics

Extron electronics RGB 580xi AAP Manuel utilisateur

Extron electronics

Extron electronics CIA111 Manuel utilisateur

Extron electronics

Extron electronics Converter CVC 200 Manuel utilisateur

Extron electronics

Extron electronics VNR 100 Manuel utilisateur

Extron electronics

Extron electronics Universal Interfaces RGB 130xi Manuel utilisateur

Extron electronics

Extron electronics PIP 422 Manuel utilisateur

Extron electronics

Extron electronics Architectural Series Universal Interfaces with Audio and ADSP RGB... Manuel utilisateur

Extron electronics

Extron electronics DMP 64 Manuel utilisateur

Extron electronics

Extron electronics CCI Pro 700 Manuel utilisateur

Extron electronics

Extron electronics CVEQ1 AAP Manuel utilisateur

Extron electronics

Extron electronics RGB 160xi Manuel utilisateur

Extron electronics

Extron electronics TLI Pro 201 Manuel utilisateur

Extron electronics

Extron electronics Inline CIA116-1 Manuel utilisateur

Extron electronics

Extron electronics VersaTools MTP DA4 Manuel utilisateur

Extron electronics

Extron electronics NetPA AT Series Manuel utilisateur

Extron electronics

Extron electronics Extron IPL T S4 Manuel utilisateur

Manuels Équipement d'enregistrement populaires d'autres marques

KV2 Audio

KV2 Audio 500 Series Manuel utilisateur

Robotics Technologies

Robotics Technologies microBus-Cam II Manuel utilisateur

Seca

Seca 460 Manuel utilisateur

Cognex

Cognex MVS-8000 Series Manuel utilisateur

Mect

Mect MPNC006 Series Manuel utilisateur

Bad Caf

Bad Caf THE LEASH Manuel utilisateur

Strymon

Strymon NIGHTSKY Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric 16CH DIGITAL RECORDER DX-TL5000U Manuel utilisateur

Tews Technologies

Tews Technologies TPMC465 Manuel utilisateur

Honeywell

Honeywell Excel 50 Manuel utilisateur

SeaLevel

SeaLevel COMM+8.LPCI Manuel utilisateur

Arturia

Arturia AUDIOFUSE STUDIO Manuel utilisateur

Rukra

Rukra RK-1240 Manuel utilisateur

Samson

Samson SCOM Manuel utilisateur

Dynacord

Dynacord DPS260 Manuel utilisateur

Nice

Nice Core Manuel utilisateur

Pyle Pro

Pyle Pro PSS8 Manuel utilisateur

RF-System

RF-System TinyGate Manuel d'utilisation et d'entretien
