Exodraft ESP-25 Manuel utilisateur
Your energy. Optimized.
Electrostatic Particle Filter
ESP-25
UK |Read and save these instructions!
Your energy. Optimized.
Particle Filter |ESP-25
Content
Product description 7
Scope of supply 7
Accessories and spare parts 7
Functionality of the electrostatic precipitator 8
Automatic on/off 8
Warranty 9
Technical specications 10
Precautions and user instructions 12
Mechanical installation 13
Positioning of the ESP-25 13
Before installation in a chimney construction 14
Installation in a chimney construction 16
Controller 18
Electrical installation 19
Start-up and conguration 21
General 21
System test 21
User operation instructions 22
User operation 22
Indications on the ESP-25 23
Maintenance and troubleshooting 24
Safety precautions 24
User maintenance 25
Inspection and service 26
Cleaning procedure - performed by user 28
Chimney sweeping - performed by chimney sweeper 29
Troubleshooting 30
Other problems and solutions 30
UK Conformity Assessed 31
Declaration of Conformity 32
Disposal
Electrical and electronic equipment (EEE) often contain materials, components and substances
that may harm the environment or be hazardous to your health. Products (WEEE) marked with
the ‘crossed-out wheeled bin’ symbol should be disposed of separately from other waste at the
end of its life. Though legislation may differ from country to country we strongly advise that
electrical and electronic waste is separated from other waste and disposed of according to
national legislation to protect the environment and personnel that may come into contact with
waste.
How to use this manual
This manual has been prepared based on the specific product and
contains relevant technical information and installations guides.
Accessories and spare parts are not covered by this manual.
Please refer to the individual manuals of these components.
This installation manual does not contain any system design documentation.
Failure to observe instructions marked with a danger symbol
may result in personal injury and/or damage to the product.
Errors and omissions excepted.
Symbols
The following symbols may be used in the manual
to draw attention to danger or risk of personal
injury or damage to the product.
General prohibition
Failure to observe instructions marked with the prohibited
symbol may result in extreme danger or serious personal injury.
General warning
Failure to observe instructions marked with a danger symbol
may result in personal injury and/or damage to the product.
General attention
Marks a dangerous situation that, in the worst-case scenario,
can cause serious personal injury or significant damage to the product.
Electricity hazard/High Voltage
Marks a situation in which caution is advised due to the risk of high voltage electric
shock which can cause serious personal injury or significant damage to the product.
Connect an earth terminal to the ground
Failure to observe instructions marked with a danger symbol
may result in personal injury and/or damage to the product.
Permitted and approved
Permitted and approved method of installation.
Prohibited and not approved
Prohibited and not approved method of installation.
Warning
To minimise the risk of fire, electric shock, personal injury
and/or damage to the product please observe the following:
• Please always read the manual and only use the product in accordance with the
manufacturer’s instructions. If in doubt, contact one of the Exodraft specialized dealers.
• All installations must be carried out by properly qualifi ed personnel in accordance with
national legislation and regulations.
• This product must be earthed. Get assistance from an qualifi ed electrician when in doubt.
• Ensure that the chimney has been swept before mounting the fi lter to avoid chimney fire.
• The product must be accessible for service and maintenance.
• Prior to servicing the product, disconnect the power supply to the fi lter. Turn off the main
switch located on the fi lter. Ensure that the heat source and the fi lter cannot be turned on
accidentally. Let the fi lter cool down before service or cleaning.
• Automatic power on/off function; when connected to a pellet boiler, high voltage is swit-
ched on, when the pellet boiler starts. Touching the electrode or the electrode holder may
be fatal.
• Exodraft always recommends the use of a smoke alarm when a solid fuel fireplace is
installed.
• If the Exodraft fan system has been designed for solid fuel/multi fuel installations, please
ensure that the design meets the requirements of BS EN15287-1. If this cannot be achie-
ved, a smoke alarm must be installed in the same room as the heat appliance.
• Undesirable stoking practice may result in problems, such as excessive soot accumulation,
chimney fi res, etc., which may damage the product.
Your energy. Optimized.
UK |7
3112024_ESP-25_UK
Warning
To minimise the risk of fire, electric shock, personal injury
and/or damage to the product please observe the following:
• Please always read the manual and only use the product in accordance with the
manufacturer’s instructions. If in doubt, contact one of the Exodraft specialized dealers.
• All installations must be carried out by properly qualifi ed personnel in accordance with
national legislation and regulations.
• This product must be earthed. Get assistance from an qualifi ed electrician when in doubt.
• Ensure that the chimney has been swept before mounting the fi lter to avoid chimney fire.
• The product must be accessible for service and maintenance.
• Prior to servicing the product, disconnect the power supply to the fi lter. Turn off the main
switch located on the fi lter. Ensure that the heat source and the fi lter cannot be turned on
accidentally. Let the fi lter cool down before service or cleaning.
• Automatic power on/off function; when connected to a pellet boiler, high voltage is swit-
ched on, when the pellet boiler starts. Touching the electrode or the electrode holder may
be fatal.
• Exodraft always recommends the use of a smoke alarm when a solid fuel fireplace is
installed.
• If the Exodraft fan system has been designed for solid fuel/multi fuel installations, please
ensure that the design meets the requirements of BS EN15287-1. If this cannot be achie-
ved, a smoke alarm must be installed in the same room as the heat appliance.
• Undesirable stoking practice may result in problems, such as excessive soot accumulation,
chimney fi res, etc., which may damage the product.
Your energy. Optimized.
Product description
The ESP-25 is an electrostatic precipitator (particle lter) for pellet boilers for inline installation in indoor
chimney constructions and is placed directly after the pellet boiler. The ESP-25 is designed to reduce the
level of particles from pellet boilers.
The ESP-25 is intended for non-condensing pellet boilers with a maximum heating output of no more than
25 kW and can only be used on chimney constructions with negative pressure.
The ESP-25 is supplied on a standard Ø150 uninsulated ue, with a 5-metre-long supply cable with strip-
ped conductors for plug installation.
If the pellet boiler is not adjusted for proper combustion, it may cause problems with soot, chimney res,
etc., which may damage the product. Please follow the instructions from the manufacturer of the pellet
boiler.
Scope of supply
• ESP-25 with 5-metre connection cable (with stripped conductors)
• Installation manual and user instructions
• Cleaning brush and handle
• Brush stop
• 3x Warning labels
An adapter for mounting the ESP-25 in an existing chimney must be ordered separately.
Accessories and spare parts
The table below shows the accessories and spare parts available for the ESP-25 model.
Accessories* Spare parts
Adapters** Electrode
Insulator
Controller
Cleaning brush
*This manual does not describe the specic use of accessories. We refer to the separate manuals for such components.
For more details contact your Exodraft dealer.
**Following adapters are currently available:
• Ø150 double male
• Ø150 double female
• Ø130-Ø150 double male increaser
• Ø130-Ø150 dobule female increaser
For other types we refer to suppliers of chimney adapters, for example chimney manufactures.
8|UK
Your energy. Optimized.
Functionality of the electrostatic precipitator
ESP-25 is an electrostatic precipitator that reduces the number of ne and ultra-ne particles in a ue gas
stream by creating an electrostatic eld between the charging and collecting electrodes.
The electrostatic eld is generated by the charging electrode which is connected to a high voltage controller
which ionises the surrounding gas, consequently charging the particles and creating an electrostatic eld
strong enough to push the charged particles towards the ue (collecting electrode). The ue gas particles
are captured and retained in the electrostatic eld and can be removed when the lter is cleaned.
Insulator
Smoke inlet
Smoke outlet
Automatic on/off
It is possible to connect the ESP-25 to the pellet boiler so that it receives an automatic start/stop signal and
standby mode if there is an available and suitable electrical output on the pellet boiler that switches on and
off with the boiler. See Electrical installation.
Controller
Electrode
(collecting)
Electrode
(charging)
UK |9
3112024_ESP-25_UK
Warranty
All Exodraft products are covered by a 2-year guarantee as per European consumer rights legislation. For
some countries an extended period of guarantee may apply depending on either national legislation or
other clearly stipulated conditions. Customer complaints must be handled by a specialised dealer or
wholesaler (preferably where the Exodraft product has been bought originally). An updated list of Exodraft
specialised dealers can be found on our website for the country in question.
Exodraft products must always be installed by properly qualied personnel. Exodraft reserves the right to
change these guidelines without prior notice.
The warranty and liability does not cover instances regarding personal injury or damage to property or the
product that can be ascribed to one or more of the following causes:
• Failure to follow this installation and operation manual
• Incorrect installation, start-up, maintenance or servicing
• Improper repairs
• Unauthorised structural modications made to the product
• Installation of additional components that have not been tested/approved with the product
• Any damage resulting from continued use of the product despite an evident defect
• Failure to use original spareparts and accessories
• Failure to use the product as intended
• Exceeding or failure to meet the limit values in the technical data
• Force majeure
10 |UK
Your energy. Optimized.
603HH 750H
150O
266De
177WH
650HB
603HH 750H
150
O
266De
177WH
650HB
Technical specications
Model
Motor specications
V Amp Hz
Power
consumption
in use [W]
Power
consumption
standby [W]
High Voltage
[kV/mA]*
ESP-25 1 x 115 - 230 0.5 50 - 60 20 - 50 2 30 / 1.7
*Power consumption at min. ambient temperature of -20°C and max. ambient temperature of 35°C.
Model Weight Dimension [mm]
kg H HB HH WH DE Ø
ESP-25 8750 650 603 177 266 150
