EXPERT GRILL GBC2016W Manuel utilisateur

OWNER’S MANUAL

Important Safeguard

s....................

Page 2

Limited Warranty ........................... 5

Expanded View & Hardware ................ 6 & 7

Assembly Instructions........................ 8

Installing LP Gas Tank....................... 12

Operating Instructions....................... 13

Cleaning and Care ......................... 14

Troubleshooting ........................... 16

The use and installation must conform with local codes or,

in the absence of local codes, with either the National Fuel

Gas Code, ANSI Z223.1/NFPA 54, Natural Gas and Propane

Installation Code, CSA B149.1, or Propane Storage and

Handling Code, B149.2, or the Standard for Recreational

Vehicles, ANSI A 119.2/NFPA 1192, and CSA Z240 RV

Series, Recreational Vehicle Code, as applicable.

This instruction booklet contains important safety

information. Please read and keep for future reference.

If you are assembling this unit for someone else, give

this manual to him or her to read and save for future

reference.

California Proposition 65: Handling the brass material on

this product exposes you to lead, a chemical known to the

State of California to cause cancer, and birth defects or

other reproductive harm. Wash your hands after handling

this product.

Outdoor LP Gas Barbecue Grill

Model No. XG10-101-002-02 / GBC2016W

& GBC2016WRS

WARNING

FOR YOUR SAFETY:

1. Do NOT store or use gasoline or

other ﬂammable liquids or vapors in

the vicinity of this or any other

appliance.

2. An LP cylinder not connected for

use shall not be stored in the vicinity

of this or any other appliance.

WARNING

FOR YOUR SAFETY:

For Outdoor Use Only! (outside any enclosure)

DANGER

If you smell gas -

1. Shut off gas to appliance.

2. Extinguish any open flame.

3. Open lid.

4. If odor continues, keep away from

the appliance, immediately call your

gas supplier or your fire department.

Failure to follow these instructions

could result in fire or explosion

which could cause property damage,

personal injury or death.

Manufactured in China for: RevoAce Inc. Limited

Hong Kong, China

1.800.694.0013 • [email protected]

9:00 am to 5:00 pm eastern time, Monday to Friday.

DANGER

Do not leave this appliance

unattended, especially cooking the

fatty meat and close the lid too long

time.

GBC2016W-OM-E-F107

Table of Contents

WARNING

CALIFONIA PROPOSITION 65

This product can expose you to

chemicals including benzene, which

is known to the State of California to

cause cancer. For more information,

go to www.P65Warnings.ca.gov.

FOR YOUR SAFETY

WWARNINGS:

1. Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage.

2. Read the installation, operation, and maintenance instructions thoroughly before installing or servicing this

equipment.

3. Failure to follow these instructions could result in ﬁre or explosion, which could cause property damage,

personal injury, or death.

4. This instruction manual contains Important information necessary for the proper assembly and safe use of

the appliance.

5. Read and follow all warnings and instructions before assembling and using the appliance.

6. Follow all warnings and instructions when using the appliance.

7. Keep this manual for future reference.

8. Do Not store or use gasoline or other ﬂammable liquids or vapors in the vicintiy of this or any other appliance.

9. An LP cylinder not connected for use shall not be stored in the vicinity of this or any other appliance.

IMPORTANT SAFEGUARDS

WDANGER: Failure to follow the dangers, warnings and cautions in this manual may result in serious

bodily injury or death, or in a fire or an explosion causing damage to property.

WWARNINGS:

WThis grill is for outdoor use only, and should not be used in a building, garage or any other enclosed area.

WDo NOT operate, light or use this appliance within ten feet (3.05 m) of walls, structures or buildings.

WFor residential use only. This grill is NOT for commercial use.

WThis grill is not intended for and should never be used as a heater. TOXIC fumes can accumulate and cause

asphyxiation.

WThis grill is safety certified for use in the United States and/or Canada only. Do NOT modify for use in any

other location. Modification will result in a safety hazard and will void your warranty.

WThis grill is for use with liquid propane (LP) gas only. The conversion to or attempted use of natural gas in this

LP gas grill is dangerous, may cause bodily harm and will void your warranty.

WLP gas characteristics:

a. LP gas is flammable and hazardous if handled improperly. Become aware of the characteristics before

using any LP gas product.

b. LP gas is explosive under pressure, heavier than air, and settles/pools in low areas.

c. LP gas in its natural state has no odor. For your safety, an odorant is added that smells like rotten

cabbage.

d. Contact with LP gas can cause freeze burns to skin.

WApartment dwellers: Check with management to learn the requirements and fire codes for using a LP gas grill

in your apartment complex. If allowed, use outside on the ground floor with a ten foot (3.05 m) clearance from

any structure. Do NOT use on or under balconies.

WLP gas cylinder needed to operate. Only cylinders marked “propane” may be used.

WThe LP gas cylinder must be constructed and marked in accordance with the Specifications for LP-gas

Cylinders of the U.S. Department of Transportation (D.O.T.) or the National Standard of Canada, CAN/

CSA-B339, Cylinders, Spheres and Tubes for the Transportation of Dangerous Goods; and Commission.

WLP gas cylinder must be arranged for vapor withdrawal.

WThe LP gas cylinder must have a listed overfilling prevention device (OPD).

WOnly use LP gas cylinders equipped with a cylinder connection device compatible with the connection for

outdoor cooking appliances.

WThe LP gas cylinder must have a cylinder collar to protect the cylinder valve.

IMPORTANT SAFEGUARDS

WNever use an LP gas cylinder with a damaged body, valve, collar or footing.

WDented or rusted LP gas cylinders may be hazardous and should be checked by your LP gas supplier prior to

use.

WThe LP gas cylinder should not be dropped or handled roughly.

WLP gas cylinders must be stored outdoors out of the reach of children and must not be stored in a building,

garage or any other enclosed area. Your cylinder must never be stored where temperatures can reach over

125°F.

WDo NOT insert any tool or foreign object into the valve outlet or safety relief valve. You may damage the valve

and cause a leak. Leaking propane may result in an explosion, fire, severe personal injury or death.

WDo NOT block holes in sides or back of grill.

WNever keep an LP gas cylinder in a hot car or trunk. Heat will cause the gas pressure to increase, which may

open the relief valve and allow gas to escape.

WPlace dust cap on cylinder valve outlet whenever the cylinder is not in use. Only install the type of dust cap

on the cylinder valve outlet that is provided with the cylinder valve. Other types of caps or plugs may result in

leakage of propane.

WIf grill is not in use, the gas must be turned off at the supply cylinder and disconnected.

WDo NOT store a spare LP gas cylinder under or near this appliance.

WNever fill the cylinder beyond 80 percent full.A fire causing serious injury or damage to property may occur if

the above is not followed exactly.

WNever attempt to attach this grill to the self-contained LP gas system of a camper trailer, motor home or

house.

WNever use charcoal, lighter fluid, lava rocks, gasoline, kerosene or alcohol with this product.

WYour grill has been checked at all factory connections for leaks. Re-check all connections as described in

the “Operating Instructions” section, as shipping can loosen connections.

WCheck for leaks even if your unit was assembled for you by someone else.

WDo NOT operate if a gas leak is present. Gas leaks may cause a fire or explosion.

WYou must follow all instructions in the “Checking for Leaks” section before operating. To prevent fire or

explosion hazard when testing for a leak:

a. Always perform a leak test before lighting the grill and each time the cylinder is connected for use.

b. No smoking. Do NOT use or permit sources of ignition in the area while conducting a leak test.

c. Conduct the leak test outdoors in a well-ventilated area.

d. Do NOT use matches, lighters, or a flame to check for leaks.

e. The use of alcohol, prescription or non-prescription drugs may impair the consumer’s ability to properly

assemble or safely operate the appliance.

f. Strong odors, colds, sinus congestion, etc. may prevent the detection of propane. Use caution and

common sense when testing for leaks.

g. Do NOT use grill until any and all leaks are corrected.

If you are unable to stop a leak, disconnect the LP gas supply. Call a gas appliance serviceman or your

local LP gas supplier.

WThis grill is designed to operate at an inlet pressure of: 11 inches water column.

WDo NOT store or use gasoline or other flammable liquids or vapors within 25 feet (7.62 m) of this appliance.

WDo NOT use in an explosive atmosphere. Keep grill area clear and free from combustible materials, gasoline

and other flammable vapors and liquids.

WMinimum clearance from sides and back of unit to combustible construction is 36 inches (91.4 cm). Do NOT

use this appliance under any type of overhang or roof.

IMPORTANT SAFEGUARDS

WIt is essential to keep the grill’s valve compartment, burners and circulating air passages clean.

WInspect grill before each use.

WDo NOT alter grill in any manner. Any alteration will void your warranty.

WDo NOT use the grill unless it is COMPLETELY assembled and all parts are securely fastened and tightened.

WDo NOT build this model of grill in any built-in or slide-in construction. Ignoring this warning could cause a

fire or an explosion that can damage property and cause serious bodily injury or death.

WThis grill should be thoroughly cleaned and inspected on a regular basis.

WClean and inspect the hose before each use of the appliance. If there is evidence of abrasion, wear, cuts or

leaks, the hose must be replaced prior to operation.

WUse only the regulator and hose assembly provided.

WUse only factory-authorized parts. The use of any part that is not factory-authorized can be dangerous and

will void your warranty.

WDo NOT operate this appliance without reading “Operating Instructions” in this manual.

WDo NOT touch metal parts of grill until they have completely cooled to avoid burns, unless you are wearing

protective gear (pot holders, gloves, BBQ mittens, etc.).

WDo NOT install or use in or on boats or recreational vehicles.

WWhen cooking, fire extinguishing materials should be readily accessible. In the event of an oil/grease fire, do

NOT attempt to extinguish with water. Use type BC dry chemical fire extinguisher or smother with dirt, sand

or baking soda.

WDo NOT use grill in high winds.

WNever lean over the grill when lighting.

WDo NOT leave a lit grill unattended. Keep children and pets away from grill at all times.

WDo NOT leave grill unattended while preheating or burning off food residue on high. If grill has not been

cleaned, a grease fire can occur that may damage the product.

WDo NOT place empty cooking vessels on the appliance while in operation.

WUse caution when placing anything on the grill while the appliance is in operation.

WDo NOT attempt to move grill when in use. Allow the grill to cool before moving or storing.

WLP gas cylinder must be properly disconnected and removed prior to moving this grill.

WStorage of grill indoors is permissible only if the cylinder is disconnected, removed from the grill and properly

stored outdoors.

WAlways open grill lid carefully and slowly as heat and steam trapped within grill can cause severe burns.

WDo NOT attempt to disconnect the gas regulator from the cylinder or any gas fitting while the grill is in use.

WAlways place your grill on a hard, non-combustible, level surface. An asphalt or blacktop surface may not be

acceptable for this purpose.

WMove gas hoses as far away as possible from hot surfaces and dripping hot grease.

WKeep all electrical cords away from a hot grill.

WAfter a period of storage and/or nonuse, check for leaks, burner obstructions and inspect for any abrasion,

wear or cuts to the hose.

WFailure to open lid while igniting the grill’s burners, or not waiting 5 minutes to allow the gas to clear if the

grill does not light, may result in an explosive flame-up.

WNever operate grill without its heat plates installed.

WAlways use a meat thermometer to ensure food is cooked to a safe temperature.

WUse protective gloves when assembling this product.

WDo NOT force parts together as this can result in personal injury or damage to the product.

Limited Warranty

RevoAce Inc. Limited (“RA”) warrants to the original retail purchaser of this product, and to no other person, that if

this product is assembled, maintained, and operated in accordance with the printed instructions accompanying it,

then for a period of one (1) year for all remaining parts from the date of purchase, all parts in such product shall be

free from defects in material and workmanship. RA may require reasonable proof of your date of purchase. Therefore,

you should retain your sales slip or invoice. This Limited Warranty shall be limited to the repair or replacement of

parts, which prove defective under normal use and service and which RA shall determine in its reasonable discretion

upon examination to be defective. Before returning any parts, you should contact RA’s Customer Care Department

using the contact information listed below. If RA conforms, after examination, a defect covered by this Limited

Warranty in any returned part, and if RA approves the claim, RA will replace such defective part without charge. If

you return defective parts, transportation charges must be prepaid by you. RA will return replacement parts to the

original retail purchaser, freight or postage prepaid. This Limited Warranty does not cover any failures or operating

difﬁculties due to accident, abuse, misuse, alteration, misapplication, improper installation or improper maintenance

or service by you or any third party, or failure to perform normal and routine maintenance on the product as set out in

this owner’s manual. In addition, the Limited Warranty does not cover damage to the ﬁnish, such as scratches, dents,

discoloration, rust or other weather damage, after purchase.

This Limited Warranty is in lieu of all other express warranties. RA disclaims all warranties for products that are

purchased from sellers other than authorized retailers or distributors, including the warranty of merchantability or the

warranty of ﬁtness for a particular purpose. RA ALSO DISCLAIMS ANY AND ALL IMPLIED WARRANTIES, INCLUDING

WITHOUT LIMITATION THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

RA SHALL HAVE NO LIABILITY TO PURCHASER OR ANY THIRD PARTY FOR ANY SPECIAL, INDIRECT, PUNITIVE,

INCIDENTAL, OR CONSEQUENTIAL DAMAGES. RA further disclaims any implied or express warranty of, and assumes

no responsibility for, defects in workmanship caused by third parties. This Limited Warranty gives the purchaser

speciﬁc legal rights; a purchaser may have other rights depending upon where he or she lives. Some jurisdictions

do not allow the exclusion or limitation of special, incidental or consequential damages, or limitations on how long a

warranty lasts, so the above exclusion and limitations may not apply to everyone. RA does not authorize any person or

company to assume for it any other obligation or liability in connection with the sale, installation, use, removal, return,

or replacement of its equipment, and no such representations are binding on RA.

Manufactured in China for: RevoAce Inc. Limited

Hong Kong, China

1.800.694.0013 • [email protected]

9:00 am to 5:00 pm eastern time, Monday to Friday.

IMPORTANT SAFEGUARDS

WNever cover entire cooking area with aluminum foil.

WDeaths, serious injury or damage to property may occur if the above is not followed exactly.

Expanded View

1Handle G2016-010

2Lid* G1716-010

3Brand Plate* B0109-LBD

4Heat Plate (3) G1716-080

5Top Hinge (2)* G1916-020

6Bottom Hinge (2)* G1916-030

7Heat Shield G1916-050

8Warming Rack G1716-060

9Cooking Grid G1716-070

10 Side Shelf (2) G2016-020

11 Grill Body Assembly G1916-040

12 Burner (3)* G1716-050

13 Control Knob (3) G1025-255

14 Grease Cup B0219-HA0

15 LP Gas Tank Heat Shield* G1916-060

16 Regulator/Hose Assembly* B0308-A18

17 LP Gas Tank Retainer Wire G1716-100

18 Front Panel G2016-030

19 Upper Cart Frame (2) G2016-050

20 Upper Left Support Wire G2016-070

21 Cart Rear Support G2016-040

22 Lighting Hook* B0223-D00

23 Lower Left Support Plate G2016-080

24 Longer Leg (2) G2016-060

25 Foot (2)* B0305-C00

26 Shorter Leg (2) G1816-340

27 Shorter Leg Connector G1716-190

28 Axle G2016-090

29 Wheel (2) B0302-EB0

* Pre-assembled

Hardware

AScrew M6x15 Nickel Plated Phillips Truss Head 4 pcs

B Screw M6x45 Nickel Plated Phillips Truss Head 10 pcs

CWing Screw M6x16 Nickel Plated 4 pcs

DWing Nut M6 Nickel Plated 4 pcs

EWasher ø6x16 Nickel Plated 4 pcs

FWasher ø6x22 Nickel Plated 2 pcs

GWasher ø11x20 Nickel Plated 1 pcs

HCotter Pin ø1.4x30 Nickel Plated 1 pcs

Parts List

8 Assembly Instructions

Do Not Return To Place of Purchase

Assemble Shorter Legs and Shorter Leg Connector

Assemble Longer Legs

Assemble Cart Frames and Side Shelves

Please have your owner’s manual and model number available

for reference.

Note: The model number is printed on a label which can be

found on the inside door, back or side of the cart assembly.

Assembly Tips:

1. Select an area where you will assemble this product.

To protect components, choose a smooth surface that’s

free of cracks or openings.

2. Spread out all parts.

3. Tighten all hardware as direct in each step. Be careful

not to over-tighten which could damage surfaces or

strip threads.

4. For best results, complete each step in the order

presented.

To complete assembly you will need:

• (1) Leak detection solution (instructions on how to

make the solution are included in the “Operating

Instructions” section of this manual).

• (1) Precision-filled LP gas grill tank with Acme Type 1

external threaded valve connection (standard grill size)

(not included).

Typical assembly is approximately 30 minutes.

Ax 4

Notch upside

26 27

Dx 2 Bx 2

Note: Fully tighten hardware.

Attach Front Panel, Upper Left Support Wire and

Lower Left Support Plate to Longer Legs

Attach Shorter Leg to Front Panel

Attach LP Gas Tank Retainer Wire, Axle and

Wheels

Attach Rear Cart Support, Upper Left Support

Wire and Lower Left Support Plate

Gx 1

Hx 1

Bx 2 Bx 2

Bx 4

Note: Leave hardware loose until grill body assembly in step 9. Note: Leave hardware loose until grill body assembly in step 9.

Note: Leave hardware loose until grill body assembly in step 9.

Attach Grill Body Assembly

Attach Handle, Heat Shield and Control Knobs

Ex 4

Insert Heat Plates and Cooking Grid

Insert Warming Rack

Cx 4 Fx 2

Dx 2

Note: Match up with the grill body holes and upper cart frame holes.

Install hardware and leave loose until 4 screws are attached then fully

tighten.

Note: Attach the warming rack end per 4 sequence.

Note: Fully tighten hardware.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels EXPERT GRILL Gril

EXPERT GRILL

EXPERT GRILL XG17-096-034-18 Manuel utilisateur

EXPERT GRILL

EXPERT GRILL XG18-102-001-13 Manuel utilisateur

EXPERT GRILL

EXPERT GRILL 720-0969D Manuel utilisateur

EXPERT GRILL

EXPERT GRILL XG10-108-002-01 Manuel utilisateur

EXPERT GRILL

EXPERT GRILL XG1136207827002 Manuel utilisateur

EXPERT GRILL

EXPERT GRILL XG18-103-002-05 Manuel utilisateur

EXPERT GRILL

EXPERT GRILL Atlas XG1136224169003 Manuel utilisateur

EXPERT GRILL

EXPERT GRILL 720-0789C Manuel utilisateur

EXPERT GRILL

EXPERT GRILL XG19-103-001-01 Manuel utilisateur

EXPERT GRILL

EXPERT GRILL Commodore Manuel utilisateur

EXPERT GRILL

EXPERT GRILL XG19-102-001-01 Manuel utilisateur

EXPERT GRILL

EXPERT GRILL 720-0789C Manuel utilisateur

EXPERT GRILL

EXPERT GRILL Pioneer Manuel utilisateur

EXPERT GRILL

EXPERT GRILL XG19-103-001-02 Manuel utilisateur

EXPERT GRILL

EXPERT GRILL GBC1703WB-U Manuel utilisateur

EXPERT GRILL

EXPERT GRILL XGS236178263003 Manuel utilisateur

EXPERT GRILL

EXPERT GRILL 720-0864T Manuel utilisateur

EXPERT GRILL

EXPERT GRILL XG11-362-071-230-02 Manuel utilisateur

EXPERT GRILL

EXPERT GRILL BG2824BP Manuel utilisateur

EXPERT GRILL

EXPERT GRILL DH122212-W Manuel utilisateur

EXPERT GRILL

EXPERT GRILL 810-0040C Manuel utilisateur

EXPERT GRILL

EXPERT GRILL XG17-096-034-17 Manuel utilisateur

EXPERT GRILL

EXPERT GRILL 720-0988EC Manuel utilisateur

EXPERT GRILL

EXPERT GRILL XG1910200103 Guide d'installation

Manuels Gril populaires d'autres marques

Orbegozo

Orbegozo GR 2300 Manuel utilisateur

bora

bora PT11 Manuel utilisateur

Klarstein

Klarstein 10031664 Manuel utilisateur

Garland

Garland MWE3W Manuel utilisateur

Char-Broil

Char-Broil 463722714 Manuel utilisateur

Nexgrill

Nexgrill 720-0830HK Manuel utilisateur

Kenmore

Kenmore 415.16123800 Manuel utilisateur

Camp Chef

Camp Chef PG24CLAU Manuel utilisateur

Tucker Barbecues

Tucker Barbecues GTR Series Instructions de montage

Monogram

Monogram ZGG540NCP1SS Manuel utilisateur

Equipex

Equipex Sodir Savoy Manuel utilisateur

Gaggenau

Gaggenau VR 414 610 Manuel utilisateur

Miele

Miele KM 408-1 Manuel utilisateur

George Foreman

George Foreman GGR50B Manuel utilisateur

AOG

AOG T series Manuel utilisateur

Gorenje

Gorenje TG2000CB Mode d’emploi

Weber

Weber Genesis Silver-B Permamount NG 051701 Manuel utilisateur

Glen

Glen SA 3037 Manuel utilisateur
