DVI DA2 and DVI DA 4 • User Guide

This guide describes the installation and operation of the Extron DVI DA2 and DVI DA4 Distribution Ampliers. Unless stated

otherwise, “distribution amplier” or “the unit” in this guide refer to both models.

FCC Class A Notice

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part15 of the

FCC rules. The ClassA limits provide reasonable protection against harmful interference when the equipment is operated in a

commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used

in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment

in a residential area is likely to cause interference. This interference must be corrected at the expense of the user.

NOTE: For more information on safety guidelines, regulatory compliances, EMI/EMF compatibility, accessibility, and related topics,

see the “Extron Safety and Regulatory Compliance Guide” on the Extron website.

Speciﬁcations Availability

Product specications are available on the Extron website, www.extron.com.

About the DVI DA2 and DVI DA4

The Digital Visual Interface (DVI) Distribution Ampliers (DAs) have one input and either two (DVI DA2) or four (DVI DA4) outputs.

Output 1 for each model is for a local monitor and is used for Digital Display Channel (DDC) reference.

Both distribution ampliers accept one single link DVI-D input and drive two (DVI DA2) or four (DVI DA4) single link DVI-D output

signals.

12V

0.4A MAX

POWER

DVI-D INPUT DVI-D OUTPUT

1 2

DVI DA2

Ext

ron

I DA 2

Dist

ribution Amplier

w/ DVI Output

Local Monitor

Flat Panel Display

w/ DVI Input

Figure 1.DVI DA2 Application Diagram

DVI DA2 and DVI DA4 Features

• External power supply — The DVI DA2 and DVI DA4 are powered by an external 12VDC power supply (provided with the

units).

• DVI-D input — Both distribution ampliers accept one single link DVI-D input with a range of resolutions up to 1920 x 1200

or 1080p @ 60 Hz.

• Input equalization — Input Equalization (EQ) conditions the input signals to ensure the integrity of the signals delivered to

the output devices.

• DVI-D outputs — The units drive two (DVI DA2) or four (DVI DA4) single link DVI-D output signals.

• DDC routing to the local monitor — Output 1 is used as a DDC reference and is labeled “Local Monitor” for easy reference.

The video source uses the bidirectonal DDC to communicate with the local monitor, which allows the source to determine the

resolution and refresh rate of the signal that it sends.

NOTES:

• Since output 1 is used as the reference, all other display devices must be capable of handling resolutions equal to

or greater than that of the local monitor.

• The actual signal transmission distance can vary greatly and depends on signal resolution, cable type, cable

quality, graphics card, and the display used in the system.

• Versatile mounting options — Both units are 1U high, 3 inches (7.62 cm) deep, and 1/2rack (8.7 inches or 22.1 cm) wide,

allowing them to be conveniently mounted in a rack, mounted under a desk, or set on a tabletop.

Installation Overview

Both distribution ampliers can be placed on tabletops, or mounted under furniture or in racks by following these steps:

1. Turn off all electrical equipment. Make sure that the input sources, the DA and the output display(s) are all turned off and all

power sources and signal cables are disconnected.

2. Mount the unit (see Mounting page 5).

3. Connect the cables (see DVI Connections on page 3).

4. Plug in the power supply (see page 3), then turn on the display devices and input devices.

Front Panel Features

The front panels of the DVI DA2 and DVI DA4 are identical and shown in the illustration below

DVI DA SERIES

DVI DISTRIBUTION AMPLIFIER

Figure 2. DVI DA2 and DVI DA4 Front Panel (both models are identical)

aLED indicator — On both the DVI DA2 and DVI DA4, the LED indicator lights when the unit is receiving power.

Rear Panel Features

12V

0.4A MAX

POWER DVI-D INPUT DVI-D OUTPUT

LOCAL MONITOR

DVI DA2

12V

0.4A MAX

POWER DVI-D INPUTDVI-D OUTPUTS

LOCAL MONITOR

1234

DVI DA4

1243

Figure 3. DVI DA2 (top) and DVI DA4 (bottom) Rear Panels

a Power input

b Input connector

c Output connector

d Local Monitor

connector

aPower input — Connect the provided power suppy to the 3.5 mm, screw

12V

0.4A MAX

POWER

Power Supply

Output Cord

SECTION A–

RidgesSmooth

DC Power Cord

Captive Screw Connector

AC Power Cord

Ground

+12 VDC

External

Power Supply

(12 VDC, 1 A )

power receptacle.

NOTES:

• The length of the exposed wires in the stripping process is critical.

The ideal length is 3/16 inch (5 mm).

• If the exposed section is longer, the exposed wires may touch,

causing a short circuit between them.

• If it is shorter, the wires can be easily pulled out, even if tightly

fastened by the captive screws.

• Do not tin the wires. Tinned wire does not hold its shape and can

become loose over time.

Figure 4. Power Connection

ATTENTION:

• This product is intended to be supplied by a Listed Power Unit marked “Class 2” or “LPS,” rated 12 VDC, maximum

1.0 A. Always use a power supply supplied or specied by Extron. Use of an unauthorized power supply voids all

regulatory compliance certication and may cause damage to the supply and the end product.

• Unless otherwise stated, the AC/DC adapters are not suitable for use in air handling spaces or in wall cavities. The

power supply is to be located within the same vicinity as the Extron A/V processing equipment in an ordinary location,

Pollution Degree 2, secured to the equipment rack within the dedicated closet, podium, or desk.

• The installation must always be in accordance with the applicable provisions of National Electrical Code ANSI/NFPA70,

article 75, and the Canadian Electrical Code part 1, section 16. The power supply shall not be permanently xed to

building structure or similar structure.

DVI Connections

bInput connector — Connect the input signal to the female DVI connector. The DVI input signal is equalized to ensure integrity.

cOutput connectors — Connect up to two (DVI DA2) or four (DVI DA4) DVI-D outputs to display devices, using the female DVI

connectors.

NOTE: The outputs are not HDCP compatible.

dLocal Monitor connector — Output 1 (Local Monitor) is used as a Hotplug Detect, a DDC clock, and a DDC data reference.

For the input device to provide a signal at the correct resolution and refresh rate, there must be a display device connected to

output1.

NOTE: Although the source device, local monitor, and remote display devices all connect to the distribution amplifiers

through DVI-I connectors, the DVI DA2 and DVI DA4 are compatible only with single-link DVI-D video signals.

To enable the units to accept sources providing HDMI signals or to provide signals to displays that accept HDMI signals,

use a HDMI to DVI adapter or cable, such as the Extron HDMIF-DVIDM female HDMI to male DVI-D adapter or the Extron

HDMIM-DVI-D M series of male HDMI to male DVI cables.

The input signal is one single link DVI-D with a resolution range up to 1920x1200 or 1080p@ 60 Hz.

Input EQ conditions input signals to ensure the integrity of the signals delivered to the output devices.

NOTES:

• The actual signal transmission distance can vary and depends on the signal resolution, cable quality, graphics card, and

display used in the system.

• To ensure proper operation, display devices connected to outputs 2 through 4 must be able to handle resolutions equal

or greater than that of the local monitor on output 1.

DVI Connector Pin Assignments

The illustration below shows the pin assignments for the male and female DVI-I connectors.

NOTE: Although DVI-I dual link connectors are used, the DVI DA2 and DVI DA4 are compatible only with single-link DVI-D

video signals.

Pin Signal Pin Signal Pin Signal

Three rows of eight holes and two contacts

above and below the "

" socket.

DVI-I Dual Link - Female

(analog and digital)

17 24 C3 C4

C1 C2

1 TMDS data 2- 9 TMDS data 1- 17 TMDS data 0-

2 TMDS data 2+ 10 TMDS data 1+ 18 TMDS data 0+

3 TMDS data 2/4

shield

11 TMDS data 1/3

shield

19 TMDS data 0/5

shield

4 TMDS data 4- 12 TMDS data 3- 20 TMDS data 5-

5 TMDS data 4+ 13 TMDS data 3+ 21 TMDS data 5+

6 DDC clock 14 +5V power 22 TMDS clock shield

7 DDC data 15 Ground 23 TMDS clock+

8 Analog vertical sync 16 Hot plug detect 24 TMDS clock1

C1 Unused C3 Unused C5 Unused

C2 Unused C4 Unused

Operation

To operate the unit (see ﬁgure 3 on page 2 and ﬁgure 4 on page 3):

1. Connect the power supply.

2. Connect and power on the Local Monitor.

3. Connect and power on any other output displays.

4. Connect and power on the source device.

NOTE: Output 1 (Local Monitor) is used as a DDC reference and must be connected to the distribution amplifier before the

source device is powered on. If the source device cannot communicate with the local monitor when it is being powered

on, it may not be able to send a video signal or the signal may have the wrong resolution or refresh rate.

If there are any problems, consult the Troubleshooting section below.

Troubleshooting

• No output signal — Check that the front panel LED is lit. If it is not, check the power supply connections to the unit (see

page 4).

• No output signal or poor quality signal — Check the integrity of the cabling to output1 (Local Monitor) and ensure that

output 1 is connected to the distribution amplier before powering on the source device.

If the source device cannot communicate with output 1 when it is being powered on, it may not be able to send a video signal or the signal

may have the wrong resolution or refresh rate.

No output signal or poor quality signal — Check the input and output cabling (page3). DVI signals run at very high frequency and poor

connections can cause degradation or loss of the signal, or jitter. To avoid this:

• Use only cable that is designed for DVI signals.

• Limit or avoid the use of adapters.

• Display device shows a flashing black or blue screen, snow or other distortion — A device that is not HDCP compliant

may be receiving HDCP-encrypted signals.

The DVI DA2 and DVI DA4 are not High-Bandwidth Digital Content Protection (HDCP) compliant. They will pass HDCP-encrypted signals

only to the local output device.

• Signal on local monitor but not on other displays — Check that all output devices (monitors or projectors) can handle

resolutions equal to or greater than that of the local monitor.

Extron Headquarters

+800.633.9876 Inside USA/Canada Only

Extron USA - West Extron USA - East

+1.714.491.1500 +1.919.850.1000

+1.714.491.1517 FAX +1.919.850.1001 FAX

Extron Europe

+800.3987.6673

Inside Europe Only

+31.33.453.4040

+31.33.453.4050 FAX

Extron Asia

+65.6383.4400

+65.6383.4664 FAX

Extron Japan

+81.3.3511.7655

+81.3.3511.7656 FAX

Extron China

+86.21.3760.1568

+86.21.3760.1566 FAX

Extron Middle East

+971.4.299.1800

+971.4.299.1880 FAX

Extron Korea

+82.2.3444.1571

+82.2.3444.1575 FAX

Extron India

1800.3070.3777

(Inside India Only)

+91.80.3055.3777

+91.80.3055.3737 FAX

Mounting

Attach the four provided rubber feet to the bottom of the unit and place it in any convenient location.

Rack Mounting

UL Guidelines for Rack Mounting

The following Underwriters Laboratories (UL) guidelines are relevant to the safe installation of these products in a rack:

1. Elevated operating ambient temperature — If the unit is installed in a closed or multi-unit rack assembly, the operating

ambient temperature of the rack environment may be greater than room ambient temperature. Therefore, install the

equipment in an environment compatible with the maximum ambient temperature (Tma: +122 °F, +50°C) specied by Extron.

2. Reduced air flow — Install the equipment in the rack so that the equipment gets adequate air ow for safe operation.

3. Mechanical loading — Mount the equipment in the rack so that uneven mechanical loading does not create a hazardous

condition.

4. Circuit overloading — Connect the equipment to the supply circuit and consider the effect that circuit overloading might

have on overcurrent protection and supply wiring. Consider the equipment nameplate ratings when addressing this concern.

5. Reliable earthing (grounding) — Maintain reliable grounding of rack-mounted equipment. Pay particular attention to supply

connections other than direct connections to the branch circuit (such as the use of power strips).

Rack Mounting Procedure

The unit can be mounted on any rack systems. To mount the product on a rack shelf, follow the instructions provided with the

shelf accessories.

Under-desk Mounting

Mount the unit under a desk or podium, using the optional Extron MBU 125 under-desk mounting kit. Follow the instructions

provided with the MBU 125 kit.

68-1376-01 Rev. F

09 13

Autres manuels pour DVI DA2

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Extron electronics Amplificateur

Extron electronics

Extron electronics P/2 DA2xi MT Manuel utilisateur

Extron electronics

Extron electronics MPA 401-70V Manuel utilisateur

Extron electronics

Extron electronics VersaTools MDA 2V EQ Manuel utilisateur

Extron electronics

Extron electronics SW HD 4K PLUS Series Manuel utilisateur

Extron electronics

Extron electronics MPA 401-100V Manuel utilisateur

Extron electronics

Extron electronics XTRA Series Manuel utilisateur

Extron electronics

Extron electronics ASA 204 Manuel utilisateur

Extron electronics

Extron electronics VGA Distribution Amplifiers P/2 DA12 Series Manuel utilisateur

Extron electronics

Extron electronics P/2 DA2xi MT Manuel utilisateur

Extron electronics

Extron electronics P/2 DA2xi MT Manuel utilisateur

Extron electronics

Extron electronics P/2 DA2 Plus Manuel utilisateur

Extron electronics

Extron electronics DP DA2 Manuel utilisateur

Extron electronics

Extron electronics XPA Ultra Series Manuel utilisateur

Extron electronics

Extron electronics NetPA U 8001 SUB Manuel utilisateur

Extron electronics

Extron electronics P/2 DA2 Plus Manuel utilisateur

Extron electronics

Extron electronics Video and Audio Line Drivers with Gain and EquaLization CVEQ... Manuel utilisateur

Extron electronics

Extron electronics SW2 VGA DA2 A Manuel utilisateur

Extron electronics

Extron electronics P/2 DA2 MT Manuel utilisateur

Extron electronics

Extron electronics DTP HD DA8 4K 330 Manuel utilisateur

Extron electronics

Extron electronics VersaTools MDA 2V EQ Manuel utilisateur

Extron electronics

Extron electronics P/2 DA2 EC F Manuel utilisateur

Extron electronics

Extron electronics VGA Distribution Amplifiers P/2 DA4xi s Manuel utilisateur

Extron electronics

Extron electronics VersaTools MTP DA4 Manuel utilisateur

Extron electronics

Extron electronics VGA Distribution Amplifiers P/2 DA4xi s Manuel utilisateur

Manuels Amplificateur populaires d'autres marques

ASTRO

ASTRO HVO V40 P Manuel utilisateur

Marantz

Marantz SUPERSCOPE BLA-545 Instructions de montage

NAD

NAD CI980 Manuel utilisateur

Technics

Technics SE-CH770 Manuel utilisateur

Harman Kardon

Harman Kardon HK6300 Manuel utilisateur

NAD

NAD T975 Manuel utilisateur

McIntosh

McIntosh MA6850 Manuel utilisateur

Electro-Harmonix

Electro-Harmonix ENGLISH MUFF’N Manuel utilisateur

Viatron

Viatron Autrix Manuel utilisateur

GME

GME GA9800 Manuel utilisateur

Atlas

Atlas CP700 Manuel utilisateur

Roland

Roland KC-1000 Manuel utilisateur

Pyle

Pyle PFMRA350BW Manuel utilisateur

Advantage

Advantage S-250 Manuel utilisateur

IRT Electronics

IRT Electronics DVA-3007 Manuel utilisateur

Dimavery

Dimavery BA-100 Series Manuel utilisateur

Sony

Sony XM-S400D Manuel utilisateur

Schertler

Schertler ROY X Manuel utilisateur
