EW-08
Owner’s Manual
"
"
www.ewheelsdealers.com
(888) 305-0881 Sales
(888) 571-2845 Service
1"
"
Table of Contents
Page"2"-"Feature"Guide"
Page"3"-"Technical"Specifications"
Page"4-6"-"Operation"of"Scooter"
Page"7-8"-"Charging"and"Battery"Information"
Page"9"-"Ramps"and"Curbs"
Page"9"-"General"
Page"10"-"Use"While"Under"Influence"
Page"10-12"-"Safety"Requirements"
Page"13"–"Warranty"
"
"
"
"
2"
"
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!Charger!Port!!!
!!!!!!!!!!!!!!!!!!!!!!!Rear!Wheel!Hub!Motor!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!Front!Shocks!
"""""""""""""""""""""""""
"
"
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!Headset!with!Ignition!
""""""""""""""""Backrest!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!Front!Headlight!
"
"
"
"
"
"
"
"
3"
"
Technical Specifications
Model"
EW-08"Fat"Tire"
Weight"Capacity"
350LBS"
Speed:"
Up"to"20mph"
Distance:"
23"miles"per"charge"(distance"varies"on"terrain,"riders"
weight,"road"surface,"etc.)"
Front"Seat:"Type"
Extended"Bicycle"Style"Seat,"2"Rider"Capacity"
Front"seat:"Size"
23”"x"8”"x"7.5”"
Front"Seat:"
28”"from"ground"
Rear"Seat:"Type"
N/A"
Rear"Seat:"Size"
N/A"
Steering"Height"
45”"from"Ground"
Rear"Foot"Rest:"
N/A"
Power:"
Electric"60"volts"
Watts:"
800"Watt"
Motor"Type:"
Electric"Hub"Motor"
Amps:"
12"AH"
Volts:"
60"Volts"
Dimensions:"
69”"x"13”"x"45”"(LxWxH)""
Floor"Clearance:"
7”"
Rear"Basket:"
N/A"
Batteries:"
(1)"60v"12"AH"Lithium"Ion"Battery"
Forward/Reverse"switch:"
N/A"
High/"Low"Speed"switch:"
N/A"
Front"tire"size:"
18.5”"x"8.5”"
Rear"tire"size:"
18.5”"x"8.5”"
Charger:"
60"volt"Smart"Charger"Included"
Throttle"Type:"
Variable"Twist"Throttle"
Key"Start:"
Yes"
Braking"System:"
Hydraulic"Disc"Brakes"
Drive"System:"
Electric"Hub"Motor"60volt"800watt"
Headlight:"
LED"Headlight"
Rear"lights:"
N/A"
Carton"Size:"
80”"x"36”"x"54”"
Scooter"Weight:"
128lbs"
Battery"Indicator:"
Yes"
Front"Suspension:"
Front"Fork"Suspension"
Rear"Suspension:"
N/A"
Reflectors:"
N/A""
Warranty:"
Limited"–"3"Year"Warranty"
4"
"
Operation of Scooter: "
1. Turning!on!the!power!
Insert"key"into"ignition"and"turn"
clockwise"to"turn"the"scooter"on."
The"battery"indicator"will"display"
the"current"charge"level"when"on."
Turn"the"key"counter-clockwise"to"
power"off"when"stopped.""
"
"
"
"""""""""""""""""""""""""""""""""""""""""
""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""
!
!
2. Battery!Power!Indicator!
The"battery"power"indicator"lights"
will"show"when"the"scooter"is"on."
The"battery"indicator"lights"will"not"
display"when"the"scooter"power"is"
off."Only"the"empty"light"will"be"on"
when"the"scooter"needs"to"be"
recharged."
"
"
"
"
5"
"
"
3. Headlight!
The"ignition"has"three"
positions."All"the"way"left"
powers"off"the"machine."The"
middle"position"turns"on"the"
scooter."The"position"all"the"
way"right"activates"the"LED"
headlight"bulbs.""
"
!
!
!
!
4. Horn!
The"horn"button"is"
located"on"the"left-
hand"side"of"the"
handlebars."Push"in"to"
sound"when"the"
scooter"power"is"turn"
on.""
!
!
!
!
!
6"
"
5. Bluetooth!Speaker!
The"Bluetooth"
speaker"can"be"
connected"to"your"
Bluetooth"capable"
device."The"scooter’s"
Bluetooth"
connection"name"is"
“Bluetooth”"and"
does"not"require"a"
password."When"
paired"for"the"first"time,"it"will"automatically"reconnect"when"the"scooter"
is"turned"on,"and"the"Bluetooth"setting"on"the"device"being"used"in"also"
turned"on."
"
"
"
6. Kickstand"
The"kickstand"is"spring"loaded"for"
easy"activation"and"deactivation."
Use"your"foot"to"push"the"
kickstand"while"activating"for"
deactivating."
"
7"
"
Charging Instructions:
The"smart"charger"included"with"your"scooter"will"shut"off"its"high"current"
mode"when"the"scooter"is"fully"charged."When"the"light"on"the"charger"is"red,"
the"scooter"is"still"charging."When"the"light"turns"green,"this"means"the"scooter"
is"fully"charged."Once"fully"charged,"unplug"within"two"hours"to"avoid"
overcharging."
"
The"charging"time"varies"depending"on"how"charged"the"batteries"are."If"almost"
empty,"the"charge"time"may"take"up"to"8"hours."If"the"red"lights"stays"on"for"
more"than"8"hours,"unplug"the"charger."
"
Batteries and Battery Maintenance:"
Only"use"lithium"ion"batteries"for"your"scooter."Do"not"use"deep"cycle"sealed"
lead"acid"batteries."Waiting"until"the"machine"is"low"on"charger"before"
recharging"is"best"for"lithium"ion"batteries."Prematurely"charging"the"machine"
can"cause"the"battery"to"not"last"as"long"in"the"future.""
"
"
8"
"
Specification"of"the"battery"that"we"recommend:"
"
Type:"""""(1)"60"volt,"12"AH"Lithium"Ion"Battery."
Note:"
- Do"not"use"automotive"batteries."They"are"not"designed"to"handle"and"
long"deep"discharge"and"are"unsafe"for"use"in"your"scooter."
- The"useful"life"of"a"battery"is"quite"often"a"reflection"of"the"care"it"
receives."
- Always"charge"the"batteries"in"a"well-ventilated"area."
- The"charger"is"intended"for"indoor"use"only."
- Replace"all"batteries"at"the"same"time"if"weak."
- If"the"scooter"will"not"be"used"for"an"extended"period,"arrange"to"have"the"
batteries"recharged"at"least"once"every"month"to"avoid"deterioration"of"
the"batteries.""
"
"
"
9"
"
Ramps and Curbs:"
1. Check"that"the"ramp"surface"is"roughened"to"prevent"slipping."Never"drive"
across"a"slope"or"turn"sharply"on"a"slope."
2. When"driving"up"curbs,"always"check"the"height"of"the"curb"to"ensure"that"
it"does"not"exceed"4”"height."
3. Always"go"forward"up"ramps"and"curbs."
4. Avoid"stopping"completely"when"going"over"small"objects"or"obstructions.""
General:"
1. Always"keep"your"feet"on"the"scooter"while"riding."
2. Do"not"exceed"the"weight"capacity"of"350lbs."
3. Do"not"attempt"to"lift"or"move"the"scooter"by"any"of"its"removable"parts."
Personal"injury"and"damage"to"the"scooter"may"result."
4. Never"try"to"use"your"scooter"beyond"its"limitations"as"described"in"the"
manual."
5. Do"not"connect"any"electrical"or"mechanical"device"to"the"scooter."Failure"
to"obey"this"instruction"may"result"in"injury"and"will"void"the"warranty."
6. Always"comply"with"local"laws"and"regulations."
