USER MANUAL
Contents
Key Features .......................................... 1
Dashboard Instructions ........................... 2
Password Access ................................... 5
Menu Settings ......................................... 6
Running Lights ........................................ 7
How to Unfold .......................................... 8
How to Fold ............................................. 9
Safe Riding Tips ..................................... 10
How to Charge ........................................ 11
Battery Safety ......................................... 12
Care & Maintenance ............................... 14
Product Specication .............................. 15
Limited Warranty .................................... 16
Charge Up Your Journey
Front Pneumatic Tire
Front Signal
Light
Pro V2 / Pro-R V2
1
Front Hydraulic
Disc Brake
Rear Pneumatic Tire
Rear Signal
Light
Deck Running
Lights
Steering Column
Running Lights
Display + Throttle
Front + Rear
Brake Lever
ECO / Turbo
Button
Single / Dual
Button
+
Quad Lock
Clamp
Rear Hydraulic
Disc Brake
Rear Suspension
Spring
Front Suspension
Spring
Folding Deck
Hook
Folding Latch
2
Power Switch
Press and hold the power button for 1 second to turn on scooter. The scooter turns off
automatically if not used for 10 minutes.
Speed Control
While stationary, and with the power on, press the “ + “ and “ - “ button to change
speed levels from 1 to 3. Use the throttle to control the speed within each speed level.
Main Headlight
Hold down the “ + “ button to turn on or off the steering stem and deck running lights.
The main headlight and taillight will always stay on. The taillight will ash automatically
when braking.
Data Zero Out
To zero the data, including AVG Speed, Max Speed, Trip, and Time, press and hold
both “ + “ and “ - “ buttons for a few seconds.
Trip / Dual Motor Display
Press the “ M “ button once to switch between Trip and Dual Motor information screen.
Menu Setting
Please see page 6 for menu and advance settings.
Dashboard Instructions
PowerPlus
Minus
Menu
Turn
Signals
Trip Info Screen
Dual Motor Info Screen
Power Switch Cluster
Main Headlight
Dashboard Instructions
3
Power Status
Speed Levels
Brakes Engaged
Speed
Time
Front Motor On / Off
Error Codes
1 Motor phase
2 Hall sensor fault
4 Handle turning fault
6 Controller error
7 Communication error
8 Over temperature protection
Front Motor Power
Rear Motor Power
Rear Motor On / Off
Current Amperage
Controller
Temperature
Error Code
ECO: Maximizes range. Limits riders to a set speed limit at each speed level but
enables you to ride longer. Eco mode is turned on when the “ ECO / TURBO “ button
is pressed once.
When Eco mode is engaged, speed is limited to:
Speed 1: 15 km/h / 9 mph
Speed 2: 20 km/h / 12 mph
Speed 3: 25 km/h / 15 mph
TURBO: Maximizes power and allows riders to reach top speed. Turbo mode is turned
on when the “ ECO / TURBO “ button is decompressed.
1. Do not press ECO mode when riding fast because the scooter will slow
down immediately.
2. Only activate ECO mode when not in motion.
SINGLE / DUAL
DUAL: Engages the front motor allowing riders to use both motors. Dual mode is
turned on when the “ SINGLE / DUAL “ is pressed once. The display will show
“ R : ON “ and “ F : ON “ when dual is pressed.
1. Do not start riding on DUAL mode. Engage DUAL mode when riding so you are
accustomed to the power change.
CAUTION:
CAUTION:
Dashboard Instructions
4
Password Access
Press “ M “ button to enter the password setting menu.
Enter the default password “ 0000 “.
Adjust the numbers by pressing “ + “ or “ - “ buttons. Press “ M “ to save the settings.
5
Start password option: Turn on this option to enable the password screen whenever
the scooter is turned on. Turn it off to disable it.
To reset the password, you will need to enter the current password.
Press the “ M “ button twice quickly to enter the settings. Press the “ M “ button twice again to exit.
Click “ + “ or “ - “ to switch pages.
To change parameters. press “ M “ and the page will start ashing. Adjust the settings by clicking “ + “
or “ - “ buttons. Press “ M “ to save settings.
Menu Settings
Advance Settings
Enter the advanced setting screen with password “ 2112 “.
Cruise
(Optional)
OFF AUTO: Cruise control enabled
MANUAL:
OFF: Cruise control disabled
ABS OFF Do not change
Speed Magnets 15 Do not change
Assist Parameter > Do not change
Export NO Do not change
Wheel 10.0 Do not change
Power System 52V / 60V Do not change
Zero Start
(Optional)
N N: Kickstart enabled
Y: Kickstart disabled
Temp Protection 120 Degree Celcius Do not change
Exit Press Exit or “ POWER “ button to exit menu
Brightness Adjust brightness levels from 1 to 5.
Unit System Metric / Imperial
Auto Off Adjust auto off time from 1 to 10 minutes or turn off completely.
Clock Adjust time value.
Start Password Turn on / off password access when starting vehicle
Informations Overview of vehicle information.
Advance Settings Please see table below.
Factory Settings Pressing “ Yes “ will restore all parameters to factory settings except ODO.
Exit
6
Running Lights
Static Colors
Increases / Decreases
the brightness of the lighting
Power
Plus
Turn On
Press and hold the “ + “ button on the power switch cluster. The running lights on the
deck and steering stem will turn on.
Turn Off
Pressing the “ OFF “ button or holding down “ + “ on the power switch cluster will turn
off the running lights.
The lighting system will save its last displayed pattern.
S+ / S - Increase or decrease the speed of the pattern progression.
M+ / M - Changes through the lighting modes. Switch through 100+ different colour /
pattern combinations.
Random colour patterns
Power Switch Cluster
7
