Published July 2017

9035171

AP-8533 Access Point

Regulatory Guide - CDRDB

AP-8533 Regulatory Guide

Extreme Networks Inc. 1

Extreme Confidential Restricted

1.Regulatory Information

This device is approved under Extreme Networks Inc.

This guide applies to Model Number: CDRDB

All Extreme devices are designed to be compliant with the rules and regulations in the locations they are sold and will be

labeled as required.

Local language translations are available at the following website:

http://www.extremenetworks.com/support/documentation/.

Any changes or modifications to Extreme equipment not expressly approved by Extreme Networks could void the user’s

authority to operate the equipment.

Extreme devices are professionally installed — the Radio Frequency Output Power will not exceed the maximum allowable

limit for the country of operation.

Antennas: Use only the supplied or an approved replacement antenna. Unauthorized antennas, modifications, or

attachments could cause damage and may violate regulations.

This device is only to be used with an Extreme Wireless Switch.

For use only with Extreme approved and UL Listed mobile computers, Extreme approved, and UL Listed/Recognized

battery packs.

AP-8533 Regulatory Guide

Extreme Networks Inc. 2

Extreme Confidential Restricted

2. Wireless Device Country Approvals

NOTE

This section is only applicable to WW/WR/EU configurations.

NOTE

Regulatory markings subject to certification are applied to the device signifying the

radio(s) is/are approved for use in the following countries and continents: United

States, Canada, Japan, China, South Korea, Australia, and Europe.

Please refer to the Declaration of Conformity (DoC) for details of other country markings. This is available at:

http://www.extremenetworks.com/support/documentation/.

NOTE

Europe includes Austria, Belgium, Bulgaria, Croatia, Czech Republic, Cyprus, Denmark,

Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia,

Liechtenstein, Lithuania, Luxembourg, Malta, Nether-lands, Norway, Poland, Portugal,

Romania, Slovak Republic, Slovenia, Spain, Sweden, Switzerland, and the United

Kingdom.

CAUTION

Operation of the device without regulatory approval is illegal.

Country Selection

Select only the country in which the device will be used. Any other selection will make the operation of this device illegal.

Country Roaming

This device incorporates the International Roaming feature (IEEE802.11d), which will ensure the product operates on the

correct channels for the particular country of use.

AP-8533 Regulatory Guide

Extreme Networks Inc. 3

Extreme Confidential Restricted

Frequency of Operation – IC

5 GHz Only:

The use in the UNII (Unlicensed National Information Infrastructure) band 1 (5150-5250 MHz) is restricted to Indoor Use

Only; any other use will make the operation of this device illegal.

Industry Canada Statement:

CAUTION

The device for the band 5150-5250 MHz is only for indoor usage to reduce potential for

harmful interference to co-Channel mobile satellite systems. High power radars are

allocated as primary users (meaning they have priori-ty) of 5250-5350 MHz and 5650-

5850 MHz and these radars could cause interference and/or damage to LE-LAN devices.

Avertissement

Le dispositive fonctionnant dans la bande 5150-5250 MHz est réservé uniquement pour

une utilisation à l'intérieur afin de réduire les risques de brouillage préjudiciable aux

systèmes de satellites mobiles utilisant les mêmes canaux. Les utilisateurs de radars de

haute puissance sont désignés utilisateurs principaux (c.-à-d., qu'ils ont la priorité) pour

les bands 5250-5350 MHz et 5650-5850 MHz et que ces radars pourraient causer du

brouillage et/ou des dommages aux dispositifs LAN-EL.

2.4 GHz Only:

The available channels for 802.11 b/g operation in the US are Channels 1 to 11. The range of channels is limited by firmware.

Warnings for Use of Wireless Devices

CAUTION

Please observe all warning notices with regard to the usage of wireless devices.

AP-8533 Regulatory Guide

Extreme Networks Inc. 4

Extreme Confidential Restricted

Potentially Hazardous Atmospheres – Fixed Installations

You are reminded of the need to observe restrictions on the use of radio devices in fuel depots, chemical plants etc. and

areas where the air contains chemicals or particles such as grain, dust, or metal powders.

Safety in Aircraft

Switch off your wireless device whenever you are instructed to do so by airport or airline staff. If your device offers a ‘flight

mode’ or similar feature, consult airline staff as to its use in flight.

Safety in Hospitals

Wireless devices transmit radio frequency energy and may affect medical electrical equipement.

Wireless devices should be switched off wherever you are requested to do so in hospitals, clinics, or healthcare facilitlies.

These requests are designed to prevent possible interference with sensitive medical equipement.

Wireless devices transmit radio frequency energy and may affect medical electrical equipment. When installed adjacent to

other equipment, it is advised to verify that the adjacent equipment is not adversely affected.

Pacemakers

Pacemaker manufacturers recommended that a minimum of 15cm (6 inches) be maintained between a handheld wireless

device and a pacemaker to avoid potential interference with the pacemaker. These recommendations are consistent with

independent research and recommendations by Wireless Technology Research.

Persons with Pacemakers:

•Should ALWAYS keep the device more than 15cm (6 inches) from their pacemaker when turned ON.

•Should not carry the device in a breast pocket.

•Should use the ear furthest from the pacemaker to minimise the potential for interference.

•If you have any reason to suspect that interference is taking place, turn OFF your device.

Other Medical Devices

Please consult your physician or the manufacturer of the medical device to determine if the operation of your wireless

product may interfere with the medical device.

AP-8533 Regulatory Guide

Extreme Networks Inc. 5

Extreme Confidential Restricted

RF Exposure Guidelines

Safety Information

•Reducing RF Exposure – Use Properly

Only operate the device in accordance with the instructions supplied.

•International

The device complies with internationally recognized standards covering human exposure to electromagnetic

fields from radio devices. For information on ‘International’ human exposure to electromagnet fields, refer to the

Extreme Declaration of Conformity (DoC) at http://www.extremenetworks.com/support/documentation/.

US and Canada

•Co-located statement

To comply with FCC RF exposure compliance requirement, the antenna used for this transmitter must not be co-

located or operating in conjunction with any other transmitter/antenna except those already approved in this

filling.

To satisfy US and Canadian RF exposure requirements, a transmitting device must operate with

a minimum separation distance of XX cm or more from a person’s body. The minimum

separation distance 35 cm must match the distance established in the SAR Test report.

Pour satisfaire aux exigences Américaines et Canadiennes d'exposition aux radio fréquences, un

dispositif de transmission doit fonctionner avec une distance de séparation minimale de XX cm

ou plus de corps d'une personne.

Radiation Exposure Statement:

This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This

equipment should be installed and operated with minimum distance 35 cm between the radiator and your body.

NOTE IMPORTANTE: (Pour l'utilisation de dispositifs mobiles)

Déclaration d'exposition aux radiations:

Cet équipement est conforme aux limites d'exposition aux rayonnements IC établies pour un non

contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 35 cm de distance entre la source de

rayonnement et votre corps.

oRemote and Standalone Antenna Configurations

To comply with FCC RF exposure requirements, antennas that are mounted externally at remote locations or

operating near users at stand-alone desktop of similar configurations must operate with a minimum

separation distance of 35 cm from all persons.

To comply with FCC Antenna requirements, the Antenna must be adjust such that the RF emission lobes are

below 30 degrees elevation.

AP-8533 Regulatory Guide

Extreme Networks Inc. 6

Extreme Confidential Restricted

3. Radio Frequency Interference

Requirements- FCC

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15

of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications. However there is no

guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to

radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try

to correct the interference by one or more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

•Consult the dealer or an experienced radio/TV technician for help.

Note: This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15

of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the

equipment is operated in commercial environment. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the

user will be required to correct the interference at his own expense.

Radio Transmitters (Part 15)

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device

may not cause harmful interference, and (2) this device must accept any interference received including interference that

may cause undesired operation. When the radio is configured for outdoor operation, EIRP will be limited to below 21dBm

based on the antenna gain and elevation gain entered. The software automatically restricts the output power to the

certified levels when the professional installer selects the approved antenna that is being used.

AP-8533 Regulatory Guide

Extreme Networks Inc. 7

Extreme Confidential Restricted

Maximum conducted

power(dBm)

Antenna

Gain(dBi)

Maximum EIRP

power(dBm)

2.4GHz

26.28

4.4

30.68

5GHz UNII-1 / indoor

22.79

5.9

28.69

5GHz UNII-1 / outdoor

16.88

5.9

22.78

5GHz UNII-1 / outdoor

Above 30 degree

16.88

4.1

20.98

5GHz UNII-2A

21.91

5.9

27.81

5GHz UNII-2C

22.41

5.9

28.31

5GHz UNII-3

22.84

5.9

28.74

AP-8533 Regulatory Guide

Extreme Networks Inc. 8

Extreme Confidential Restricted

4. Radio Frequency Interference

Requirements- Canada

CAN ICES-3 (B)/NMB-3(B)

Radio Transmitters

For RLAN Devices:

The use of 5 GHz RLAN’s, for use in Canada, have the following restrictions:

•Restricted Band 5.60 – 5.65 GHz

This device is in compliance with the NRC for Industry Canada applicable to license-exempt radios. Use is

allowed with the following two conditions: (1) the device must not produce interference, and (2) the the device

must accept any interference to the radio even if the interference is likely to compromise operation.

Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de

licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de

brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radio électrique subi même si le

brouillage est susceptible d'en compromettre le fonctionnement.

Label Marking: The Term ‘IC:’ before the radio certification only signifies that Industry Canada technical specifications

were met.

In accordance with the regulations of Industry Canada, this radio transmitter can operate with an antenna of a

type and a maximum gain (or lower) approved for the transmitter by Industry Canada. With the aim of

reducing the risk of radio interference to other users, the chosen antenna type and it gain should be selected so

that the equivalent isotropically radiated power (e.i.r.p.) does not exceed the intensity necessary for the

establishment of a satisfactory connection.

Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une

antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le

but de réduire les risques de brouillage radio électrique à l'intention des autres utilisateurs, il faut choisir le type

d'antenne et son gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas

l'intensité nécessaire à l'établissement d'une communication satisfaisante.

This radio transmitter (CDRDB) has been approved by Industry Canada to operate with the antenna types

listed below and having a maximum gain allowable and the impedance required for each type of antenna. The

antenna types not included in this list, or whose gain is higher than the maximum gain indicates, are strictly

prohibited for the operation of the transmitter.

AP-8533 Regulatory Guide

Extreme Networks Inc. 9

Extreme Confidential Restricted

The antenna list and types are included in the following tables:

Part Number Antenna

Type

2.4

GHZ

Gain

(dBi)

GHZ

Gain

(dBi) Elevation

Gain

Impedance

(Ohms)

ML-2452-HPAG4A6-01

Dipole

7.3

5.7

ML-2452-APAG2A1-01

Dipole

2.7

1.7

N/A

ML-2452-HPA6-01

Dipole

5.3

6.1

4.09

ML-2452-APA2-01

Dipole

3.17

4.85

N/A

ML-2452-PNA5-01R

Panel

5.5

5.2

ML-2452-SEC5M4-N36

Polarized

Panel

6.92

7.23

3.95

ML-2452-PTA4M4-036

Patch

6.6

N/A

ML-2499-HPA6H-01

Polarized

Dipole

5.4

N/A

ML-5299-HPA5H-01

Polarized

Dipole

N/A

-1.21

Le présent émetteur radio (identifier le dispositif par son numéro de certification ou son numérode modèle s'il

fait partie du matériel de catégorie I) a été approuvé par Industrie Canada pour fonctionner avec les types

d'antenne énumérés ci-dessous et ayant un gain admissible maximal et l'impédance requise pour chaque type

d'antenne. Les types d'antenne non inclus dans cette liste ou dont le gain est supérieur au gain maximal

indiqué, sont strictement interdits pour l'exploitation de l'émetteur.

Statement of Compliance

Extreme Networks hereby declares that this device is in compliance with the essential requirements and other relevant

provisions of Directive 1999/5/EC and 2011/65/EU. A Declaration of Conformity may be obtained from

http://www.extremenetworks.com/support/documentation/.

Autres manuels pour AP-8533

Table des matières

Autres manuels Extreme Networks Point d'accès sans fil

Extreme Networks

Extreme Networks ExtremeWireless AP510i Manuel utilisateur

Extreme Networks

Extreme Networks Altitude 4700 Series Manuel d'installation et d'exploitation

Extreme Networks

Extreme Networks ExtremeWireless AP5010 Manuel utilisateur

Extreme Networks

Extreme Networks Altitude 450 Manuel utilisateur

Extreme Networks

Extreme Networks Altitude 4600 Series Manuel utilisateur

Extreme Networks

Extreme Networks ExtremeWireless AP560h Manuel utilisateur

Extreme Networks

Extreme Networks ExtremeWireless AP360i ExtremeWireless... Manuel utilisateur

Extreme Networks

Extreme Networks ExtremeWireless WS-AP3965i-FCC Manuel utilisateur

Extreme Networks

Extreme Networks Altitude 3510 Manuel utilisateur

Extreme Networks

Extreme Networks ExtremeWireless AP560i Manuel utilisateur

Extreme Networks

Extreme Networks WiNG AP-7612 Manuel utilisateur

Extreme Networks

Extreme Networks ExtremeWireless AP3935e Manuel utilisateur

Extreme Networks

Extreme Networks ExtremeMobility AP410i/e Manuel utilisateur

Extreme Networks

Extreme Networks ExtremeWireless AP560h Manuel utilisateur

Extreme Networks

Extreme Networks Altitude 4532 Series Manuel utilisateur

Extreme Networks

Extreme Networks AP-7522 Manuel utilisateur

Extreme Networks

Extreme Networks WS-AP3805-FCC/ROW Manuel utilisateur

Extreme Networks

Extreme Networks Altitude 4700 Series Manuel utilisateur

Extreme Networks

Extreme Networks ExtremeWireless AP410i Manuel utilisateur

Extreme Networks

Extreme Networks AP460C Manuel utilisateur

Extreme Networks

Extreme Networks AP-7622 Manuel utilisateur

Extreme Networks

Extreme Networks AP305C Manuel d'installation

Extreme Networks

Extreme Networks ExtremeWireless AP310i Manuel utilisateur

Extreme Networks

Extreme Networks ExtremeWireless AP3965i Manuel utilisateur

Manuels Point d'accès sans fil populaires d'autres marques

D-Link

D-Link DWL-2100AP - AirPlus Xtreme G Manuel utilisateur

Ubiquiti

Ubiquiti NanoStation NSM2 Manuel utilisateur

Cisco

Cisco Aironet 1550 Series Manuel utilisateur

Aruba

Aruba IAP-335 Manuel utilisateur

Advantek Networks

Advantek Networks AWN-AP-54MR Manuel utilisateur

IP-COM

IP-COM AP355 Manuel utilisateur

Buffalo

Buffalo AirStation WLA-L11G Manuel utilisateur

EnGenius

EnGenius EnStationACv2 Manuel utilisateur

D-Link

D-Link DAP-3662 Manuel utilisateur

xG Technology

xG Technology xMax CN1300 Manuel utilisateur

Widelink

Widelink ezWave WAP-1100 Series Manuel utilisateur

Edimax

Edimax CAP1200 Manuel utilisateur

Ubiquiti

Ubiquiti LBE-5AC-Gen2 Manuel utilisateur

Aruba

Aruba AP-203R Manuel utilisateur

LuXout Shades

LuXout Shades LUXSHADE MOTION Manuel utilisateur

CreatComm

CreatComm TB5F Manuel utilisateur

SineDigital

SineDigital MW-1500AP(H) Manuel utilisateur

TP-Link

TP-Link AP9650 V1 Manuel utilisateur
