Battery Installation
NOTE: It is highly recommended that the vehicle be testing driven before
installation of the EVOLUTION lithium battery product to ensure that the vehicles
existing systems operate as normal.
Step 1: Remove the seat bottom. Remove the vehicles existing lead acid
batteries or other type of batteries.
Note: Recycle the original lead-acid batteries properly.
Step 2: The battery tray should be thoroughly cleaned of any residual battery acid
using a 50/50, mixture of baking soda and water to clean the tray with a soft
bristle brush. The tray should be rinsed with water and dried thoroughly before
proceeding.
Step 3: Install the special customized base frame for lithium-ion battery (based
on the vehicles brand or model) to the vehicle.
Step 4: Two people should team lift the lithium battery into the vehicle. The lithium
battery sits down vertically into the battery base frame which has been installed
priority in step3. Lock the battery pack to the base frame.
Step 5: Connect positive terminal and negative terminal of the lithium-ion battery
to the vehicle original main electric system. Make sure the cables are right
tightened.
Step 6: Install the lithium-ion battery power indicator to the reasonable position
on the dash panel and (we provide two optional indicators: round and diamond
shape and cables).
Connect the battery power indicator to port on the lithium battery pack.
Step 7: Testing drive the vehicle and battery charging.
Battery Charging
Charging should be performed when ambient temperatures are between 32°F and
110°F (0°C and 45°C). The battery pack may be charged or topped off after every
use.
Turn the key to the OFF position and remove it.
Inspect the charger cord for cracks, frayed wires or loose connections, if
damaged replace it.
Inspect the vehicle charger receptacle and charger plug for dirt, debris or damage.
Clean if necessary and replace immediately if damage is found.
Connect the charger to a wall receptacle. Do not use a multi-plug adapter or
power strip. Do not connect anything else to the same receptacle.
When the battery pack is finished charging, disconnect the charger cord from the
vehicle. If disconnecting before the charge cycle is complete, it is recommended
that the charger be disconnected from the wall receptacle first, then unplug the
charger from the vehicle receptacle.
