LIMITED WARRANTY
Exile warrants this product to be free from defects in material and workmanship under normal use for a period of one (1) year from date of original purchase when purchased from an Authorized Exile Dealer. If the product is labeled
B Stock/Refurbished and purchased from an Authorized Exile Dealer, it is warranted for 90 days from date of purchase, regardless of place of installation. Should service be necessary under this warranty for any reason due to manu-
facturing defect or malfunction during the warranty period, Exile will replace or repair (at its discretion) the defective merchandise with equivalent merchandise at no charge. Warranty replacements on B-Stock merchandise may have
cosmetic scratches and blemishes. Discontinued products may be replaced with more current equivalent products. This warranty is valid only for the original purchaser and is not extended to owners of the product subsequent to the
original purchaser. Any applicable implied warranties are limited in duration to a period of the express warranty as provided herein beginning with the date of the original purchase at retail, and no warranties, whether express or implied,
shall apply to this product thereafter. Some states do not allow limitations on implied warranties, therefore these exclusions may not apply to you. This warranty gives you specic legal rights; however you may have other rights that
vary from state to state. This warranty is only valid within the USA, for warranties outside of the USA consult the appropriate international distributor.
EXILE AUDIO
LAKE OSWEGO, OR USA
WWW.EXILEAUDIO.COM
exIle SuBwooFer MAnuAl
MAnuel du cAISSon d’extrêMeS GrAVeS exIle
ENG
FR
© 2012 Exile Audio • www.exileaudio.com Xi12/Xi12D Owner’s Manual 04/12
DESIGNED AND ENGINEERED IN THE USA
xI12d xI12
Mounting Depth 6.8 Inches 6.8 Inches
Mounting Diameter 11 Inches 11 Inches
Overall Diameter 12.8 Inches 12.8 Inches
RMS Power Handling 600 Watts 600 Watts
Peak Power Handling 1200 Watts 1200 Watts
t/S PArAMeterS:
FS 27.62 Hz 27.98Hz
RE 7.815 Ohms 3.08 Ohms
QMS 5.016 4.93
QES .492 .45
QTS .448 .41
VAS 52.1 Liters 44.11 Liters
MMS 222.3 Grams 256.3 Grams
CMS 149.13 uM/Newton 126 uM/Newton
BL 24.755 Tesla-M 17.63 Tesla-M
SPL (1w/1m) 89dB 89dB
Xmax 36mm Peak to Peak 36mm Peak to Peak
Specications subject to change.
xI12/xI12d SPecIFIcAtIonS
Vented BoxeS SIze Vent dIA. Vent lenGth
xI12/12d - SPl 1.6 4” 11”
xI12/12d - norMAl 2.2 4” 14”
xI12/12d - SQ 3.0 4” 12”
(All Boxes sizes in CU. FT. and INCLUDE displacement of the subwoofer)
SeAled BoxeS SIze
xI12/12d - SPl .75
xI12/12d - norMAl 1.1
xI12/12d - SQ 1.4
Box SIzeS And BuIldInG tIPS
The material of choice for building a strong box is 3/4” to 1” MDF (Medium
Density Fiberboard or HDF (High Density Fiberboard). For a large dual boxes
more than 2 Cu.Ft. adding additional cross bracing using strips of this material
is a good idea to help reduce panel vibration. Don’t use particle board is not
very good for speaker enclosures. It soaks up water like a sponge, is exible
and will crumble when you try to screw the woofer in. A solid bead of wood glue
is recommended for joining two pieces of wood together along with 1-1/4 to 1
1/2” drywall screws or 1-1/2” staples. Remember the glue will be doing almost
all the work once it has dried. A fastener placed about every 3” will hold the box
together good enough until the glue dries. After assembling the box and allowing
the glue to set up, use silicone sealer to make absolutely sure the corners and
other visible seams are perfectly sealed. The sizes below are a guidelines accord-
ing to our in car testing and computer analysis. Don’t worry if you box is a little
larger or smaller than the below recommendations the world will not come to an
end, the sun will come up tomorrow and you will probably won’t hear the differ-
ence. Usually a change of more than .15 Cu.Ft. is needed before even someone
with golden ears is able to hear the difference.
tAIlleS de BoîtIer et conSeIlS de FABrIcAtIon
Le matériau de choix pour construire un boîtier solide est le MDF (panneau de bres à
densité moyenne) ou le HDF (panneau de bres à haute densité) de ¾ po à 1 po. Pour
un grand boîtier double de plus de 2 pieds carrés, ajouter un renforcement croisé
supplémentaire en utilisant des bandes de ce matériau est une bonne idée pour
contribuer à réduire les vibrations des panneaux. N’utilisez pas de l’aggloméré de bois
qui n’est pas très adapté aux boîtiers pour haut-parleur. Il absorbe l’eau comme une
éponge, est exible et s’émiettera lorsque vous essaierez de visser le haut-parleur de
graves en place. Il est recommandé d’utiliser une quantité importante de colle à bois
pour xer deux pièces de bois ensemble en plus des vis à cloison sèche de 1-1/4 à 1
½ po ou des agrafes 1-1/2 po. N’oubliez pas que la colle fera presque tout le travail
une fois qu’elle aura séché. Des attaches placées tous les 3 po environ maintiendront
sufsamment le boîtier jusqu’à ce que la colle sèche. Une fois le boîtier assemblé et
une fois la colle sèche, utilisez un agent d’étanchéité à base de silicone pour vous
assurer à 100 % que les coins et autres arêtes visibles sont parfaitement étanches.
Les tailles ci-dessous sont des recommandations découlant de nos analyses ef-
fectuées sur ordinateur et en conditions réelles dans des voitures. Ne vous inquiétez
pas si votre boîtier est un petit peu plus grand ou plus petit que les recommandations
ci-dessous. Ce n’est pas la n du monde, le soleil continuera à se lever demain matin
et vous n’entendrez probablement pas la différence. Il faut généralement une variation
de plus de 0,15 pied cube avant que la différence puisse être entendue par quelqu’un
ayant une oreille en or !
xI12d xI12
Profondeur de montage 6.8 po 6.8 po
Diamètre de montage 11 po 11 po
Diamètre global 12.8 Ipo 12.8 po
Puissance R.M.S admissible 600 Watts 600 Watts
Puissance de crête admissible 1200 Watts 1200 Watts
t/S PArAMeterS:
FS 27.62 Hz 27.98Hz
RE 7.815 Ohms 3.08 Ohms
QMS 5.016 4.93
QES .492 .45
QTS .448 .41
VAS 52.1 Liters 44.11 Liters
MMS 222.3 Grams 256.3 Grams
CMS 149.13 uM/Newton 126 uM/Newton
BL 24.755 Tesla-M 17.63 Tesla-M
SPL (1w/1m) 89dB 89dB
Xmax 36mm Peak to Peak 36mm Peak to Peak
